HMI Electronics

1
HMI Electronics
HMI00381

• Russell Lindgren
• Electronics Lead
• russ.lindgren_at_lmco.com

2
Agenda

• Top Level Requirements
• Key Drivers
• Design Considerations
• Key Trades
• Design Overview
• HMI Electronics Box
• HEB Packaging
• Processor
• PCI to Local Bus Bridge/1553 Interface
• Mechanism Controllers
• Housekeeping Data Acquisition
• CCD Camera Interface
• Compressor/Spacecraft HSB Interface
• Power Converter Subsystem
• Oven Controller
• Image Stabilization System
• Test Plans Open Issues

3
Top Level Requirements

• Provide conditioned power and control for all HMI
  subsystems
• Includes Image Stabilization System and Filter
  Oven Controller Electronics
• Includes Mechanism Heater Control Electronics
• Provide processor for
• Control of all HMI subsystems
• Decoding and execution of commands
• Acquire and format housekeeping telemetry
• Self-contained operation for extended periods
• Program modifiable on-orbit
• Provide stable jitter free timing reference
• Provide compression and formatting of science
  data from two CCD cameras
• Provide dual interface for 55 Mbps of science
  data
• Provide spacecraft 1553 interface
• Commands 2.0 kbps
• Housekeeping telemetry 2.0 kbps
• Diagnostic telemetry 10 kbps for short periods
  upon request

4
Key Drivers

• Cadence/Data Rate
• Required cadence is two 4096 x 4096 x 14 bit
  images every 4 seconds. Requires camera interface
  link rate of 200 Mbits per second.
• Data Continuity and Completeness
• HMI requirement is 99.99 of the data 95 of the
  time. In other words, we need very good data
  integrity over the 90 second observing periods,
  and we need the observables for 95 of all
  observing time.
• Timing
• The internal reference clock controlling the HMI
  observing cycle must maintain a stability of one
  part per million, and must be within 100 mS of
  the correct absolute time at all times.

5
Design Considerations

• Radiation Tolerance
• Parts must be latch up free. Parts are chosen to
  have 100K rad TID. FPGAs use TMR to avoid single
  event upsets. Possible SEU issues with Atmel
  Spacewire ASICs (SMCS332 and SMCSlite) are being
  worked.
• Cross Strapping
• Cross strapping (to improve reliability) requires
  care to insure components are properly cold
  spared.
• Power Sequencing
• The BaE Processor card requires proper sequencing
  of power supply voltages. Also, the Actel FPGAs
  require sequencing of power supply voltages to
  avoid a possible current surge problem.
• Parts Selection
• Since we are re-using past designs, replacements
  must be found for some obsolete parts (or old
  stock must be re-screened).
• De-rating
• EEE parts must be de-rated in accordance with
  EEE-INST-0002.

6
Key Trades

• HMI00195 HMI Processor Trade Study
• A trade study was conducted to determine which
  processor board best met the requirements of HMI.
  The BAE RAD6000 processor used on a previous
  program (C) was found to have more than adequate
  performance and lower risk than other choices.
  Besides this processor, we looked at a BAE
  RAD750, BAE RAD6000 (6U), Maxwell SCS750 and
  General Dynamics RH-CF5208.
• HMI00212 HMI Reliability Trade Summary
• The proposed instrument was almost entirely
  single string in nature. A trade study was
  conducted to investigate ways of enhancing the
  reliability of HMI. As a result we added
  redundant tuning mechanisms, a redundant power
  subsystem, a redundant high speed data interface,
  a redundant processor, a redundant PCI
  Bridge/1553 board and a modest amount of
  electrical cross strapping.
• Packaging
• Moved connectors to large face of box to improve
  spacing.
• Currently finalizing mechanical design to place
  I/O connectors on daughter boards to improve
  routing of traces for high speed signals
  (Spacewire).

7
Design Overiew

• Electronics are included in both the HMI
  Electronics Box (HEB) and the HMI Optics Package
  (HOP)
• HMI Electronics Box Includes
• RAD6000 Processor Board (2) Specified in 2H00016
• PCI to Local Bus Bridge 1553 Interface Board
  (2) Specified in 2H00120
• Mechanism Heater Controller Board (4)
  Specified in 2H00123
• Housekeeping Data Acquisition Board Specified in
  2H00121
• CCD Camera Interface Board (2) Specified in
  2H00124
• Data Compressor/High Rate Interface Board (2)
  Specified in 2H00125
• Image Stabilization Subsystem Specified in
  2H00122
• ISS Limb Tracker Board
• ISS PZT Driver Board
• Power Converter Subsystem Specified in 2H00119
• Optics Package Electronics include
• Oven Controller Electronics Specified in 2H00126
• Oven Controller Board (2)
• Oven Controller Pre-amp (2)
• ISS Electronics
• ISS Limb Tracker Pre-amp
• CCD Cameras

8
Top Level Block Diagram
9
HMI Electronics Box (HEB)

• Most of the HMI electronics are contained in the
  HEB
• Exceptions are Oven Controller Electronics, ISS
  Pre-amps, and CCD Camera Electronics
• Package design is currently being finalized
• I/O connectors moved to larger face to increased
  spacing and placed on daughter boards to minimize
  trace length for high speed interfaces
  (Spacewire).
• Conservative thermal design
• Conductive transfer through base.
• Power subsystem components mounted on heat sinks
  against edges at bottom of box.
• Wedge-lock on each card to insure good thermal
  contact at card edges.
• Heat sinks used where thermal analysis indicated
  necessity.
• Operating temperature range specified at 0 to 40
  deg C to maximize reliability.
• Conservative mechanical design
• Stiffeners on printed wiring boards for
  vibration.
• Walls are 0.160 in thick for radiation shielding
  (Spacecraft provides 0.040).
• Considerable heritage from MDI, TRACE, and other
  programs (C,D).

10
HEB Packaging
10.0 in H 15.2 in W 11.1 in D
11
HEB Block Diagram
12
Processor

• Same processor as previous programs (C,D)
• 2H00016 Specification for the HMI Processor Board
• Redundant cold spared processor boards
• Mass lt900 grams
• Power lt13.5 W at 20 Mhz
• Radiation gt100K rad (Si)
• SEU lt1 upset in 10 years, Latchup immune
• SRAM 4 Mbytes
• PROM 64 Kbytes
• EEPROM 512 Kbytes
• EEPROM is powered off during normal operation to
  reduce radiation damage
• Resources
• 8 External Interrupts
• 4 Programmable Interrupt/Discretes
• Quad High Speed Serial Buses
• PCI Bus

13
Processor Block Diagram
14
PCI to Local Bus Bridge

• Two redundant cards are cold spared (along with
  its associated processor).
• Specified in 2H00120
• Either card can communicate with all other cards.
• Resides on processor PCI bus
• Provides interface between the Processor card and
  other parts of the HMI electronics.
• Mechanism Heater Controllers
• Image Stabilization Subsystem
• Housekeeping Data Acquisition
• Power Converter Subsystem
• Oven Controller
• Provides On Board Clock
• System tick to Processor
• Shutter Sync
• Provides 1553B Interface to Spacecraft

15
PCI to Local Bus Bridge
16
Bridge Board Functions and Requirements

• On-Board Clock (OBC)
• 48 bit real time clock readable by the processor
  32 bits of seconds and 16 bits of sub-seconds.
• Must maintain absolute accuracy of .1 sec. May be
  maintained by adjustments from the processor at a
  maximum of once per 24 hours.
• Must latch time with signals from external
  events.
• Serial Interfaces
• Processor must control/configure oven controller
  and image stabilization system. Must maintain
  ohmic isolation (isolated grounds).
• Mechanism/heater controller must be controlled
  and status read back to the processor.
• Low bandwidth requirements.
• Power System Interface
• Processor must control relays and LEDs.
• Processor readback of relay status required.
• Keep the circuitry in the Power System as simple
  as possible.

17
Bridge Board Functions and Requirements

• Housekeeping telemetry interface
• Provides an interface for the processor to read
  analog telemetry points throughout the system.
• Must be able to read at a 2.5 Khz rate (ISS
  requirement).
• 1553 interface
• Must provide a 1553 interface between the
  spacecraft and the processor.
• Interrupts/Time ticks
• Must output a 512 hz interrupt to the processor.
• Must be synchronized with the On Board Clock.

18
Bridge Board Design

• OBC
• Clock is an adder
• LSB of clock is 2-16 seconds (15.259 µs).
• To maintain .1 sec accuracy over 24 hours
  requires adjustments of 1 part in 2-23.
• To keep count output continuous (no missing
  counts) need to clock at a 7.6294 µs rate
  requiring 1 extra bit in increment value for 24
  bits total.

19
Bridge Board Design Status

• Serial interfaces
• Re-using designs from previous programs (C,D)
• 100 khz serial clock
• 16 bit command
• 8 bit status (mechanism/heater controller only)
• Using opto-isolators for ISS and oven controller
  for return isolation
• Housekeeping telemetry interface
• Re-used design from previous program (D)
• 1553 interface
• Circuit copied from a previous program (A). Uses
  same AMBI interface chip.
• All functionality is contained in one FPGA
• RTL has been written and simulated and meets
  current requirements
• Design has been synthesized and placed and routed
  to get preliminary numbers on utilization and
  timing
• Preliminary design is complete
• Plan to have detailed review after PDR
• Open issues include the oscillator to be used for
  the OBC (stability requirements)

20
Mechanism Controllers

• Four cards of two types
• Specified in 2H00123.
• Provide Mechanism Operational Heater Interfaces
  via serial interface to Bridge card.
• Each Mechanism Controller card can communicate
  with either Bridge card.
• Redundant mechanisms interface to different
  controller cards.
• 15 Mechanisms
• Shutters (2)
• Cal/Focus Wheels (2)
• Polarization Selectors (3)
• Tuning Motors (4)
• Aperature Door Motors (2)
• Alignment Leg Motors (2)
• Operational Heaters
• Two per board (for a maximum of 8 total)

21
Mechanisms Controllers Block Diagram
22
HMI Mechanisms Controller 1 2
23
HMI Mechanisms Controller 3 4
24
Housekeeping Data Acquisition

• Single card similar to that used in previous
  program (D)
• Specified in 2H00121
• Controlled by PCI Local Bus Bridge
• Either Bridge card can control Housekeeping Data
  Acquisition (cold spare)
• The Housekeeping Data Acquisition electronics are
  contained on a single printed wiring board within
  the HMI Electronics Box. This board contains a 12
  bit analog to digital converter, signal
  conditioning amplifiers, and analog multiplexers
  for selection of various input sources.
• Status
• Currently reviewing HMI requirements with goal of
  using existing design from a previous program
  (D).
• Will need re-layout of board.

25
Housekeeping Data Acquisition
26
CCD Camera Interface

• Two boards located in the HMI Electronics Box
• Specified in 2H00124
• The HEB to CEB interface electronics are
  contained on two identical printed wiring boards
  within the HEB, one for each camera. Each board
  provides an interface for commands and
  housekeeping data between the HMI processor
  boards and a single CEB, and an interface for
  science data between a single CEB and either of
  two Data Compression/High Rate Interface boards.
• Commands and status data are passed between
  either Processor card and the CCD Camera
  Interface via a High Speed Serial (HSS) Bus in
  Programmed I/O mode (DMA is not used). HSS words
  are used either to configure the SMCSlite, or are
  passed as Spacewire (IEEE 1355) packets by the
  SMCSlite to the CEB. Status and/or housekeeping
  packets from the CEB are passed to either
  Processor A or B after conversion to HSS protocol
  by the Control and Interface Logic.
• CCD camera data (4K x 4K x 16 bits) is
  transferred as a single Spacewire packet from the
  CEB to the SMCSlite, and then to buffer memory on
  the CCD Interface Card. CCD pixels, which are
  read from each corner of the CCD and interleaved
  in the Spacewire packet, are deconvolved by the
  control and interface logic and stored in the
  buffer memory. Data in the buffer memory may be
  read by either of the two Compressor/High Rate
  Interface Cards.
• Status
• Currently developing detailed specification.

27
CCD Camera Interface
28
Compressor/Spacecraft HSB Interface

• Two boards located in HMI Electronics Box
• Specified in 2H00125
• The Data Compression and Spacecraft High Rate
  Interface (DC/HRI) electronics are contained on
  two identical printed wiring boards within the
  HMI Electronics Box (HEB). Each board provides an
  interface for commands and header data from
  either HMI processor board, an interface from
  either of two CCD Camera Interface boards, and
  interfaces for high rate science data to either
  of two Spacecraft High Rate Interfaces. Either
  board is capable of performing lossless data
  compression, formatting into CCSDS packets, and
  outputting of science data at the full data rate
  allocated to HMI (55 Mbits/sec).
• Commands, status and header data are passed
  between either Processor card and the
  Compressor/High Rate Interface card via a High
  Speed Serial (HSS) Bus in Programmed I/O mode
  (but DMA may be used for table loads). HSS words
  are used to configure the Interface Control and
  Compression Logic, to initialize and control the
  SMCS, or to load header data into the output
  Buffer Memory.
• Status
• Currently developing detailed specification

29
Compressor/Spacecraft HR Interface
30
Power Converter Subsystem

• Redundant power converters are located within the
  HMI Electronics Box
• Specified in 2H00119
• The HEB power electronics is designed to perform
  two primary functions convert 28V from the S/C
  to secondary voltages used by the instrument and
  route power to the proper HMI sub-system.
• The HEB power electronics is powered by either of
  four spacecraft (S/C) bus inputs, Bus A, Bus A,
  Bus B and Bus B. The S/C 28V is converted into
  operating voltages for the HEB, the optics
  package and the Instrument Stabilization System
  (ISS).
• The HEB power electronics switches 28V primary to
  the two camera sub-systems and the
  decontamination heaters. Secondary power is
  routed via latching relays to the mechanisms
  controllers, oven controllers, operational
  heaters as well as the HEB computer. The power
  electronics secondary voltages consist of 3.3V,
  5V, 15V and -15V, 72V, 15V operational
  heater power and 15V mechanisms power.
• Key Design requirements
• The HMI Power Electronics shall be a redundant
  system.
• The HMI Power Electronics shall not be damaged by
  simultaneous application of power from the S/C
  primary and redundant bus.
• The HMI Power Electronics secondary power and
  return lines shall be isolated from the primary
  power and return lines by gt/ 1 Megohm.
• HMI Electronics shall meet EMC, grounding and
  radiation requirements specified in the SDO
  Electrical System Specification.

31
Power Converter Subsystem
32
Power Converter Subsystem

• Design considerations
• Cross-strapping the Power Electronics supplies
  such that the primary supply could supply power
  to either the primary or redundant HMI subsystem
  The study concluded that implementing
  cross-strapping without discrete commands from
  the S/C would cause the design of the Power
  Electronics to become very complex and would
  lower the reliability of the system.
• Using mechanical relays versus solid state
  switches to route power to the HMI subsystems
• Mechanical latching relays will allow SP/DT
  functionality needed for the 3.3V power supply
  and the decontamination heaters. The board design
  is much simpler and uses less parts with the
  mechanical relays. Mechanical relays are
  unaffected by the radiation environment.
• Designing an in-rush current limiter into the
  power electronics The rise time of the S/C SSPC
  will allow the HMI instrument to meet the in-rush
  current specification without in-rush current
  limiting.
• Status
• First draft specification complete.
• Parts selection complete.
• Preliminary layout complete.

33
Oven Controller

• Two redundant Controller boards and two redundant
  pre-amp boards located in the HMI optics package
• Specified in 2H00126
• The HMI Oven Controller is an updated version of
  the MDI Primary Oven Controller. It has two
  identical redundant controllers, with redundant
  heater elements, temperature sensors and
  pre-amplifiers. The oven controller electronics
  are located in the HMI Optics Package, and
  interface with the PCI/Local Bus Bridge board and
  the Power Converter Subsystem in the HMI
  Electronics Box.
• Electronics are thermally coupled to oven to
  enhance stability.
• Operating temperature range 28 - 35 deg C
• Temperature accuracy 0.5 deg C
• Temperature stability 0.01 deg C per hour
• Status
• Selection of key parts complete.
• Preliminary layout complete.
• Design update in progress

34
Oven Controller
35
Image Stabilization System

• Two boards (Limb Tracker and PZT Driver) located
  in the HMI Electronics Box, plus pre-amp and
  sensor boards located in the Optics Package
• Specified in 2H00122
• The HMI Image Stabilization System (ISS) is a
  closed loop system with a tip-tilt mirror to
  remove jitter measured at a primary image within
  HMI. This system is based on the MDI ISS limb
  sensor, mirror and servo loop.
• Interfaces to the PCI Local Bus Bridge, the
  Housekeeping Data Acquisition board, and the
  Power Subsystem.
• Status
• Selection of key parts complete.
• Preliminary layout complete.
• Design update in progress

36
Test Plan Open Issues

• Breadboard
• Plan to build limited version of backplane and
  one PCI Bridge/1553 board to support early start
  to software development
• Brassboard
• Plan to build brass board system with at least
  one of each type of board for design verification
• Brass board is then used for flight board testing
  and software development.
• During initial phase of integration, brass board
  electronics may be shared between flight board
  testing, software development, and flight system
  integration.
• Open Issues
• Need to finalize HEB packaging and board layouts.
• SEU testing of Atmel SMCSlite.
• Need to resolve issues involving use of SDRAM on
  CCD Interface board (SEU mitigation).
