Air / Ground Communications in Europe

1
Air / Ground Communications in Europe

• danny.van-roosbroek_at_eurocontrol.int
• Future Communications Sub-Domain Manager
• 27 31 March 2006, Malmö

European Organisation for the Safety of Air
Navigation
2
Strategic Context
ADS-B
8.33 kHz CPDLC Mode S EHS
Airborne Separation Trajectory
negotiation Voice Autonomous Separation
Voice Transfer of ControlClearances Microphone
Check Downlink of Heading, Speed, Selected flight
level
New Applications FCI
Voice Departure Clearance Digital-ATIS Oceanic
Clearance Classical Radar
Voice Initial ADS-B services More CPDLC
services More D-FIS services
ACARS
Voice VDL2
Voice VDL2
PS RADAR
Mode S
ADS-B Receiver
Mode S
2000gt
2005 gt
2010 gt
3
CPDLCLINK 2000
European Organisation for the Safety of Air
Navigation
4
Operational CPDLC in the Cockpit
5
Overview LINK

• LINK implementation is well underway
• The extra Capacity is required, essential to
  implement in time
• LINK provides the infrastructure for future
  datalink enhancements
• E.g. CASCADE programme
• LINK is seen as a necessary step towards SESAR
• Continued co-ordination with FAA is ongoing
• Was in place with FAA CPDLC Programme
• Continues in PARC/ Datalink Roadmap initiative
• Using ATN and VDL2

http//www.eurocontrol.int/link2000
6
Implementing Rule for Data Link Services
European Organisation for the Safety of Air
Navigation
7
Milestones of Data Link Services Mandate

• The European Commission, gave a Mandate to
  EUROCONTROL for the development of an
  Implementing Rule (IR) for Datalink Services on
  30th May 2005

Delivery of Initial Plan 15 July 2005
Delivery of Regulatory Approach January 2006
Draft final report including proposed draft Implementing Rule May 2006
Delivery of the final report including the draft Implementing Rule and the justification material September 2006
8
CPDLC ADS-BCASCADE
European Organisation for the Safety of Air
Navigation
9
CASCADE Scope Schedule

• Stream 1
• ADS-B-out, Auto-CPDLC, D-TAXI and D-OTIS
• First implementation in 2008
• Stream 2
• ADS-B-in out (ATSAW applications) and more
  advanced CPDLC
• First implementation in 2011

10
CASCADE Validation

• CRISTAL Ireland Portugal Austria focusing on
  ADS-B-NRA
• CRISTAL Sweden focusing on ADS-B-NRA, ADS-B-RAD,
  ADS-B-APT and ATSA-AIRB
• CRISTAL UK focusing on ADS-B-RAD
• CRISTAL MED focusing on ADS-B-NRA, ADS-B RAD and
  ADS-B APT
• CRISTAL Toulouse focusing on ADS-B certification
• CRISTAL Paris focusing on ASPA SM
• CRISTAL Germany focusing on TIS-B
• Maastricht UAC focusing on Auto-CPDLC
• D-OTIS D-TAXI at Brussels Airport

11
Priorities 2006

• Finalise standardisation work for Stream 1.
• Continue trials for Stream 1.
• Establish a 2008 implementation baseline with an
  operational approval roadmap.

www.eurocontrol.int/cascade
12
Priorities 2006

• Finalise standardisation work for Stream 1.
• Continue trials for Stream 1.
• Establish a 2008 implementation baseline with an
  operational approval roadmap.

www.eurocontrol.int/cascade
13
Future Communication System for A/G
communications
European Organisation for the Safety of Air
Navigation
14
Future Aeronautical A/G CommunicationsMost
likely base on IP protocol
1090 ES
ATS
AOC
APC
Always Best Connected
VHF 25/8.33
Regional Networks
15
FAA/Eurocontrol Joint Study

• FAA/Eurocontrol 3 year joint study
• Objectives
• Identification of requirements and operating
  concepts
• Investigation into new mobile communication
  technologies
• Investigation of a flexible avionics architecture
• Development of a Future Communications Roadmap
• Creation of industry buy-in
• Improvements to maximise utilisation of current
  spectrum

Coordinated With IATA
Federal Aviation Administration/EUROCONTROL ,
Cooperative Research and Development Action Plan
17 Future Communications Study (AP 17-04)
16
Aircraft Traffic ? Communications
A Day in 2025

• More than double of todays traffic
• Advanced ATC concept
• Data Primary

• T -Throughput
• C - Continuity
• I - Integrity
• A - Availability

17
ATC/AOC Services by Domain
En Route/Oceanic/Polar
Red Service Available After 2015
ACM
FLIPCY
FLIPINT
ACL
PPD
COTRAC
GRECO
DSC
D-SIGMET
ADS-B
ADS-B / ITP
ARMAND
D-ORIS
SAP
ADS-B / SM
Also Available
D-ALERT AMC
URCO
18
Process to Identify Communications Parameters

• Concepts Services
• High Level Safety and Security Analysis ? C, I,
  A
• Operational Performance ?Latency
• Allocation to the Communications Pipe
• Communications Loading Analysis
• Typical Service Volumes
• STATFOR SAAM
• Transactions per A/C per Service Volume
• Queueing Model ?Thoughput

19
COCR Document
Cooperation EUROCONTROL and FAA

• Results
• 2020 and 2030
• A/G voice A/G data A/A data
• ATC and/or AOC

• Usage
• Industry Consultation - ongoing
• Europe Provided to SESAR
• Technology Selection
• Spectrum Calculation
• US Used by JPDO for future system
• Coordinated with ICAO

20
Role of IP in the FCS
European Organisation for the Safety of Air
Navigation
21
Role of Communications in an ATM System
Aircraft
Procedures Flight Deck
Flight Crew
ATC Services, Procedures
Pilot HMI
Airborne Router
End System
ATN
IP?
IP?
ATN
Data Link
End-toEnd Networking
ATC Centre
Procedures
ARINC, SITA,
Controller HMI
A/G Router
End System
FDP
Network
Router
ATN
IP?
Router
G/G Network
IP?
ATN
ATN
ATN
IP?
IP?
22
A/G Communications IP for A/G ATC ?

• Study Use of IP for A/G safety critical comms
• Internet Engineering Task Force (IETF) emerging
  IP standards
• Live Cycle
• Commercial Of The Shelf (COTS) Dilemma
• Transition

23
Thank You
