Title: Chapter 1: From bla to bla


1
Online Chapter B
2
The Traditional Approach to Requirements
Online Chapter B
  • Systems Analysis and Design in a Changing World
    6th Ed
  • Satzinger, Jackson Burd

3
Online Chapter B Outline
  • Traditional and Object-Oriented Views of
    Activities and Use Cases
  • Data Flow Diagrams
  • Documentation of DFD Components
  • Locations and Communication through Networks

4
Learning Objectives
  • Explain how the traditional approach and the
    object-oriented approach differ when modeling the
    details of a use case
  • List the components of a traditional system and
    the symbols representing them on a data flow
    diagram
  • Describe how data flow diagrams can show the
    system at various levels of abstraction
  • Develop data flow diagrams, data element
    definitions, data store definitions, and process
    descriptions
  • Develop tables to show the distribution of
    processing and data access across system locations

5
Overview
  • Chapters 3, 4, and 5 described two key concepts
    associated with modeling functional requirements
    in the newer (OO) approaches to information
    systems development the use cases and the domain
    classes involved in users work
  • This chapter describes an older and more
    traditional approach to representing requirements
  • Entity-relationship diagrams represent things in
    the users work domain
  • Data flow diagrams (DFDs) and associated concepts
    model system processes instead of use case
    diagrams and system sequence diagrams

6
Traditional vs. OO Approach
7
Requirements Models for Traditional vs. OO
Approach
8
Data Flow Diagram Symbols
9
DFD for process Look up item availability
10
DFD Decomposes To show different levels of
abstractionContext DiagramDiagram 0Diagram 1
11
DFD FragmentsOne for each use case
12
Combine DFD FragmentsTo Create Diagram 0
13
RMO Data Flow DiagramsContext Diagram
14
RMO Subsystems and Use Cases
15
Context Diagram for RMO Order Entry Subsystem
16
DFD Fragments for RMO Order Entry Subsystem
17
Diagram 0 for RMO Order Entry Subsystem
18
Decomposing Process 2 from DFD Fragment 2
19
Physical DFDsSometimes useful for modeling
processes
20
Evaluating DFD Quality
  • Minimize complexity
  • Information overload difficulty in
    understanding that occurs when a reader receives
    too much information at one time
  • Rule of 7 2 (Millers number) the rule of
    model design that limits the number of model
    components or connections among components to no
    more than nine
  • Minimization of interfaces a principle of model
    design that seeks simplicity by limiting the
    number of connections among model components

21
Evaluating DFD Quality
  • Ensuring Data Flow Consistency
  • Three Common Errors
  • Differences in data flow content between a
    process and its process decomposition
  • Data outflows without corresponding data inflows
  • Data inflows without corresponding outflows
  • Balancing equivalence of data content between
    data flows entering and leaving a process and
    data flows entering and leaving a process
    decomposition DFD
  • Black hole a process or data store with a data
    input that is never used to produce a data output
  • Miracle a process or data store with a data
    element that is created out of nothing

22
Process Descriptions
  • Structured English a method of writing process
    specifications that combines structured
    programming techniques with narrative English
  • Decision table a tabular representation of
    processing logic containing decision variables,
    decision variable values, and actions or formulas
  • Decision tree a graphical description of
    process logic that uses lines organized like
    branches of a tree

23
Structured English Example
24
RMO Process 2.1 Structured English
25
Structured English to determine delivery charges
26
Decision Table calculating shipping charges
27
Decision Tree calculating shipping charges
28
Decision Table with multiple action rows
29
Data Flow Definitions
  • Data flow definition a textual description of a
    data flows content and internal structure
  • Can be simple list of data elements that make up
    the data flow. For new order
  • Can use an algebraic notation to indicate
    elements and structure

30
Data Flow Definitions
  • RMO products and items report defined using
    algebraic notation. Note nested repeating groups
    like typical control break report.

31
Data Dictionary and Other Definitions
  • Data dictionary a repository for definitions of
    data flows, data elements, and data stores
  • A data store on the DFD represents a data entity
    on the ERD, no separate definition is typically
    needed
  • Data element definitions
  • Describe a data type, such as string, integer,
    floating point, or Boolean
  • Each element should also be defined to indicate
    specifically what it represents and how it is
    validated
  • Use the person from Mars conceptwould someone
    from Mars know what element means?

32
Data Element Definitions
33
Locations and Communication Through Networks
  • Location diagram a diagram or map that
    identifies all the processing locations of a
    system
  • Activity-location matrix a table that describes
    the relationship between processes and the
    locations in which they are performed
  • Activity-data matrix a table that describes
    stored data entities, the locations from which
    they are accessed, and the nature of the accesses
  • CRUD acronym for create, read, update, and
    delete

34
RMO Location Diagram
35
RMO Activity-Location Matrix
36
RMO Activity-Data Matrix
37
Summary
  • Data flow diagrams (DFDs) are used in combination
    with the use cases and entity-relationship
    diagram (ERD) to model system requirements
  • DFDs model a system as a set of processes, data
    flows, external agents, and data stores
  • Many types of DFDs are developed, including
    context diagrams, DFD fragments, subsystem DFDs,
    diagram 0, and process decomposition DFDs
  • Each process, data flow, and data store requires
    a detailed definition

38
Summary (continued)
  • Analysts may define processes in a number of
    ways, including a structured English process
    specification, a decision table, a decision tree,
    or a process decomposition DFD
  • Data flows are defined in terms of their
    component data elements and their internal
    structure.
  • Data elements may be further defined in terms of
    their type and allowable content
  • Data stores correspond to entities on the ERD and
    thus require no additional definition
  • The location diagram, activity-location matrix,
    and activity-data matrix describe important
    information about system locations
