2G/3G Authentication with SIM cards: usage

1
2G/3G Authentication with SIM cardsusage
roaming basics for the Internet challenged

• Michael Haberler
• Internet Foundation Austria

2
outline

• a SIM card mini-tutorial
• features, protocol flow, usage, production,
  addressing
• UMTS authentication and key agreement
• principles and protocol flow
• the universal integrated circuit card (UICC)
• USIM app
• how 2G, 3G roaming works
• over the air (OTA) loading of UICC apps
• example X.509 certificate download
• (U)SIMs and Internet access authentication
• how SIMs and RADIUS roaming works
• (U)SIMs and SIP authentication
• what the SIP server does
• How the parameter logistics works
• a bonus business model thrown in
• summary

3
whats a 2G SIM card

• crypto smart card as per ISO 7816
• access protected by a PIN code(s) (card holder
  verification)
• fixed storage of subscriber identity IMSI
  (international mobile subscriber identity) GSM
  MAC address
• E.164 number to IMSI mapping at the operator only
• safe storage for shared secret - accessible only
  through CHAP operation
• not broken as of today except for most stupid
  CHAP algorithm known
• CHAP algorithm in hardware
• operator chooses algorithm
• tree structured filesystem
• stream, record, cyclic record files
• can be readonly, read/write or none at all (for
  the key)
• some permission hierarchy

4
how are SIM cards produced

• unprogrammed chips are personalized and
  closed (parameters written sealed)
• mass product - 5-7 apiece at 1000
• GEMplus, Giesecke Devrient ....
• everybody can have SIMs made even MomPop ISP
• not everybody may
• roam with other cellular operators
• use the GSM algorithm A3/A8 you wouldnt want
  it anyway
• must be member of GSM association for that
• having your own algorithm in a chip mask is a
  circa 50K affair
• for testing development unprogrammed castrated
  chips used (XOR algorithm for CHAP...)

5
how are (U)SIM cards accessed

• 2G, 3G use
• builtin reader in the mobile handset
• for Internet use
• maybe builtin in PDA, PC (e.g.DELL)
• external USB token 20 apiece
• re-use a mobile SIM card via Bluetooth SIG SIM
  Access Profile (only if roaming against 2G/3G
  operator)
• read 3G (U)SIM Security Reuse by Peripheral
  Decices on local interfaces contains some
  threat analysis

6
SIM usage in 2G authentication
Authentication Center
2G GSM handset
keys
shared secret
7
IMSI structure

• MCC/MNC uniquely designates an operator and his
  authentication center
• when roaming, MCC/MNC tells the visiting network
  where to route the authentication request
• this is done via SS7 MAP (mobile application
  part)

8
what is OTA (over the air) loading?

• SIM cards are writable by mobile equipment
• if authenticated to network
• if instructed by operator over the air
• if file/directory is writable
• example ISIM X.509 certificate bootstrap
• AKA authenticated
• let user visit PKI portal
• download certificates through HTTP/Digest
  mechanism
• certificates are stored in record structured
  files, as ar CA certifcates
• The Air can also be an IP connection
• download of executable applets possible
• SIM Toolkit, USAT (USIM Application toolkit)
• bytecode instructions sent encrypted by 3DES,
  stored on card
• regularly used in 2G networks today for
  functionality upgrades parameter download

9
UMTS authentication and key agreement (AKA)

• substantially improved over 2G SIM
• protection against replay, MITM attacks
• sports also network-to-user authentication
• more complex algorithm
• compatibility functions 2G network/3G card, 3G
  network/2G card

10
3G AKA authentication flow
Authentication Center
3G UMTS handset
challenge RAND AUTN token
keys
shared secret, Sequence numbers
result Cipher key Integrity key
11
whats the universal integrated circuit card
(UICC) about

• generic support mechanism for multiple
  applications on one card
• 2G,3G authentication become applications
  selected as needed
• USIM application implements AKA
• 2G SIM app implements 2G CHAP
• additional apps possible (ISIM, PKI certificate
  storage etc)
• ISIM is pretty close to SIP client needs!!
• mobile equipment chooses application

12
using (U)SIMs for Internet access authentication

• embed flow in EAP and tunnel in RADIUS
• between 802.1x supplicant in client and RADIUS
  EAP backend using EAP-SIM or EAP-AKA
• RADIUS server MAY gateway to SS7 MAP and roam
• WiFi network looks like a GSM roaming partner
• example WiFi roaming through www.togewanet.com
• OR RADIUS server access an ISP-style database for
  keys
• ISP is the SIM card issuer!

13
using (U)SIM for SIP authentication

• speak HTTP/AKA (RFC3310) between SIP UA and proxy
• proxy translates into EAP-AKA-in-RADIUS
• RFC specified only for AKA (3G auth)
• no mapping of EAP-SIM onto HTTP/SIM for 2G auth
• bad almost all networks today use 2G auth
  which breaks SIP authentication through GSM/UMTS
  operators
• we need to address this and spec HTTP/SIM

14
how 2G roaming works

• mobile equipment presents IMSI
• visited network looks at MCC,MNC part of IMSI
• if no roaming agreement, drop him
• otherwise send access request thru SS7 MAP to
  home network
• the home network verifies IMSI and sends a
  triplet (challenge, expected response, cipher
  key) authentication vector
• visited network presents challenge, reads
  response
• if (response expected response), service user
• the triplet is essentially an access ticket
• note no replay detection these fellows seem to
  trust each other

15
how 3G roaming works

• not much different from 3G, just more parameters
  needed for AKA
• triplets become quintets

16
how the 2G/3G user ids (IMSIs) are mapped to
RADIUS authentication

• take mobile country code, mobile network code
• use them to create a realm
• Example
• IMSI 232011234567890
• means mcc232 (Austria) mnc01 (Mobilkom)
• resulting realm
• mnc01.mcc232.owlan.org
• resulting RADIUS user
• 232011234567890_at_mnc01.mcc232.owlan.org
• routing to Radius servers decided by subdomain
• convention established by Nokia
• Nokia owns owlan.org domain pro-bonofrom thereon
  this is vanilla RADIUS roaming
• but its just fine if we call it
  mnc01.mcc232.visionNG.org if that sounds better,
  realms just gotta be unique

17
how does 2G/3G address logistics work

• if you are a service provider and have E.164
  ranges, get a MNC from your MCC administrator
  (FCC, regulator...)
• the E.164 range might also be, for example, from
  visionNG (87810 ff) MCC 901
• this doesnt mean youre part of 2G/3G roaming yet
  contracts regulatory prerequisites needed
• but the addressing is all set to go!!

18
a bonus business model thrown in

• combine a SIP-based iTSP with a Mobile Virtual
  Network Operator (MVNO)
• an MVNO has authentication, billing, customers,
  numbers, but the radio network is outsourced
  from somewhere else
• issue (U)SIM cards which work both in a 2/3G
  handset AND as WiFi/SIP auth tokens note the
  same card authenticates both uses!
• leave choice to user how to connect Internet or
  cellular using the same E.164 number

19
Summary

• 2G/3G has a strong/very strong authentication
  architecture
• it is almost copy paste for iTSP use at WiFi
  access, WiFi roaming acces, SIP and other levels
  (TBD!)
• it can serve to solve the X.509 certificate
  distribution problem
• operator model (2G/3G home network, ISP home
  network) has no impact on Internet-side terminals
• numbering addressing resources are compatible
  and available (maybe not obviously so)
• the Internet could become the biggest (U)SIM
  authenticated mobile network ever to roam with
  2G/3G land
