Maximize the

1
Maximize the Power of the Admin Client
Rob Axelrod
2
What We'll Cover ...

• Walking through the Admin client
• Great features you never noticed In Admin
• Working with little known but really useful
  console commands and techniques
• Finding additional administration tools

3

Walking Through the Admin Client
4
People and Groups Renaming a Non-Notes User

• The Problem
• AdminP can't be used to update the Readers and
  Authors fields because the user needs to accept
  the name change in their ID
• But, you can "trick" Domino into doing it!

5
People and Groups Renaming a Non-Notes User
(cont.)

• Here is the trick
• Create a group by the same name as the person
• Run the Action "Rename Group"
• Force Adminp to process the request -- Issue the
  command "Tell Adminp process all" twice
• Once to process the rename group request, and
  once to process the changes in the Authors and
  Readers fields

Tip
6
People and Groups Renaming a Non-Notes User
(cont.)

• Here is the trick (cont.)
• Manually rename the person in the Person Document
• Delete the group

7
People and Groups Speeding Up User Registration

• Use 'create file in background' to speed up
  registrations

8
People and Groups Speeding Up User Registration
(cont.)

• Take advantage of 'import from text file' to
  register large numbers of users
• Particularly good if you can get human resources
  to dump you a text file of new hires in a format
  that is close to the required format in
  Administrator
• Control separator with ini parameter
  BatchRegSeparator
• See Domino Administrator help for details

9
People and Groups Registering Non-Notes Users

• Quick way to register a non-Notes user.
• Uncheck both ID options
• Be sure to change the Mail System from Notes
  anything else
• This will allow you to create a person document
  and mailfile without generating a Notes ID

Secret
10
People and Groups Validate Internet Address

• Compares all Internet addresses and looks for
  duplicate addresses
• Will recurse through additional directories that
  are configured in Directory Assistance
• Dumps the output into your local Log.nsf database

11
People and Groups Managing Group Membership

• Use the Group Management tool to discover all
  group privileges that an individual has
  regardless of whether they actually appear in the
  group
• From the Groups view open Group Manager and
  select 'Only Member Hierarchies'
• This lets you select an individual and see all of
  the groups they belong to either directly or
  through nesting

Great Feature
12
People and Groups Managing Group Membership
(cont.)
13
Files Resorting Files without the Directory
Structure

• Awesome for finding files
• Quick way of comparing properties

Good Thing
14
Files Managing Files

• Create and delete subdirectories from the files
  tab
• View files other than .nsf and .ntf
• Pretty handy if you don't have easy OS level
  access to the box
• Launch any .nsf or .ntf right from the files tab
  by double clicking on it

15
Files Manage ACLs

• Use the ACL Manager in Administrator to add
  entries to multiple databases
• Use the right click in the files tab to copy and
  paste ACLs (This is my favorite feature)

Great
16
Server Monitoring Servers

• Configure which servers will be monitored by
  right clicking on the servers list
• Add or remove tasks as needed
• Add or remove statistics
• Select any statistics that are important to your
  environment

17
Server Monitoring Servers (cont.)
18
Server Broadcasting a Message

• When broadcasting a message, it shows up in the
  status bar
• No one looks at it!
• Broadcast a message with a popup
• From Server Status tab
• Choose the Broadcast Message task
• Just precede the message with a '(!)'

19
Server Viewing Statistics

• From the Statistics Tab
• Use F9 to refresh
• Gives the same results that you would get with a
  'Show Stats' but without the info scrolling off
  of the screen

20
Messaging Creating Messaging Reports

• You should see the reports database in the
  messaging tab
• If you don't, either you don't have ACL rights to
  it, or it doesn't exist
• Reports.nsf creates great detailed reports on
  messaging usage, but ...
• On a very active server they seem to bring the
  server down after time (assuming they are running
  on the server)
• Uses the MTC task, but this is another server
  killer

21
Messaging Tracing Mail Routing

• Mail Trace from messaging tab is nice since it
  doesn't drop an email into the user's mailfile so
  they don't need to know that you are testing mail

22
Bookmark Pane -- Favorites Getting Server
Information

• The Server Properties box is an awesome place to
  get quick stats on a server
• Right click on the server name from the Favorites
  pane and choose Properties

23
Bookmark Pane -- Favorites Getting Server
Information (cont.)
Use the server properties window to configure
ports on the server too!
24
Additional Administrative Tips Directory
Customizations Worth Making

• Adding Views to the Directory
• Modifying the Directory is a pain
• Every time you upgrade you need to worry about
  your design elements being stomped by the
  template
• A concern with adding views is that they will
  degrade server performance
• The following views are really worth having
• You can solve the above problems by creating them
  either as 'Private' or 'Desktop Private on First
  Use'

Issue
25
Additional Administrative Tips Directory
Customizations Worth Making (cont.)

• View of People by ID Expiration Date
• People view sorted by a column with the formula
  _at_Certificate( expiration Certificate)
• This gives you the expiration date of each users
  ID

26
Additional Administrative Tips Directory
Customizations Worth Making (cont.)

• View of Groups By Member
• Groups view sorted and categorized by the member
  field.

27
Additional Administrative Tips Directory
Customizations Worth Making (cont.)

• Accessible View of Users
• Create a copy of the Users view
• Rename the view
• To see what Users looks like hold down
  ctrl-shift while opening names.nsf.

28
Additional Administrative Tips Another Trick
People Ask About All the Time

• Creat a replica on a server when you don't have
  network/security access to the server that has a
  copy of the file
• Go to the R4 workspace
• Make sure that no database is selected
• Choose File -- Replication -- New Replica
• Type in the server and file name of the target
  database
• Click select
• Fill in the New Replica dialog as normal

Hidden Bonus
29

Working With the Console
30
Cool Console Tricks

• Pipe the output from the console to a text file
• show statistics gtstats.txt
• The file name is relative to the Domino program
  directory

31
Cool Console Tricks

• You can launch a batch of console commands from a
  batch file that resides on the server
• Great for triggering replication from a hub to a
  large number of servers manually
• Keep text files of the commonly used commands in
  the Domino program directory of the server
• Syntax is gt batchfile.txt

Good Thing
32
Cool Console Tricks Great But Seldom Used Commands

• show database dbname.nsf
• Displays the of deletion stubs by Note type and
  the byte size of every view
• Quicker than using NotesPeek when working with
  deletion stubs

33
Cool Console Tricks Great But Seldom Used
Commands (cont.)

• show transactions
• Provides detailed statistics on all NRPC
  transactions occurring on the server
• Gives you an idea of what kind of things your
  users do
• Use this data when you want to build benchmarking
  scripts

34
Cool Console Tricks Great But Seldom Used
Commands (cont.)

• TRACE servername/org or trace port !!!
  servername/org
• Returns exactly the same information that you get
  from a client network trace in the 'preferences'
  dialog
• Great for confirming connectivity and resolving
  connectivity problems
• Once I discovered this -- I use it almost every
  day

Great Feature
35
Finding Other Tools
36
Other Tools

• Two options for automating tasks
• Know LotusScript/Java (or have a friend that
  does) and write your own tool anytime you need
  one
• Know where to look for tools that other people
  made (often for free)

37
Other Tools www.notes.net

• Iris Sandbox
• If you want to automate a common task, odds are
  you aren't the first to think of it and odds are
  someone posted their cut at it here
• Almost all code is open for you to edit and
  improve and free for your non-commercial use
• Bad news is it is all unsupported and without
  warrantee

Re-use
38
Other Tools www.notes.net (cont.)

• Iris Sandbox (cont.)
• Some tools I can't live without from Iris
• NPing/NotesConnect -- This utility tests network
  availability over a specific port
• Antrid -- Allows you to either copy or change
  replica ID's of databases
• Awesome for the standard NTF files as well as for
  building test environments
• NotesPeek -- This is great for looking at the
  guts of an NSF
• It lets you see deletion stubs as well as profile
  documents
• A Domino detective's best friend (When the user
  says "duh, I didn't delete anything)

39
Other Tools

• Some 3rd party tools that are helpful for
  administrators and worth a look -- especially for
  large environments
• Percussion ServerAdmin Plus
• ACL Management / User Management / Monitoring and
  Database Management
• GSX Utilities
• Includes all kinds of cool monitoring tools as
  well as an ID management tool
• TeamStudio Delta (The whole TeamStudio suite is
  super)
• Not just for developers, really useful for
  comparing templates to find differences in design
  as well as comparing individual documents
• Useful in making sure that server configurations
  are consistent
• Help Software Power Tools
• This has a bunch of utilities for automating day
  to day admin tasks

40
Other Tools

• Tons more tools -- check out
• www.notes411.com
• www.searchdomino.com
• www.lotus.com/partners
• www.dominopower.com

41
Questions?
Submit your questions now by clicking on the
Ask A Question button in the bottom left corner
of your presentation screen.
