Introduction to Science

1
Introduction to Science
Science the study of the world around us.
Knowledge of the physical or material world
gained through observation and experimentation.
2
The Nature of Science

• Scientific law versus theory
• Scientific law a summary of an observed natural
  event.
• Scientific theory a well tested, possible
  explanation of a natural event.

3
The Way Science Works

• Science involves critical thinking, or applying
  logic and reason to observations and conclusions.
• Observation vs. Inference
• Observation descriptive of what you see, hear,
  taste, feel, smell
• Inference an assumption made as a result of an
  observation (not always correct!!)

4
Variables and Controls

• A variable is anything that can change in an
  experiment.
• Independent variable The variable being changed
  or controlled by the scientist.
• Dependent variable The variable being measured
  or observed by the scientist.
• A controlled experiment tests only one variable
  at a time.

5
The Scientific MethodA series of logical steps
to follow in order to solve problems.

• OBSERVE
• FORMULATE A QUESTION
• FORM A HYPOTHESIS
• DESIGN AND CONDUCT AN EXPERIMENT
• MAKE OBSERVATIONS
• RECORD AND ANALYZE DATA
• DRAW CONCLUSIONS
• FORMULATE NEW QUESTIONS and CONTINUE CYCLE

6
Making Measurements

• Measurements are made in this class using SI
  units.
• LENGTH (m) distance between 2 points
• VOLUME (L) space occupied.
• MASS (kg) the amount of matter in an object.
• WEIGHT (N) the force with which gravity pulls on
  a quantity of matter.

7
Precision vs. Accuracy

• Accuracy the extent to which a measurement
  approaches the true value.
• Precision the degree of exactness of a
  measurement.
• A scale may be precise to the nearest 100th of a
  gram, or /- 0.01g

8
Precision vs. Accuracy
increasing precision
increasing accuracy
9
Density mass/volume

• Example 1
• What is the density of water if a 5 mL sample of
  water has a mass of 5 g?

M
D
V
10
Example 2

• What is the mass of 10 mL of a liquid that has a
  density of 3.76 g/mL?
• d m / v
• m dv
• m (3.76 g/mL)(10 mL)
• m 37.6 g

11
Coke vs. Diet Coke

• Which is less dense? Meaning which will float in
  water?
• Coke or Diet Coke?

12
Calculations

• Calculate the density of each
• A can of Coke has a volume of 355 mL and a mass
  of 394 g (assuming that the weight of the
  aluminum can is constant)
• A can of Diet Coke has a volume of 355 mL and a
  mass of 355.1 g (assuming that the weight of the
  aluminum can is constant)

13
WHY is Diet Coke less dense?

• There is less mass in the same volume (355 mL)
• Coke has 39 grams of sugar in it to sweeten it
  (355 39 394 g)
• Diet Coke only needs 0.1 g of Nutra Sweet to make
  is just as sweet as Coke
  (355 0.1 355.2 g)

14
Temperature Conversions

• Temperature is a measure of the average kinetic
  energy in a system.
• K Kelvin
• oF degree Fahrenheit
• oC degree Celsius

15
Temperature Conversions

• K oC 273
• oF (1.8 x oC) 32
• oC (oF 32) / 1.8

16
Percentage Error

• Calculate this value in labs where the accepted
  value is given.

17
Organizing DataData is organized and presented
in tables, charts, and graphs.
GRAPHING...

• Graph - visual representation of data
• 1) title
• 2) x and y axis labeled
• 3) units for both the x and y axis
• 4) scale is evenly and correctly spaced for data
• 5) legend when appropriate

18
LINE GRAPH

• LINE GRAPH best for displaying data that change.
• Independent Variable x-axis
• Dependent variable y-axis

19
BAR GRAPHS
BAR GRAPH useful when you want to compare data
for several individual items
20
PIE CHARTS
PIE CHART ideal for displaying data that are
parts of a whole.
21

• Scientific Notation/Powers of 10
• Significant Figures
• Dimensional Analysis (Factor Label Method)

22
MATH IS THE LANGUAGE OF CHEMISTRY!!!
23
Scientific Notation

• Scientist use special notation to express very
  large or very small numbers.
• Example I 300,000,000 m/sec can be written as
• 3 x 108 m/sec
• Ex II 1,007,000,000 sec can be written as
• 1.007 x 109 sec
• Ex III 0.000 000 000 004 76 m can be written as

• 4.76 x 10-12 m

24
Converting Metric Measurements (PART 4 of Things
to Know and Love)
To convert, move the decimal place the number of
stairs you step on in the direction you are
traveling OR use dimensional analysis.
kilo-
103
hecto-
102
deca-
basic unit
101
1
deci-
Example 3.75 km ? mm
10-1
centi-
10-2
milli-
? 3,750,000 mm
10-3
25
Video

• Powers of Ten

26
SIGNIFICANT FIGURES

• Scientists indicate the precision of measurements
  by the number of digits they report sig. figs.
• A value of 3.52 g is more precise than a value of
  3.5 g
• All known digits plus one estimated digit
• the equipment used for a measurement will
  determine the number of sig. figs.

27
Significant Figures

• Atlantic - Pacific Rule
• Decimal Present Count from the Pacific side
• Decimal Absent Count from the Atlantic side
• Start counting at the first non-zero number and
  count until you reach the end of the number
• Ex. I 3.00700
• Decimal Present Pacific (left) 6 sig. figs.
• Ex. II 300,700
• Decimal Absent Atlantic (right) 4 sig. figs.
  (the last 2 zeros are PLACE HOLDERS)

28
REVIEW
Determine how many significant figures are in
each of the following measurements.
5 (the first 3 zeros are PLACE HOLDERS)

1. 0.0034050 L ___________
2. 33.600 m ___________
3. 7500.0 g ___________
4. 47,900 mm ___________
5. 7,000,000,001 miles ___________
6. 8.07 Hz ___________

5
5
3 (the last 2 zeros are PLACE HOLDERS)
10
3
29
More practice
Round the following measurements off so that they
each contain 3 significant figures.

1. 366.2 L ___________
2. 9,047,022 mg ___________
3. 12.76 g ___________
4. 999.9 J ___________

366 L
9,050,000 mg
12.8 g
1.00 x 103 J
Notice this one must be in scientific notation to
have 3 sig. figs.
30
Significant Figures in Calculations

• When multiplying and dividing, limit and round
  to the least number of significant figures in any
  of the factors.
• Example
• 23.0 x 432 x 19 188,784 190,000
• The answer is expressed as 190,000 or 1.9 x 105
  since 19 has only two sig. figs.

31
Significant Figures in Calculations

• When adding and subtracting, limit and round
  your answer to the least number of decimal places
  in any of the numbers involved in the
  calculation.
• Example
• 123.25 46.0 86.257 255.507 255.5
• The answer is expressed as 255.5 since 46.0 has
  only one decimal place.

32
REVIEW
Perform the prescribed operations. Round your
answers to the proper of sig. figs.
11.4 m/s

1. 36.57 m / 3.21 s ___________
2. 41.376g 13.3g 42.9g___________
3. 5.67 m x 13.44 m ___________
4. (5.83 m/ 2.67 s) /2.1 s ___________
5. 9.374 V x 6 ___________

97.6 g
76.2 m2
1.0 m/s2
60 V
From now on, we will round all our answers to the
correct of significant figures.
33
EXTRA REVIEW

• Using a calculator for EXPONONETS
• (EE, EXP or x10x button)
• Example 1
• (5.02 x 10-3) x (6.3369 x 105)
• 3181.1238
• put in correct sig figs
• 3 sig figs
• 3180 or 3.18 x 103

34
Example 2 (use EE button!)

• (2.99 x 106) x (2.334 x 10-3)
• 6978.66
• 3 sig figs
• 6980

35
DIMENSIONAL ANALYSIS

• How old are you in seconds?
• Go from number of years to number of seconds.
• EX 15 years old ? _____ seconds old.
• To do this, you need to use CONVERSION FACTORS (a
  ratio of equivalent values used to express the
  same quantity in different units)

36
Given Information NOTETAKERS General Format...
going to
given

X
coming from
37
GIVEN INFORMATION

• 1 kildurkin 18 gallons
• 2 farkins 1 kildurkin
• 1 hogshead 63 gallons
• 1 barrel 3.3 bushels
• 1 bushel 8 gallons

38
Make a UNIT CONVERSION MAP

• Draw connections between the units in the
  conversion factors
• (as you draw connections, check that conversion
  factor off the list)

Its kind of like a road map
39
hogshead
kildurkins
farkins
gallons
barrel
bushel
40
Dimensional Analysis
Performing these conversions is a lot like going
on a road trip.
41
ROAD TRIP!!!
Lets say you want to travel from Oracle Jct to
Casa Grande...
You must travel through Tucson a two part trip.
42
Rule You must stay on the roads REMEMBER SIG
FIGS!!!
43
DO NOT GO OFF ROAD! ?
X
44
Rule You need a map. Sometimes the map can be
in your head. But, not at first. (show all
work!!)
45
Lets calculate

• Convert 14 gallons to kildurkins

46

• Convert 14 barrels to hogshead

47

• Convert 3.00 bushels to farkins

48
OKLets talk about making maps and solving
conversion problems. The method we use is called
the Factor-Label method, a.k.a. dimensional
analysis.
49
For Example Given 1.0 kildurkin 18
gallons
kildurkins
gallons
This is our map.
50
For Example Given 1.0 kildurkin 18
gallons
kildurkins
gallons
How many kildurkins is 14 gallons?
1.0 kildurkins
14 gallons
X
0.78 kildurkins
18 gallons
51
Lets expand the map...
Also given 2.0 farkins 1.0 kildurkin
kildurkins
farkins
gallons
52
Also given 1.0 hogshead 63 gallons
1.0 barrel 3.3 bushels
hogshead
1.0 bushel 8.0 gallons
kildurkins
farkins
gallons
barrel
bushel
53
Now, Lets solve a problem. How many hogsheads are
14 barrels?
Finish Here
hogshead
kildurkins
farkins
3
gallons
2
barrel
bushel
Given Start Here
1
The trip will require 3 transitions
54
How many hogsheads are 14 barrels?
hogshead
Given
3
gallons
1.0 hogshead
14 barrels
8.0 gallons
3.3 bushels
X
X
X
63 gallons
1.0 barrel
1.0 bushel
2
5.9 hogsheads
barrel
bushel
1
55
Now you try one. How many farkins is
3.00 bushels?
End Here
hogshead
kildurkins
farkins
gallons
Start Here
barrel
bushel
This will require 3 Conversions.
56
farkins
bushels
gallons
kildurkins
8.0 gallons
1.0 kildurkin
2.0 farkins
3.00 bushels
X
X
X
1.0 bushel
18 gallons
1.0 kildurkin
2.67 farkins
57
Wow! How Cool Is That!
58
Handout Fun Factor Label

• Handout
• Piece of lined paper (landscape format)
• Front is web for Distance and back is for Vol.
• Conversion Factors change 10-10 to
  1 x 10-10
• Lets do league ? km ? m ? cm to start
• You finish web, then do 3,6,7,9
• Then do vol. web
• Then finish questions 4, 5, 8, 10
• FINISH FOR HW

59
