Extending the p-Cycle Concept to Path-Segment Protection

1
Extending the p-Cycle Concept to Path-Segment
Protection

• Gangxiang Shen, Wayne D. Grover
• gshen,grover_at_trlabs.ca
• URL http//hey.to/gxshen

2
Outline

• Background and Motivation
• Concept of Flow p-Cycles
• Flow p-Cycle Design Model
• Test Methods and Results
• Operational Aspects and Potential Applications
• Conclusions

3
Basic Approaches to Transport Network
Survivability
4
Background Span-Protecting p-Cycles

• Characteristic Ring-like switching speed and
  mesh-like capacity efficiency

5
Comparison between Ring and p-Cycle Protection
Ring network
p-Cycle
Spare Capacity
Protection Coverage
Able to restore 9 spans
Able to restore 19 spans
6
The Unique Position Span p-Cycles Occupy
Path rest, SBPP
Speed
Span (link)rest.
200 ms
BLSR
50 ms
100
50
200
Redundancy
7
Motivation

• All the studies so far on p-cycles consider
  span-protecting p-cycles, so it is natural to
  ask
• Q. is there is a path protection equivalent to
  p-cycles? --
• A. Yes the answer is Flow p-Cycles !

8
Concept of Flow p-Cycles

• Characteristic
• Protect spans that span p-cycles can protect as
  well as spans that span p-cycles cannot protect
  (example span 6-7 below)
• Intermediate node failure restoration (example
  node 7)
• Path restoration like spare capacity efficiency,
  11 path protection like switching speed

9
The Position Flow p-Cycles Occupy
Path rest, SBPP
p -cycles BLSR speedmesh efficiency
Speed
Span (link)rest.
200 ms
BLSR
50 ms
100
50
200
Redundancy
10
Various Flow-to-Cycle Relationships

• Related basic concepts
• Intersecting and non-intersecting
• Intersection nodes
• Intersection flow segment
• Straddling and on-cycle flow relationship

11
Mutual Capacity Consideration

• Single span-failure causes multiple flow-failures
  simultaneously
• Flow-based restoration is required

12
Flow p-Cycle Design Model for 100 Span Failure
Restoration

• Objective minimize total spare capacity
• Constraints
• Affected flows upon a span failure must be fully
  restored
• Number of cycle copies to build is set by the
  largest span failure-specific simultaneous use
  for unit copies of cycle
• The spare capacity on a span must be enough to
  support the number of copies of each p-cycle that
  overlies the span

13
Test Networks
14
Result Performance Comparison between Various
Protection Schemes
15
Operational Aspects and Protocol
16
Applications of the General Concept
17
Conclusions

• Flow p-cycle concept was proposed and evaluated
• Flow p-cycle method achieves path restoration
  like spare capacity efficiency and 11 path
  protection like restoration speed

18
Future Work

• Identify the impacts from the network details and
  demand patterns
• Further consider operational aspects and develop
  control protocol
• Implement some applications of the general
  concept
• Consider an evolutional scheme, pre-configured
  segments p-segments
• Compare to ordinary node-encircling p-cycles
  for node protection.

19
Main References

• 1 W. D. Grover and D. Stamatelakis,
  Cycle-oriented distributed preconfiguration
  Ring-like speed with mesh-like capacity for
  self-planning network restoration, in Proc. of
  IEEE ICC98, 1998, pp. 537-543.
• 2 D. Stamatelakis, W. D. Grover, IP layer
  restoration and network planning based on virtual
  protection cycles, IEEE Journal on Selected
  Areas in Communications, vol.18, no.10, October
  2000, pp. 1938 - 1949.
• 3 D. A. Schupke, C. G. Gruber, and A.
  Autenrieth, Optimal configuration of p-cycles in
  WDM networks, in Proc. of IEEE ICC02, 2002.
• 4 W. D. Grover, and J. E. Doucette, Advances
  in optical network design with p-cycles Joint
  optimization and pre-selection of candidate
  p-cycles, to appear in Proc. of the IEEE-LEOS
  Summer Topical Meeting on All Optical Networking,
  2002.
• 5 M. Herzberg and S. Bye, An optimal
  spare-capacity assignment model for survivable
  network with hop limits, in Proceedings of IEEE
  GLOBECOM94, 1994, pp. 1601-1607.
• 6 R. R. Iraschko, M.H. MacGregor, and W.D.
  Grover, Optimal capacity placement for path
  restoration in STM or ATM mesh-survivable
  networks, IEEE/ACM Transactions on Networking,
  vol. 6, no. 3, June 1998, pp. 325-336.

20
Literature Survey on Span-Protecting p-Cycles

• 1998, Grover and Stamatelakis first proposed
  p-cycles concept and developed self-organized
  protocol 1
• 2000, application of p-cycles to IP/MPLS layer
  2 including node-encircling p-cycles
• 2002, application to DWDM networks 3
• 2002, studies on joint optimization of p-cycle
  network designs 4

21
Evolution of Survivability Schemes

• First Generation
• Pre-configured dedicated protection facilities
• Fast restoration speed
• Bad spare capacity redundancy
• Example various ring-based techniques like 11,
  UPSR, BLSR
• Second Generation
• Pre-planned but not pre-configured protection
  routes and shared spare capacities
• Good spare capacity redundancy
• Slow restoration speed
• Example mesh-based restoration schemes like
  span, path, SBPP

22
Evolution of Survivability Schemes (cont)

• Third Generation
• Pre-configured cycles
• Fast restoration speed
• Good spare capacity redundancy
• Example p-cycles
• Future Generation
• Pre-configured segments
• Fast restoration speed
• Good spare capacity redundancy
• Example p-segments

23
Comparison between Mesh (SBPP) Restoration and
p-Cycle Protection
Mesh restorable network
p-Cycle
Two-way talk Generalized adaptive
reconfiguration
No two-way talk Immediate action Fully
pre-prepared action
24
Cycle Preselection Strategy

• D is set of nonzero demand pairs (i.e., flows)
  on the traffic matrix
• Sr is set of spans traversed by the working path
  between demand pair r
• P(j) denotes cycle j in cycle set P
• k enumerates spans on cycle P(j) and ck
  represents the cost of span k
• gr denotes number of traffic demand units of the
  working flow between demand pairs r
• lr denotes length of the working flow of demand
  pair r

25
Flow p-Cycle Design Model II 100 Span and Node
Failure Restoration

• Objective minimize total spare capacity
• Constraints
• Affected flows upon a span failure must be fully
  restored
• Affected flows upon an intermediate node failure
  must be fully restored
• Number of cycle copies to build is set by the
  largest span failure-specific simultaneous use
  for unit copies of cycle
• Number of cycle copies to build is set by the
  largest node failure-specific simultaneous use
  for unit copies of cycle
• The spare capacity on a span must be enough to
  support the number of copies of each p-cycle that
  overlies the span

26
Concept of Multi-QoP

• R0 restorability this is a wholly best-effort
  class with no assured restorability
• Rs restorability this class is assured by design
  of restorability against any span failure, but
  receives only best efforts with no guarantee for
  node failure
• Rsn restorability this class enjoys assured
  restorability against any span failure or failure
  of an intermediate node other than its own
  end-nodes.

27
Flow p-Cycle Design Model III Design to Support
Multi-QoP

• Objective minimize total spare capacity
• Constraints
• Affected Rs and Rsn flows upon a span failure
  must be fully restored
• Affected Rsn flows upon an intermediate node
  failure must be fully restored
• Number of cycle copies to build is set by the
  largest span failure-specific simultaneous use
  for unit copies of cycle
• Number of cycle copies to build is set by the
  largest node failure-specific simultaneous use
  for unit copies of cycle
• The spare capacity on a span must be enough to
  support the number of copies of each p-cycle that
  overlies the span

28
Flow p-Cycle Design Model IV Maximal Node
Recovery under a Spare Capacity Budget

• Objective maximize overall node failure
  restorability
• Constraints
• Affected flows upon a span failure must be fully
  restored
• The restored traffic flows of a demand pair never
  exceeds its total lost traffic flows upon an
  intermediate node failure
• Number of cycle copies to build is set by the
  largest span failure-specific simultaneous use
  for unit copies of cycle
• Number of cycle copies to build is set by the
  largest node failure-specific simultaneous use
  for unit copies of cycle
• The spare capacity on a span must be enough to
  support the number of copies of each p-cycle that
  overlies the span
• Total spare capacity should not exceed a budget

29
Result II Impact of Cycle Preselection
Strategies and Number of Cycles of Flow p-Cycles
30
Result III Impact of Physical Distance Limit of
Cycle Circumference of Flow p-Cycles
31
Result IV Performance on Node Failure Recovery
(1)
Rs 100 span failure restoration Rsn 100 span
and intermediate node failure restoration
32
Result IV Performance on Node Failure Recovery
(2)
Normalized spare capacity for 100 span failure
restoration
33
Result IV Performance on Node Failure Recovery
(3)
100 Rs services
100 Rsn services
34
Publications

• 1 Wayne D. Grover, Gangxiang Shen, "Extending
  the p-cycle concept to path-segment protection,"
  to appear in ICC2003, Anchorage, Alaska, USA,
  May, 2003.
• 2 Gangxiang Shen, Wayne D. Grover, "Capacity
  requirements for network recovery from node
  failure with dynamic path restoration," to appear
  in OFC2003, Atlanta, Georgia, USA, March, 2003.
• 3 Gangxiang Shen, Wayne D. Grover, Extending
  the p-cycle concept to path-segment protection
  for span and node failure recovery, submitted to
  IEEE JSAC special issue (Optical communications
  and networking series 2003).
