Cardiovascular

1
Chapter 6

• Cardiovascular
• System Blood

2
Points to Ponder

• What type of tissue is blood and what are its
  components?
• What is found in plasma?
• Name the 3 formed elements in blood and their
  functions.
• How does the structure of red blood cells relate
  to their function?
• Describe the structure and function of each white
  blood cell.
• What are disorders of red blood cells, white
  blood cells and platelets?
• What do you need to know before donating blood?
• What are antigens, antibodies and blood
  transfusions?
• How are ABO blood types determined?
• What blood types are compatible for blood
  transfusions?
• What is the Rh factor and how is this important
  to pregnancy?
• How does the cardiovascular system interact with
  other systems to maintain homeostasis?

3
Functions of Blood
6.1 Blood An overview

• Transportation
• - Oxygen (from lungs), nutrients (from
  digestion), wastes (from tissue fluid), carbon
  dioxide (from tissue fluid) and hormones
  (influence cellular metabolism)
• Defense
• against invasion by pathogens
• Some cells phagocytize and destroy pathogens
• Others secrete antibodies into the blood
• Antibodies incapacitate pathogens so they can be
  destroyed
• Regulatory functions
• body temperature ? pick up heat from active
  muscle and transport around or out of the body
• water-salt balance and body pH (blood contains
  buffers)

4
Composition of Blood
6.1 Blood An overview

• Remember blood is a fluid connective tissue
• Formed elements Cells and cell fragments
• produced in red bone marrow via stem cell
  differentiation
• Cells and cell fragments
• Red blood cells/erythrocytes (RBC)
• White blood cells/leukocytes (WBC)
• Platelets
• Plasma liquid medium
• suspends the formed elements, carries substances,
  distributes the heat generated by metabolism and
  muscle contractions
• 91 water and 9 salts and organic molecules
• Salts act as buffer to help maintain the pH of
  the blood
• Organic molecules glucose and amino acids for
  the cells
• Plasma proteins are the most abundant molecules

5
3 major types of plasma proteins
6.1 Blood An overview

• Produced by the Liver
• Functions
• 1. Maintain homeostasis
• take up and release hydrogen ions
• 2. Establish osmotic pressure between blood and
  tissue fluid
• Force that prevents excessive loss of plasma from
  the capillaries into tissue fluid
• Albumins most abundant
• Function plasmas osmotic pressure and
  transportation
• Globulins
• Function transportation of hormones,
  cholesterol, and iron
• Fibrinogen
• Function formation of blood clots

6
Formed Elements
6.1 Blood An overview
7
Structure and Function of Red Blood Cells
6.2 Blood Red blood cells and transport of oxygen

• Lack a nucleus ? Biconcave shape increases
  surface area
• Lack most organelles ? including mitochondria
• ATP produced anaerobically so they dont consume
  any oxygen that they transport
• Contain about 280 million hemoglobin molecules
  that bind 4 molecules of O2 each
• Globin 4 tertiary polypeptides
• Heme iron-containing group ?Iron combines
  reversible with oxygen

8
How is carbon dioxide transported?
6.2 Blood Red blood cells and transport of oxygen

• 68 as bicarbonate ions in the plasma
• this conversion of CO2 takes place in RBCs by
  carbonic anhydrase
• H binds to amino acids of the globin to assist
  in keeping the pH of the blood constant
• At lungs carbonic anhydrase in RBCs reverse this
  reaction to expel CO2 from the blood
• 25 bound to hemoglobin in red blood cells
• 7 as carbon dioxide dissolved in the plasma

9
Production of red blood cells

• Produced in red bone marrow
• Lifespan 120 days
• Erythropoietin (EPO)
• Excreted by kidney cells
• Moves to red marrow when oxygen levels are low
• Stimulates the stem cells to produce more RBCs
• Old cells are destroyed by the liver and spleen
• Hemoglobin
• Globin broken down into amino acids and recycled
• Iron is recovered and reused
• Heme undergoes chemical degradation and is
  excreted

10
What is blood doping?
6.2 Blood Red blood cells and transport of oxygen

• Any method of increasing the number of RBCs to
  increase athletic performance
• It allows more efficient delivery of oxygen and
  reducing fatigue
• EPO is injected into a person months prior to an
  athletic event
• Is thought to be able to cause death due to
  thickening of blood that leads to a heart attack

11
What disorders involve RBCs?
6.2 Blood Red blood cells and transport of oxygen

• Anemia
• a condition resulting from too few RBCs or
  hemoglobin that causes a run-down feeling
• Maybe due to decrease levels of iron, vitamins
  B12 and B vitamin folic acid
• Sickle-cell anemia
• genetic disease that causes RBCs to be sickle
  shaped
• tend to rupture as they pass through the narrow
  capillaries
• Hemolytic disease of the newborn
• condition with incompatible blood types
• leads to rupturing of blood cells in a baby
  before and continuing after birth

12
White blood cells (leukocytes)
6.3 White blood cells and defense against disease

• Derived from red bone marrow
• Large blood cells that have a nucleus
• Production is regulated by colony-stimulating
  factor (CSF)
• Can be found in the blood and tissues
• Fight infection and part of immune system
• Phagocytosis
• engulf pathogen and fuses with lysosome where
  enzymes digest the pathogen to debris that leaves
  the cell
• Antibodies
• proteins that combine with antigens and mark them
  for destruction
• Some live days and others live months or years

13
Movement of WBCs out of circulation
6.3 White blood cells and defense against disease
14
How are white blood cells categorized?
6.3 White blood cells and defense against disease

• Granular contain noticeable granules, lobed
  nuclei
• Eosinophil
• Basophil
• Neutrophil
• Agranular no granules, nonlobed nuclei
• Lymphocyte
• Monocyte

15
Neutrophils
6.3 White blood cells and defense against disease

• About 50-70 of all WBCs
• Contain a multi-lobed nucleus
• Upon infection they move out of circulation into
  tissues to use phagocytosis to engulf pathogens
• Large numbers result in pus

16
Eosinophils
6.3 White blood cells and defense against disease

• Small percentage of WBCs
• Contain a bilobed nucleus
• Many large granules
• function in parasitic infections and play a role
  in allergies

17
Basophil
6.3 White blood cells and defense against disease

• Small percentage of WBCs
• Contain a U-shaped or lobed nucleus
• Release histamine related to allergic reactions
• Dilate blood vessels and constricts the air tubes
  that lead to lungs

18
Lymphocyte
6.3 White blood cells and defense against disease

• About 25-35 of all WBCs
• Large nucleus that takes up most of the cytoplasm
• Develop into B and T cells that are important in
  the immune system
• B-cells protect us by producing antibodies that
  mark pathogens for destruction
• T-cells directly destroy pathogens

19
Monocyte
6.3 White blood cells and defense against disease

• Relatively uncommon WBCs
• Largest WBC with horseshoe-shaped nucleus
• Take residence in tissues and develop into
  macrophages
• Macrophages use phagocytosis to engulf pathogens

20
How do blood cell leave circulation?
6.3 White blood cells and defense against disease
21
What disorders involve WBCs?
6.3 White blood cells and defense against disease

• Severe combined immunodeficiency disease (SCID)
• an inherited disease in which stem cells of WBCs
  lack an enzyme that allows them to fight any
  infection
• Leukemia
• a groups of cancers that affect white blood
  cells in which cells proliferate without control
• Infectious mononucleosis
• also known as the kissing disease occurs when
  the Epstein-Barr virus (EBV) infects lymphocytes
  resulting in fatigue, sore throat and swollen
  lymph nodes

22
Platelets (thrombocytes)
6.4 Platelets and blood clotting

• Made of fragments of large cells called
  megakaryocytes made in the red bone marrow
• About 200 billion are made per day
• Function in blood clotting
• Blood proteins thrombin and fibrinogen (produced
  in the liver) are important for blood clotting by
  leading to fibrin threads that catch RBCs
• Thrombin acts as an enzyme that severs two
  short amino acid chains from each fibrinogen
  molecule
• Activated fragments join end to end, forming long
  threads of fibrin
• Fibrin threads wind around the platelets plug and
  provide framework for the clot
• Plasmin enzyme destroy fibrin network and
  restores the fluidity of plasma after repair is
  complete

23
6.4 Platelets and blood clotting
24
What disorders involve platelets?
6.4 Platelets and blood clotting

• Thrombocytopenia
• a disorder in which the number of platelets is
  too low due to not enough being made in the bone
  marrow or the increased breakdown outside the
  marrow
• Thromboembolism
• when a clot forms and breaks off from its site of
  origin and plugs another vessel
• Hemophilia
• a genetic disorder that results in a deficiency
  of a clotting factor so that when a person
  damages a blood vessel they are unable to
  properly clot their blood both internally and
  externally

25
Health Focus What do you need to know about
donating blood?
6.4 Platelets and blood clotting

• Donating blood is a safe and sterile procedure
• You will donate about a pint of blood
• You will replace the plasma in a few hours and
  the cells in a few weeks
• A few people may feel dizzy afterwards so sit
  down, eat a snack and drink some water
• Your blood will at least be tested for syphilis,
  HIV antibodies and hepatitis and if any of them
  come back positive you will be notified
• Your blood can help save many lives
• You should not give blood if
• You have ever had hepatitis, malaria or been
  treated for syphilis or gonorrhea within 12
  months
• If you risk for having HIV or have AIDS

26
Terminology for ABO blood typing
6.5 Blood typing and transfusions

• Antigen - a foreign substance, often a
  polysaccharide or a protein, that stimulates an
  immune response
• Antibody proteins made in response to an
  antigen in the body and bind to that antigen
• Blood transfusion transfer of blood from one
  individual into another individual
• Involves determining the
• ABO blood group
• Rh- or Rh

27
The A, B, AB or O blood type
6.5 Blood typing and transfusions

• Presence and/or absence of 2 blood antigens, A
  and B
• Type of antibodies present
• Antibodies are only present for those antigen
  lacking on the cells because these proteins
  recognize and bind the protein they are named
  after

28
How can you remember what each blood type means?
6.5 Blood typing and transfusions

• Blood types are named after the protein antigens
  that are present on the surface of their cell,
  except type O that entirely lacks A and B
  proteins
• Blood types only have antibodies to antigens they
  do not have on the surface of their cells
• For example Type A blood
• Have A proteins on its surface
• Has B antibodies
• What can you say about someone with type AB
  blood?

29
6.5 Blood typing and transfusions
30
How can you determine if blood types are
compatible for a blood transfusion?
6.5 Blood typing and transfusions

• Consider the antigens found on the blood
  transfusion recipient
• 2. Consider the antibodies found in the donor
  blood
• If the antibodies in the donor blood can
  recognize the antigen on the recipients blood
  then the blood will agglutinate (clump) and cause
  rejection

31
(No Transcript)
32
Testing your understanding
6.5 Blood typing and transfusions

• Can a person with blood type O accept blood type
  A without agglutination occurring? Why or why
  not?
• Why can people with AB blood type accept more
  blood types than people with type O, A or B?
• Which blood type is able to be used most often as
  a donor blood type? Why?

33
What about Rh blood groups?
6.5 Blood typing and transfusions

• The Rh factor is often included when expressing a
  blood type by naming it positive or negative
• People with the Rh factor are positive and those
  without it are negative
• Rh antibodies only develop in a person when they
  are exposed to the Rh factor from anothers blood
  (usually a fetus)

34
When is the Rh factor important?
6.5 Blood typing and transfusions

• During pregnancy under these conditions
• Mom Rh-
• Dad Rh
• Fetus Rh (possible with the parents above)
• In this case above some Rh blood can leak from
  the fetus to the mother during birth causing the
  mother to make Rh antibodies
• This can be a problem if the mother has a second
  fetus that is Rh because she now has antibodies
  that can leak across the placenta and attack the
  fetus
• This condition is known as hemolytic disease of
  the newborn that can lead to retardation and even
  death

35
Visualizing how hemolytic disease of the newborn
happens?
6.5 Blood typing and transfusions
36
How can hemolytic disease of the newborn be
prevented?
6.5 Blood typing and transfusions

• Rh- women are given an injection of anti-Rh
  antibodies no later than 72 hours after birth to
  an Rh baby
• These antibodies attack fetal red blood cells in
  the mother before the mothers immune system can
  make antibodies
• This will have to be repeated if an Rh- mother
  has another Rh baby in case she has later
  pregnancies

37
Heart, blood vessels and blood work with other
systems to maintain homeostasis
38
(No Transcript)
