SPECIAL SENSES

1
SPECIAL SENSES

• Making Sense of The World

2
Sensation

• relationship between physical energies in the
  environment psychological experience of those
  energies
• to perceive detect physical energies encode
  them into neural signals

3
Basic Senses

• Sight
• Hearing
• Touch
• Smell
• Taste
• also
• Pain
• Pressure
• Temperature
• Joint position
• Muscle sense
• Movement

4
SENSES

• systems that translate outside information into
  activity in nervous system
• gather information by detecting energies
• environment contains many different forms of
  energies

5
Receptors

• detect only the energies have receptor for
• restricted awareness
• receptor cells transduce or change physical
  energy into a signal brain can understand

6
Transduction

• conversion of physical energies into language of
  brain
• receptor cells convert physical energies into
  neural impulses which travel to cerebral cortex
  to be decoded
• all sense signals except smell go to relay
  station-thalamus
• from there to primary sensory areas in
  cerebrum-different for each sense
• here they are modified and sent on to higher
  regions of brain

7
Olfaction

• sense of smell
• chemical sense
• air borne chemicals detected
• oldest sense
• all organisms have some type of chemical sense
• major senses in most animals
• help locate food, recognize trails territories
  identify kin find receptive mates
• social insects send receive intricate chemical
  signals which tell them where to go and how to
  behave
• social behavior of most animals is controlled by
  chemical signals
• olfactory receptor area in German Shepherd-72X
  bigger than in humans

8
Olfactory System

• humans are able to distinguish 10,000 smells
• detected in paired olfactory organs in nasal
  cavity by specialized receptor cells found in
  olfactory epithelium-olfactory receptor neurons

9
Olfactory System

• olfactory organs posses 2 layers
• olfactory epithelium
• lamina propria
• olfactory epithelium covers inferior cribifrom
  plate, superior perpendicular plate superior
  nasal conchae of ethmoid bone
• covered by mucus which contains olfactory
  receptors
• lamina propria-comprised of areolar tissue, blood
  vessels, nerves olfactory or Bowmans glands
• produce secretions that bathe surface of
  olfactory receptors

10
Olfactory System

• 10 100 million olfactory receptors
• modified bipolar neurons
• have terminal enlargements or knobs which project
  above epithelial surface
• from each 8-20 olfactory cilia extend into mucus
• contain smell receptors
• cilia project from knob lie parallel to
  epithelia surface
• exposes considerable surface area to dissolved
  compounds
• at other end of receptor cell, axons project to
  olfactory bulb
• 10-100 axons form into bundles, penetrate
  cribriform plate? terminate in olfactory bulb
• stem cells allow neurons to regenerate

11
(No Transcript)
12
Olfaction

• refers to breathing in chemicals
• Inhale?take in chemicals or odorants
• chemicals that stimulate olfactory receptors
• must be small enough to be volatile to vaporize,
  reach the nose dissolve in mucus to stimulate
  olfactory receptors
• at olfactory organs?water lipid soluble
  materials diffuse into mucus

13
OLFACTION

• dissolved chemicals interact with receptors-
  odorant binding proteins
• 4 odorant molecules will activate an olfactory
  receptor?activates adenylate cyclase?converts
  ATP?cAMP?opens Na channels in membrane ?local
  depolarization?depolarization large enough
  ?action potential in axon? conveyed to CNS

14
(No Transcript)
15
Olfactory Pathways

• axons of receptors extend through olfactory
  foramina in cribiform plate to form? right left
  olfactory nerves
• terminate in brain in the olfactory bulbs?axons
  of bulbs extend posteriorly?form olfactory tract?
  projects to primary olfactory cortex located at
  inferior medial surface of the temporal lobe
• projects to hypothalamus amygdala
• parts of limbic system
• amygdale associate experiences with
  smells?producing emotion
• projections are sent to thalamus and to frontal
  cortex-recognition

16
Olfactory Discrimination

• can recognize 2000-4000 chemical stimuli
• several primary smells for which thousands of
  receptors are needed
• 1) ethereal2) camphoraceous3) musky4)
  floral5) minty6) pungent7) putrid
• 1 of genes are needed to make receptor proteins
  to recognize smells
• no distinct receptor for each detectable odor

17
Gustation

• chemical sense
• chemicals are taken into the body dissolved in
  oral cavity
• drives appetite
• protects from poisons
• bitter sour tastes produce aversive, avoidance
  reactions
• most poisons are bitter
• off food goes sour or has an acidic taste

18
Taste Discrimination

• 5 primary sensations
• Sweet
• Salty
• Sour
• Bitter
• Umami
• MSG
• taste of beef, chicken broth parmesan cheese
• taste combined with smell gives flavor
• when nose is blocked foods seem bland or
  tasteless

19
Anatomy of Gustation

• receptor-taste bud
• 10,000
• tongue, soft palate, pharynx epiglottis
• survives about 10 days
• Consists of
• taste receptors or gustatory cells
• basal or stem cells
• supporting cells

20
Anatomy of Gustation

• Supporting cells
• surrounds about 50 gustatory receptors cells in
  each taste bud
• one single long micovillus (gustatory hair)
  projects from each gustatory receptor cell to
  surface through taste pore
• Basal cells
• stem cells
• found in periphery of taste buds

21
Anatomy of Gustation

• gustatory receptors
• embedded in specializations of surrounding
  epithelium called papillae
• three types contain taste buds
• vallate
• fungiform papillae
• folliate

22
PapillaeTypes

• Vallate or circumvallate papillae
• have 100 taste buds
• back of tongue
• Fungiform papillae
• possess 5 taste buds
• over entire tongue
• Folliate
• lateral margins
• taste buds degenerate in early childhoog
• Filiform papillae
• no taste buds
• Tactile receptors
• provide friction sensations

23
Gustatory Transduction

• dissolved chemicals contact taste hairs
• bind to receptor proteins on gustatory cell
• causes series of chemical reactions
  producing?action potential

24
Gustatory Transduction

• different tastes involve different receptor
  mechanisms
• salt receptors?depolarize after Na channels open
• sweet receptors depolarize after K channels open

25
Gustatory Transduction
26
Gustatory Pathways

• Taste is monitored by cranial nerves VII-facial
• picks up sensation from anterior 2/3rds of
  tongue
• IX-glossopharyngeal
• covers posterior 1/3rd of tongue
• X-vagus
• receives information from epiglottis
• axons from these nerves synapse on nucleus
  solitarius in medulla oblongata
• axons of postsynaptic neurons enter medial
  lemniscus synapse in thalamus
• then project to gustatory cortex? conscious
  perception
• here information is correlated with other sensory
  data such as texture, peppery, hot

27
Vision

• primary sense in humans
• sensory organs-eyes

28
Accessory Eye Structures

• Eyelids or palpebrae
• continuations of skin
• blink continually to keep surfaces lubricated
  things out of eyes
• Palpebral fissure
• gap separating free margins of upper lower
  eyelids
• Medial Lateral canthus
• where eyelids are connected
• Eyelashes
• keep foreign materials out

Medial Canthus
Lateral Canthus
29
Accessory Eye Structures

• Tarsal glands
• sebaceous glands associated with eyelashes at
  inner margin
• secrete lipids to keep eyelids from sticking
  together
• Lacrimal Caruncle
• medial canthus
• makes a thick, gritty secretion often found in
  eyes after sleeping

30
ACCESSORY STRUCTURES

• Palpebral conjunctiva
• epithelium covers inner surface of eye
• Ocular conjunctiva
• covers anterior surface
• extends to edges of cornea
• transparent part of outer fibrous layer

31
ACCESSORY STRUCTURES-Lacrimal Apparatus

• produces, distributes removes tears
• tears reduce friction, remove debris, prevent
  bacterial infections provide nutrients and O2
  to eye
• consists of
• lacrimal gland
• lacrimal canaliculi
• lacrimal sac
• nasolacrimal duct
• lacrimal gland produces key ingredients and most
  of volume
• tears accumulate at medial canthus or lacrimal
  lake
• lacrimal puncta drains lake?empties into lacrimal
  caniliculi?lacrimal sac?nasolacrimal duct?
  nasolacrimal canal?nasal cavity

32
THE EYE

• irregular spheroid
• three layers or tunics
• outer fibrous tunic
• intermediate vascular tunic
• inner neural tunic
• two hollow cavities
• posterior, vitreous chamber
• contains gelatinous vitreous body
• helps stabilize shape of eye
• anterior chamber
• filled with aqueous humor
• functions to retain shape of eyeball

33
Fibrous Tunic

• sclera cornea
• Functions
• mechanical support
• physical protection
• attachment site-extrinsic eye muscles
• housing of focusing structures
• Sclera
• white of eye
• site for insertion of 6 extrinsic eye muscles
• contains blood vessels nerves
• Cornea-continuous with sclera
• cornea lens comprise-refractive system
• focuses light on retina
• where photosensitive pigments are found

34
Vascular Tunic-Uvea

• site of attachment for intrinsic eye muscles
• provides route for blood lymph
• regulates amount of light entering eye
• secretes reabsorbs aqueous humor
• controls shape of lens
• Parts
• iris
• cilliary body
• choroid

35
THE IRIS

• consists of pigment cells 2 layers of smooth
  muscle
• contraction of muscle produces change in diameter
  of pupil
• central opening in iris
• controlled by ANS
• bright light causes constriction via consensual
  light reflex
• parasympathic pathway
• dim light causes dilatation via pupillary reflex
• sympathetic pathway

36
Cilliary Body

• thicken area at periphery of eye
• iris is attached to it
• composed of cilliary muscles

37
CHOROID

• separates fibrous neural tunics

38
Neural Tunic-Retina

• light sensitive
• thin, pigmented outer layer
• sheet of melanin containing cells
• thick, inner layer-contains light receptors
• begins visual pathway
• consists of three layers

39
Retina Layers

• Photoreceptor layer
• Bipolar cell layer
• Ganglion cell layer

40
The Retina

• Third layer
• light energy converted into neural activity
• contains specialized photoreceptor cells-rods
  cone
• transduce light wavelengths into information the
  brain understands
• Second layer
• bipolar cells
• magnifies image
• First layer
• ganglion cells
• further adjust image
• axons form optic nerve

41
Retina

• if eyes simply transferred stimuli from retina to
  brain?images would be blurry
• images are sharpened by sending information from
  photoreceptor cells back through first 2 layers
  of retina
• Bipolar cells connect photoreceptors to retinal
  ganglion cells
• axons from ganglion cells form optic nerve

42
Third Layer

• light energy is converted into neural activity
• contains specialized photoreceptor cells-rods
  cones
• rods cannot see color
• more sensitive than cones
• sensitive enough to respond to a single photon of
  light
• basic unit of light
• create coarse, gray image
• adequate for seeing in poor or dim light
• can make out shapes fairly well
• colors are completely absent
• no color vision in dim light

43
RODS CONES

• 18X more rods than cones
• approximately 125 million rods
• 6 million cones
• arranged to produce best possible combination of
  night day vision

44
Cones

• color vision
• operate in bright light
• Three types
• Blue
• Red
• Green
• experience of color is due to combination of
  these three cones

45
Cones

• concentrated in macula leutea
• center is fovea centralis
• site of highest visual acuity or resolution

46
THE LENS

• transparent structure located behind pupil in
  cavity of eyeball
• consists of concentric layers of cells, filled
  with crystallins
• transparent proteins responsible for clarity of
  lens for focusing

47
Focusing

• requires the cornea lens
• light is refracted or bent as it passes from one
  medium to another with different density
• greatest amount of refraction occurs as light
  passes from air to cornea
• more refraction occurs as light passes from
  aqueous humor to lens
• lens provides extra refraction needed to focus
  light from object to focal point
• specific point of interaction in retina
• distance between center of lens focal point is
  focal length or distance

48
PhotoPathway

• Horizontal cells extend across outer part of
  retina at level of synapses between photoreceptor
  bipolar cells
• Amacrine cells found where ganglion cells synapse
  with bipolar cells
• Light energy must pass through both ganglion
  bipolar cells to get to photoreceptor cells where
  light energy is converted into neural signals
  which activates bipolar cells
• One cone converges on one bipolar cell
• preserves precise information, provides high
  acuity and fine detail
• 1000 or more rods funnel information onto one
  bipolar cell
• increases original illumination activates
  ganglion cells

49
OPTIC NERVE

• Axons from 1 X 106 ganglion cells converge on
  optic disc
• circular region medial to fovea
• origin of optic nerve
• penetrates wall of eye at area known as blind
  spot
• no photoreceptors
• forms optic nerve which partially crosses at
  optic chiasm
• continues on to thalamus
• from there to other areas of cortex all at the
  same time

50
Refraction

• light rays reflected by object enter eye through
  cornea
• light proceeds through pupil
• size controlled by iris
• behind pupil?lens focuses light rays into an
  inverted image onto retina at back of eye

51
Refraction

• lens focuses image on photoreceptors by changing
  shape
• accommmoation
• shape of lens is determined by tone of ciliary
  muscles
• shape determined by tone of cilliary muscles

52
Accommodation

• cilliary muscles relax for far vision
• zonular fibers are pulled taut ?lens is under
  tension flat
• cilliary muscle contract for near vision
• releases zonular fibers from tension?lens
  assumes a natural, rounder more refractive
  state
• rounder shape increases refractive power of lens

53
Errors of Refraction

• Presbyopia
• lens thickens?becomes harder? won't accommodate
• seen in almost all people over the age of 40
• Myopia-near sightedness
• eyeball is too long

54
Errors of Refraction

• Hypermetropia-far-sightedness
• eyeball is too short
• Astigmatism
• lens or cornea not smoothly spherical

55
Image Formation

• Final stage- constriction of pupil
• pupil constricts ?hole narrows
• due to the circular muscles of iris

56
Photoreception

• Photoreceptors detect photons of light
• basic unit of visible light
• light is radiant energy or electromagnetic
  radiation
• comes in waves
• referred to by wavelengths
• wavelengths eyes detect are found in visible part
  of spectrum
• can detect these because possess receptors
  excited by wavelengths between 400-700nm

57
LIGHT

• 2 physical characteristics of light determine
  sensory experience of it
• Wavelength
• distance of one wave peak to next
• each wavelength is sensed as a color
• Amplitude
• indicates amount of energy
• determines intensity of light
• large amplitude makes for bright color
• small amplitude makes dull color

58
Photoreceptors

• have outer segment containing discs
• shape of outer segment provides name of
  photoreceptor
• Rods
• each disc is independent entity
• outer segment forms elongate cylinder
• Cones
• discs are infoldings of cell membrane
• outer segment tapers to tip
• outer segment is connected to inner by narrow
  stalk
• outer segments of both contain photopigment
• absorbs light

59
PHOTOPIGMENTS

• one in rods
• one in each of 3 cones
• derivatives of rhodopsin or visual purple
• consists of
• protein-opsin-bound to light sensitive
  chromophore-retinal-made from vitamin A
• Retinal-common to all photopigments
• attaches to different opsins in cones
• opsin determines wavelength of light that can be
  absorbed by retinal

60
Photoreception

• photon strikes part of rhodopsin molecule
• absorbed by visual pigment
• retinal has 2 possible configurations
• cis trans forms
• normally retinal is in cis form
• once light is absorbed?cis form?trans
  form?triggers chain of enzymatic steps

61
Steps in Photoreception

• Step 1 Isomerization
• Photon of light absorbed
• Opsin is activated
• cis form?trans form

62
Step 2-Photoreception

• Bleaching
• trans retinal separates from opsin
• Photopigment looks colorless

63
Step 3-Photoreception

• Regeneration
• Trans retinal transforms back to the cis form
• Cis-retinal can bind to opsin
• Photopigment is functional again

64
Color Deficiency

• Humans can discriminate 7X106 colors
• some have difficulty with color perception
• color deficient
• 1 out of 50 individuals
• gene responsible is sex-linked
• deficiency seen more in males than in females
• 8 of males 0.05
• color deficient usually lacks either red or green
  opsin
• have difficulty distinguishing red from green
  (both appear the same)
• cant color blend
• Vision is said to be di- instead of tri-chromatic

65
(No Transcript)
66
Depth Perception

• have binocular vision
• when looking at an object a representation comes
  from both retinas
• foveas are about 5-7.5 cm apart
• visual fields for each eye slightly different
• occipital cortex receives both of these images
  fuses them into one picture
• fusing confers perception of depth
• Convergence

67
Visual Processing

• axons from all ganglion cells?optic disc
• optic nerves reach diencephalon incompletely
  cross over at optic chiasm
• From there ½ the fibers? lateral geniculate
  nucleus on same side of brain
• ½ the fibers continue to opposite lateral
  geniculate nucleus
• From there image proceeds to occipital cortex via
  projection fibers

68
The Ear

• three anatomical areas
• External
• collects sound waves directs them toward middle
  ear
• Middle
• consists of a chamber in temporal bone
• Inner
• contains sensory organs for hearing equilibrium

69
External Ear

• composed of pinna
• cartilaginous auricle
• surrounds
• external auditory canal
• channels sound waves through auditory canal to
• eardrum or tympanic membrane
• thin, semi transparent membrane separates
  external from middle ear
• ceruminous glands
• secrete cerumen
• waxy substance
• needed for protection
• helps keep foreign objects out of ear
• helps slow infections

70
Middle Ear

• filled with air
• communicates with nasopharynx through auditory or
  eustachian tube
• equalization of pressures
• contains auditory ossicles
• 3 tiny bones
• malleus
• incus
• stapes
• malleus attaches to tympanic membrane
• stapes is bound to oval window
• opening in middle ear going to inner ear
• incus lies between malleus stapes

71
Inner Ear

• labyrinth
• contains receptors for hearing equilibrium
• Outer bony labyrinth encloses an inner-membranous
  labyrinth
• bony labyrinth consists of vestibule, cochlea
  semicircular canals
• filled with perilymph
• fluid in membranous part is endolymph
• vestible comprised of membranous sacs saccule
  utricle
• house receptors for gravity linear acceleration
  perception
• semicircular canals
• receptors in canals provide information on head
  location
• vestibule semicircular canals make up
  vestibular complex

72
Hearing Receptors

• receptors for hearing are in cochlea
• spiral shaped bony chamber
• divided into thee channels
• cochlear duct, scala vestibuli scala tympani
• the vestibular membrane separates the cochlear
  duct from the scala vestibuli
• the basilar membrane separates cochlear duct form
  scala tympani
• Resting on basilar membrane is spiral organ or
  organ or Corti

73
Hearing Receptors

• sensory receptors are hair cells
• on basilar membrane
• 16 X 106 hair cells found in two groups
• one-inner group arranged in a row
• outer group arranged in three rows
• free surface of each hair cell contains 40-80
  stereocilia
• similar to long microvilli
• tectorial membrane covers the hair cells

74
Audition

• detection of sound
• stimulus is sound waves
• from compression rarefaction of air-or
  alternating air pressure
• distance between pressure peaks is wavelength
• frequency determines pitch
• measured in terms of cycles or waves per second
  called hertz-Hz
• humans detect sounds in frequency range from 20
  to 20,000Hz
• longer waves produce lower frequencies lower
  pitches
• shorter wavelengths make higher frequencies
  higher pitches
• amplitude determines loudness
• greater amplitude? louder a sound

75
Sound

• measured in decibels
• 0 decibelsabsolute threshold
• 10 decibels indicates 10X increase
• normal conversation- around 60 decibels
• passing train-about 100
• above 80 damages hair cells
• uncomfortable at 120
• painful above 140

76
Transduction of Sound

• when we speak vocal cords vibrate? molecules of
  air move?bump into one another producing waves of
  compressed, expanded air
• ears detect these waves transduce them into
  nerve impulses?brain decodes as sound
• sound waves enter via external ear?continue on
  to tympanic membrane
• air molecules under pressure cause tympanic
  membrane to vibrate

77
Transduction of Sound

• movement of tympanic membrane displaces
  auditory ossicles
• first malleus vibrates
• handle of malleus strikes incus causing it to
  vibrate
• vibrating incus moves stapes
• vibrates oval window
• total force transferred to oval window
• because window is much smaller? force per unit
  area increases 15-20X.
• vibrations of oval window produce pressure waves
  that vibrate perilymph in vestibular duct
• these waves distort basilar membrane on way to
  round window of tympanic duct
• location of maximum distortion varies with
  frequency

78
Frequency Coding

• basilar membrane is narrow and stiff at window
  end
• wide and flexible at apical end
• topographical difference results in different
  regions vibrating at different frequencies
• end near stapes (window end) vibrates at high
  frequencies
• apical end vibrates at low frequencies

79
Transduction of Sound

• pressure waves continue into endolymph inside
  cochlear duct
• pressure waves in endolymph cause basilar
  membrane to vibrate which moves the hair cells of
  spiral organ against tectorial membrane
• leads to bending of stereocillia generation of
  nerve impulse

80
Transduction of Sound
81
Auditory Pathways

• bending of hair cells opens potassium channels
• Produces depolarizing potential
• opens calcium channels
• causes neurotransmitter vesicles (probably
  glutamate) release
• generates nerve impulse
• impulses pass along axons of forming cochlear
  branch of vestibulocochlear nerve (VIII)
• axons synapse with neurons in cochlear nucleus in
  medulla
• some axons cross over ascend in lateral
  meniscus terminate in inferior colliculi in
  midbrain
• other axons form cochlear nuclei
• end in superior olivary nucleus in pons

82
Localization of Sounds

• requires binaural fusion
• brain compares information received from each ear
• ears are about 6 inches apart
• makes for intensity differences time lags to
  brain
• very small but allow for stereophonic or
  3-dimensional hearing
• auditory system can detect minute differences
• time difference of 0.000027 seconds is all that
  is needed to be able to identify direction from
  which 2 sounds are coming
• localization is quite accurate unless sound is
  located directly ahead, behind, overhead or
  beneath ears-equidistant from both

83
Hair Cells

• 16,000 hair cells
• extremely vulnerable
• overexposure to loud noises, disease, heredity or
  aging most humans will lose 40 of hearing by age
  65
• once destroyed hair cells cannot regenerate

84
Equilibrium

• vestibular sense
• sensation provided by vestibular complex
• Two types
• Static
• Dynamic

85
Static Dynamic Equilibrium

• Static
• maintenance of position of body (mainly head)
  relative to force of gravity
• know where head is when it is tilted
• Dynamic
• maintenance of body position (mainly head) in
  response to sudden movements, such as rotational
  deceleration or acceleration
• know where head is if it moves quickly

86
Vestibular Sense Receptors

• Vestibular apparatus
• Saccule
• Utricle
• Semicircular ducts

87
Saccule Utricle

• Otolithic organs
• walls contain macula
• houses receptors for equilibrium
• contains two types of cells
• 1) hair cells-sensory receptors 2) supporting
  cells

88
Saccule Utricle

• hair cells of utricle saccule have 40-80
  stereocillia of grduated height one kinocillium
• Longer than longest stereocilia
• steorcillia are connected by tip inks
• Together sterocilia and kinocillium are-hair
  bundle

89
Saccule Utricle

• supporting cells secrete a gelatin like
  glycoprotein layer called otolithic membrane
• rests on hair cells
• layer of dense calcium carbonate crystals called
  otoliths extend over surface of otolithic
  membrane

90
Equilibrium

• when head is upright? statoconia sit on top of
  macula
• weight presses down
• when head is tilted?statoconia shift to
  side?distorting hair cells
• sends information to CNS that head is no longer
  level

91
Semicircular Ducts

• contain receptors which respond to rotational
  head movements-dynamic equilibrium
• anterior, posterior lateral semicircular ducts
  are continuous with utricle
• each semicircular duct has an ampulla-expanded
  region containing hair cells
• hair cells attached to wall of ampulla form
  crista
• each crista consists of hair and supporting cells
• covering the cells is a gelatinous structure-
  cupula

92
Vestibular Sense

• when head is rotated?endolymph moves?pushes
  cupula ?distorts processes of receptor
• gluid movement in one direction?stimulates hair
  cells
• movement in other direction?inhibits hair cells

93
Vestibular Sense Equilibrium

• Hair cells of vestible semicircular ducts are
  monitored by sensory neurons-vestibular ganglia
• Branches form cranial nerve 8- vestibulocochlear
  nerve
• innervates vestibular nuclei located between pons
  medulla
• nuclei send information to cranial nerves III,
  IV, VI and XI-involved with eye, head and neck
  movements
• information is then sent down vestibulospinal
  tracts of spinal cord ? adjusts peripheral
  muscle tone complements reflexive movements of
  head neck
• nuclei also connect with cerebellum to coordinate
  movement
• one spins very fast stops abruptly, liquid
  cannot return to normal?feel dizzy
• Neural connections are also made with
  ANS?digestive system part?nausea.
