Grade 10

1
Grade 10 Objective 2
2
1 The illustration above shows a
cell model with starch solutions both inside and
outside the cell. In which of the following
situations will the solution rise highest in
the tube? A B C D
3
2 Which would most likely cause the
liquid in Tube A to rise? F Starch
concentrations being equal on each side of the
membrane G Water passing from a
region of lower starch concentration to
one of higher starch concentration H Water
and starch volumes being the same J Solute in
the tubes changing from a higher temperature to a
lower temperature
4
3 Energy conversion within an animal cell
would be severely limited by removal of the
cells A mitochondria B
chloroplasts C plastids D lysosomes
5
4 Food provides the human body with all of
the following except F calories G
amino acid H hydrochloric acid J lipids
6
5 The diagram shows different
parts of a human sperm cell. Which part of the
cell is most likely specialized for
mobility? A Q B R C S D T
7
6 Which of these is a function of the cell
membrane in all cells? A Producing cellular
nutrients B Preserving cellular wastes C
Neutralizing chemicals D Maintaining
homeostasis
8
7 The structures marked 3 in the
diagram are responsible for A absorbing
oxygen B carrying genetic codes C lining
up amino acids D serving as an anticodon
9
8 DNA molecules separate into single
strands, which are then used to construct two
identical strands of DNA. This process ensures
that the A cytoplasm is in equilibrium B
mitochondria are genetically identical to the
chloroplasts C parent cells use little ATP D
daughter cells are genetically identical to
the parent cells
10
3' AATCGC 5' 9 Which of the following
nucleotide base sequences complements the
section of DNA modeled above? F 5' UTCGCA
3' G 5' TTAGCG 3' H 5' GCGATT 3' J 5'
TTUCGC 3'
11
10 The information in the box
identifies some of the organs of the kitten.
Which of the following is identical for every
cell in each of the four organs? A Amount
of ATP B Function of cell C Size of
cells D Genes in DNA
12
11 Which molecule resembles the shape of
a twisted ladder? A DNA B Sugar C
ATP D Lipid
13
12 The diagram represents the
chromosomes of a person with a genetic disorder
caused by nondisjunction, in which the
chromosomes fail to separate properly. Which
chromosome set displays nondisjunction? F
2 G 8 H 21 J 23
14
13 The chain above represents
three codons. Which of the following changes
would be expected in the amino acid chain if the
mutation shown above occurred? F The amino
acid sequence would be shorter than expected. G
The identity of one amino acid would change. H
The amino acid sequence would remain
unchanged. J The identities of more than one
amino acid would change.
15
14 Ultraviolet radiation can cause
mutations in the DNA of skin cells that have
been overexposed to the sun. This mutated
DNA has no effect on future offspring because
F changes in skin cell DNA are homozygous
recessive G mutations must occur within the
RNA codons H offspring reject parental skin
cells J only changes to gamete DNA can be
inherited
16
15 The diagram shows three
generations of cells produced by a single cell
through mitosis. In the process, a single
mutation occurred at the point indicated. The
mutation caused changes within a dominant
allele. How many of the 15 cells contain the
mutation? Record and bubble in your answer on
the answer document.
17
16 This illustration is an example of a
normal DNA sequence. Which of the following
represents a single base change in the sequence?
18
17 In order for a species to survive, it
must be able to F consume a wide variety
of food G reproduce successfully H
maintain a constant body temperature J
destroy competing species
19
18 If an organism has the genotype
RrSsTtUu, what proportion of its gametes will be
RSTU? A B C D
20
19 Dogs (Canis familiaris) are most
closely related genetically to which of the
following organisms? A African hunting dog
(Lycaon pictus) B Gray wolf (Canis lupus) C
Grizzly bear (Ursus arctos) D Domestic cat
(Felis catus)
21
20 What trait will most likely be
observed in all offspring of the above set of
parents? A Green feathers B Yellow
feathers C Long beak D Short beak
Bird Traits Bird Traits
Gene Trait
G Green feathers (dominant)
g Yellow feathers (recessive)
L Long beak (dominant)
l Short beak (recessive)
GGLl (male) x Ggll (female) GGLl (male) x Ggll (female)
22
21 According to the table, which of
the following phenotypes would probably occur in
all the offspring from the parents shown
above? F Solid gray fur G Striped gray
fur H Green eyes J Blue eyes
Allele Trait Type
G Solid gray fur Dominant
g Striped gray fur Recessive
B Green eyes Dominant
b Blue eyes Recessive
GgBb (male) x ggBB (female) GgBb (male) x ggBB (female) GgBb (male) x ggBB (female)
23
22 A pea plant with the genotype TtWW is
crossed with a pea plant with the genotype ttWw.
How many different genotypes can be expressed in
the offspring? F 1 G 2 H 3 J 4
24
23 If a plant that is homozygous
tall and wrinkled is crossed with a short,
wrinkled plant, which percentage of genotypes
would most likely be found in the
first-generation offspring? F 50 TTss, 50
ttSS G 100 TtSs H 100 Ttss J 50 TtSS,
50 ttSS
T tall t short S smooth s wrinkled
25
California Sea Lions 24 Male sea
lions can be twice the size of female sea lions.
Which best explains the difference in size
between male and female sea lions? A Orcas
and sharks prey on sea lions. B Male and
female sea lions hunt on land and at sea. C
Sea lions hold their breath while diving. D
Males compete with one another for females.
Mammals Hold breath while diving Can dive
as deep as 250 m Hunt on land and at sea
Preyed on by orcas and great white sharks
Establish large communities Males compete for
females Males can reach a mass of 300 kg
Females can reach a mass of 150 kg
26
Punnett Square for Corn Height
25 Square 4 of this Punnett square represents
the genotype of the offspring if F ovule
T is fertilized by pollen grain T G ovule t
is fertilized by pollen grain T H ovule T is
fertilized by pollen grain t J ovule t is
fertilized by pollen grain t
27
26 Which two kingdoms have members that
are photosynthetic? A Eubacteria and
Fungi B Protista and Animalia C Plantae
and Protista D Animalia and Fungi
28
27 In this food web, how many
organisms are in kingdom Animalia? A 8 B
7 C 6 D 5
29
28 A laboratory investigation included
examining prepared slides of pond water.
Single-celled organisms with a nucleus and either
cilia or flagella were visible. These organisms
probably belong to the kingdom F
Animalia G Fungi H Plantae J Protista
30
29 Multicellular eukaryotes that are
usually mobile and obtain food from other
organisms probably belong to the kingdom A
Plantae B Fungi C Animalia D Protista
31
30 Some zooplankton belong to the kingdom
Protista. Members of this kingdom are
characterized as A having segmented bodies
with jointed appendages B containing one or
more eukaryotic cells C laying eggs with a
leathery protective shell D having a
four-chambered heart
32
31 The cell above most likely belongs
to an organism of the kingdom F
Animalia G Plantae H Fungi J
Eubacteria
33
32 Which is a characteristic of members of
the plant kingdom that distinguishes them from
members of the animal kingdom? A Storage of
energy in chemical bonds B Exchange of H2O
with the environment C Use of mRNA during
protein production D Use of chlorophyll for
solar-energy transformation
34
Characteristics of a Newly Discovered
Organism 33 Knowledge of which of these
is most important in classifying this new
organism into a kingdom? F The color of light
absorbed by the organism G The type of
radiation emitted H The use of
photosynthesis J The color of the organism
Absorbs blue light Emits infrared radiation
Contains RNA in nucleus Appears as a red
organism in full daylight Can obtain nutrition
through photosynthesis
35
34 Which of these statements describes the
vertebrate circulatory system and its primary
function? A A web of structures that provide
support while protecting vital organs B
A series of ductless glands that secrete
hormones directly into the blood C A
network of tissues that carry nutrients and
oxygen through the body D A complex
of cytoplasmic cell membranes that transport
materials made by the cell
36
35 Which structure in the upper arm
is responsible for raising the lower arm? A
1 B 2 C 3 D 4
37
36 The medulla, part of the brain stem,
reacts quickly to increased levels of CO2
in the blood and stimulates a response from the
A excretory system B immune system C
respiratory system D integumentary system
38
37 Which system is responsible for
producing enzymes that aid in breaking down
substances to be absorbed for the bodys growth
and repair? F Digestive system G
Reproductive system H Respiratory system J
Skeletal system
39
38 Which of the following is directly
caused by muscle action? F Regeneration of
nerves G Healing of wounds H Release of
hormones J Extension of limbs
40
39 Which system of the body would be
directly affected if a large number of T cells
were attacked by a virus? A Cardiovascular
system B Immune system C Endocrine
system D Respiratory system
41
40 In the diagram above, one cell
creates and releases chemicals that travel to a
second cell and quickly induce that cell into
action. This diagram represents part of the
A endocrine system B skeletal
system C muscular system D nervous system
42
41 Hemoglobin carries oxygen to body cells.
Which body system contains hemoglobin? A
Circulatory system B Respiratory system C
Endocrine system D Nervous system
43
42 Pelicans prevent serious wing damage by
entering the water in the manner shown above.
Which two organ systems in the pelican work
together the most to accomplish this
maneuver? A Circulatory and nervous
systems B Nervous and muscular systems C
Muscular and digestive systems D Digestive and
circulatory systems
44
Grade 10 Objective 2 Answer Key
45

Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key
Question Correct Answer Objective Measured Student Expectation Source - item number
1 D 2 BIO 4B 2004 Info Booklet 9
2 G 2 BIO 4B 2003 TAKS 14
3 A 2 BIO 4B 2003 TAKS 27
4 H 2 BIO 4B 2004 TAKS 8
5 D 2 BIO 4B 2006 TAKS 5
6 D 2 BIO 4B 2006 TAKS 13
7 B 2 BIO 6A 2004 Info Booklet 10
8 D 2 BIO 6A 2004 TAKS 21
9 G 2 BIO 6A 2004 TAKS 36
10 D 2 BIO 6A 2006 TAKS 41
11 A 2 BIO 6A 2002 Biology EOC 39
12 H 2 BIO 6C 2003 TAKS 22
13 G 2 BIO 6C 2003 TAKS 26
14 J 2 BIO 6C 2004 TAKS - 26
15 7 2 BIO 6C 2004 TAKS - 20
16 D 2 BIO 6C 2006 TAKS 39
17 G 2 BIO 6C 2002 Biology EOC 22
18 D 2 BIO 6D 2004 Info Booklet 6
19 B 2 BIO 6D 2003 TAKS 1
20 A 2 BIO 6D 2003 TAKS 53
21 H 2 BIO 6D 2004 TAKS - 40
46

Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key Grade 10 Objective 2 Answer Key
Question Correct Answer Objective Measured Student Expectation Source - item number
22 J 2 BIO 6D 2004 TAKS 46
23 H 2 BIO 6D 2006 TAKS 34
24 D 2 BIO 6D 2006 TAKS 55
25 J 2 BIO 6D 2002 Biology EOC 34
26 C 2 BIO 8C 2004 Info Booklet 7
27 A 2 BIO 8C 2004 Info Booklet 26
28 J 2 BIO 8C 2003 TAKS 4
29 C 2 BIO 8C 2003 TAKS 37
30 B 2 BIO 8C 2004 TAKS 17
31 G 2 BIO 8C 2004 TAKS 38
32 D 2 BIO 8C 2006 TAKS 31
33 H 2 BIO 8C 2006 TAKS 52
34 C 2 BIO 10A 2004 Info Booklet 8
35 C 2 BIO 10A 2003 TAKS 17
36 C 2 BIO 10A 2003 TAKS 25
37 F 2 BIO 10A 2003 TAKS 48
38 J 2 BIO 10A 2004 TAKS 6
39 B 2 BIO 10A 2004 TAKS 41
40 D 2 BIO 10A 2004 TAKS 51
41 A 2 BIO 10A 2006 TAKS - 15
42 B 2 BIO 10A 2006 TAKS - 47
