Virtual Synchrony

1
Virtual Synchrony

• Justin W. Hart
• CS 614
• 11/17/2005

2
Papers

• The Process Group Approach to Reliable
  Distributed Computing. Birman. CACM, Dec 1993,
  36(12)37-53.
• Understanding the Limitations of Causally and
  Totally Ordered Communication.  Cheriton and
  Skeen.  14th SOSP, 1993.

3
Background

• Chandy-Lamport Logical Clocks
• Consistent Cuts
• Distributed Snapshots
• Publish/Subscribe
• Fail-Stop

4
Fail Stop

• Group Membership Service
• Processes appear to fail by halting
• How does this affect the FLP result?

5
Motivation

• Information Backplane
• Customization
• Hierarchical Structure
• Fault-Tolerance
• Reliability

6
Process Groups

• Types of groups
• Anonymous groups
• Explicit groups

• Implementation Requirements
• Group communication
• Group membership as input
• Synchronization

7
Anonymous Groups

• Group addressing
• Messages sent exactly once to all or no
  recipients
• Ordering
• Logging

8
Explicit Groups

• Group members cooperate directly
• May execute algorithms based on membership
  knowledge
• Communication is sensitive to membership changes

9
Building groups over conventional technology

• Conventional message passing technologies
• Group addressing
• Logical time causal dependency
• Message delivery ordering
• State transfer
• Fault tolerance

10
Close Synchrony

• Close Synchrony
• 100 lock-step execution model

11
A synchronous execution
p
q
r
s
t
u

• With true synchrony executions run in genuine
  lock-step.

12
So whats wrong with that?

• Under close synchrony, execution is limited by
  the slowest process in the group!

13
Virtual Synchrony

• Relax synchronization requirements where possible
• Benefit by allowing for asynchronous interactions
• Do this where the result is identical to close
  synchrony

14
A few protocols

• fbcast
• cbcast
• abcast
• gbcast

15
Four protocols!?!?

• but Justin. The paper only discussed 2
  protocols youre getting off-topic!

16
A few protocols

• fbcast
• Simple protocol upon which well build the
  others.
• Delivery is FIFO ordered, with respect to the
  original sender
• Accomplished easily with a logical timestamp
• cbcast
• abcast
• gbcast

17
Single updater

• If p is the only update source, the need is a bit
  like the TCP fifo ordering
• fbcast is a good choice for this case

1
2
3
4
p
r
s
t
18
A few protocols

• fbcast
• cbcast
• Receipt is causally ordered
• Protocol in paper uses token passing
• Another simple protocol uses vector timestamps
• abcast
• gbcast

19
Causally ordered updates

• Simple protocol based on token passing

20
Causally ordered updates

• Example messages from p and s arrive out of
  order at t

VT(b)1,0,0,1
c is early VT(c) 1,0,1,1 but
VT(t)0,0,0,1 clearly we are missing one
message from s
p
VT(c) 1,0,1,1
When b arrives, we can deliver both it and
message c, in order
r
s
t
VT(a) 0,0,0,1
21
Causally ordered updates

• Each thread corresponds to a different lock
• In effect red events never conflict with green
  ones!

2
5
p
1
r
3
s
t
2
1
4
22
Hey that sped things up!

• Now I get it! Processes only have to wait for
  processes that they depend on. Not the slowest
  in the group!

23
A few protocols

• fbcast
• cbcast
• abcast
• Atomic delivery ordering
• With respect to other abcasts
• More costly than cbcast, but with a stronger
  ordering property
• ISIS builds abcast over cbcast
• gbcast

24
A few protocols

• fbcast
• cbcast
• abcast
• gbcast
• Atomic delivery ordering
• With respect to everything

25
Three Round Multicast
26
As a time-line picture
Phase 1
Phase 2
Vote?
Commit!
2PC initiator
p
q
r
s
t
All vote commit
27
Just one more
28
Flush protocol

• We say that a message is unstable if some
  receiver has it but (perhaps) others dont
• For example, qs message is unstable at process r
• If q fails we want to flush unstable messages
  out of the system

29
Styles of groups

• Peer Groups
• Processes cooperate closely
• Client-Server Groups
• Group acts as a server
• Client multicasts repeatedly to the group
• Diffusion Groups
• Group serves information
• Clients connect to receive data from group
• Hierarchical Groups
• Offer scalability through a hierarchy of
  connected groups

30
Historical Aside

• Two major classes of real systems
• Virtual synchrony
• Weaker properties not quite FLP consensus
• Much higher performance (orders of magnitude)
• Requires that majority of system remain
  connected. Partitioning failures force protocols
  to wait for repair
• Quorum-based state machine protocols are
• Closer to FLP definition of consensus
• Slower (by orders of magnitude)
• Sometimes can make progress in partitioning
  situations where virtual synchrony cant

31
Names of some famous systems

• Isis was first practical virtual synchrony system
• Later followed by Transis, Totem, Horus
• Today Best options are Jgroups, Spread, Ensemble
• Technology is now used in IBM Websphere and
  Microsoft Windows Clusters products!
• Paxos was first major state machine system
• BASE and other Byzantine Quorum systems now
  getting attention from the security community
• (End of Historical aside)

32
Sounds good whats wrong with it?

• Tries to solve state problems at communication
  level
• This violates the end-to-end argument!
• Consistency requirements are typically stated
  with respect to application state

33
Stable vs Durable

• Stable messages are buffered until received by
  all group members
• Durable message will be delivered, even if the
  sender dies

34
Ordering semantics

• Incidental Ordering
• Semantic Ordering
• Prescriptive Ordering

35
The problem with CATOCS

• It cant say for sure
• It cant say the whole story
• It cant say together
• It cant say it efficiently

36
It cant say for sure

• Processes communicating over a hidden channel
• Common database
• Shared memory
• Two threads reacting to external event

37
It cant say together

• Standard solution locking
• Transaction models allow for abort and rollback
• Higher level conditions what happens if a
  message arrives, but is not successfully processed

38
Stock trading example
39
Cant say the whole story

• Not everything can be expressed through the
  happens-before relationship
• Semantic ordering constraints
• Causal memory, the weakest of these, cannot be
  expressed in causal multicast
• Total ordering helps some of these, but is far
  too expensive
• Inexpensive, state-level protocols with logical
  clocks can solve these

40
It cant say it efficiently

• False causality
• Potential causality ! Actual causality
• Memory requirements for buffering unstable
  messages
• Ordering information during transmission and
  reception

41
And what of the end to end argument?

• All of this considers our communication channels
  isnt the application-level check far more
  important?

42
Classes of distributed applications

• Data dissemination
• Netnews
• Trading application example
• Global predicate evaluation
• Transactional applications
• Replicated data
• Replication in the large
• Distributed real-time applications

43
Implementing only part of the messaging?

• Can you cut down on overhead by implementing only
  part of the messaging using CATOCS?

44
Semantics

• Are the semantics of state-based approaches
  superior to those of virtual synchrony?

45
Scalability

• N Processes
• Time T to propagate a message across the system
• Grows roughly proportional with the square root
  of the number of processes
• Arcs in the active causal graph grow
  quadratically
• Quadratic causal graph

46
Buffering grows

• Quadratic arcs
• Linear communication of causal dependencies
• Linear growth in required buffering
• Changing topologies doesnt help
• CATOCS would require separate process groups for
  read and write to accomplish optimization of
  updates vs queries

47
Group membership protocols

• Must enforce atomic delivery semantics
• Run our most expensive protocol gbcast
• Failures increase with the size of the system,
  increasing load on the GMS

48
Who uses ISIS?

• Brokerage
• Database replication and triggers

49
ISIS-based utilities

• NEWS
• A pub/sub application with that will replay
  histories
• NMGR
• Manages batch-style jobs and performs load
  sharing
• Parallel make

50
ISIS-based utilities

• DECEIT
• NFS compatible file system
• META/LOMITA
• Sensors actuators
• Abstract sensors
• Specify control actions in high-level terms
• SPOOLER/LONG-HAUL FACILITY

51
Now somewhat supported

• ISIS/Horus/Ensemble/QuickSilver
• JGroups
• Spread
• Totem
• Transis
• WebSphere Windows Cluster (internally)

52
and people actually use it.

• NYSE
• French ATC System
• AEGIS

53
An ongoing debate

• The effort continues here at Cornell with the
  QuickSilver effort
• Youve been presented the options what are your
  conclusions?

54
References

• Some slides borrowed from Ken Birmans CS 614
  slide sets on Virtual Synchrony
  http//www.cs.cornell.edu/courses/cs514/2005sp/Sli
  de20Sets.htm
• Images have been borrowed from The Process Group
  Approach to Reliable Distributed Computing.
  Birman. CACM, Dec 1993, 36(12)37-53.
• Images have been borrowed from Understanding the
  Limitations of Causally and Totally Ordered
  Communication.  Cheriton and Skeen.  14th SOSP,
  1993.
• Statements and ideas have been borrowed verbatim
  from both papers, including section headings, and
  statements in notes. This has been mostly for
  coherence between the slides and papers
• Also sourced data from http//www.cs.cornell.edu/k
  en/
