ORF 510: Directed Research II

1
(No Transcript)
2

• ORF 510 Directed Research II
• Analyzing travel time distributions using GPS
  data
• Santiago Arroyo
• Advisor Prof. Alain L. Kornhauser
• January 13th, 2004

3
Objectives

• Obtain travel time distributions between
  monuments on the US road network in order to
• Find more realistic shortest paths (according to
  travel time, not distance)
• Obtain travel time patterns according to
  categories
• Day of week (week/weekend)
• Time of day
• Road type
• Forecast travel times in real time

4
Concepts

• Road network US (Copilot)
• Different levels
• Level 0 30 x 106 arcs
• Level 1 500.000 arcs
• Level 2 10.000 arcs
• Level 3 1.000 arcs
• Nodes ??
• Monuments
• Midpoints of all/some arcs on level 1 (used
  originally to build network)
• ??

5
Data

• Copilot
• Generated on Nov 14th, 2003
• Every 3 seconds
• Matched to link using position and heading
• Biased geographically and by users
• More precise than Qualcomm
• Identified by vehicle, position, heading, speed,
  date and time

6
Data

• 1.500.000 monument to monument (m2m) times
• Max of observations for m2m pair 1202
• Total of m2m pairs 34879
• Only 1730 (4.96) pairs have 100 observations or
  more
• Biased around Princeton area

7
Time vs. Speed

• Time
• Absolute (dont care about what happens in
  between measures)
• Readily extractable from data

• Speed
• Calculate estimated time using speed measurements
• More difficult to take into account changes in
  speed between points (intersections, left turns,
  stops)
• Significant errors around intersections due to
  matching

8
Case Study
9
Case Study
Mean 191.63 Median 115 St Dev 508.81
Mean 308.39 Median 197 St Dev 647.00
10
Case Study
Mean 122.18 Median 114 St Dev 17.87
Mean 197.58 Median 197 St Dev 20.10
11
Case Study
12
Problem

• Stochastic Shortest Path
• Travel time is a function of departure time
• Discrete time of day intervals?
• Continuous function relating travel time and
  departure time
• Edge weights are random variables
• What are their distributions?
• Are they independent?
• How do we add distributions on a path?
• Memory limitations
• Cant store all possible paths
• Which paths should we store?

13
Travel time as a function of departure time

• Schrader Kornhauser (2003)
• Milwaukee Highway System (Weekday travel time)

where TT travel time t departure time
14
Travel time as a function of departure time

• Schrader Kornhauser (2003)
• Ten-parameter function fit to data from the
  Milwaukee Highway System

15
Edge weights are random variables

• Extension of deterministic algorithms
• Dijkstras, Bellman-Ford, A and variations
• Use expected value as edge weight
• Need to know travel time distribution
• Stochastic Shortest Path algorithms
• Priority First Search (PFS) with dominance
  pruning (Wellman et al., 1995)
• Adaptive Path Planning (Wellman et al., 1995)
• Vertex-Potential Model (Cooper et al., 1997)
• Path Optimality Indexes (Sigal et al., 1980)

16
Edge weights are random variables

• PFS with dominance pruning
• Stochastically consistent network
• cij(x) time dependent travel time from i to j
• For all i, j, sltt, and z Prs
  cij(s)ltzgtPrt cij(t)ltz
• i.e. the probability of arriving by any given
  time z cannot be increased by leaving later

17
Edge weights are random variables

• PFS with dominance pruning
• Stochastic dominance
• Arrival time distribution at a node dominates
  another iff cumulative probability function is
  uniformly greater or equal to that of the other

18
Edge weights are random variables

• PFS with dominance pruning
• Utility is nonincreasing with respect to arrival
  time
• How do we find arrival time distributions from a
  path with two edges or more?

• Priority queue only keep stochastically
  undominated paths
• Apply variations like A

19
Further Research

• Establish m2m time travel distribution
  approximations (normal, lognormal, exponential,
  etc.)
• Addition of distributions on a path (stochastic
  model)
• Investigate on independence of distributions in a
  path (maybe as a function of edges in the path)
• Categorize by time of day, day of week, road type
• Develop travel time as a function of departure
  time using Copilot data
• Construct network with expected travel times
  instead of distances (PTNM)
• Use travel times from Copilot data to forecast
  travel times, incorporating real time data

20
Bibliography

• C. Cooper, A. Frieze, K. Mehlhorn and V. Priebe,
  Average-case of shortest-paths problems in the
  vertex-potential model, International Workshop
  RANDOM97, Bologna, Italy
• A.M. Frieze and G.R. Grimmett, The Shortest-Path
  Problem for Graphs with Random Arc-Lengths,
  Discrete Applied Mathematics, 10 (1985) 57-77.
• S. Pallottino and M. Scutella, Shortest Path
  Algorithms in Transportation Models Classical
  and Innovative Aspects. In Marcotte, P., Nguyen,
  S., eds. Equilibrium and Advanced Transportation
  Modelling. Kluwer, Amsterdam (1998) 245-281.
• C. Schrader and Alain L. Kornhauser, Using
  Historical Information in Forecasting in Travel
  Times, BSE Thesis, Princeton University, 2003
• C. Elliot Sigal, A. Alan B. Pritsker and James J.
  Solberg, The Stochastic Shortest Route Problem,
  Operations Research, (1980) 1122-1129.
• Michael P. Wellman, Kenneth Larson, Matthew Ford
  and Peter R. Wurman, Path Planning Under
  Time-Dependent Uncertainty, Eleventh Conference
  on Uncertainty in Artificial Intelligence, 28-5
  (1995) 532-539.
• Fastest Path Problems in Dynamic Transportation
  Networks, in www.husdal.com
