The Relevant Standards Update

1
The Relevant Standards Update

• Louis T. Fiore
• Chair
• CSAA Standards Committee

2
What this will cover

• the status of codes and standards that impact the
  monitoring industry, including revisions to NFPA
  72 and the organizations commenting process
• advise on the impact of proposed revisions and
  standard developments, as well as suggest actions
  to protect your business

3
What are these standards

• NFPA 72
• NFPA 730/731
• NFPA 3/4
• UL 827 UL 1981
• UL 1610
• CS-V-01

4
NFPA Codes and Standards
5
(No Transcript)
6
CSAA Representatives to NFPA Committees

• Bob Bonifas, ADS (P) 72 FUN
• Tom Chambers, Vector (P) 72 ECS
• Jim Murphy, Vector (P) 72 TMS
• Rick Simpson, Vector (P) 72 HOU
• John Olenick, Vector (P) 72 PRO
• Robert Williams, Vector (A) 72 FUN
• Ted Stoler, Vector (A) 72 HOU
• Paul Silva, Wayne Alarm (P) 72 SSS
• Stan Martin, SIAC (P) 730/731
• Lou Fiore 72 Correlating Committee

7
Others

• Tony Mucci 72 SSS, 730/731
• Ed Bonifas 72 SSS
• Lou Fiore 72 SSS
• Rich Kleinman, AFA 72 SSS
• Shane Clary 72 FUN, 72 PRO
• Jim Murphy 730/731
• Pat Egan 72 SSS
• Mike Slattery, AFA 72 TMS
• Scott Harris, AFA 72 PRO

8
NFPA 72

• National Fire Alarm and Signaling Code
• Current Edition 2013
• Next Edition 2016

9
Various Chapters

• Mostly editorial changes to clarify language

10

• SIG-PRO (Protected Premises) proposal to
  eliminate ground fault detection on networked
  (CAT5/6) wiring. This would be a Class N Circuit.
• SIG-PRO voted to change the definition of fire
  protection zones within a premises. Non-fire
  additions would require a isolation module to be
  installed for each entry into a zone.

11
NFPA 72

• Chapter 29
• Household Fire

12
Interactive Servicessuggested revisions

• 29.7.6.8 Any data exchange between the fire alarm
  system and separate independent devices via
  remote access shall not compromise the integrity
  of the fire alarm system.
• 29.7.6.9 Remote resetting and silencing of a fire
  alarm control unit from other than the protected
  premises shall be inhibited for a minimum of 4
  minutes from the initial activation of the fire
  alarm signal.

13
On site power requirements

• Communicators
• 24 hour power minimum for all necessary equipment

• Report a signal indicating loss of power

14
Mesh Networks

• Mesh networks shall meet the same requirements of
  supervision as low power wireless
• Shared with other premise operating systems, but
• Shall be listed as a fire alarm devices
• Troubles within 200 seconds
• Zigbee Z-Wave

15
Smoke and CO Alarm Life

• 10 year life
• (replace if device fails operability test
  inside of 10 years)
• CO devices require a End of Life Signal

16
Smoke Detector SupervisionChapter 23 Protected
Premises Fire Alarm Systems

• 23.16.4 Monitoring for Integrity.
• 23.16.4.2 The occurrence of any single fault that
  disables
• transmission between any low-power radio
  transmitter and the receiver/fire alarm control
  unit shall cause a latching trouble signal within
  200 seconds.
• Exception Until the expiration date for this
  exception of
• June 30, 2013,
• the time period for a low-power radio
  transmitter
• 4 hours maximum for a transmitter serving a
  single initiating device
• 4 hours maximum for a retransmission device
  repeater

17
How we mitigate

• We have plans to submit a TIA to eliminate the
  exception's date which would then allow a 4 hour
  check-in.
• Tentative Interim Amendment

18
Household Testing

• 14.4.6.1 Testing. Household fire alarm systems
  shall be tested by a qualified service technician
  at least annually. The installing contractor
  shall be required to provide this information in
  writing to the customer upon completion of the
  system installation.
• To the extent that the fire alarm system is
  monitored offsite, the supervising station
  contractor shall provide notice of this
  requirement to the customer on a yearly basis.

19
Next-Gen 911

• Lack of data to develop satisfactory code
  guidelines for the 2016 cycle

20
Chapter 26

• (SSS) Supervising Station
• Six hour requirement for DACT testing still in
  the document
• Expanded language for Remote Station

21
AICC POTS SurveyAugust 2012 and 2013

22
NFPA 3

• Recommended Practice for the Commissioning of
  Fire Protection Systems.
• Move this cycle to make it a Standard.
• Fine for large buildings and projects, but is it
  necessary for small projects?
• Could raise construction costs.
• Look for a move to make NFPA 3 a Standard during
  the next cycle.

23
NFPA 4

• New Standard for the Integrated Testing of Fire
  Protection Systems.
• To be done when a building is first put on line
  and then at five-year cycles.
• This is for end-to-end testing, which no NFPA
  Standard requires at this time.
• Will require alarm providers to work closely with
  sprinkler and other fire protection providers.

24
NFPA 730 Guide to Premises Security

• NFPA 731 Standard for the Installation of
  Electronic Premises Security Systems

25
NFPA 730 Guide to Premises Security

• Will remain a Guide this cycle, but there will be
  continue efforts to convert to a Code during the
  next cycle.
• Several Task Forces have been formed to explore
  areas of the document that could be converted to
  code language (shall vs. should).

26
NFPA 731 Standard for the Installation of
Electronic Premises Security Systems

• No major changes made to this cycles edition.
• There is no known jurisdictions that have adopted
  731 to date.

27
UL Standards
28
UL 827 UL 1981

• UL 827
• Central-Station Alarm Services

• UL 1981
• Central-Station Automation Systems

29
UL 827 UL 1981

• Task Groups were convened to rewrite both
  standards
• Task Groups finished their work and drafts have
  been correlated.
• Drafts posted on ULs CSDS site for comments
  (Closed 7/8/13)
• Will soon be up for a vote by the STP
• Comments will be accepted by those registered for
  ULs CSDS
• Collaborative Standards Development System

30
UL 1610

• Central-Station Burglar-Alarm Units

31
Needed change

• Currently under 62A Packet Switched Data
  Networks
• A loss of connection/signal shall be reported
  and identified within 200 seconds at the central
  station receiving unit.
• Language is also in UL 365 Police Station
  Connected Burglar Alarm Units and Systems

32
CSAA Standards
33
CS-V-01

• Alarm Verification and Notification Procedures

34
Changes to CS-V-01

• Clean up and updates
• Public Comment Period open until November 25,
  2013
• Go to
• www.ltfiore.com/CS-V-01-2013.html
• to download the draft required form to submit a
  comment

35

• www.ltfiore.com/CS-V-01-2013.html

36
Questions?
37
Thank you!
