Wave Properties

1
Wave Properties Types of Waves
2
Wave

• Wave - Rhythmic disturbance that carries energy
  through matter and space
• ALL WAVES CARRY ENERGY!
• Pulse one wave that travels through a medium
• Continuous waves waves that repeatedly move up
  and down

3
Transverse Waves

• Transverse waves matter in the medium moves
  back and forth at right angles to the direction
  that the wave travels.

4
Parts of a Transverse Wave

• Crest top of a wave
• Trough bottom of a wave

5
Parts of a Transverse Wave

• Amplitude ½ the height of a wave
• Relates to the amount of energy carried by the
  wave

6
Parts of a Transverse Wave
7
Parts of a Transverse Wave

• Wavelength the length of one cycle of a wave
• Abbreviated by using the symbol, ?

8
Transverse Wave

• Frequency how many cycles (waves) are completed
  in a given time (usually 1 second)

9
Compression/Longitudinal Waves

• Compressional waves matter in the medium moves
  in the same direction that the wave travels.
  Example Sound waves

10
Parts of a compression wave
compression
Compression the area where the particles are
more dense
11
Parts of a compression wave
Rarefaction The less dense area of the wave
Rarefaction
12
Parts of a compression wave
Wavelength One complete cycle of a wave
?
13
Surface Waves

• both transverse compressional
• examples water waves, seismic waves

14
Medium

• Most waves need something to travel on (or
  through)
• The substance through which a wave travels is a
  medium

15
Standing Waves

• Appear to be standing still
• Standing waves are caused by two waves
  continuously interfering with each other.

16
Types of Waves
17
Reflection

• The angle at which a ray strikes a surface is
  equal to the angle at which it is reflected

18
Reflection
(line drawn perpendicular to the reflecting
surface
normal line
19
Reflection
(ray striking a surface)
incident ray
20
Reflection
(ray that bounces off of a surface)
Reflected ray
21
Reflection
angle of incidence
angle of reflection
22
Period and Frequency

• Period (T) time it takes for one wave to pass
• The unit of a period is the second (s)
• Frequency (f) the number of waves that pass
  each second
• The unit of frequency is Hertz (Hz)

23
Formula 1

• Frequency 1/ period
• f 1/T

24
Formula 2

• Frequency waves / time
• f waves / t

waves
f
t
25
Formula 3

• Speed frequency x wavelength
• S f x ?

s
f
?
