Geo479/579: Geostatistics Ch13. Block Kriging

1
Geo479/579 Geostatistics Ch13. Block Kriging
2
Block Estimate

• Requirements
• An estimate of the average value of a variable
  within a prescribed local area
• One method is to discritize the local area into
  many points and then average the individual point
  estimates to get the average over the area
• This method is computationally expensive

3
Objective

• See how the number of computations can be
  significantly reduced by constructing and solving
  only one kriging system for each block estimate
• Block Kriging

4
Block Kriging

• Block Kriging is similar to the point kriging
• The mean value of a random function over a local
  area is simply the average (a linear combination)
  of all the point random variables contained in
  the local area
• Where VA is a random variable corresponding to
  the mean value over an area A, and Vj are random
  variables corresponding to point values within A

Equation 13.1
5
Point Kriging

• In point kriging, the covariance matrix D
  consists of random variables at the sample
  locations and the location of interest

(12.13)
(12.14)
6
Point Kriging

• In point kriging, these are point-to-point
  covariances. For block kriging, these are
  point-to-block covariances (the block of
  interest)

7
Block Kriging

• Point-to-block covariances required for Block
  Kriging

8
Block Kriging

• The covariance between the random variable at the
  ith sample location and the random variable VA
  representing the average value over the area A is
  the same as the average of the point-to-point
  covariances between Vi and the random variables
  at all the points within A

9
Block Kriging

• The Block Kriging System
• The average covariance between a particular
  sample location and all of the points within A

Equation 13.3
Equation 13.4
10
Block Kriging

• The Block Kriging Variance
• The value C is the average covariance between
  pairs of locations within A

Equation 13.5
Equation 13.6
11
Ordinary Kriging Variance

• Calculate the minimized error variance by using
  the resulting to plug into equation (12.8)

12
Block Estimates vs. the Averaging of Point
Estimates

• The average of the four point estimates is the
  same as the direct block estimate
• The average of the point kriging weights for a
  sample is the same as the block kriging weight
  for the sample

Figure 13.1
13
Varying the Grid of Point Locations within a Block

• When using the Block Kriging approach - How to
  discretize the local area for block being
  estimated?
• The grid of discretizing points should be always
  regular
• The spacing between points may be larger in one
  direction than the other if the spatial
  continuity is anisotropic (Figure 13.2)

14
Discretizing Points

• The shaded block is approximated by six points
  located on a 2X3 grid. The closer spacing of the
  points in a north-south direction reflects a
  belief that there is less continuity in this
  direction than in the east-west direction.
  Despite the differences in the east-west and
  north-south spacing, the regularity of the grid
  ensures that each discretizing point accounts for
  the same area, as shown by the dashed line

Figure 13.2
15
Discretizing Points

• Discretizing points lt 16, Significant differences
  Discretizing points gt 16, Estimates are similar

• Sufficient discretizing points number
• 2D block 4x4 16, 3D block 4x4x4 64

Table 13.2
16
Block Kriging vs. Inverse Distance Squared Block
Estimates

• A plus symbol denotes a positive estimation error
  while a minus symbol denotes negative estimation
  error
• The relative magnitude of the error corresponds
  to the degree of shading indicated by the grey
  scale at the top of the figure

17
Block Kriging vs. Inverse Distance Squared Block
Estimates
Figures 13.3, 13.4
Figure 13.4
18
Case Study

• Comparison of summary statistics for Block
  Kriging and Inverse Distance Weighted
• Inverse Distance Weighted has larger errors
• For Inverse Distance Weighted, there are several
  large overestimation where relatively sparse
  sampling meets much denser sampling
• Inverse Distance Weighted did not correctly
  handle the clustered samples, giving too much
  weight to the additional samples in the
  high-valued areas
• Block Kriging showed some underestimation due to
  its smoothing effect and the positive skewness of
  the distribution of the true block values

19
Block Kriging vs. Point Kriging
Figures 13.3, 13.5
20
Block Kriging vs. Inverse Distance Squared Block
Estimates
Table 13.3 Estimates
Table 13.4 Errors
21
Block Kriging versus Point Kriging
Table 13.5 Errors
