Smart Grid by Rokura

1
Smart Grid by Rokura Kamstrup
2
Why Smart Grid?
20-20-20

• 20 reduction in CO2 emissions
• 20 increase of energy efficiency
• -20 energy from renewables

3
(No Transcript)
4








50,5 Hz
50,0 Hz
Production
Consumption
49,5 Hz
Consumption must follow production
Source DanGrid
5
Interconnectors are important
Source Energinet.dk
6
Using power when its plentiful and cheap
7
What the Smart Grid must do?
Integrate increased amounts of renewables
Integrate distributed energy
Support increased demand for electricity
Reduce peak loads
Improve market functioning and customer service
Optimise distribution grid assets
Ensure a secure grid
What the Smart Grid must do
8
OMNIAAn all-comprising smart grid platform
9
OMNIA SUITEOverview
10
The Smart MeterA Smart Grid component
11
UtiliKeeper at a glance
12
SCADA integration via IEC 60870-5-104

• UtiliKeeper has built-in support for SCADA
  integration in slave mode
• A SCADA system must connect to UtiliKeeper as a
  master
• UtiliKeeper pushes alarms as they happen
• Most meter values and alarms are supported
• The relay outputs can be controlled from SCADA
• Double command and single command supported
• Digital inputs supported as single and double
  indicators

13
M/490 Compliance
14
OMNIA SUITEIntegration Points
15
Thank You!
The Smart Grid is a journey Ensure you build the
right foundation
