From Data to Differential Equations

1
From Data to Differential Equations

• Jim Ramsay
• McGill University
• With inspirations from
• Paul Speckman and Chong Gu

2
The themes

• Differential equations are powerful tools for
  modeling data.
• We have new methods for estimating differential
  equations directly from data.
• Some examples are offered, drawn from chemical
  engineering and medicine.

3
Differential Equations as Models

• DIFES make explicit the relation between one or
  more derivatives and the function itself.
• An example is the harmonic motion equation

4
Why Differential Equations?

• The behavior of a derivative is often of more
  interest than the function itself, especially
  over short and medium time periods.
• How rapidly a system responds rather than its
  level of response is often what matters.
• Velocity and acceleration can reflect energy
  exchange within a system. Recall equations like f
  ma and e mc2.

5

• Natural scientists often provide theory to
  biologists and engineers in the form of DIFEs.
• Many fields such as pharmacokinetics and
  industrial process control routinely use DIFEs
  as models.
• Especially for input/output systems, and for
  systems with two or more functional variables
  mutually influencing each other.
• DIFEs arise when feedback systems must be
  developed to control the behavior of systems.

6

• The solution to an mth order linear DIFE is an
  m-dimensional function space, and thus the
  equation can model variation over replications as
  well as average behavior.
• A DIFE requires that derivatives behave smoothly,
  since they are linked to the function itself.
• Nonlinear DIFEs can provide compact and elegant
  models for systems exhibiting exceedingly complex
  behavior.

7
The Rössler Equations

• This nearly linear system exhibits chaotic
  behavior that would be virtually impossible to
  model without using a DIFE

8
Stochastic DIFEs

• We can introduce randomness into DIFEs in many
  ways
• Random coefficient functions.
• Random forcing functions.
• Random initial, boundary, and other constraints.
• Time unfolding at a random rate.

9
Deliverables

• If we can model data on functions or functional
  input/output systems, we will have a modeling
  tool that greatly extends the power and scope of
  existing nonparametric curve-fitting techniques.
• We may also get better estimates of functional
  parameters and their derivatives.

10
A simple input/output system

• We begin by looking at a first order DIFE for a
  single output function x(t) and a single input
  function u(t). (SISO)
• But our goal is the linking of multiple inputs to
  multiple outputs (MIMO) by linear or nonlinear
  systems of arbitrary order m.

11

• u(t) is often called the forcing function, and
• is an exogenous functional independent
• variable.
• Dx(t) -ß(t)x(t) is called the homogeneous
• part of the equation.
• a(t) and ß(t) are the coefficient functions
• that define the DIFE.
• The system is linear in these coefficient
• functions, and in the input u(t) and output
• x(t).

12
In this simple case, an analytic solution is
possible
However, it is necessary to use numerical
methods to find the solution to most DIFES.
13
A simpler constant coefficient example

• We can see more clearly what happens when
• the coefficients a and ß are constants,
• a 1, x0 0, and
• u(t) is a step function, stepping from 0 to 1 at
  time t1

14

• Constant a/ß is the gain in the system.
• Constant ß controls the responsivity of the
  system to a change in input.

15
A Real Example Lupus treatment

• Lupus is an incurable auto-immune disease that
  mainly afflicts women.
• It flares unpredictably, inflicting wide damage
  with severe symptoms.
• The treatment is prednisone, an immune system
  suppressant used in transplants.
• But prednisone has serious short- and long-term
  side affects, and exposure to it must be
  controlled.

16
(No Transcript)
17
How to Estimate a Differential Equation from Raw
Data

• A previous method, principal differential
  analysis, first smoothed the data to get
  functions x(t) and u(t), and then estimated the
  coefficient functions defining the DIFE.
• This two-stage procedure is inelegant and
  probably inefficient. Going directly from data
  to DIFE would be better.

18
Profile Least Squares

• The idea is to replace the function fitting the
  raw data, x(t), by the equations defining the fit
  to the data conditional on the DIFE.
• Then we optimize the fit with respect to only the
  unknown parameters defining the DIFE itself.
• The fit x(t) is defined as a by-product of the
  process, but does not itself require additional
  parameters.

19

• This profiling process is often used in nonlinear
  least squares problems where some parameters are
  easily solved for given other parameters.
• There we express the conditional estimates of the
  these easy-to-estimate parameters as functions of
  the unknown hard-to-estimate parameters, and
  optimize only with respect to the hard
  parameters.
• This saves both computational time and degrees of
  freedom.
• An alternative strategy is to integrate over the
  easy parameters, and optimize with respect to the
  hard ones this is the M-step in the EM
  algorithm.

20
The DIFE as a linear differential operator

• We can re-express the first order DIFE as a
  linear differential operator

More compactly, suppressing (t), and making
explicit the dependency of L on a and ß,
21
Smoothing data with the operator L

• If we know the differential equation, then the
  differential operator L defines a data smoother
  (Heckman and Ramsay, 2000).
• The fitting criterion is

The larger ? is, the more the fitting function
x(t) is forced to be a solution of the
differential equation Laßx(t) 0.
22

• Let x(t) be expanded in terms of a set K basis
  functions fk(t),

• Let N by K matrix Z contain the values of these
  basis functions at time points ti , and
• Let y be the vector of raw data.

23

• Then the smooth values have the expression Zc,
• where c is the vector of coefficients.
• But these coefficients are easy parameters to
  estimate given operator Laß . The expression for
  them is

• We therefore remove parameter vector c by
• replacing it with the expression above.

24
How to estimate L

• L is a function of weight coefficients a(t) and
  ß(t).
• If these have the basis function expansions

then we can optimize the profiled error sum of
squares
with respect to coefficient vectors a and b.
25

• It is also a simple matter to
• constrain some coefficient functions to be zero
  or a constant.
• force some coefficient functions to be smooth,
  employing specific linear differential operators
  to smooth them towards specific target spaces.
  We do this by appending penalties to SSE(a,b),
  such as

where M is a linear differential operator for
penalizing the roughness of ß.
26
And more

• This approach is easily generalizable to
• DIFEs and differential operators of any order.
• Multiple inputs uj(t) and outputs xi(t).
• Replicated functional data.
• Nonlinear DIFEs and operators.

27
Adaptive smoothing

• We can also use this approach to have the level
  of smoothing vary. We modify the differential
  operator as follows

The exponent function ?(t) plays the role of a
log ? that varies with t.
28

• Choosing the smoothing parameter ? is always a
  delicate matter.
• The right value of ? will be rather large if the
  data can be well-modeled by a low-order DIFE.
• But it should not so large as to smooth away
  additional functional variation that may be
  important.
• Estimating ? by generalized cross-validation
  seems to work reasonably well, at least for
  providing a tentative value to be explored
  further.

29
A First Example

• The first example simulates replicated data where
  the true curves are a set of tilted sinusoids.
• The operator L is of order 4 with constant
  coefficients.
• How precisely can we estimate these coefficients?
• How accurately can we estimate the curves and
  first two derivatives?

30

• For replications i1,,N and time values j1,,n,
  let

where the ciks and the eijs are N(0,1) and t
0(0.01)1. The functional variation satisfies
the differential equation
where ß0(t) ß1(t) ß3(t)0 and ß2(t) (6p)2
355.3.
31
(No Transcript)
32

• For simulated data with N 20 replications and
  constant bases for ß0(t) ,, ß3(t), we get
• L D4 best results are for ?10-10 and the
  RIMSEs for derivatives 0, 1 and 2 are 0.32, 9.3
  and 315.6, respectively.
• L estimated best results are for ?10-5 and the
  RIMSEs are 0.18, 2.8, and 49.3, respectively.
• giving precision ratios of 1.8, 3.3 and 6.4,
  resp.
• ß2 was estimated as 353.6 whereas the true value
  was 355.3.
• ß3 was 0.1, with true value 0.0.

33
(No Transcript)
34

• In addition to better curve estimates and much
  better derivative estimates, note that the
  derivative RMSEs do not go wild at the end
  points, which is usually a serious problem with
  polynomial spline smoothing.
• This is because the DIFE ties the derivatives to
  the function values, and the function values are
  tamed at the end points by the data.

35
A decaying harmonic with a forcing function

• Data from a second order equation defining
  harmonic behavior with decay, forced by a step
  function, is generated by
• ß0 4.04, ß1 0.4, a -2.0.
• u(t) 0, t lt 2p, u(t) 1, t 2p.
• Adding noise with std. dev. 0.2.

36
(No Transcript)
37
With only one replication, using minimum
generalized cross-validation to choose ?, the
results estimated for 100 trials are
Parameter True Value Mean Estimate Std. Error
ß0 4.040 4.041 0.073
ß1 0.400 0.397 0.048
a -2.000 -1.998 0.088
38
An oil refinery example

• The single input is reflux flow and the output
  is tray 47 level in a distillation column.
• There were 194 sampling points.
• 30 B-spline basis functions were used to fit the
  output, and a step function was used to model the
  input.

39
(No Transcript)
40

• After some experimentation with first and second
  order models, and with constant and varying
  coefficient models, the clear conclusion seems to
  be the constant coefficient model

The standard errors of ß and a in this model,
as estimated by parametric bootstrapping,
were 0.0004 and 0.0023, respectively. The delta
method yielded 0.0004 and 0.0024,
respectively. Pretty much the same.
41
(No Transcript)
42
Monotone smoothing

• Some constrained functions can be expressed as
  DIFEs.
• A smooth strictly monotone function can be
  expressed as the second order DIFE

43

• We can monotonically smooth data by estimating
  the second order DIFE directly.
• We constrain ß0(t) 0, and give ß1(t) enough
  flexibility to smooth the data.
• In the following artificial example, the
  smoothing parameter was chosen by generalized
  cross-validation. ß1(t) was expanded in terms of
  13 B-splines.

44
(No Transcript)
45
(No Transcript)
46
Analyzing the Lupus data

• Weight function ß(t) defining an order 1 DIFE for
  symptoms estimated with and without prednisone
  dose as a forcing function.
• Weight expanded using B-splines with knots at
  every observation time.
• Weight a(t) for prednisone is constant.

47
The forced DIFE for lupus
48
The data fit
49

• Adding the forcing function halved the LS fitting
  criterion being minimized.
• We see that the fit improves where the dose is
  used to control the symptoms, but not where it is
  not used.
• These results are only suggestive, and much more
  needs to be done.
• We want to model treatment and symptom as
  mutually influencing each other. This requires a
  system of two differential equations.

50
Summary

• We can estimate differential equations directly
  from noisy data with little bias and good
  precision.
• This gives us a lot more modeling power,
  especially for fitting input/output functional
  data.
• Estimates of derivatives can be much better,
  relative to smoothing methods.
• Functions with special properties such as
  monotonicity can be fit by estimating the DIFE
  that defines them.
