Ultrastructure of bacterial cell. Form and Function.

1
Ultrastructure of bacterial cell. Form and
Function.
2
Structure of a Prokaryotic Cell
3
Bacterial Morphology and Ultrastructure

• Only two types of cells are produced by all
  living organisms on earth.
• Prokaryotes (pro. or primitive nucleus) do not
  have a membrane bound nucleus
• eubacteria (true bacteria)
• archaebacteria (ancient bacteria)
• Eukaryotes (eu, or true nucleus) have a membrane
  bound nucleus
• Algae
• fungi
• protozoa
• plants
• animals

4
(No Transcript)
5
Prokaryotes
6
Chemical Composition of Bacteria

• Water - 70
• Dry weight - 30 composed of
• DNA - 5 MW 2,000,000,000
• RNA - 12
• protein- 70 found in
• Ribosomes(10,000) RNA
• Protein particles - MW 3,000,000
• Enzymes
• Surface structures
• polysaccharides - 5
• lipids - 6
• phospholipids - 4

7
Prokaryote Structures

1. Appendages- flagella, pili, fimbrae
2. Cell envelope- glycocalyx, cell wall , cell
   membrane
3. Cytoplasm- ribosomes, granules,
   nucleoid/chromosome.

8
Appendages
9
Bacterial Appendages

• Pili (pl), pilus (s)
• only found in gram negative bacteria
• tubulare, hairlike structures of protein larger
  and more rare than fimbriae.
• 2 types of pili
• atacnement pilus - allow bacteria to attach to
  other cells
• sex pilus, - transfer from one bacterial cell to
  another- conjugation.

10
Fimbriae

• fimbriae (pl) fimbria (s)
• Adhesion to cells and surfaces
• Responsible for biofilms.
• Pathogenesis of gonococcus and E.coli

Escherichia coli.
11
Flagella

• Flagella (pl), flagellum(s)
• long appendages which rotate by means of a
  "motor" located just under the cytoplasmic
  membrane.
• bacteria may have one, a few, or many flagella in
  different positions on the cell.
• Advantages
• - chemotaxis - positive and negative.
• - motility
• All spirilla, half of bacilli, rare cocci.

12
(No Transcript)
13
Structure of flagellaallows for 360 degree
filament rotation
14
Flagella

• Three morphological regions
• Helical filament
• long outermost region composes up to 90 of its
  length
• contains the globular (roughly spherical) protein
  flagellin arranged in several chains and form a
  helix around a hollow core
• Hooked or curved area
• filament is attached consists of a different
  protein
• Basal body
• terminal portion of the flagellum
• fix the flagellum to the cell wall and plasma
  membrane
• composed of a central rod inserted into a series
  of rings
•
• Gram negative - 2 pairs of rings
• Outer pair - fixed to the outer membrane and
  peptidoglycan layer
• Inner pair - fixed to the plasma membrane (SM
  ring)
• Gram positive - only inner pair is present

15
Motility

• Types of bacterial motility
• run or swim - when a bacterium moves in
  one direction for a length of time
• tumbles - periodic, abrupt random changes
  in direction
• swarming - rapid wavelike growth across a
  solid culture medium
• Mechanism of flagellar movement - relative
  rotation of the rings in the basal body of the
  flagellum
• Antigenicity
• flagellar or H antigen - useful in the
  serological identification of serotypes of
  Salmonella organisms

16
Arrangements

• Flagella vary in number and arrangement.
• Polar arrangment
• Monotrichious - 1 flagellum at one end
• Fastest Pseudomonas -example
• Lophotrichious - tuft at one end
• Amphitrichious- bipolar
• Peritrichious - multiple flagella randomly
  dispersed around the bacterial cell
• E. coli - example

17
Flagellar arrangements

• Monotrichous
• Lophotrichous
• Amphitrichous
• Peritrichous
• Atrichous

18
Axial filaments
19
Axial filaments

• tuft of fibrils that arise at the ends of the
  cell under the outer membrane and spiral around
  the cell
• rotation an opposing of the outer membrane
  movement that propels the spirochetes by causing
  them to move like corkscrews
• Found in Spirochetes and are similar to flagella,
  but are located between the cell wall and an
  outer membrane, and are attached to one end of
  the organism.

20
Evidence of motility

• Two ways by which motility can be demonstrated
• direct or microscopic
• hanging drop preparation or wet mount preparation
  by dark field mycroscope
• Distinguishes
• Brownian movement - when the bacteria show
  molecular movement
• true motility - if a bacterium describes a
  rotatory, undulatory or sinuous movement
• indirect or macroscopic
• Stab inoculation of the semisolid media
• nonmotile - growth is limited at the point of
  inoculation
• motile - growth is diffuse or moves away from the
  line of inoculation turbidity of the medium

21
Detection of Motility

• Direct

• Indirect

Presence mobile bacteria
22

• Bacterial motility (QuickTime movie)
• http//diverge.hunter.cuny.edu/weigang/Animations
  /SalmonellaFlagella-S.mov

23
Prokaryote Structures

• Appendages- flagella, pili, fimbrae
• Cell envelope
• glycocalyx
• cell wall
• cell membrane
• Cytoplasm- ribosomes, granules,
  nucleoid/chromosome.

24
2. Bacterial Surface Structure - cell envelope

• Glycocalyx - some extracellular material
  secreted by many bacterial cells in the form of
• capsule - attached tightly to the bacterium and
  has definite boundaries.
• slime layer - loosely associated with the
  bacterium and can be easily washed off
• Compositions
• layer of polysaccharide
• proteins - sometimes

25
(No Transcript)
26
Functions of the Capsule

• Protection
• Identification
• Vaccine preparation
• Tissue attachment
• Antibiotic barrier
•

27
Medical Importance -

• rapid serological identification of
• Several groups of streptococci
• Meningococcus
• Hemophilus influenzae
• Klebsiella pneumoniae
• Some of the coliforms
• Yersinia and Bacillus specie
•

28
Identification

• Two simple methods to distinguish the capsule
• India ink technique - most satisfactory method of
  demonstrating the capsule by Burri-Gins technique
• Bacteria is suspended in diluted India ink
• Stain with fuxin
• Bacterial cells appear to lie in a lacunae
• and red cytoplasme.
•
• Quellung reaction - Homologous antibody is added
  to a preparation of capsule.
• microprecipitation at the periphery of the
  capsule altering its refractive index rendering
  the capsule to be visible

29
(No Transcript)
30
Staining by Burri-Gins
31
Neisseria meningitidis - Gram- negative coccus,
non-motile bacteria occur as two cells (orange)
in a capsule (yellow)
32
Haemophilus influenza bacteria in the process of
expressing polysaccharide capsules.
33
Cell wall

• Peptidoglycan (polysaccharides protein),
• Support and shape of a bacterial cell.
• The three primary shapes in bacteria are
• coccus (spherical),
• bacillus (rod-shaped)
• spirillum (spiral).
• Mycoplasma are bacteria that have no cell wall
  and therefore have no definite shape.

34
Cell wall

• peptidoglycan (polysaccharides protein)
• Components of the peptidoglycan layer
• Repeating glycan chains (N acetyl glucosamine
  and N acetyl muramic acid)
• a set of identical tetrapeptide side chains
  attached to N- acetylmuramic acid
• a set of identical peptide cross bridges

35
Peptidoglycan
36
Differences in Cell Wall Structure

• Basis of Gram Stain Reaction
• Hans Christian Gram- 1884
• Differential Stain
• Gram Positive vs Gram Negative Cells
• Gram Positive Cells-
• Thick peptidoglycan layer with embedded
  teichoic acids
• Gram Negative Cells-
• Thin peptidoglycan layer, outer membrane of
  lipopolysaccharide.

37
Cell wall
38
Gram Stain Reaction

• Hans Christian Gram- 1880s
• Divides bacteria into 2 main groups-
• Gram positive
• Gram negative
• Also- gram variable
• Gram nonreactive
• Gram positive bacteria
• many layers of peptidoglycan and teichoic acids.
• form a crystal violet-iodine-teichoic acid
  complex
• Large complex, difficult to decolorize

39
Gram positive bacteria
40
Gram Stain Reaction

• Gram negative bacteria
• Very thin peptidoglycan
• No teichoic acids
• Alcohol readily removes the crystal violet.
• Alcohol also dissolves the lipopolysaccharide of
  the cell wall.
• Gram variable cells
• Some cells retain crystal violet some decolorize
  and take up the safranin
• 4 factors-
• Genetics- variable amount of teichoic acid.
• Age of culture- older cultures have variable
  amount of teichoic acid
• Growth medium- necessary nutrients not available
• Technique-
• smear not thin or evenly made.
• Staining procedure not done correctly-
  decolorizer left on too long.

41
Gram negative bacteria
42

43
Gram stain technique
44
(No Transcript)
45
Gram stain
46
Gram stain
47

• Gram nonreactive cells
• Have peptidoglycan but have very waxy- thick
  lipids waterproof, dyes cannot enter either.
• Examples- Mycobacterium tuberculosis and leprosy.

• Alternative staining- acid fast stain

48
Cell wall deficient forms

• L- forms ( Lister Institute where discovered)
• Bacteria loses cell wall during the life cycle
• Result of a mutation in cell wall forming genes
• Induced by treating with lysozyme or penicillin
  which disrupts the cell wall
• Protoplast-
• G bacterium with no c. wall, only a c.
  membrane
• Fragile, easily lysed
• Spheroplast-
• G bacterium loses peptidoglycan, but has outer
  membrane
• Less fragile but weakened.

49
Surface structures continued

• Outer membrane
• This lipid bilayer is found in Gram negative
  bacteria and is the source of lipopolysaccharide
  (LPS) in these bacteria
• LPS is toxic and turns on the immune system.
• Not found in Gram positive bacteria.

50
Lipopolysaccharide
51
C. Cell membrane

• Located just under cell wall
• Very thin
• Lipid bilayer, similar to the plasma membrane of
  other cells. Transport of ions, nutrients and
  waste across the membrane
• Typical
• 30-40 phospholipids
• 60-70 proteins
• Exceptions-
• Mycoplasma- sterols
• Archaea- unique branched hydrocarbons

52
(No Transcript)
53
(No Transcript)
54
Mesosome

• Extension of cell membrane
• Folding into cytoplasm internal pouch
• Increases surface area.
• Gram-positive bacteria-prominent
• Gram negative bacteria- smaller, harder to see.
• Functions-
• Cell wall synthesis
• Guides duplicated
  chromosomes into
  the daughter cells

  in cell division.

55
Functions of Cell Membrane

• Carries out functions normally carried out by
  eukaryote organelles.
• Site for energy functions
• Nutrient processing
• Synthesis
• Transport of nutrients and waste
• Selectively permeable
• Most enzymes of respiration and ATP synthesis
• Enzyme synthesis of structural macromolecules
• Cell envelope and appendages
• Secretion of toxins and enzymes into environment.

56
Prokaryote Structures

• Appendages- flagella, pili, fimbrae
• Cell envelope
• glycocalyx
• cell wall
• cell membrane
• Cytoplasm
• Nucleoid/chromosome
• Plasmid
• Ribosomes
• Granules

57
3. Cell cytoplasm

• Encased by cell membrane
• Dense, gelatinous
• Prominent site for biochemical and synthetic
  activities
• 70-80 water- solvent
• Mixture of nutrients- sugar, amino acids, salts
• Building blacks for cell synthesis and energy

58
A. Bacterial chromosome

• Singular circular strand of DNA
• Aggregated in a dense area- nucleiod
• Long molecule of DNA tightly coiled around
  protein molecules.

59
(No Transcript)
60
B. Plasmids

• Nonessential pieces of DNA
• Often confer protection- resistance to drugs
• Tiny, circular
• Free or integrated
• Duplicate and are passed on to offspring
• Used in genetic engineering

61
Types of plasmid

• Fertility-F-plasmids. They are capable of
  conjugation (transfer of genetic material between
  bacteria which are touching).
• Resistance-(R)plasmids, which contain genes that
  can build a resistance against antibiotics or
  poisons and help bacteria produce pili.
• Col-plasmids, which contain genes that determine
  the production of bacteriocins, proteins that can
  kill other bacteria.
• Degradative plasmids, which enable the digestion
  of unusual substances, e.g., toluene or salicylic
  acid.
• Virulence plasmids, which turn the bacterium into
  a pathogen (one that causes disease).

62
Cell division in Prokaryotes

• Prokaryotes use a relatively simple form of cell
  division - binary fission.
• The diagram at 1.shows a bacterial cell.
• The cell wall and membrane are in red,
• the bacterial chromosome in blue,
• the cytoplasm in light green,
• the yellow dot represents a point of attachment
  of the chromosome to the cell membrane.

63
C. Ribosomes

• Site of protein synthesis
• Thousands
• Occurs in chains polysomes
• 70S
• 2 smaller subunits
• 30S and 50S

64
(No Transcript)
65
D. Inclusions

• If nutrients abundant- stored intracellularly
• Granules
• Crystals of inorganic compounds not enclosed by
  membranes
• Polyphosphate- corynebacterium
• Sulfur granules- photosynthetic
• Metachromatic- Mycobacterium

66
Bacterial Internal Structures

• Endospores
• inert, resting, cells produced by some G genera
  Clostridium, Bacillus and Sporosarcina
• have a 2-phase life cycle
• vegetative cell metabolically active and
  growing
• endospore when exposed to adverse environmental
  conditions capable of high resistance and very
  long-term survival
• Features of spores- size, shape,
  locationidentification
• sporulation -formation of endospores
• hardiest of all life forms
• Forms inside a cell- functions in survival
• not a means of reproduction
• withstands extremes in heat, drying, freezing,
  radiation and chemicals
• germination- return to vegetative growth

67
(No Transcript)
68
Endospores

• Resistance linked to high levels of calcium and
  dipicolinic acid
• Dehydrated, metabolically inactive thick coat
• Longevity verges on immortality - 25,250 million
  years.
• Resistant to ordinary cleaning methods and
  boiling
• Pressurized steam at 120oC for 20-30 minutes will
  destroy

69
Bacterial Shapes, Arrangements, and Sizes

• Variety in shape, size, and arrangement but
  typically described by one of three basic shapes
• coccus - spherical
• bacillus rod
• coccobacillus very short and plump
• vibrio gently curved
• spirillum - helical, comma, twisted rod,
• spirochete spring-like

70
(No Transcript)
71
(No Transcript)
72
Thank you!
