Statistical significance

1
Statistical significance
P-values
Analytic Decisions
2
Where we are

• Thus far weve covered
• Measures of Central Tendency
• Measures of Variability
• Z-scores
• Frequency Distributions
• Graphing/Plotting data
• All of the above are used to describe individual
  variables
• Tonight we begin to look into analyzing the
  relationship between two variables

3
However

• As soon as we begin analyzing relationships, we
  have to discuss statistical significance, RSE,
  p-values, and hypothesis testing
• Descriptive statistics do NOT require such
  things, as we are not testing theories about
  the data, only exploring
• You arent trying to prove something with
  descriptive statistics, just show something
• These next few slides are critical to your
  understanding of the rest of the course please
  stop me for questions!

4
Hypotheses

• Hypothesis - the prediction about what will
  happen during an experiment or observational
  study, or what researchers will find.
• Examples
• Drug X will lower blood pressure
• Smoking will increase the risk of cancer
• Lowering ticket prices will increase event
  attendance
• Wide receivers can run faster than linemen

5
Hypotheses

• Example
• Wide receivers can run faster than linemen
• However, keep in mind that our hypothesis might
  be wrong and the opposite might be true
• Wide receivers can NOT run faster than linemen
• So, each time we investigate a single hypothesis,
  we actually test two, competing hypotheses.

6
Hypothesis testing

• HA Wide receivers can run faster than linemen
• This is what we expect to be true
• This is the alternative hypothesis (HA)
• HO Wide receivers can NOT run faster than
  linemen
• This is the hypothesis we have to prove wrong
  before our real hypothesis can be correct
• The default hypothesis
• This is the null hypothesis (HO)

7
Hypothesis Testing

• Every time you run a statistical analysis
  (excluding descriptive statistics), you are
  trying to reject a null hypothesis
• Could be very specific
• Men taking Lipitor will have a lower LDL
  cholesterol after 6 weeks compared to men not
  taking Lipitor
• Men taking Lipitor will have a similar LDL
  cholesterol after 6 weeks compared to men not
  taking Lipitor (no difference)
• or very simple (and non-directional)
• There is an association between smoking and
  cancer
• These is not an association between smoking and
  cancer

8
Why null vs alternative?

• All statistical tests boil down to
• HO vs. HA
• We write and test our hypothesis in this
  competing fashion for several reasons, one is
  to address the issue of random sampling error
  (RSE)

9
Random Sampling Error

• Remember RSE?
• Because the group you sampled does NOT EXACTLY
  represent the population you sampled from (by
  chance/accident)
• Red blocks vs Green blocks
• Always have a chance of RSE
• All statistical tests provide you with the
  probability that sampling error has occurred in
  that test
• The odds that you are seeing something due to
  chance (RSE)
• vs
• The odds you are seeing something real (a real
  association or real difference between groups)

10
Summary so far

• 1- Each time we use a statistical test, there
  are two competing hypotheses
• HO Null Hypothesis
• HA Alternative Hypothesis
• 2- Each time we use a statistical test, we have
  to consider random sampling error
• The result is due to random chance (RSE, bad
  sample)
• The result is due to a real difference or
  association

These two things, 1 and 2, are interconnected
and we have to consider potential errors in our
decision making
11
Examples of Competing Hypotheses and Error

• Suppose we collected data on risk of death and
  smoking
• We generate our hypotheses
• HA Smoking increases risk of death
• HO Smoking does not increase risk of death
• Now we go and run our statistical test on our
  hypotheses and need to make a final decision
  about them
• But, due to RSE, there are two potential errors
  we could make

12
Error

• There are two possible errors
• Type I Error
• We could reject the null hypothesis although it
  was really true
• HA Smoking increases risk of death (FALSE)
• HO Smoking does not increase risk of death
  (TRUE)
• This error led to unwarranted changes. We went
  around telling everyone to stop smoking even
  though it didnt really harm them

OR
13
Error

• Type II Error
• We could fail to reject the null hypothesis when
  it was really untrue
• HA Smoking increases risk of death (TRUE)
• HO Smoking does not increase risk of death
  (FALSE)
• This error led to inaction against a preventable
  outcome (keeping the status quo). We went around
  telling everyone to keeping smoking while it
  killed them

OR
14

• HA Smoking increases risk of death
• HO Smoking does not increase risk of death

There are really 4 potential decisions, based on what is true and what we decide There are really 4 potential decisions, based on what is true and what we decide Our Decision Our Decision
There are really 4 potential decisions, based on what is true and what we decide There are really 4 potential decisions, based on what is true and what we decide Reject HO Accept HO
What is True HO Type I Error Unwarranted Change Correct
What is True HA Correct Type II Error Kept Status Quo
1
2
3
4
Questions?
15
Random Sampling error
Kent Brockman Mr. Simpson, how do you respond to
the charges that petty vandalism such as graffiti
is down eighty percent, while heavy sack beatings
are up a shocking nine hundred percent? Homer
Simpson Aw, you can come up with statistics to
prove anything, Kent. Forty percent of all people
know that.
16
Example of RSE

• RSE is the fact that - each time you draw a
  sample from a population, the values of those
  statistics (Mean, SD, etc) will be different to
  some degree
• Suppose we want to determine the average points
  per game of an NBA player from 2008-2009
  (population parameter)
• If I sample around 30 players 3 times, and
  calculate their average points per game Ill end
  up with 3 different numbers (sample statistics)
• Which 1 of the 3 sample statistics is correct?

17
8 random samples of 10 of population Note the
varying Mean and SD this is RSE!
18
Knowing this

• The process of statistics provides us with a
  guide to help us minimize the risk of making Type
  I/Type II errors and RSE
• Statistical significance
• Recall, random sampling error is less likely
  when
• You draw a larger sample size from the population
  (larger n)
• The variable you are measuring has less variance
  (smaller standard deviation)
• Hence, we calculate statistical significance with
  a formula that incorporates the sample size, the
  mean, and the SD of the sample

19
Statistical Significance

• All statistical tests (t-tests, correlation,
  regression, etc) provide an estimate of
  statistical significance
• When comparing two groups (experimental vs
  control) how different do they need to before
  we can determine if the treatment worked?
  Perhaps any difference is due to the random
  chance of sampling (RSE)?
• When looking for an association between 2
  variables how do we know if there really is an
  association or if what were seeing is due to the
  random chance of sampling?
• Statistical significance puts a value on this
  chance

20
Statistical Significance

• Statistical significance is defined with a
  p-value
• p is a probability, ranging from near 0 to near1
• Assuming the null hypothesis is true, p is the
  probability that these results could be due to
  RSE
• If p is small, you can be more confident you are
  looking at the reality (truth)
• If p is large, its more likely any differences
  between groups or associations between variables
  are due to random chance
• Notice there are no absolutes here never 100
  sure

21
Statistical Significance

• All analytic research estimates statistical
  significance but this is different from
  importance
• Dictionary definition of Significance
• The probability the observed effect was caused by
  something other than mere chance (mere chance
  RSE)
• This does NOT tell you anything about how
  important or meaningful the result is!
• P-values are about RSE and statistical
  interpretation, not about how significant your
  findings are

22
Example

• Tonight well be working with NFL combine data
• Suppose I want to see if WRs are faster than
  OLs
• Compare 40-yard dash times
• Ill randomly select a few cases and run a
  statistical test (in this case, a t-test)
• The test will provide me with the mean and
  standard deviation of 40 yard dash times along
  with a p-value for that test

23
Results
Position Mean 40yd (seconds) SD p-value
WR 4.52 0.12 0.02
OL 5.32 0.25

• HA WR are faster than linemen
• HO WR are not faster than linemen
• WR are faster than linemen, by about 0.8 seconds
• With a p-value so low, there is a small chance
  this difference is due to RSE

24
Results
HO WR are not faster than linemen
Position Mean 40yd (seconds) SD p-value
WR 4.52 0.12 0.02
OL 5.32 0.25

• WR are faster than linemen, by about 0.8 seconds
• If the null hypothesis was true, and we drew more
  samples and repeated this comparison 1,000 times,
  we would expect to see a difference of 0.8
  seconds or larger only 20 times out of 1,000 (2
  of the time)
• Unlikely this is NOT a real difference (low prob
  of Type I error)

25
ExampleAGAIN

• Suppose I want to see if OGs are faster than
  OTs
• Compare 40-yard dash times
• Ill randomly select a few cases and run a
  statistical test
• The test will provide me with the mean and
  standard deviation of 40 yard dash times along
  with a p-value for that test

26
Results
Position Mean 40yd (seconds) SD p-value
OG 5.33 0.14 0.57
OT 5.42 0.16

• HA OG are faster than OT
• HO OG are not faster than OT
• OG are faster than OT, by about 0.1 seconds
• With a p-value so high, there is a high chance
  this difference is due to RSE (OG arent really
  faster)

27
Results
HO OG are not faster than OT
Position Mean 40yd (seconds) SD p-value
OG 5.33 0.14 0.57
OT 5.42 0.16

• OG are faster than OT, by about 0.1 seconds
• If the null hypothesis was true, and we drew more
  samples and repeated this comparison 1,000 times,
  we would expect to see a difference of 0.1
  seconds or larger 570 times out of 1,000 (57 of
  the time)
• Unlikely this is a real difference (high prob of
  Type I error)

28
Alpha

• However, this raises the question, How small a
  p-value is small enough?
• To conclude there is a real difference or real
  association
• To remain objective, researchers make this
  decision BEFORE each new statistical test (p is
  set a priori)
• Referred to as alpha, a
• The value of p that needs to be obtained before
  concluding that the difference is statistically
  significant
• p lt 0.10
• p lt 0.05
• p lt 0.01
• p lt 0.001

29
p-values

• WARNINGS
• A p-value of 0.03 is NOT interpreted as
• This difference has a 97 chance of being real
  and a 3 chance of being due to RSE
• Rather
• If the null hypothesis is true, there is a 3
  chance of observing a difference (or association)
  as large (or larger)
• p-values are calculated differently for each
  statistic (t-test, correlations, etc) just
  know a p-value incorporates the SD (variability)
  and n (sample size)
• SPSS outputs a p-value for each test
• Sometimes its 0.000 in SPSS but that is NOT
  true
• Instead report as p lt 0.001

30
SLIDE
31
Correlation

• Association between 2 variables

32
The everyday notion of correlation

• Connection
• Relation
• Linkage
• Conjunction
• Dependence
• and the ever too ready cause

NY Times, 10/24/ 2010 Stories vs. Statistics By
JOHN ALLEN PAULOS
33
Correlations

• Knowing p-values and statistical significance,
  now we can begin analyzing data
• Perhaps the most often used stat with a p-value
  is the correlation
• Suppose we wished to graph the relationship
  between foot length and height of 20 subjects
• In order to create the scatterplot, we need the
  foot length and height for each of our subjects.

34
Scatterplot

• Assume our first subject had a 12 inch foot and
  was 70 inches tall.
• Find 12 inches on the x-axis.
• Find 70 inches on the y-axis.
• Locate the intersection of 12 and 70.
• Place a dot at the intersection of 12 and 70.

35
Scatterplot
Height
Foot Length
36
Scatterplot

• Continue to plot each subject based on x and y
• Eventually, if the two variables are related in
  some way, we will see a pattern

37
A Pattern Emerges

• The more closely they cluster to a line that is
  drawn through them, the stronger the linear
  relationship between the two variables is (in
  this case foot length and height).
• Envelope

Height
Foot Length
38
Describing These Patterns

• If the points have an upward movement from left
  to right, the relationship is positive
• As one increases, the other increases (larger
  feet gt taller people smaller feet gt shorter
  people)

39
Describing These Patterns

40
Describing These Patterns

• If the points on the scatterplot have a downward
  movement from left to right, the relationship is
  negative.
• As one increases, the other decreases (and visa
  versa)

41
Strength of Relationship

• Not only do relationships have direction
  (positive and negative), they also have strength
  (from 0.00 to 1.00 and from 0.00 to 1.00).
• Also known as magnitude of the relationship
• The more closely the points cluster toward a
  straight line, the stronger the relationship is.

42
Pearsons r

• For this procedure, we use Pearsons r
• aka Pearson Product Moment Correlation
  Coefficient
• What calculations go into this calculation?
  Recognize them?

43
Pearsons r

• As mentioned, correlations like Pearsons r
  accomplish two things
• Explain the direction of the relationship between
  2 variables
• Positive vs Negative
• Explain the strength (magnitude) of the
  relationship between 2 variables
• Range from -1 to 0 to 1
• The closer to 1 (positive or negative), the
  stronger it is

44
Strength of Relationship

• A set of scores with r 0.60 has the same
  strength as a set of scores with r 0.60
  because both sets cluster similarly.

45
(No Transcript)
46
Statistical Assumptions

• From here forward, each new statistic we discuss
  will have its own set of assumptions
• Statistical assumptions serve as a checklist of
  items that should be true in order for the
  statistic to be valid
• SPSS will do whatever you tell it to do you
  have to personally verify assumptions before
  moving forward
• Kind of like being female is an assumption of
  taking a pregnancy test
• If you arent female you can take one but
  its not really going to mean anything

47
Assumptions of Pearsons r

• 1) The measures are approximately normally
  distributed
• Avoid using highly skewed data, or data with
  multiple modes, etc, should approximate that
  bell curve shape
• 2) The variance of the two measures is similar
  (homoscedasticity) -- check with scatterplot
• See upcoming slide
• 3) The sample represents the population
• If your sample doesnt represent your target
  population, then your correlation wont mean
  anything
• These three assumptions are pretty much critical
  to most of the statistics well learn about (not
  unique to correlation)

48
Homoscedasticity

• Homoscedasticity is the assumption that the
  variability in scores for one variable is roughly
  the same at all values of the other variable
• Heteroscedasticitydissimilar variability across
  values ex. income vs. food consumption (income
  is highly variable and skewed, but food
  consumption is not

49
NBA Data Heteroscedasticity Example
50
Note how variable the points are, especially
towards one end of the plot
51
NFL Data Homoscedasticity Example
52
Here, the variance appears to be equal across the
entire range of scores
53
Two more (most) critical assumptions for r

• 4) The relationship is linear
• Cant use variables that have a curvilinear
  relationship
• Check with scatterplot (like last week), plotting
  is always the first step!
• 5) The variables are measured on a interval or
  ratio scale (continuous variables)
• No nominal or ordinal data
• Cant correlate body weight with gender (even if
  its coded as a number!)

54
Linear correlations cant inform you about
non-linear relationships
55
Strength of Association - r
Describing and/or comparing multiple correlations
can be difficult. However, there are standards
to use

• High (Strong) 0.85 - 1.0
• Moderately-High 0.60 - 0.85
• Moderate 0.30 - 0.60
• Low 0.00 - 0.30
• (R.M. Malina C. Bouchard, 1991)

Correlations are generally reported with two or
three digits past the decimal (as 0.57 or
0.568) Most use 2, just make sure you are
consistent
56
Research Questions

• Typical research questions that can be answered
  through correlation
• What is the relationship between GRE scores and
  graduate school GPA?
• What is the relationship between athletic
  performance and admissions applications in
  college athletics?
• What is the relationship between BF and blood
  pressure?

57
Research Questions

• Typical research questions that can be answered
  through correlation (continued)
• What is the relationship between throwing
  mechanics and shoulder distraction in
  professional baseball pitchers?
• What is the relationship between certain baseball
  statistics (batting average, on-base percentage,
  etc) and runs scored?

58
Correlations and causality

• WARNING on correlations
• Correlations only describe the relationship, they
  do not prove causation (that variable A causes B)
• Correlation is just not a sufficient test for
  determining causality when used alone
• Statistically speaking, there are 3 Requirements
  to Infer a Causal Relationship
• 1) A statistically significant relationship (r
  yes)
• 2) Time-order (A comes before B), (r maybe)
• 3) No other variable can explain this association
  (r no)

59
Correlations and causality

• If there is a relationship between A and B it
  could be because
• A -gtB
• Alt-B
• Alt-C-gtB
• In this example, C is a confounding variable

60
Other Types of Correlations

• Besides r, there are many types of correlations.
• For example
• Spearman rho correlation Use when 1 or both of
  the two variables are ordinal
• Computed in SPSS the same way as Pearsons
  rsimply toggle the Spearman button on the
  Bivariate Correlations window

61
Correlation Example

• Our research question (NBA Dataset)
• Is there a relationship between free throw
  percentage and 3-point percentage (min. 1 attempt
  game)?
• HA There is a relationship between FT and 3PT
• HO There is no relationship between FT and 3PT
• Analysis Plan
• 1) Visually check data (scatterplot)
• 2) Pearson correlation between the two variables

62
Scatterplot
63
Results of correlation analysis

• Correlation is positive
• Correlation is 0.38, moderate-to-low
• Correlation is statistically significant, p
  0.003
• If there were no real relationship, we would only
  see a correlation of 0.375 or greater 0.3 of the
  time with repeated sampling and analysis
• CONCLUSION Reject the null hypothesis and accept
  the alternative

64
Results of correlation analysis
CONCLUSION Reject the null hypothesis and accept
the alternative There is a positive,
moderate-to-low relationship between NBA 3-point
percentage and free throw percentage. Players
that tend to shoot well at the free throw line
also tend to shoot well behind the three point
line.
QUESTIONS??
65
Upcoming

• In-class activity
• Homework
• Cronk 5.1 and 5.2
• Holcomb Exercises 25 and 26
• Reading Cronk 6.1 (optional, may be helpful)
• Regression/Prediction next week
