SYSLOG, NetConf, NetFlow

1
SYSLOG, NetConf, NetFlow

• W.lilakiatsakun

2
syslog (1)

• The purpose of syslog is to write system messages
  to a log
• Syslog messages can include everything from
  critical alarm conditions to ordinary debugging
  statement
• It provides a general trail of activities
• It provides the capability for the device to emit
  event messages without solicitation

3
syslog (2)

• Syslog message has 2 parts
• A message header and the message body
• The message body contains the content of the
  message itself (english text, unstructured)
• The message header contains minimal but essential
  information in structured manner

4
General syslog message

• 179.19.209.130 IP Address
• 000024 sequence number
• Apr 12 180155643 local time
• ENV_MON facility emitting the alarm
• 1 severity
• SHUTDOWN Event

5
syslog Protocol

• IETF is in process of passing a particular
  version of syslog as a standard
• RFC 3164 BSD syslog protocol
• RFC 3195 reliable delivery for syslog
• Refer to RFC3164
• UDP is used as transport service
• Port 514

6
(No Transcript)
7
definition

• A machine that can generate a message will be
  called a "device".
• A machine that can receive the message and
  forward it to another machine will be called a
  "relay".
• A machine that receives the message and does not
  relay it to any other machines will be called a
  "collector". This has been commonly known as a
  "syslog server".

8
syslog message

• Consists of 3 parts PRI /HEADER/MSG
• Total length 1024 bytes or less

9
PRI (Priority) part

• Priority combination of a facility and severity

• Facility category of a message (kernel message)
  , it is a numeric code
• Severity numeric code 0 -7 , 0 is the most
  severe
• Priority is formed by multiplying the numeric
  code of the facility by 8 and adding the severity

• Facility 7 and severity 3 , so priority 59

10
Example of Facility code
11
Example of Severity
12
HEADER part (1)

• The HEADER part contains a timestamp and an
  indication of the hostname or IP address of the
  device
• The HEADER part of the syslog packet MUST contain
  visible (printing) characters (7-bit Ascii)
• HOSTNAME field will contain the hostname or IP
  address
• Timestamp field will contain the local time and
  is in the format of Mmm dd hhmmss"

13
HEADER part (2)

• Mmm month of the year with the first character
  in uppercase and the other two characters in
  lowercase
• Jan, Feb, Mar, Apr, May, Jun, Jul, Aug, Sep,
  Oct, Nov, Dec
• dd -dd is the day of the month.
• If the day of the month is less than 10, then it
  MUST be represented as a space and then the
  number.
• For example,
• the 7th day of August would be represented as
  "Aug 7", with two spaces between the "g" and the
  "7

14
HEADER part (3)

• hhmmss is the local time.
• The hour (hh) is represented in a 24-hour format.

• Valid entries are between 00 and 23
• The minute (mm) and second (ss) entries are
  between 00 - 59

15
MSG part (1)

• It contains some additional information of the
  process that generated the message, and then the
  text of the message
• It has 2 fields TAG and CONTENT
• TAG field will be the name of the program or
• process that generated the message.(not
  exceed 32 chars)
• CONTENT field contains the details of the
  message.
• This has traditionally been a freeform message
  that gives some detailed information of the event

16
Example of syslog message

• lt34gt Oct 11 221415 mymachine su su root failed
  on /dev/pts/8
• lt34gt - priority
• Oct 11 221415 timestamp
• mymachine hostname
• su TAG
• su root failed for on /dev/pts/8 - Content

17
Security consideration (1)

• Authentication
• The syslog delivery mechanism does not strongly
  associate the message with the message sender
• a misconfigured machine may send syslog messages
  to a collector representing itself as another
  machine
• An attacker may transmit syslog messages to a
  collector.

18
Security consideration (2)

• Sequenced delivery
• the syslog process and protocol do not ensure
  ordered delivery.
• Reliable delivery
• no mechanism within either the syslog process or
  the protocol to ensure delivery
• May be maliciously intercepted or discarded
• Message Integrity
• syslog messages may be damaged in transit or an
  attacker may maliciously modify them.

19
Security consideration (3)

• Message observation
• No mechanisms to provide confidentiality of the
  messages in transit. (clear-text messages)
• Message Prioritization Differentiation
• No mechanism relating to priority message
• Critical message and non critical message can be
  treated as equal in term of reception

20
Security consideration (4)

• Misconfiguration
• The syslog message may go to untended receiver
• Load Considerations
• An attacker may perform a Denial of Service
  attack by filling the disk of the collector with
  false messages.

21
syslog deployment (1)

• Two roles are distinguished
• syslog sender (management agent)
• syslog receiver (management manager)
• Syslog receiver (1)
• Device itself writing the messages to a local log
  file
• use circular log file for a limit size
• Log files are created with a certain capacity

22
syslog deployment (2)
Circular log file
23
syslog deployment (3)

• syslog receiver (cont)
• Centralized logging host
• Receiving messages from several devices and
  logging those messages
• Applications access this logging host instead of
  individual devices
• Syslog relay , forwarding syslog messages to
  various apps.

24
syslog deployment (4)
Logging host
syslog relay
25
Netconf (1)

• Netconf is a network management protocol
  developed in the IETF by the Netconf working
  group.
• It was published as RFC 4741.
• The NETCONF protocol provides mechanisms to
  install, manipulate, and delete the configuration
  of network devices.
• It also can perform some monitoring functions.

26
Netconf (2)

• It uses an Extensible Markup Language (XML) based
  data encoding for the configuration data as well
  as the protocol messages.
• The NETCONF protocol operations are realized on
  top of a simple Remote Procedure Call (RPC)
  layer.

27
Netconf Datastore (1)

• The configuration information of devices can be
  thought of and handle as being contained in a
  datastore (like a file)
• The datastore resembles a MIB.
• Netconf provides the operations to manage those
  datastores.
• SNMP targets the individual managed object in
  side MIB
• Netconf targets the MIB as a whole or portion

28
Netconf Datastore (2)
A hierarchical datastore in Netconf
29
Netconf Datastore (3)

• Management operations can be applied to
  individual subtrees
• This capability feature is called as subtree
  filtering

30
State Data and Configuration Data (1)

• The information that can be retrieved from a
  running system is separated into two classes,
  configuration data and state data.
• Configuration data is the set of writable data
  that is required to transform a system from its
  initial default state into its current state
• State data is the additional data on a system
  that is not configuration data such as read-only
  status information and collected statistics

31
State Data and Configuration Data (2)

• NETCONF protocol recognizes the difference
  between configuration data and state data and
  provides operations for each.
• The ltget-configgt operation retrieves
  configuration data only.
• The ltgetgt operation retrieves configuration and
  state data.

32
Netconf and XML (1)

• Netconf uses XML as encoding for its management
  operations
• XML documents contain so-called tags to delimit
  different pieces of information
• Tags are defined by users such as
• ltemailgtalex_at_cisco.com(/email)

33
Netconf Architecture (1)
34
Netconf Architecture (2)

• Transport layer - NETCONF implementation MUST
  support the SSH transport protocol mapping Secure
  (Authentication, Integrity, and Confidentiality )
• Block Extensible Exchange Protocol (BEEP) RFC4744
• Simple Object Access Protocol (SOAP) RFC4743
• Remote Procedure Call layer
• Allow manager to invoke function on agent
• rpc request / rpc reply

35
Netconf Architecture (3)

• The operation layer
• To manipulate configuration files
• Get-config / Edit-config
• The content layer
• Configuration data
• The management information will be transported
  and exchanged as XML documents

36
Netconf Message Structure

• Fig 8-14

37
A netconf request (1)

• Ex 8-4

38
A netconf request (2)

• RPC tag
• ltrpc message-id 101 gt . lt/rpcgt
• The ltrpcgt element has a mandatory attribute
  "message-id", which is an arbitrary string chosen
  by the sender of the RPC that will commonly
  encode a monotonically increasing integer.
• The receiver of the RPC does not decode or
  interpret this string but simply saves it to be
  used as a "message-id" attribute in any resulting
  ltrpc-replygt message.

39
A netconf request (3)

• Namespace
• All NETCONF protocol elements are defined in the
  following namespace
• urnietfparamsxmlnsnetconfbase1.0
• Netconf operation
• ltget-configgt lt/get-configgt
• Netconf Data addressing
• ltsourcegt lt/sourcegt specifies the address of data

• ltfiltergt lt/filtergt specifies the subtree

40
A netconf reply

• Ex 8-5

41
Management operations

• Get-config to retrieve config file (default is
  running config)
• Get to retrieve state information
• Edit-config to modify or change a configuration
• Copy-config to copy new configuration
• Delete-config to remove a configuration
• Lock and unlock to protect configuration file

42
Security Consideration (1)

• Configuration information is by its very nature
  sensitive.
• Its transmission in the clear and without
  integrity checking leaves devices open to classic
  eavesdropping attacks.
• Configuration information often contains
  passwords, user names, service descriptions, and
  topological information, all of which are
  sensitive.

43
Security Consideration (2)

• The protocol, therefore, must minimally support
  options for both confidentiality and
  authentication. (SSH, BEEP, etc)

44
Netflow protocol /IPFIX (1)

• RFC 3954 (Netflow V.9)
• RFC 5101 (IPFIX- aka. Netflow V.10)
• Netflow was introduced by cisco to collect data
  about networking traffic from a device.
• Who are the top talker in the network
• How much traffic is being exchanged between two
  destination
• How are links in the network being used
• Where are the traffic bottlenecks in the network?

45
Netflow protocol /IPFIX (2)

• Netflow communicates statistical information
  about IP-based data traffic that flow over router
• The statistics are provided on a per-flow basis
• A flow consists of all traffic that belongs to
  the same communication context
• A filetransfer application ,all packets belong
  to the same transfer

46

• Fig 8-15

47
Flow

• Identified by the following information
• Source address/Source port
• Destination address/Destination port
• Protocol type (TCP or UDP)
• Type of service (TOS)
• Input logical interface (same index in SNMP MIB)
• Flow record includes the keys that identify the
  flow as well as the time when flow started
  /stopped /how many packets were transported

48
Terminology (1)

• Observation Point
• An Observation Point is a location in the network
  where IP packets can be observed for example,
  one or a set of interfaces on a network device
  like a router.
• Observation Domain
• The set of Observation Points that is the largest
  aggregatable set of flow information at the
  network device with NetFlow services enabled is
  termed an Observation Domain.

49
Terminology (2)

• IP Flow or Flow
• Set of IP packets passing an Observation Point in
  the network during a certain time interval.
• All packets that belong to a particular Flow have
  a set of common properties derived from the data
  contained in the packet and from the packet
  treatment at the Observation Point.
• Flow Record
• A Flow Record provides information about an IP
  Flow observed at an Observation Point.
• The Flow Data Records are also referred to as
  NetFlow services data and NetFlow data.

50
Terminology (3)

• Exporter
• A device (for example, a router) with the NetFlow
  services enabled, the Exporter monitors packets
  entering an Observation Point and creates Flows
  from these packets.
• The information from these Flows is exported in
  the form of Flow Records to the NetFlow Collector

51
Terminology (4)

• NetFlow Collector
• The NetFlow Collector receives Flow Records from
  one or more Exporters.
• It processes the received Export Packet(s) that
  is, it parses and stores the Flow Record
  information.
• Flow Records can be optionally aggregated before
  being stored on the hard disk.

52
Benefit

• Allow network managers to account for detailed
  network use by individual users
• Charge based on actual traffic consumption
• Provide a wealth of data for traffic analysis,
  bottleneck and network planning
• Provide tool to spot and defend against attacks
  on a network

53
Netflow Protocol

• Netflow version5 is commonly used
• The newest version is RFC 3954 (version 9)
• Flow information is exported from the router in
  User Datagram Protocol (UDP) or Stream Control
  Transmission Protocol (SCTP) packets and
  collected using a netflow collector.
• Juniper Networks provides a similar feature for
  its routers called Jflow .
• Huawei Technology routers also support the same
  technology, but call it NetStream

54
Netflow packet structure
55
Packet structure

• Header
• Sequence number of the packet
• The number of flow records contained in the
  Netflow packet
• The version number of the netflow protocol itself
• Flow record
• keys to identify flow
• Start/finish time
• Statistical data

56
Finishing the flow (1)

• 1. If the Exporter can detect the end of a Flow.
  For example, if the FIN or RST bit is detected in
  a TCP RFC793 connection, the Flow Record is
  exported.
• 2. If the Flow has been inactive for a certain
  period of time. This inactivity timeout SHOULD be
  configurable at the Exporter, with a minimum
  value of 0 for an immediate expiration.

57
Finishing the flow (2)

• 3. For long-lasting Flows, the Exporter SHOULD
  export the Flow Records on a regular basis. This
  timeout SHOULD be configurable at the Exporter.
• 4. If the Exporter experiences internal
  constraints, a Flow MAY be forced to expire
  prematurely for example, counters wrapping or
  low memory.

58
Security Consideration (1)

• Disclosure of Flow Information Data
• Export Packets are not encrypted, the observation
  of Flow Records can give an attacker information
  about the active flows in the network,
  communication endpoints and traffic patterns.
• This information can be used both to spy on user
  behavior and to plan and conceal future attacks.
  The information that an attacker could derive
  from the interception of Flow Records depends on
  the Flow definition.

59
Security Consideration (2)

• Forgery of Flow Records or Template Records
• If Flow Records are used in accounting and/or
  security applications, there may be a strong
  incentive to forge exported Flow Records (for
  example to defraud the service provider, or to
  prevent the detection of an attack).
• This can be done either by altering the Flow
  Records on the path between the Observer and the
  Collector, or by injecting forged Flow Records
  that pretend to be originated by the Exporter.

60
Security Consideration (3)

• Attacks on the NetFlow Collector
• Denial of service attacks on the NetFlow
  Collector can consume so many resources from the
  machine that, the Collector is unable to capture
  or decode some NetFlow Export Packets. Such
  hazards are not explicitly addressed by the
  NetFlow Version 9 protocol, although the normal
  methods used to protect a server from a DoS
  attack will mitigate the problem.

61
Example of Export Packet (1)
62
Example of Export Packet (2)
63
Example of Export Packet (3)
64
Management protocol positioning
