WP2 Review Meeting

1
MODERN ENIAC WP2 Meeting

• WP2 and Tasks review
• Milano Agrate, 2011 Oct. 05
• Meeting hosted by Micron
• 1300 1600 pm

2
Overview D233

• Identification of most relevant process
  variations in planar bulk CMOS devices down to
  32nm, parameter fluctuation effects based on
  hardware (STF2, IUNET, AMS)
• Evaluation of Vt, ? and Id matching performances
  of C032/028 RVT devices (STMicroelectronics)
• Main mechanisms affective threshold voltage
  variability investigated through sensitivity
  analysis (IUNET)
• Generation of Correlated Monte Carlo SPICE models
  (Austria Microsystems AG)
• Sources for PV in new device architectures,
  suitable for 22nm CMOS major deltas in
  comparison to standard planar bulk CMOS (NXP,
  LETI IMEP)
• Drain current variability and MOSFETs parameters
  correlations in planar FDSOI (LETI-CEA)
• FinFET mismatch in subthreshold region (IUNET
  NXP)

3
Evaluation of Vt, b and Id matching performances
of C032/028 RVT devices (STMicroelectronics)
Normalized Vt mismatch parameter for (a) NMOS
and (b) PMOS, using Vt_Gmmax method in linear
mode, Vt_cc in linear mode and Vt_cc in saturated
mode
AVt
2.8mV.µm for NMOS and 2.5mV.µm for PMOS
A?
0.6.µm for NMOS and 0.5.µm for PMOS
3
4
Main mechanisms affecting threshold voltage
variability investigated through TCAD sensitivity
analysis (IUNET)
Doping profiles of 32 nm RVT NMOS (a) and PMOS
(b) as obtained by STM after calibration with
electrical characteristics
RDD gt AVt1.5 to 1.8mV.µm LER gt
AVt0.75 to 0.9 mV.µm
4
5
Generation of Correlated Monte Carlo SPICE models
(AMS AG)
EXP
TCAD
HV NMOS Ron vs. VTHLIN results for TCAD (left)
and measurement (right)
SPICE
TCAD
Histograms for VTH HV NMOS, TCAD (blue, mean
413mV)vs. SPICE Monte Carlo (red, mean 412mV)
5
6
Drain current variability and MOSFETs parameters
correlations in planar FDSOI (LETI-CEA)
Benchmark of the on state ID mismatch in FDSOI vs
bulk data
s(?ID/ID) versus gate and drain voltages
On-resistance RON for various effective lengths
s(?ID/ID) comes from s ?VT and s?Ron plus
correlation (s?Ron related to Rsd)
6
7
FinFET mismatch in subthreshold region (IUNET)
LER for Lgt55nm
Correlation between ?Vth and ?S as a function of
the gate length. For L55 nm ?Vth and ?S are
uncorrelated, while for Llt55nm a negative
correlation is observed
A(?Vth) equal to 2.91mVmm and 2.58mVmm for
nFinFET and pFinFET
7
8
Main conclusions D233

• Vt, , b and Id matching performances of typical
  C32/28
• good matching performances, AVtlt 3mV.µm, and
  centered on 0.5.µm for b (STM).
• TCAD 32/28nm Vt variability simulations major
  contribution from RDD central part of channel and
  from LER (IUNET).
• A flow for implementing PV simulation results
  into statistical SPICE models has been presented
  (AMS). Gaussian distribution shows good agreement
  with the measurement statistics in terms of
  correlation. The extraction of covariance matrix
  and implementation into SPICE was shown.
• Variability of drain current (ID) in 6nm thin
  undoped Silicon-On-Insulator (SOI) MOSFETs
  studied (LETI IMEP). ID variations (sID) are
  found to be highly correlated with both threshold
  voltage (VT) and ON-state resistance (RON)
  fluctuations. Improving the access resistances
  (RSD) enables lowering the RON variability.
• Drain current mismatch of FinFET devices in
  subthreshold, has been studied from both modeling
  and experimental points of view (IUNET NXP).
  Critical length delimits two different mismatch
  behavior of a FinFET in subthreshold region
  (Lc55nm). For LltLc, both VT and SS fluctuations
  increase Id variability.

8
