Dispersion due to meandering

1
Dispersion due to meandering

• Dean Vickers, Larry Mahrt
• COAS, Oregon State University
• Danijel Belušic
• AMGI, Department of Geophysics, University of
  Zagreb
• dbelusic_at_irb.hr

2
Overview

• Introduction (long)
• Particle model
• Dispersion due to meandering
• Meandering vs. turbulence

3
Meandering intro

• Meandering mesoscale wind direction variation
• Usually recognized by and studied in terms of its
  effects on dispersion in stable weak-wind ABL
• Unknown dynamics

4
Turbulence vs. mesoscale
5
Modeling transient mesoscale motions

• Regional models, LES models, etc. do not include
  the common transient mesoscale motions
• Not resolved
• Physics missing
• Eliminated by explicit or implicit numerical
  diffusion.

6
Types of small mesoscale motions

1. Gravity flows (sometimes multiple flows
   superimposed)
2. Flow distortion by terrain/obstacles
3. Transient mesoscale motions (gravity waves,
   meandering)
4. Nonstationary low-level jets
5. Solitons

7
Based on 14 eddy-correlation datasets, the
strength of mesoscale motions are

• Not related to u, z/L, Ri or wind speed
• Can be greater in complex terrain although less
  in thermally generated circulations.
• Different types of mesoscale motions may have
  quite different dispersive behavior.
• NOT PREDICTABLE

8
(No Transcript)
9
Effects on dispersion (1)

• To a first approximation, the variation of wind
  direction s? is inversely proportional to the
  mean wind speed

and is usually parameterized in models as
10
Indeed
11
Effects on dispersion (2)

• Therefore, s? (i.e. meandering) is significant
  only in weak winds
• The lateral dispersion is then

12
Effects on dispersion (3)

• Now, the parameterizations actually state that
  the variability of cross-wind component sv is
  constant ? not completely true, but it is
  independent of V and stability

13
(No Transcript)
14
Effects on dispersion (4)

• What does that actually mean?

• The dispersion due to meandering does NOT depend
  on wind speed and stability?!

15
Effects on dispersion (5)

• Lets compare the two expressions

Space or time??

• In time, the dispersion due to meandering does
  NOT depend on wind speed nor stability.

16
Particle model

• Lagrangian stochastic particle model
• Particle position updated as
  Xp(tdt) Xp(t) (Uu)dt
• Turbulence described by a Markov Chain Monte
  Carlo process with one step memory

17
Wind field for particle models

• Observed from single mast (assume spatially
  homogeneous)
• Mesoscale model
• LES model
• Observed using a tower network (this study)

18
Observations CASES-99

• Grassland in rural Kansas in October
• Seven towers inside circle of radius 300 m
• 13 sonic anemometers ? 20-hz (u,v,w,T)
• Site has weak meandering (ranked 8th out of 9
  sites studied)

19
CASES-99 network
20
Wind field

• High temporal resolution (no interpolation
  required)
• Meandering wind components and the turbulence
  velocity variances are spatially interpolated in
  3-D every time step
• Meandering resolved!

21
Decomposition

• Velocity variances are partitioned into
  meandering and turbulence based on the time scale
  associated with the gap region in the heat flux
  multiresolution cospectra
• Turbulence and meandering are generated by
  different physics and have different influences
  on the plume

22
Animations
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Case studies show

• Spatial streaks and bimodal patterns in the 1-h
  average distribution
• Double maximum patterns with higher C on the
  plume edges and minimum C on plume centerline
• Wind direction often jumps between preferred
  modes rather than oscillate back and forth
• Time series are highly non-stationary even when
  1-h average distribution is Gaussian

28
Removing record-mean flow

• Particles leave the tower network domain too
  quickly with any significant mean wind, so the
  record-mean wind is removed
• Removing mean wind has a huge impact on the
  spatial distribution, however, it has little
  impact on the travel-time dependence of particle
  dispersion (verified using particle simulator)
• This allows us to look at all the records
  including the stronger wind speeds

29
Measure of particle dispersion

• Travel time dependence of particle dispersion
  computed as
• sx2 (Xp(t) - Xp(t))2,
• where t is travel time and brackets denote an
  average over all particles
• E.g., for 1-h records there are 72,000 samples of
  Xp for all travel times
• sxy (sx2 sy2)½

30
(No Transcript)
31
The entire dataset shows

• The meandering motions, not the turbulence, are
  primarily responsible for the horizontal
  dispersion, and streaks, bimodal patterns and
  non-stationary time series are a consequence
• Meandering dominates in weak winds, strong winds,
  stable and unstable conditions
• Tracer experiments cannot measure the travel time
  dependence and therefore they suggest that
  meandering is only important in weak winds

32
Problems

• Horizontal dispersion is parameterized in terms
  of turbulence, while meandering dominates
  horizontal dispersion (and has different
  properties than the turbulence)
• Regional models under-represent meandering
  motions
• While sxy f(suvM ) works well, such a velocity
  scale is not available in models, nor does it
  appear predictable, nor is it very useful since
  distributions are highly non-Gaussian
