Intertidal Communities

1
Chapter 13

• Intertidal Communities

2
Key Concepts

• The intertidal zone is the coastal area
  alternately exposed and submerged by tides.
• Organisms that inhabit intertidal zones must be
  able to tolerate radical changes in temperature,
  salinity, and moisture and also be able to
  withstand wave shock.

3
Key Concepts

• Organisms on rocky shores tend to be found in
  definite bands, or zones, on the rocks.
• In contrast to sandy shores, rocky shores provide
  a relatively stable surface for attachment.
• Tide pool organisms must be able to adjust to
  abrupt changes in temperature, salinity, pH, and
  oxygen levels.

4
Key Concepts

• Biotic factors are most important in determining
  the distribution of organisms on rocky shores,
  but physical factors are most important on sandy
  shores.

5
Characteristics of the Intertidal Zone

• Daily fluctuations of the environment
• organisms must tolerate radical changes in
  temperature, salinity and moisture, and endure
  the crushing force of waves
• Inhabitants are most active during high tide,
  when area is submerged
• water provides food for filter feeders
• As the tide retreats, organisms adjust to
  exposure to air and sunlight

6
(No Transcript)
7
Rocky Shores

• Composed of hard materials
• Found from California to Alaska on the west coast
  and from Cape Cod northward on the east coast of
  North America
• Coasts may be recently uplifted, formed from lava
  flows, or highly eroded by wind and waves

8
Rocky Shore Zonation

• Zonationseparation of organisms into prominent
  horizontal bands defined by color or distribution
  of organisms
• Rocks provide a stable surface for attachment of
  organisms
• As tide retreats...
• upper regions exposed to air, changing
  temperatures, solar radiation, dissication
• lower regions exposed only a short time before
  tide returns to cover them

9
(No Transcript)
10
Rocky Shore Zonation

• Zone system for rocky shore proposed by Alan and
  Anne Stephenson
• supralittoral (maritime) zonearea above high
  water that may extend several miles inland
• supralittoral fringe (splash zone)uppermost area
  covered only by the highest (spring) tide,
  usually just dampened by spray of crashing waves

11
Rocky Shore Zonation

• Zone system (continued)
• midlittoral zonethe true intertidal zone
  extensive part that is regularly exposed during
  low tides and covered during high tides
• infralittoral fringearea extending from the
  lowest of low tides to the upper limits reached
  by large kelps (laminarians)
• subtidal (infralittoral) zonethe region of shore
  covered by water, even during low tide

12
(No Transcript)
13
(No Transcript)
14
Rocky Shore Zonation

• Supralittoral fringe of rocky shores
• receives very little moisture
• exposed to drying heat of the sun in summer and
  extreme cold in winter
• few organisms inhabit this harsh area
• gray and orange lichens composed of fungi and
  algae are common
• sea hair a filamentous alga
• most common animal periwinkles, molluscs of
  Littorina and associated genera

15
Rocky Shore Zonation

• Supralittoral fringe (continued)
• other inhabitants include limpets and isopods
• some periwinkles and isopods breathe air
• Midlittoral zone of rocky shores
• inhabitants must avoid desiccation, maintain gas
  exchange, and deal with temperature extremes as
  the tide moves in and out
• wave shockforce of the waves as they crash
  against the rocks during low tide

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Rocky Shore Zonation

• Midlittoral zone (continued)
• upper midlittoral zone
• typical organisms acorn barnacles and rock
  barnacles
• barnacles permanently attach to surfaces
• barnacles open their shells to filter feed during
  high tide, and close them to trap water inside
  during low tide
• barnacles cool themselves by opening the shell
  slightly and allowing a little water to evaporate

22
Rocky Shore Zonation

• Midlittoral zone (continued)
• middle and low midlittoral zone
• oysters, mussels, limpets, and periwinkles
  dominate
• oysters and mussels survive low tides by trapping
  water in their shells
• limpets and chitons graze algae at high tide
• common periwinkles bury themselves in seaweed to
  retain moisture during low tide
• rock urchins survive wave shock by hollowing out
  a space in the rock and wedging into it

23
Rocky Shore Zonation

• Midlittoral zone (continued)
• seaweeds of the midlittoral zone
• rockweeds (brown algae) grow on rocks without
  full exposure to the sea
• rockweeds compete with barnacles for space by
  sweeping the rocky surface with their blades,
  preventing cyprid larvae of barnacles from
  settling
• some rockweeds are toxic to deter grazing
• rockweeds produce a gelatinous covering that
  retards water loss and prevents desiccation
• they form large mats that trap water and provide
  a haven for animals during low tide

24
Rocky Shore Zonation

• Midlittoral zone (continued)
• tide poolsdepressions in the rocks which retain
  water during low tide
• water loses oxygen as it heats in the sun
• salinity may change owing to rainfall or
  evaporation of water by the sun
• oxygen in tide pools containing algae may change
  drastically high during the day when algae are
  active, low ( low pH) at night
• salinity, temperature, pH abruptly returned to
  ocean conditions when tide reaches the pool

25
(No Transcript)
26
Rocky Shore Zonation

• Midlittoral zone (continued)
• tide pool organisms
• e.g. algae, sea stars, anemones, tube worms,
  hermit crabs, molluscs
• many are filter feeders
• biotic interactions help structure tide pool
  communities
• e.g., in New England, Irish moss lives in tide
  pools where common periwinkles eat the green alga
  Enteromorpha, which normally outcompetes Irish
  moss

27
(No Transcript)
28
Rocky Shore Zonation

• Infralittoral fringe of rocky shores
• transitional area submerged except at spring
  tides
• rich flora and fauna of organisms that can
  tolerate limited air exposure
• rocks may be covered with seaweeds
• in cooler waters, molluscs, sea stars and brittle
  stars live among large kelps
• other animals include hydrozoans, anemones, sea
  urchins, spider crabs

29
(No Transcript)
30
Tropical Rocky Shores

• Less temperature variation and seasonal rainfall
• higher temperatures are more stressful
• less temperature variation and fewer storms are
  less stressful
• Zonation patterns on intertidal rocks
• supralittoral fringe and midlittoral fringe each
  have major subdivisions evident in tropical areas

31
Supralittoral Fringe

• White zonethe true border between the land and
  the sea
• hermit crabs, isopods, knobby periwinkles
• Gray zone
• knobby (and other) periwinkles
• nerites an exclusively tropical group that
  tends to replace limpets in higher intertidal
  zones
• farthest zone from low tide line where
  macroscopic marine algae grow

32
Supralittoral Fringe

• Black zone
• immersed only at the highest spring tides
• lacks knobby periwinkle
• several species of algae and cyanobacteria
  dominate
• smaller periwinkles, other nerites, fuzzy chitons

33
Midlittoral Fringe

• Yellow zone
• microscopic boring algae covering its surface
  give it a yellow or green color
• barnacles, limpets, fuzzy chitons, rock snails,
  irregular worm snails

34
(No Transcript)
35
Midlittoral Fringe

• Pink zone
• sometimes underlies the yellow zone
• characterized by widespread encrustation of
  coralline algae
• irregular worm snail, mats of anemones, keyhole
  limpets, gastropods

36
(No Transcript)
37
Infralittoral Fringe

• surf zone includes the edge of the lower rocky
  platform and parts of the reef
• rocks may be covered with algae such as Sargassum

• boring urchins, anemones, sponges, bryozoa, sea
  cucumbers, keyhole limpets

38
Subtidal Zone

• Relatively barren compared to subtidal zone in
  temperate climates
• Small, turf-forming red algae dominate
• lack of larger algae present in higher zones
  thought to be owing to herbivory
• in experiments, exclusion of herbivores permitted
  erect algae to establish themselves where they
  were not found previously

39
Comparison of Temperate and Tropical Rocky
Intertidal Systems

• Higher stress and predation in tropical
  environment
• Abundant mobile invertebrates, but fewer sessile
  ones in the tropics
• Large body size or residence in higher areas more
  important means of avoiding predators in
  temperate areas
• Macroalgae have less impact on community
  structure in the tropics

40
Intertidal Fishes

• Resident species
• typically have special adaptations for surviving
  harsh intertidal conditions
• small size absent, reduced or firmly attached
  scales compressed/elongate or depressed body
  shape absent or reduced swim bladder greater
  body density
• tolerant of temperature and salinity changes
• some intertidal fish can leave the water to feed
• Temporary inhabitants
• tidal, seasonal and accidental visitors

41
Ecology of the Rocky Shore

• East coast rocky shores
• barnacles dominate upper zones
• below the barnacles are mussels
• algae and consumers survive on protected shores
• West coast rocky shores
• barnacles compete with algae mussels displace
  barnacles by growing over them
• balance maintained by ochre sea stars, the
  keystone predator

42
Ecology of the Rocky Shore

• Rocky shores in the tropics
• total predation is strong, and control of
  competitively dominant species is spread over a
  number of consumers
• Top-down and bottom-up factors
• top-down factorsfactors whose effects flow down
  the food chain competition, herbivory and
  predation
• bottom-up factorsfactors that affect the basal
  level of food chains nutrient availability,
  recruitment

43
Sandy Shores

• Many temperate and tropical shorelines consist of
  sandy beaches
• Extend almost continuously from Cape Cod south to
  the Gulf Coast on the east coast of North America

44
Role of Waves and Sediments

• Sediment particle size influences the beachs
  nature, porosity of sediments, ability of animals
  to burrow
• Wave action influences sediment type
• heavy wave action coarse sediments
• little wave action fine sediments
• Beach slope results from interaction of waves,
  sediment particle size, and relationship of swash
  and backwash

45
Role of Waves and Sediments

• swashwater running up a beach after a wave
  breaks
• backwashwater flowing down the beach
• Types of beaches
• dissipative beachwave energy is strong but is
  dissipated in a surf zone some distance from the
  beach face
• usually flat with fine sediment
• reflective beachwave energy is directly
  dissipated on the beach
• usually steep with course sediment

46
Role of Waves and Sediments

• On all sandy beaches, a cushion of water
  separates the grains of sand below a certain
  depth
• especially true on beaches with fine sand where
  capillary action is greatest
• Fine sand beaches have a greater abundance of
  organisms
• greater water retention
• sediment is more suitable for burrowing

47
(No Transcript)
48
Comparison of Rocky and Sandy Shores

• Sandy shores lack readily apparent pattern of
  zonation
• wave action is most important factor in
  determining organism distribution
• temperature has less effect because of insulating
  properties of sand and water retention
• oxygen levels may be low beneath the sand owing
  to lack of water exchange

49
Sandy Shore Zonation

• Less defined pattern of longitudinal zonation
• Vertical zonation exists among organisms buried
  in the sand
• depends on amount of water trapped at each level
• 3 major zones
• supralittoral
• midlittoral
• subtidal (infralittoral)

50
(No Transcript)
51
Life above the High Tide Line

• Supralittoral fringe stretches from the high tide
  line to the point where terrestrial vegetation
  begins
• sand dunes may border uppermost extent
• Below is zone of drying sand, where moisture
  reaches only during the highest tides and
  gradually evaporates
• inhabited mostly by infaunaorganisms that burrow
  in the sand to survive dry periods and intense
  heat from the sun

52
(No Transcript)
53
Life above the High Tide Line

• Temperate inhabitants insects, isopods, amphipod
  crustaceans
• Ghost crabs and fiddler crabs replace amphipods
  in the tropics
• Ghost crabs have gills, but only make short
  forays into water to wet them
• Ghost crabs live in burrows, and are nocturnal
  scavengers

54
(No Transcript)
55
Life in the Sandy Shore Midlittoral Zone

• Vertical zonation
• less extensive zones of dry and drying sand than
  supralittoral zone
• zone of retentionretains moisture at low tide
  because of capillary action of water
• inhabited by isopod crustaceans worldwide
• zone of resurgencewater is retained at low tide
• supports crustaceans, polychaete worms
• zone of saturationconstantly moist supports
  greatest diversity of organisms

56
(No Transcript)
57
Life in the Sandy Shore Midlittoral Zone

• Animals of the midlittoral zone
• echinoderms (e.g. sand dollars, sea stars)
• snails (e.g. moon snails, olive snails)
• moon snails feed on bivalves by drilling a hole
  in the shell and inserting their proboscis
• lugworms
• deposit feeders that leave coiled, cone-shaped
  casts during low tide

58
(No Transcript)
59
(No Transcript)
60
Life in the Sandy Shore Midlittoral Zone

• Relationship between tides and the activity of
  midlittoral organisms
• during high tide, bivalves project their siphons
  to filter feed and bathe their gills
• carnivorous snails hunt bivalves
• echinoderms emerge in search of food
• mole crabs and coquinas move up and down the
  beach with the tide, filter feeding
• predators come in with the tide as well

61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
Life below the Low Tide Line

• Subtidal zone is truly marine, exposed only
  during lowest spring tides
• Variety/distribution of organisms primarily
  influenced by sediment characteristics
• Seagrass beds occur in the subtidal zones of some
  coasts
• Many species of fish live here
• Pace of life is constant relative to that on the
  beach

66
Meiofauna

• Meiofauna
• microscopic organisms that inhabit the spaces
  between the sediment particles of intertidal and
  subtidal zones
• pass though a 0.5-mm screen but are retained by a
  62-mm screen

67
(No Transcript)
68
Meiofauna

• Factors affecting the distribution of meiofauna
• grain size
• coarse-grain sediments have greater interstitial
  volume that allows larger organisms to move
  between the particles
• fine-grain sediments have less space and exhibit
  more burrowing forms
• water circulation
• fine sediments can inhibit water flow and produce
  anoxic conditions

69
Meiofauna

• Factors affecting distribution (cont.)
• oxygen availability
• also lower at greater depths
• temperature
• upper layers are more variable
• salinity
• wave action
• can suspend sediments along with organisms,
  making them more vulnerable to predation

70
Meiofauna

• Characteristics of the meiofauna
• invertebrates from many phyla
• generally elongated with few lateral projections
• many are armored to protect them from being
  crushed by moving sand grains
• include predators, herbivores, suspension feeders
  and detrivores
• most exhibit brood protection because they
  produce a small number of offspring

71
Meiofauna

• Factors affecting the size of meiofaunal
  populations
• seasons (peak during summer months)
• protection from wave action greater abundance
• predation can have severe effects in the upper
  layers of sediments

72
Ecology of the Sandy Shore

• Fauna is less abundant than in rocky shores, and
  does not occupy all available space
• Competition is not a major factor in determining
  distribution
• Predation is less important fewer predators
  among invertebrates there
• Predation and disturbance important on sand flats
• Greater exposure less influence of competition
  and predation, more influence of abiotic
  (physical) factors
