Oracle Grid Computing: Trending for Capacity Planning

1
Oracle Grid Computing Trending for Capacity
Planning
Ashish RegeSEISession S307772
2
What DBAs, SYS admins need

• Database Administrators, Sys Administrators are
  called on everyday to make decisions on capacity
  planning.
• Which database has trended high for CPU, Memory,
  I/O etc. over the last year, month, week, day
  versus other databases on the same server?
• Do these trends have some unique cyclical
  patterns based on year, month, week, day for
  different applications?
• Do we see new functionality, additional users,
  increased concurrency with time?
• Do we have the capacity to add one or more
  database to existing servers?
• Where do we re-allocate databases at the next
  opportunity and where do we see capacity?
• Do we need to buy new servers and factor this
  into next years budget?

3
Approach and Toolset

• Top down and Bottom up approach edge at the
  this sideways too ..
• SA-DBA-Middleware cross functional analysis
• Toolset that can help trend CPU/Memory/Elapsed
  Time
• OS extended stats
• OEM repository DB/Host performance metrics
• Oracle Services stats
• App-DB-Integration-elapsed time/time-out metrics
• Apache Logs fact-dimensional model
• Batch Job-stream runtime metrics
• Business measures e.g. positions, txn counts, tax
  lots, fees etc
• Fill in the gaps with data points to construct a
  complete picture

4
Requirements summary

• Database administrators and sys administrators
  need
• consolidated data points to provide holistic
• "Capacity Trend Analysis"
• from an intraday to multiyear via a web
  interface for the databases and their host
  servers from CPU, Memory, I/O, wait bottlenecks,
  throughput, and efficiencies perspective.
• Stack up trends for different database per server
  on the same graph to enable side-by-side
  comparison and a better awareness of percentage
  usage by database/application and its alignment
  with the business cycle.
• Help trend uptick or downward spiral of business
  measures and find correlation of those with
  database and server statistics to model what if
  analysis
• end-to-end trending for
• UI response times
• Batch jobs
• Processed Business measures

5
Now to the details

• OEM grid captures at a 15 minutes interval, write
  PERL scripts to transfer this to a trending
  utility that graphs those on the web with
  reporting
• At the grain of intraday to multiyear for
  performance counters like consumption of CPU,
  memory, I/O, throughput, efficiency, wait stats
  etc. for the different databases.
• Capture metadata into flat files
• (1) Details per database
• (2) Comparative numbers across different
  databases on the same or different servers
• (3) Supplement the above with details from stats
  pack

6
Putting it all together
7
Reporting Classifications ..

• Thus the reporting that comes out of the OEM is
  at two levels
• Database statistics
• Host statistics, this also includes side-by-side
  Oracle comparison for databases on that host
• The above statistics have associated flat files
  extracted out of OEM to feed this data to
  Orca/RRDTool to generate the graphs/trend.
• Have found these graphs very useful in
• Re-alignment decisions
• Budget discussions around shared infrastructure
  resources for different cost centers

8
Orca/RRD Tool

• Orca/RRD Tool is a tool useful for plotting
  arbitrary data from text files onto a directory
  on a Web server. It has the following features
• files into the same or different plots. Creates
  an HTML tree of HTML and image (PNG or GIF)
  files.
• Creates an index of URL links listing all
  available targets.
• Creates an index of URL links listing all
  different plot types.
• No separate CGI set up required.
• Can be run under cron or it can sleep itself
  waiting for file updates based on when the file
  was last updated.
• Configuration file based.
• Reads arbitrarily formatted text or binary data
  files.
• Watches data files for updates and sleeps between
  reads.
• Finds new files at specified times.
• Remembers the last modification times for files
  so they do not have to be reread continuously.
• Allows arbitrary grouping of data from different
  sources
• Allows arbitrary math performed on data read from
  one file

9
Orca architecture

• Out of the box Orca statistics for the host
• On clients, orcallator.se, a component of the SE
  Toolkit, collects data every 5 minutes and dumps
  the data in orca's home directory. Orcallator.se
  has a startup script in /etc/init.d. This data is
  dumped in /home/orca/data/lthostnamegt
• A crontab entry for the orca user polls each
  client every 5 minutes, grabs the current data,
  and prunes old data. This is done via an SCP from
  orca's crontab on the server, and is driven by a
  list of hosts on the orca server at
  /apps/orca/xfer/hostlist.
•  scp -r -p -v orca_at_host/home/orca/data/
  /apps/orca/orcallator
• Orca's crontab on the orca server calls
  /apps/orca/xfer/pull.sh which processes all files
  in /apps/orca/xfer/hostlist

10
Out of box OS performance Statistics

• The Orca server app which simply checks a
  directory tree (/apps/orca/orcallator) every five
  minutes and graphs any new data which has
  appeared there
• Then, as orca on the orca server does an ssh to
  the new client ssh ltclientgt" and when prompted,
  adds to known hosts, unless this is done for each
  client added, no data transfer can succeed.
• Then, add the client to the file
  /apps/orca/xfer/hostlist. This file contains a
  list of all clients and is used by the script
  'pull.sh', driven by orca's crontab, included
  here. Orca's crontab also prunes some files on
  each client. Clients are completely passive,
  orcallator.se dumps performance data in orca's
  home directory on each client, the server
  collects it, processes it.
• Orca produces HTML files, along with
  "index.html". A standard Apache server is
  required to publish the pages.
• The url for viewing orca is http//ltorac server
  IPgt/orca/

11
OEM Custom statistics

• Extract performance data out of OEM repository
  into flat files, via a custom script running at
  an hourly frequency. These flat files are dropped
  into the same directory which Orca checks and
  processes data from to plot graphs
  (/apps/orca/orcallator). Thus data is generated
  right off the Orca server connecting remotely to
  the OEM repository.
• Thus any data can be plotted including business
  measures. It is that simple
• Using the DBIOracle library to query the OEM
  GRID Repository joining tables like
  sysman.MGMT_TARGETS, sysman.MGMT_METRICS, sysman.
  MGMT_METRICS _1HOUR extracting data out of into
  files.
• A timestamp is written to a snapfile that tracks
  time intervals already queried and reported on
  the next run is based on querying the sysman
  repository table to find snapshots with
  rollup_timestamp greater than the last run
• e.g. 2008-11-12_190000

12
Quarterly Instance Efficiency
13
Comparative Quarterly Instance CPU Utilization
The sample compares Waits User CPU, User I/O,
Other between different databases GWMPE02, E2L1,
E2L2, EC02, ER02 across the DB server
seidevdb34  E02 is the max consumer, at times
taking 50 or more of CPU compare to other
databases which have negligible CPU consumption.
14
SNAPFILE
Snapfile helps to track last extraction time of
performance data.  pwd /export/home/oracle/orca_or
acle/snapfile  oracle_at_seieaas52z1 tail -f
ltDBNAMEgt.seic.com_Oem_snapid 2009-03-10_120000 2
009-03-10_140000 2009-03-10_160000 2009-03-10_
180000 2009-03-10_200000  oracle_at_seieaas52z1
tail -f ltSERVERNAMEgt_OemHost_snapid 2009-03-10_12
0000 2009-03-10_140000 2009-03-10_160000 2009
-03-10_180000 2009-03-10_200000
15
OEM SQL QUERY HOST DB PERFORMANCE DATA
Part 1 Decide on beginning and ending
snapshots OEM repository query "select
min(to_char (d.rollup_timestamp
,'YYYY-MM-DD_HH24MISS')) FROM sysman.mgmt_target
s tgt , sysman.mgmt_metrics met ,
sysman.mgmt_metrics_1hour d WHERE lower(tgt.target
_name) lower(?) AND tgt.target_type
'oracle_database' AND tgt.target_guid
d.target_guid AND met.metric_guid
d.metric_guid AND d.rollup_timestamp gt
to_date(?,'YYYY-MM-DD_HH24MISS') "
16
OEM SQL QUERY HOST DB PERFORMANCE DATA
Part 2 Get the latest snapshot and it's
time "select min(to_char ( d.rollup_timestamp
,'YYYY-MM-DD_HH24MISS' )) ,max(to_char (
d.rollup_timestamp ,'YYYY-MM-DD_HH24MISS'
)) FROM sysman.mgmt_targets tgt ,
sysman.mgmt_metrics met , sysman.mgmt_metrics_1hou
r d WHERE lower(tgt.target_name) lower(?) AND
tgt.target_type 'oracle_database' AND
tgt.target_guid d.target_guid AND
met.metric_guid d.metric_guid "
17
OEM SQL QUERY HOST DB PERFORMANCE DATA
Part 3 Collect the raw values from OEM for DB
stats  "SELECT DISTINCT met.metric_column ,d.key_v
alue ,d.value_average FROM sysman.mgmt_targets
tgt , sysman.mgmt_metrics met ,
sysman.mgmt_metrics_1hour d WHERE lower(tgt.target
_name) lower(?) AND tgt.target_type
'oracle_database' AND tgt.target_guid
d.target_guid AND met.metric_guid
d.metric_guid AND d.rollup_timestamp
to_date(?,'YYYY-MM-DD_HH24MISS') ORDER BY
d.rollup_timestamp,met.metric_column"
18
OEM SQL QUERY HOST DB PERFORMANCE DATA
Part 4 Collect the raw values from OEM for
HOSTS stats  "SELECT DISTINCT met.metric_column ,d
.key_value ,d.value_average . ..FROM
sysman.mgmt_targets tgt, sysman.mgmt_metrics met,
sysman.mgmt_metrics_1hour d WHERE
lower(tgt.target_name) lower(?) AND
tgt.target_type 'host AND tgt.target_guid
d.target_guid AND met.metric_guid d.metric_guid
AND met.metric_column IN ('cpuLoad,'cpuLoad_15min
,'cpuLoad_1min,'longestServ,'cpuIOWait,'cpuKer
nel' ,'cpuUser,'cpuUtil,'memUsedPct,'memfreePct
,'swapUtil,'noOfProcs,'noOfUsers,'totIO,'pgSc
anRate) AND d.rollup_timestamp
to_date(?,'YYYY-MM-DD_HH24MISS')
19
Orcallator.cfg OEM group
group oem find_files
/apps/orca/oem/(.)/(?oracle)-\d4-\d2-\d2(?
-\d3,)?(?\.(?Zgzbz2))? column_description
first_line date_source
column_name timestamp interval
3600 filename_compare sub
my (ay, am, ad) a
/-(\d4)-(\d\d)-(\d\d)/
my (by, bm, bd) b /-(\d4)-(\d\d)-(\d\
d)/ if (my c (( ay
ltgt by)
( am ltgt bm)
((ad gtgt 3) ltgt (bd gtgt
3)))) return 2c

ad ltgt bd
20
Orcallator.cfg SERVER grouping
group ltSERVER1gt find_files
/apps/orca/oemhost/( SERVER1)/(?(?
SERVER1)(?percol))-\d4-\d2-\d2-\d3 colum
n_description first_line date_source
column_name timestamp interval
3600 filename_compare sub
my (ay, am, ad) a
/-(\d4)-(\d\d)-(\d\d)/
my (by, bm, bd) b /-(\d4)-(\d\d)-(\d\
d)/ if (my c (( ay
ltgt by)
( am ltgt bm)
((ad gtgt 3) ltgt (bd gtgt
3)))) return 2c

ad ltgt bd
21
Services trending
Service performance in VSERVICE_STATS VSERVICE
_EVENT VSERVICE_WAIT_CLASS VSERVICEMETRIC VSERV
ICEMETRIC_HISTORY
22
Items Learned in this Session

• Database administrators and sys administrators
  need consolidated data points to provide holistic
  "Capacity analysis" for the databases and their
  host servers from CPU, Memory, I/O, wait
  bottlenecks, throughput, and efficiencies
  perspective.
• This presentation outlined a methodology that
  helps with "Capacity Trend Analysis" from an
  intraday to multiyear via a web interface the
  key theme here is the ability to stack up trends
  for different databases per server on the same
  graph to enable side-by-side comparison and a
  better awareness of percentage usage by
  database/application and its alignment with the
  business cycle.
