Classical Control in Quantum Programs

1
Classical Control inQuantum Programs

• Dominique Unruh
• IAKS, Universität Karlsruhe

Founded by the European Project ProSecCo
IST-2001-39227
2
Design Goals

• Quantum programming language
• We present a method of modelling a quantum
  programming language in a way that should allow
  to write quantum programs in a formal way,
  without loosing the similarity to pseudo-code
  which is essential for an intuitive approach to
  algorithms.
• Terminating and non-terminating
• Our modelling shall support the design of
  terminating as well of non-terminating programs
  within the same mathematical framework.
• Mixed classical and quantum operations
• We want to be able to represent both pure quantum
  (unitary) as well as classical operations
  (measurements, erasure) using the same framework.
  That is, we do not impose a strict separation
  between a classical controlling computer and the
  controlled quantum registers.
• Output during the programs run
• We show how to model programs which give
  classical (i.e. measured) output during the
  programs run. This is especially useful, if the
  programs in consideration do not terminate but
  give a continuous stream of results, since the
  usual run-and-then-measure-after-termination
  approach is not sensible in that case.
• Physical interpretation
• A programs behaviour can be modelled as a
  measurement process (with defined resulting state
  in case of termination). In order to avoid
  artificial constructions we adhere to these
  operational semantics and show how to transform
  any program into the mathematical description of
  a measurement process.

3
Operational Semantics

• A program is a physical experiment
• The process of running a program is very much
  comparable to performing a physical experiment
  At the beginning, the machine is in a given
  initial state. Then this state is modified by
  performing various operations. These may include
  measurements during the experiment (outputs of
  the program). The experiment possibly terminates
  (real life experiments always do, due to limited
  resources, programs not necessarily). If the
  program terminates, the machine afterwards is in
  a well-defined post-measurement state.
• A physical experiment is a measurement
• Any physical experiment can be seen as a
  measurement operation. We distinguish two kinds
  a measurement operation defining the
  post-measurement state (called general
  measurement or PMVM), and a measurement not
  defining the post-measurement state (a POVM). To
  describe measurements which may or may not have a
  post-measurement state, we need to use the convex
  combination of a general measurement and a PMVM.
  This combination we will call a mixed
  measurement.
• A program is a measurement
• Since we can consider a program as an experiment,
  and an experiment as a mixed measurement, it is
  natural to model a program as a mixed
  measurement. The outputs of the program are
  measurement results and are finite or infinite
  sequences over an alphabet S. This gives rise to
  operational semantics of programs, which are
  simply mathematical descriptions of measurements.
• Classical, measurement, unitary operations
• The mixed measurement formalism is strong enough
  to have as special cases classical
  (probabilistic) programs, orthogonal
  measurements, and unitary operations, thus
  capturing all kinds of operations in a single
  mathematical framework.

4
Composing programs

• Sequentially execute several programs
• If two programs P and Q are defined, the composed
  program PQ can be interpreted as first
  executing P (yielding some output), and thenif P
  terminatedexecuting Q on the post-execution
  state of P. The output of the composed program
  is then given by the concatenation of the
  respective inputs.

Examples Examples
PQ Run P then run Q
PQR Composition is associative, so these three are equal
PQR Composition is associative, so these three are equal
PQR Composition is associative, so these three are equal
print x print y Outputs xy
5
Print-Command

• Any outputs can be build up from constant outputs
• By defining an elementary program print x, one
  can build up any output by using switch (see
  below). E.g. switch (M as m) print m outputs the
  result of measurement M.
• Constant outputs are constant measurements
• The program print x outputting x is simply a
  measurement with constant outcome x and which
  does not modify the programs state.

Examples Examples
print a print b Equivalent programs outputting ab
print ab Equivalent programs outputting ab
switch (M as m) print m Outputs result of measuring M.
print M (shorthand) Outputs result of measuring M.
while (true) print x Outputs infinite sequence x8
6
Branching (if/switch)

• Branching as classical control
• In our modelling we consider branching which is
  conditional upon the outcomes of measurements.
  This is opposed to controlled unitary
  transformation (e.g. CNOT), where the controlling
  qubit is not measured. More complex quantum
  algorithms usually have such classical control,
  be it an overall loop repeating the experiment
  until a useful result is obtained (e.g. a
  non-trivial factor in Shors factoring
  algorithm).
• Branching programs are composed measurements
• A program if (M) P can be interpreted as the
  experiment measuring M and then executing the
  program P if M yielded the outcome true. This
  experiment can be expressed as a measurement in a
  straightforward manner if Mi denotes the
  superoperator describing the post-measurement
  state on outcome i, then if (M) P is simply
  defined as PMtrueMfalse. Analogously we define
  if (M) P else Q.
• More powerful the switch-statement
• An if-statement can only distinguish between two
  cases true and false. In many cases a more
  powerful statement, the switch statement. switch
  (M as m) P(m) measures M and then executes the
  program P(m) where m is the outcome of the
  measurement.

Examples Examples
if (M) P else Q Measure M, if true, run P otherwise Q
switch (M as m) print m2 Outputs the square of the result of measuring M.
print M2 (shorthand) Outputs the square of the result of measuring M.
switch (M as m) case m1 print one case mgt1 print many Measure M, output one or many, depending of the outcome
7
Loops

• Informal description simple
• The program while (M) P denotes the experiment
  of repeatedly measuring M and if the outcome is
  true then executing P. If the outcome is false,
  abort.
• Mathematical description turns out to be
  difficult
• Two approaches immediately come to mind for
  defining while. The first would be to define
  while as a least fixed point. However due to the
  possibility of outputs there is no natural
  lattice structure. The second would be to define
  while as the limit of if(M)Pif(M)P....
  However, there is no natural topology giving the
  desired results.
• Axiomatic approach
• Since a direct limit/fixed point approach fails,
  we define while (M) P by stating some properties
  the experiment above should fulfill. These axioms
  can informally be stated as follows
• The loop runs n times and terminates, iff M
  yields n times true and then false, and if P
  terminates n times.
• The loop runs n times and does not terminate, iff
  M yields n times true, and if P terminates n1
  times and does not terminate the n-th time.
• The loop runs an infinite number of times, iff
  always M yields true, and if P always terminates.
• The probability that one of these events occurs
  is 1.
• It can be shown that there is exactly one program
  (i.e. mixed measurement) exists fulfilling these
  axioms.

Examples Examples
while (M) P Run program P while measurement M yields true.
while (M) print N Measure M. If nonzero, measure N, output the outcome, and redo from start
8
Reasoning about programs

• Conditions are sets of states
• Modelling a pre-/postcondition as a set of states
  (density operators) gives as the ability to
  express even complex conditions like variable x
  contains an uniform random value or variables x
  and y are unentangled or variable x is in the
  computational basis.
• Pre-/postconditions
• If for any state ? in M, the program P takes ? to
  a state in N, we write M P N
• Conditional equivalence of programs
• If two programs P, Q behave identically upon a
  given set M of initial states, we say they are
  equivalent on M, written M P Q.
• Programs can be conditioned on outputs
• If P is a program possibly having output a, we
  can define Pa as the program P restricted to
  having output a. Note that Pa is not probability
  preserving.

Examples Examples
1 P 1 If the initial state is a random state, so is the post-execution state (e.g. P is a permutation of basis states)
x in computational basis Pnoop If variable x is in the computational basis, program P has no effect (e.g. P might be a dephasing of x)
tr ? 1 Pa tr ?½ Program P has probability ½ of outputting a
