Visualization and Data Mining techniques

1
Visualization and Data Mining techniques

• By-
• Group number- 14
• Chidroop Madhavarapu(105644921)
• Deepanshu Sandhuria(105595184)
• Data Mining CSE 634
• Prof. Anita Wasilewska

2
References

• http//coblitz.codeen.org3125/citeseer.ist.psu.ed
  u/cache/papers/cs/10335/ftpzSzzSzftp.cs.umn.eduzS
  zdeptzSzuserszSzkumarzSzdatavis.pdf/ganesh96visual
  .pdf
• http//www.ailab.si/blaz/predavanja/ozp/gradivo/20
  02-Keim-Visualization20in20DM-IEEE20Trans20Vis
  .pdf
• http//www.geocities.com/anand_palm/
• http//citeseer.ist.psu.edu/cache/papers/cs/27216/
  httpzSzzSzwww-users.cs.umn.eduzSzzCz7EctluzSzPape
  rTalkFilezSzits02.pdf/shekhar02cubeview.pdf
• http//www.cs.umn.edu/Research/shashi-group/
• http//www.cs.umn.edu/Research/shashi-group/Book/s
  db-chap1.pdf
• http//www.cs.umn.edu/research/shashi-group/alan_p
  lanb.pdf
• http//coblitz.codeen.org3125/citeseer.ist.psu.ed
  u/cache/papers/cs/27637/httpzSzzSzwww-users.cs.um
  n.eduzSzzCz7EpushengzSzpubzSzkdd2001zSzkdd.pdf/she
  khar01detecting.pdf

3
Motivation

• Visualization for Data Mining
• Huge amounts of information
• Limited display capacity of output devices
• Visual Data Mining (VDM) is a new approach for
• exploring very large data sets, combining
  traditional
• mining methods and information visualization
  techniques.

4
Why Visual Data Mining
5
Why Visual Data Mining
6
VDM Approach

• VDM takes advantage of both,
• The power of automatic calculations, and
• The capabilities of human processing.
• Human perception offers phenomenal abilities to
  extract structures from pictures.

7
Levels of VDM

• No or very limited integration
• Corresponds to the application of either
  traditional information
• visualization or automated data mining
  methods.
• Loose integration
• Visualization and automated mining methods are
  applied sequentially.
• The result of one step can be used as input for
  another step.
• Full integration
• Automated mining and visualization methods
  applied in parallel.
• Combination of the results.

8
Methods of Data Visualization

• Different methods are available for visualization
  of data
• based on type of data
• Data can be
• Univariate
• Bivariate
• Multivariate

9
Univariate data

• Measurement of single quantitative variable
• Characterize distribution
• Represented using following methods
• Histogram
• Pie Chart

10
Histogram
11
Pie Chart
12
Bivariate Data

• Constitutes of paired samples of two quantitative
  variables
• Variables are related
• Represented using following methods
• Scatter plots
• Line graphs

13
Scatter plots
14
Line graphs
15
Multivariate Data

• Multi dimensional representation of multivariate
  data
• Represented using following methods
• Icon based methods
• Pixel based methods
• Dynamic parallel coordinate system

16
Icon based Methods
17
Pixel Based Methods

• Approach
• Each attribute value is represented by one
  colored pixel (the value ranges of the attributes
  are mapped to a fixed color map).
• The values of each attribute are presented in
  separate sub windows.
• Examples
• Dense Pixel Displays

18
Dense Pixel Display

• Approach
• Each attribute value is represented by one
  colored pixel (the value ranges of the attributes
  are mapped to a fixed color map).
• Different attributes are presented in separate
  sub windows.

19
Visual Data Mining Framework and Algorithm
Development

• Ganesh, M., Han, E.H., Kumar, V., Shekar, S.,
• Srivastava, J. (1996).
• Working Paper. Twin Cities, MN University of
  Minnesota,
• Twin Cities Campus.

20
References

• http//coblitz.codeen.org3125/citeseer.ist.psu.ed
  u/cache/papers/cs/10335/ftpzSzzSzftp.cs.umn.eduzS
  zdeptzSzuserszSzkumarzSzdatavis.pdf/ganesh96visual
  .pdf
• http//www.ailab.si/blaz/predavanja/ozp/gradivo/20
  02-Keim-Visualization20in20DM-IEEE20Trans20Vis
  .pdf
• http//www.geocities.com/anand_palm/

21
Abstract

• VDM refers to refers to the use of visualization
  techniques in Data Mining process to
• Evaluate
• Monitor
• Guide
• This paper provides a framework for VDM via the
  loose coupling of databases and visualization
  systems.
• The paper applies VDM towards designing new
  algorithms that can learn decision trees by
  manually refining some of the decisions made by
  well known algorithms such as C4.5.

22
Components of VQLBCI

• The three major components of VQLBCI are Visual
  Representations, Computations and Events.

23
Visual Development of Algorithms

• Most interesting use of visual data mining is the
  development of new insights and algorithms.
• The figure below shows the ER diagram for
  learning classification decision trees.
• This model allows the user to monitor the quality
  and impact of decisions made by the learning
  procedure.
• Learning procedure can be refined interactively
  via a visual interface.

24
ER diagram for the search space of decision tree
learning algorithm
25
General Framework

• Learning a classification decision tree from a
  training data set can be regarded as a process of
  searching for the best decision tree that meets
  user-provided goal constraints.
• The problem space of this search process consists
  of Model Candidates, Model Candidate Generator
  and Model Constraints.
• Many existing classification-learning algorithms
  like C4.5 and CDP fit nicely within this search
  framework. New learning algorithms that fit
  users requirements can be developed by defining
  the components of the problem space.

26
General Framework

• Model Candidate corresponds to the partial
  classification decision tree. Each node of the
  decision tree is a Model Atom
• Search process is the process of finding a final
  model candidate such that it meets user goal
  specifications.
• Model Candidate Generator transforms the current
  model candidate into a new model candidate by
  selecting one model atom to expand from the
  expandable leaf model atoms.
• Model Constraints (used by Model Candidate
  Generator) provide controls and boundaries to the
  search space.

27
Search Process
28
Acceptability Constraint

• Model Constraints consist of Acceptability
  constraints, Expandability constraints and a
  Data-Entropy calculation function.
• Acceptability constraint predicate specifies when
  a model candidate is acceptable and thus allows
  search process to stop. EX
• A1) Total no of expandable leaf model atoms 0.
• A2) Overall error rate of the model candidate lt
  acceptable error rate.
• A3) Total number of model atoms in the model
  candidategt maximal allowable tree size.
• A1 is used in C4.5 and CDP

29
Expandability Constraint

• An Expandability constraint predicate specifies
  whether a leaf model atom is expandable or not.
  EX
• C4.5 uses E1 and E2
• CDP uses E2 and E3

30
Traversal Strategy

• Traversal strategy ranks expandable leaf model
  atoms based on the model atom attributes. EX
• Increasing order of depth
• Decreasing order of depth
• Orders based on other model atom attributes.

31
Steps in Visual Algorithm Development

• No single algorithm is the best all the time,
  performance is highly data dependent.
• By changing different predicates of model
  constraints, users can construct new
  classification-learning algorithm.
• This enables users to find an algorithm that
  works the best on a given data set.
• Two algorithms are developed BF based on Best
  First search idea and CDP which is a
  modification of CDP

32
BF

• This algorithm is based on the Best-First search
  idea.
• For Acceptability criteria, it includes A1 and A2
  with a user specified acceptable error rate.
• The Traversal strategy chosen is T3
• In Best-First, expandable leaf model atoms are
  ranked according to the decreasing order of the
  number of misclassified training cases. (local
  error rate size of subset training data set)
• The traversal strategy will expand a model atom
  that has the most misclassified training cases,
  thus reducing the overall error rate the most.

33
CDP

• CDP is a modification of CDP
• CDP has dynamic pruning using expandability
  constraint E3.
• Here, the depth is modified according to the size
  of the training data set of the model atom.
• We set
• B is the branching factor of the decision tree, t
  is the size of training data set belonging to
  model atom, T is the whole training data set.

34
Comparison of different classification learning
algorithms
35
Experiment

• The new BF and CDP algorithms are compared with
  the C4.5 and CDP algorithms.
• Various metrics are selected to compare the
  efficiency, accuracy and size of final decision
  trees of the classification algorithm.
• The generation efficiency of the nodes is
  measured in terms of the total number of nodes
  generated.
• To compare accuracy of the various algorithms,
  the mean classification error on the test data
  sets have been computed.

36
Classification error for 10 data sets
37
Nodes generated for 10 data sets
38
Final decision tree size
39
Results/Conclusion

• CDP has accuracy comparable to C4.5 while
  generating considerably fewer nodes.
• CDP has accuracy comparable to C4.5 while
  generating considerably fewer nodes.
• CDP outperformed CDP in error rate and number of
  nodes generated.
• Considering all performance metrics together,
  CDP is the best overall algorithm.
• Considering classification accuracy alone, C4.5P
  is the winner.

40
Conclusion

• Different datasets require different algorithms
  for best results.
• Diverse user requirements put different
  constraints on the final decision tree.
• The experiment shows that Interactive Visual Data
  Mining Framework can help find the most suitable
  algorithm for a given data set and group of user
  requirements.

41
Data Mining for Selective Visualization of Large
Spatial Datasets

• Proceedings of 14th IEEE International Conference
  on Tools with Artificial Intelligence
• (ICTAI'02),  2002.
• Washington (November 2002), DC, USA,
• Shashi Shekhar, Chang-Tien Lu, Pusheng Zhang,
  Rulin Liu
• Computer Science Engineering Department
• University of Minnesota

42
References

• http//citeseer.ist.psu.edu/cache/papers/cs/27216/
  httpzSzzSzwww-users.cs.umn.eduzSzzCz7EctluzSzPape
  rTalkFilezSzits02.pdf/shekhar02cubeview.pdf
• http//www.cs.umn.edu/Research/shashi-group/
• http//www.cs.umn.edu/Research/shashi-group/Book/s
  db-chap1.pdf
• http//www.cs.umn.edu/research/shashi-group/alan_p
  lanb.pdf
• http//coblitz.codeen.org3125/citeseer.ist.psu.ed
  u/cache/papers/cs/27637/httpzSzzSzwww-users.cs.um
  n.eduzSzzCz7EpushengzSzpubzSzkdd2001zSzkdd.pdf/she
  khar01detecting.pdf

43
Basic Terminology

• Spatial databases
• Alphanumeric data geographical cordinates
• Spatial mining
• Mining of spatial databases
• Spatial datawarehouse
• Contains geographical data
• Spatial outliers
• Observations that appear to be inconsistent with
  the remainder of that set of data

44
Spatial Cluster
45
Contribution

• Propose and implement the CubeView visualization
  system
• General data cube operations
• Built on the concept of spatial data warehouse to
  support data mining and data visualization
• Efficient and scalable spatial outlier detection
  algorithms

46
Challenges in spatial data mining

• Classical data mining - numbers and categories.
• Spatial data
• more complex and
• extended objects such as points, lines and
  polygons.
• Second, classical data mining works with explicit
  inputs, whereas spatial predicates and attributes
  are often implicit.
• Third, classical data mining treats each input
  independently of other inputs.

47
Application Domain

• The Traffic Management Center - Minnesota
  Department of Transportation (MNDOT) has a
  database to archive sensor network.
• Sensor network includes
• about nine hundred stations
• each of which contains one to four loop detector
• Measurement of Volume and occupancy.
• Volume is vehicles passing through station in
  5-minute interval
• Occupancy is percentage of time station is
  occupied with vehicles

48
Basic Concepts

• Spatial Data Warehouse
• Spatial Data Mining
• Spatial Outliers Detection

49
Spatial Data Warehouse

• Employs data cube structure
• Outputs - albums of maps.
• Traffic data warehouse
• Measures - volume and occupancy
• Dimensions - time and space.

50
Spatial Data Mining

• Process of discovering interesting and useful but
  implicit spatial patterns.
• key goal is to partially automate knowledge
  discovery
• Search for nuggets of information embedded in
  very large quantities of spatial data.

51
Spatial Outliers Detection

• Suspiciously deviating observations
• Local instability
• Each Station
• Spatial attributes time, space
• Non spatial attributes volume, occupancy

52
Basic Structure CubeView
53
CubeView Visualization System

• Each node in cube a visualization style
• S - Traffic volume of station at all times.
• TTD Time of the day
• TDW Day of the week
• STTD Daily traffic volume of each station
• TTD TDWS Traffic volume at each station at
  different times on different days

54
Dimension Lattice
55
CubeView Visualization System
56
CubeView Visualization System
57
CubeView Visualization System
58
Data Mining Algorithms for Visualization

• Problem Definition
• Given a spatial graph G S , E
• S - s1, s2, s3, s4..
• E edges (neighborhood of stations)
• f ( x ) - attribute value for a data record
• N ( x )- fixed cardinality set of neighbors of x
• ) - Average attribute value of x
  neighbors
• S( x ) - difference of the attribute value of
  each data object and the average attribute value
  of neighbors.

59
Data Mining Algorithms for Visualization

• Problem Definition cont
• S( x ) - difference of the attribute value of
  each data object and the average attribute value
  of neighbors.
• Test for detecting an outlier
• confidence level threshold ?

60
Data Mining Algorithms for Visualization

• Few points
• First, the neighborhood can be selected based on
  a fixed cardinality or a fixed graph distance or
  a fixed Euclidean distance.
• Second, the choice of neighborhood aggregate
  function can be mean, variance, or
  auto-correlation.
• Third, the choice for comparing a location with
  its neighbors can be either just a number or a
  vector of attribute values.
• Finally, the statistic for the base distribution
  can be selected as normal distribution.

61
Data Mining Algorithms for Visualization

• Algorithms
• Test Parameters Computation(TPC) Algorithm
• Route Outlier Detection(ROD) Algorithm

62
Data Mining Algorithms for Visualization
63
Data Mining Algorithms for Visualization
64
Data Mining Algorithms for Visualization
65
Software

• http//www.cs.umn.edu/research/shashi-group/vis/tr
  affic_volumemap2.htm
• http//www.cs.umn.edu/research/shashi-group/vis/Da
  taCube.htm

66
Visualization and Data Mining techniques

• Thank you!!!!
