Title: Minimizing N-Detect Tests for Combinational Circuits Master


1
Minimizing N-Detect Tests for Combinational
CircuitsMasters DefenseKalyana R. Kantipudi
  • Thesis Advisor Dr. Vishwani D. Agrawal
  • Thesis Committee Dr. Charles E. Stroud and Dr.
    Victor P. Nelson
  • Dept. of ECE, Auburn University

2
Outline
  • Background
  • Problem Statement
  • Contributions
  • Theoretical Minimum for N-Detect Tests
  • ILP Based N-Detect Test Minimization
  • Relaxed LP based methods
  • The New Recursive Rounding Approach
  • Conclusions
  • Future work

3
Background
  • Defects are modeled as faults
  • Single stuck-at faults ease the test generation
    process
  • Bridging faults emulate the defects more
    accurately
  • Test sets with greater than 95 fault coverage
    can produce only 33 coverage of node-to-node
    bridging faults (Krishnaswamy et al. ITC01)
  • About 80 of all bridges occur between a node and
    Vcc or Vss

4
N-Detect Tests
  • Some applications need much lower DPM
  • New test strategy which can be easily assimilated
    into the normal test generation process
  • The problem with N-detect tests is their size
  • There is no accurate way to achieve a minimal
    N-detect set
  • There is no proven lower bound on the size of the
    N-detect vectors

5
Problem Statement
  • To find a lower bound on the size of N-detect
    tests
  • To find an exact method for minimizing a given
    N-detect test set
  • To derive a polynomial time heuristic algorithm
    for the N-detect test minimization problem

6
The Independence Graph
  • Independence graph Nodes are faults and edges
    represent pair-wise independence relationships
  • A clique is a fully connected sub-graph
  • Example c17

A. S. Doshi, Independence Fault Collapsing and
Concurrent Test Generation, Masters thesis,
Auburn University, May 2006.
7
Lower Bound on Single-Detection Tests
  • The Independent Fault Set (IFS) is a maximal
    clique in the graph
  • Theorem 1 The size of the IFS is a lower bound
    on the single detection test set size (Akers
    et al., ITC-87)

So, the lower bound for the single detection test
set of c17 is 4.
8
Theoretical Minimum of an N-Detect Test Set
  • Theorem 2 The lower bound on the size of the
    N-detect test set is N times the
    size of the largest clique in the
    independence graph (Original Contribution)

So, at least 4N vectors are needed to detect each
fault N times.
9
Minimized N-Detect Vectors for 74181 ALU
N Lower Bound (Theorem 2) Minimized from Exhaustive set
1 12 12
10 120 120
20 240 240
30 360 360
40 480 480
50 600 607
60 720 742
70 840 877
80 960 1012
90 1080 1147
96 1152 1228
10
ILP Based N-Detect Test Minimization
  • Use any N-detect test generation approach to
    obtain a set of k vectors which detect every
    fault at least N times.
  • Use diagnostic fault simulation to get the vector
    subset Tj for each fault j.
  • Assign integer variable ti to ith vector such
    that,
  • ti 1 if ith vector is included in the minimal
    set.
  • ti 0 if ith vector is not included.

11
Objective and Constraints of ILP
Nj is the multiplicity of detection for the
jth fault. Nj can be selected for individual
faults based on some criticality criteria or on
the capability of the initial vector set.
Theorem 3 When the minimization is performed
over an exhaustive set of vectors, an ILP
solution that satisfies the above expressions is
a minimum N-detect test.
12
Derivation of N-Detect Tests
  • Generate an unoptimized M-detect test set (M ? N)
    using an ATPG (e.g., ATALANTA).
  • Remove repeated vectors.
  • Perform diagnostic fault simulation of the
    remaining vectors using a fault simulator (e.g.,
    HOPE).
  • If Tj lt N for any fault, obtain additional
    vectors for that fault.
  • Generate ILP constraints and use an ILP solver to
    determine the values of the variables ti that
    minimize the number of vectors Sti .

13
Minimal 3-Detect Test Set for c17
Fault Numbers
  • ATALANTA is used to generate 4 test sets (M 4
    iterations) and the repeated vectors
    are removed.
  • HOPE is used to perform diagnostic fault
    simulation on the remaining vectors.
  • The simulation information is used to create
    constraints for the ILP

14
Constraint Generation
  • Fault 1 is detected by the vectors 1, 2, 15, 16,
    22, 24.
  • Fault 2 is detected by the vectors 1, 2, 3, 4, 5,
    6, 7, 8, 9, 15, 16, 22, 24, 28, 29..... so on
    .... Now the Objective is

and the constraints are
Constraint for fault 1 t1t2t15t16t22t24
3 Constraint for fault 21 t13t15t16t19t23t2
4 3
15
Minimum Test Sets from ILP
  • The minimum 3-detect test set size is 13 (lower
    bound 12).
  • Vectors are 2, 6, 7, 11, 14, 15, 16, 17, 18, 21,
    23, 24, 28.
  • Suppose fault 21 is a critical fault to be
    detected 5 times
  • Constraint for fault 21 t13t15t16t19t23t24
  • The minimum test set given by ILP has 14 vectors.
  • Vectors are 2, 6, 7, 11, 12, 13, 14, 15, 16, 17,
    18, 19, 23, 28.
  • For large circuits this change in test size can
    be quite small.

16
Results
Circuit Name No. of Un Opt. Vecs Single Detection Single Detection Single Detection 2-Detect 2-Detect 3-Detect 3-Detect 5-Detect 5-Detect
Circuit Name No. of Un Opt. Vecs ILP Time (sec.s) Lower bound Set Size Lower bound Set Size Lower Bound Set Size Lower Bound Set Size
c432 14882 82.3 27 27 54 55 81 83 135 140
c499 397 5.34 52 52 104 104 156 156 260 260
c880 3042 306.81 13 25 26 44 39 63 65 105
c1355 755 16.71 84 84 168 168 252 252 420 420
c1908 2088 97 106 106 212 212 318 318 530 530
c2670 8767 1568.62 44 71 88 145 132 224 220 391
c6288 243 519.67 6 18 12 27 18 37 30 57
c7552 2156 1530 65 148 130 298 195 468 325 841
Results on Ultra-5 Ultra-10
17
Results for 15-Detect Tests
Circuit ILP ILP Prev. Result 1 Prev. Result 1 Lower Bound 15 x 2
Circuit CPU s No. of vectors CPU s No. of vectors Lower Bound 15 x 2
c432 444.8 430 292.1 505 405
c499 24.9 780 153.2 793 780
c880 521.4 321 229.6 338 195
c1355 52.0 1260 5674.6 1274 1260
c1908 191.0 1590 1563.9 1648 1590
c2670 607.8 1248 9357.6 962 660
c3540 1223.7 1411 - - 1200
c5315 1368.4 924 - - 555
c6288 1206.3 134 1813.8 144 90
c7552 346.1 2370 - 975
c499, c1355, c1908 - Type I C880,c2670,c7552 -
Type II
Results on Ultra-5 Ultra-10 Sun Fire 280R
1 Lee, Cobb, Dworak, Grimaila and Mercer, Proc.
DATE, 2002 2 Hamzaoglu and Patel, IEEECAD,
2000.
18
Minimized Vectors for 15-Detect Tests
19
CPU Time for Minimizing 15-Detect Tests
20
Classifying Combinational Circuits
TYPE - I
TYPE II
Output cones have large overlap. Any vector
detecting a fault F2 will have high probability
of detecting other faults, say fault F3 or F1.
Non-overlapping output cones. Any vector
detecting a particular fault, will have very low
probability of detecting any other fault.
c499, c1355, c1908
c880, c2670, c7552
21
Ripple Carry Adders
Iterations Number of times test sets are taken
from Atalanta ATPG
22
Relaxed-LP Approach
  • Though ILP guarantees an optimal solution, it
    takes exponential time to generate the solution.
  • Time bounded ILP solutions deviate from
    optimality.
  • LP takes polynomial time (sometimes in linear
    time) to generate a solution.
  • Redefining the variables tis as real variables in
    the range 0.0,1.0 converts the ILP problem into
    a linear one.
  • The problem now remains to convert it into an ILP
    solution.
  • The optimal value of the relaxed-LP of the ILP
    minimization problem is a lower bound on the
    value of the optimal integer solution to the
    problem.

23
Previous Solutions (Randomized Rounding)
  • The real variables are treated as probabilities.
  • A random number xi uniformly distributed over the
    range 0.0,1.0 is generated for each variable
    ti.
  • If ti xi then ti is rounded to 1, otherwise
    rounded to 0.
  • If the rounded variables satisfy the constraints,
    then the rounded solution is accepted.
  • Otherwise, rounding is again performed starting
    from the original LP solution.

24
Limitations of Randomized Rounding
  • Consider three faults f1,f2 and f3, and three
    vectors.
  • We assign a real variable ti to vector i.
  • Now the single detection problem is specified as
  • Minimize t1 t2 t3
  • Subject to constraints,
  • f1 t1 t2 1
  • f2 t2 t3 1
  • f3 t3 t1 1
  • The number of tests is much larger
  • than the size of the minimal test set.
  • The randomized rounding becomes a random search.

25
Recursive Rounding (New Method)
  • Step 1 Obtain an LP solution.
  • Stop if each ti is either 0.0 or 1.0
  • Step 2 Round the largest ti and fix its value to
    1.0
  • If several tis have the largest value,
    arbitrarily set only one to 1.0. Go
    to Step 1.
  • Maximum number of LP runs is bounded by the final
    minimized test set size.
  • Final set is guaranteed to cover all faults.
  • This method takes polynomial time even in the
    worst case.
  • LP provides a lower bound on solution.
  • Lower Bound exact ILP solution recursive LP
    solution
  • Absolute optimality is not guaranteed.

26
The 3V3F Example
  • Step 1
  • LP gives t1 t2 t3 0.5
  • Step 2
  • We arbitrarily set t1 1.0
  • Step 1
  • Gives t2 1, t3 0
  • or t2 0, t3 1
  • or t2 t3 0.5
  • Step 2 (last case)
  • We arbitrarily set t2 1.0
  • Step 1 Gives t3 0

27
Minimal Tests for Array Multipliers
  • There exists a huge difference between its
    theoretical lower bound of six and its
    practically achieved test set of size 12.
  • A 15 x 16 matrix of full-adders (FA) and
    half-adders (HA).
  • To make use of its recursive
  • structure and apply
  • linear programming
  • techniques.

28
Tests for c6288 16-Bit Multiplier
  • Known results (Hamzaoglu and Patel, IEEE-TCAD,
    2000)
  • Theoretical lower bound 6 vectors
  • Smallest known set 12 vectors, 306 CPU s
  • Our results
  • Up to four-bit multipliers need six vectors
  • Five-bit multiplier requires seven vectors
  • c6288
  • 900 vectors constructed from optimized vector
    sets of smaller multipliers
  • ILP, 10 vectors in two days of CPU time
  • Recursive LP, lower bound 7, optimized set
    12, in 301 CPU s

29
Comparison of ILP and Recursive LP method
30
Sizes of 5-Detect Tests for ISCAS85 Circuits
31
Time Taken for 5-Detect Tests
32
Optimized 15-Detect Tests
Circuit Name Unopti. Vecs LP/recursive Rounding LP/recursive Rounding ILP ILP Previous Result 1 Previous Result 1 L.B.
Circuit Name Unopti. Vecs Vect. CPU s Vect. CPU s Vect. CPU s L.B.
c432 14882 430 83.5 430 444.8 505 292.1 405
c499 1850 780 17.8 780 24.9 793 153.2 780
c880 4976 322 94.5 321 521.4 338 229.6 195
c1355 2341 1260 41.2 1260 52.1 1274 5674.6 1260
c1908 6609 1590 150.4 1590 191 1648 1563.9 1590
c2670 8767 1248 380.6 1248 607.8 962 9357.6 660
c3540 4782 1407 239.6 1411 1223.7 - - 1200
c5315 4318 924 494.3 924 1368.4 - - 555
c6288 731 134 250.5 134 1206.3 144 1813.8 90
c7552 6995 2371 359.1 2370 346.1 - - 975
1 Lee, Cobb, Dworak, Grimaila and Mercer, Proc.
DATE, 2002
33
Conclusion
  • A Lower Bound for N-Detect tests is derived.
  • An N-Detect test minimization method based on ILP
    is formulated which always guarantees optimality.
  • A polynomial time consuming recursive rounding
    LP, which can give close to optimal solutions for
    single and N-detect tests is presented.
  • A smallest ever, 10 vector set derived for c6288
    signifies the shortcomings of present test
    minimization techniques.
  • The new recursive rounding LP method has numerous
    other applications where ILP is traditionally
    used and is found to be expensive.

34
Future Work
  • The dual problem of the test minimization problem
    looks promising.
  • The dual problem
  • The Duality Theorem If m is the minimum value
    of the primal problem and M is the maximum
    value of the dual problem, then m M.

35
The Previous c17 Example
  • The primal problem gave a solution of 4 vectors.
  • The dual problem also gave a solution of 4,
    selecting faults 1, 10, 16 and 18.
  • It is observed that these four faults are
    independent of each other.
  • So the dual problem yielded an IFS of the
    circuit.
  • In cases where relaxed-LP gives non-integer
    solutions for the dual problem, rounding
    techniques can be used.
  • This new approach has the potential of generating
    much tighter lower bound compared to the IFS.

36
Thank You . . .
Write a Comment
User Comments (0)
About PowerShow.com
