A better understanding of Solar SSR

1
A better understanding of Solar SSR
Solar Building Integrated Photovoltaic (BIPV)
for Standing Seam AND Exposed Fastener Roof
Systems
2

• The Solar SSR System
• Total system working together to harvest power
• Standing seam applications
• Exposed fastener applications
• System sizes
• System costs
• Fabrals offering

3
Total System
On grid system is shown Off grid systems
require battery storage between DC Disconnect and
Inverter
4
The Total System Working together to harvest
power.

• Triple-junction technology captures three wave
  lengths (red, green/yellow and blue) of sunlight
• Panels are electrically daisy-chained together to
  maximize output
• Power is converted from DC to AC and is
  returned to the grid
• Optional Data Acquisition System provides
  real-time analysis of energy production

5
The Total System

• The Solar SSR panels are
• Highly flexible, lightweight and durable
• More efficient at producing electricity than
  alternative polycrystalline solar technology,
  especially in shadows and/or low light
• Efficient up to 185F
• A peel and stick back

6
The Total System

• No roof penetrations to install
• Eliminates additional structural support
  requirements
• Maintains serviceability and walkability of the
  roof
• Roof slopes between 112 and 2112
• Curving is permitted
• Tested to very high hail and wind resistance
  ratings extremely durable
• Extremely light weight at 0.75 psf

7
Standing Seam Applications

• Can be applied to existing metal roofs or new
  standing seam panels
• Standing Seam panels must be at least 16 seam to
  seam
• Fabral Enduracote and Flurobond paint systems
  are approved
• Solar SSR panels are field installed can be
  adhered prior or post to installing standing seam
  panels

8
Standing Seam Panel profile options
Architectural/Commercial
Post Frame/Residential
9
Exposed Fastener Applications -A PATENT PENDING
APPLICATION -

• BIVP solar thin film laminates can be adhered to
  hemmed flat sheets that are one foot longer than
  the solar panels
• Flat sheets are then attached over exposed
  fastener systems

10
Solar Panels on Grandrib 3Note panels shown
much shorter than actual length to get all
details on drawing
11
Solar Panels on Grandrib 3 PV Wires Under Ridge
Cap
12
Transparent Drawing Showing Wires Under Ridge Cap
Solar Panels on Grandrib 3
13
Baffling Material Under Flat Plate
Solar Panels on Grandrib 3
14
System Sizes

• Wide range of power sizes to choose from,
  depending upon budget and building requirements.
• Standard system sizes 1.5, 3, 5, 10, 15, 30, 60,
  120 and 240 Kw
• The system requires approximately 600 s.f. for 3
  kW

15
Watts?
Watt Unit of power Volt x Amp Watt Hour
Unit of energy equal to 1 watt of power operating
for one hour. 1,000 W (watt) 1 kW (Kilowatt)
5kW system x 1hour 5 kW-h Average 3.5-4 hours
a day of 100 efficiency Average day5kW system
x 3.8 hours 18 kW-h / Day
18kW-h will light 7.5 100w light bulbs for 24
hours
16
Typical Power Production Percentages

• Commercial buildings 11.7 17.4 kWh per sq.ft.
  floor area
• Residential buildings Average house uses 11,000
  kWh per year
• 5kW system produces approximately 5,000 8,000
  kWh per year
• 1.5kW Pennsylvania 2,020 kWh / yr
• 3kW Virginia 4,077 kWh / yr
• 5kW Washington 6,389 kWh / yr
• 5kW N. Carolina 6,939 kWh / yr
• 5kW N. Carolina 7,201 kWh / yr
• 5kW Pennsylvania 6,753 kWh / yr
• 10kW Wisconsin 12,155 kWh / yr
• 15kw Wisconsin 18,215 kWh / yr

17
Solar SSR
Other Factors

• Azimuth angle (direction the roof faces, SE, S,
  SW, etc)
• South or SW is often considered the best
• Sunlight
• Shade
• Snow cover
• Module/Panel Width 15.5 PV width
• 16 SSR most efficient
• 18 20 SSR wasted space

18
What Fabral Sells

• Fabral sells
• Solar SSR panels
• Cable Trays
• Cable Tray Covers
• Rubber Grommets
• S-5! Mini Clamps
• Our customers must obtain the other components
  themselves
• We provide suggested manufacturers and contacts
  to call

19
System Costs

• Total estimated system price
• (less the metal roof)
• 3kw (rated DC, 3.264kw) 25,786
• 5kw (rated DC, 5.44kw) 41,344

20
Installation

• Metal panels must be clean and smooth with no
  stiffening ribs, striations or embossing
• Thin-film solar laminate is adhered directly onto
  the exposed face of the SSR panel in the field or
  shop in temperatures between 50 and 100F before
  roof installation
• Video available online

21
Installation

• Fabral specifications clearly outline the scope
  of work and installation responsibilities
• Fabral manufactures and delivers the entire
  system to specification
• The system is installed in two steps
• The BIPV roofing panels by the trained roofing
  contractor
• The electrical system by the electrical
  subcontractor

22
Warranty

• The Fabral Solar SSR system comes with a
  Fabral/EnergyPeak 25-year manufacturers
  warranty
• 25 Years

23
ROI

• The perfect start
• Can be processed via paper or online at
  www.fabral.com/ROI.php
• Calculations are available for all power size
  options
• All current federal rebates, state and local
  incentives, utility provider incentives,
  renewable energy credits and depreciation are
  shown
• ROI well under 10 years is common
• About 7 days for results

24
Tax Credit Advantages
30 Solar IRS tax credit is available on PV
systems - Extended through 2016 - Previous cap
on residential PV systems has been REMOVED,
significantly increasing the tax incentives for
residential applications - Many state and local
utility rebates exist PLUS dont forget -
Homeowner Energy Credit of 30 for projects using
metal roofing meeting ENERGY STAR (cool colors)
requirements - Maximum credit is 1500 - Does
not include installation costs - Must be
installed during 2009 or 2010
25
Drawings Specifications

• Fabral will supply all required AutoCad drawings,
  electrical schematics and Masterspec
  specifications for both the electrical and
  roofing sections
• Electrical schematics and specifications should
  be given to the electrical engineer for review

26
A better understanding of Solar SSR
Solar Building Integrated Photovoltaic (BIPV)
for Standing Seam AND Exposed Fastener Roof
Systems
