Coordinated regulation of glycolysis/gluconeogenesis

1
Coordinated regulation of glycolysis/gluconeogenes
is
2
(No Transcript)
3
High blood glucose
Insulin secretion
Synthesis of hexokinase II, PFK-1, pyruvate kinase
Movement of GLUT4 to plasma membrane of myocyte
Activation of insulin-sensitive protein kinase
Activation of protein kinase B
4
p.903
5
p.887
6
Glucose
p.903
Glucose
GLUT2
Pancreatic b cell
Glucose
Glycolysis
pyruvate
Citric acid cycle
NADH,FADH2
Oxidative phosphorylation
ATP
closed
K
Ca2
ATP-gated K channel
- - - - - - -
Open

- - - - - - -
Insulin secretion

Voltage-dep. Ca2 channel
Membrane depolarization
Ca2
7
Movement of GLUT4 to plasma membrane of myocyte
p.396
Glc
Glc
Glc
Glc
Glc
Glc
Glc
Glc
Glc
Glc
Insulin receptor
Cytosol of myocyte
8
Activation of insulin-sensitive kinase
p. 588
Insulin
Insulin receptor
Insulin- sensitive kinase
Insulin- sensitive kinase
GM
Glycogen synthase a
Glycogen phosphorylase
PP1
PP1
Phosphorylase kinase
Glycogen synthesis ? Glycogen degradation ?
9
Activation of protein kinase B (PKB)
p.587
Insulin
Insulin receptor
PIP2
PI3-K
PI3-K
PIP3
PDK-1
PDK-1
PKB
PKB
IRS-1
GSK-3
GSK-3
Glycogen synthase a
Glycogen synthase a
Glycogen synthesis
10
GSK3 inactivate glycogen synthase by
phosphorylation
p.587
Phosphorylation by Casein kinase II
P
P
P
P
11
GSK3 can be inactivated by phosphorylation
p.587
PKB
P
P
12
High blood glucose affect hexokinase IV activity
p.578
Glc
nucleus
Glc
Hexokinase IV
GLUT2
Glc
Hexokinase IV
Regulator protein
Glc
Glc
Glc
Glc
Glc
Glc
Glc
Hepatocyte
13
Insulin regulate PFK-1 activity
Insulin
Insulin receptor
Phosphoprotein phosphatase
Phosphoprotein phosphatase
PFK-2 FBPase-2
FBPase-1
FBPase-1
PFK-1
PFK-1
PFK-2 FBPase-2
14
(No Transcript)
15
Low blood glucose
Glucagon secretion
Inactivation of pyruvate kinase L (liver form)
Activation of FBPase-2 and inactivation of PFK-2
Inactivation of glycogen synthase
Activation of glycogen phosphorylase
16
p.436
Regulation pathway initiated by glucagon secretion
Glucagon receptor
Glucagon receptor
Adenylyl cyclase
Adenylyl cyclase
b
cAMP
g
ATP
Protein kinase A
Protein kinase A
Pyruvate kinase L
PFK-2 FBPase-2
17
Regulation of PFK-1 by glucagon
Protein kinase A
Protein kinase A
PFK-2 FBPase-2
PFK-1
PFK-1
FBPase-1
FBPase-1
18
p. 588
Regulation of glycogen synthesis and breakdown by
glucagon
Protein kinase A
Protein kinase A
Glycogen synthase a
Glycogen phosphorylase
PP1
PP1
Phosphorylase kinase
Glycogen synthesis ? Glycogen degradation ?
19
Hexokinase

• There are four isozymes (I, II, III and IV) of
  hexokinase encoded by four different genes.
• Hexokinase I and II are allosterically inhibited
  by their product, glucose 6-phosphate. Hexokinase
  IV is not inhibited by G-6-P.

20
Hexokinase

• Hexokinase I and II are the predominant forms
  existing in muscle. Hexokinase IV is the
  predominant form in liver.
• Hexokinase I and II will be half-saturated at
  about 0.1mM, but hexokinase IV will not be
  half-saturated until 10mM.

21
Hexokinase

• Hexokinase has different functions in liver and
  muscle.
• Muscle consumes glucose, using it for energy
  production.
• Liver maintains blood glucose homeostasis by
  removing or producing glucose.

22
Muscle hexokinase

• Because blood glucose concentration is about 4 to
  5 mM, hexokinase in the muscle (which will be
  half saturated at 0.1mM) is always working at or
  near its maximal rate.

23
Liver hexokinase

• However, liver hexokinase (half-saturated at
  10mM) will not ever reach its maximal rate even
  after meal.

24
Phosphofructokinase-1

• PFK-1 catalyze the committing step of glycolysis.
• This enzyme is regulated by ATP, AMP, ADP,
  citrate and fructose 2,6-bisphosphate.

25
ATP regulate the affinity of PFK-1 towards its
substrate F-6-P

• Not only as a substrate, ATP is also one of the
  end product of the glycolytic pathway.
• ATP inhibit PFK-1 by binding to an allosteric
  site and lowering the affinity of the enzyme for
  F-6-P.

26
Molecules regulate PFK-1 and FBPase-1 activity
ATP
citrate
PFK-1
PFK-1
FBPase-1
PFK-1
ADP
AMP
F2.6BP

• ADP and AMP relieve the inhibition by ATP.
• Citrate increases the inhibitory effect of ATP.
• F-2,6-BP is the strongest activator of PFK-1.

27
Regulation of gluconeogenesis

• Pyruvate carboxylase
• FBPase-1

28
Pyruvate carboxylase

• Pyruvate carboxylase is being positively
  regulated by acetyl-CoA.
• The accumulation of acetyl-CoA signals that
  cells energy demands are met.
• Acetyl-CoA also indirectly inhibit pyruvate
  dehydrogenase complex.
