Chapters 13

1
Phases and Heat

• Chapters 13 17

2
Phases of Matter

• Chapter 13

3
Phases

• There are three phases, or states, that we will
  discuss
• Solid
• Liquid
• Gas

4
Solids

• form of matter that has a definite shape and
  definite volume.
• Use (s) to denote solids in chemical reactions

5
Solids

• In most solids the atoms, ions, or molecules are
  packed tightly together
• The particles in solids tend to vibrate around
  fixed points
• When you heat a solid, its particles vibrate more
  rapidly, eventually the solid breaks down and
  melts.

6
Types of Solids

• Crystalline Solids
• In a crystal the particles are arranged in an
  orderly, repeating, three-dimensional pattern
  called a crystal lattice. There are many
  different shapes of crystalline solids, pg 397

7
Types of Solids

• Non-Crystalline Solids
• Amorphous solids lack an orderly internal
  structure.
• Ex Rubber, plastic, and asphalt.
• Glass transparent fusion product of inorganic
  substances that have cooled to a rigid state
  without crystallizing. Sometimes called
  super-cooled liquids.

8
(No Transcript)
9
Allotropes

• Two or more different molecular forms of the same
  element in the same physical state
• Different properties because they have different
  structures

10
Allotropes of Carbon
11
Liquids

• form of matter that has a definite volume,
  indefinite shape, and flows.
• Use (l) to denote liquids in chemical reactions

12
Liquids

• In liquids the atoms or molecules are able to
  slide past each other.
• In liquids there are intermolecular attractions
  between the atoms or molecules, which determine
  the liquids physical properties.
• When you heat a liquid the particles vibrate more
  rapidly and start moving past each other faster.

13
Gases

• form of matter that takes both the shape and
  volume of its container
• Use (g) to denote gases in chemical reactions

14
Phase Changes

• Six Changes
• Solid ? Liquid Melting
• Liquid ? Solid Freezing
• Liquid ? Gas Vaporization
• Gas ? Liquid Condensation
• Solid ? Gas Sublimation
• Gas ? Solid Deposition

15
Phase Changes

• During any given phase change, both phases can
  exist together in equilibrium
• Example
• At 0C, water can exist in both the liquid and
  solid phases in equilibrium

16
Energy

• When energy is added to a reaction, or phase
  change, it is called Endothermic
• When energy is released during a reaction, or
  phase change, it is called Exothermic

17
Phase Changes

• Which phase changes are endothermic, requiring
  the addition of energy?
• Melting
• Vaporization
• Sublimation

18
Phase Changes

• Which phase changes are exothermic, releasing
  energy?
• Freezing
• Condensation
• Deposition

19
(No Transcript)
20
Phase Diagram of CO2
21
(No Transcript)
22
Energy

• What is energy?
• Capacity to do work
• Ability to do work
• Two main types
• Kinetic
• Potential

23
Types of Energy

• Kinetic Energy
• Energy of motion
• Related to the speed and mass of molecules
• Potential Energy
• Stored energy

24
Temperature

• How is energy related to Temperature?
• What happens to the temperature of a substance
  when you add energy?
• Particles move faster
• Temperature increases

25
Temperature

• Relationship between energy, particle speed, and
  temperature
• Temperature Definition
• Average Kinetic Energy

26
Temperature Scales

• Kelvin (K) and Celsius (C) scales
• Kelvin scale is called the absolute scale
• Related to the kinetic energy of a substance
• Celsius scale is a relative scale
• based on the boiling and freezing points of water

27
Temperature Conversion

• K C 273

28
Pressure

• What is pressure?
• Physics Force per unit area
• Chemistry related to the number of collisions
  between particles and container walls

29
Pressure Conversion

• 1 atm 101.3 kPa

30
Vapor Pressure

• Pressure exerted by vapor that has evaporated and
  remains above a liquid
• Related to temperature
• As temperature increases, vapor pressure increases

31
Boiling vs. Evaporation

• Boiling
• Vapor pressure equals external, or atmospheric
  pressure
• Evaporation
• Some molecules gain enough energy to escape the
  liquid phase
• At temp. less than boiling point

32
Normal Boiling Point

• Boiling Point at Standard Pressure
• 1 atm or 101.3 kPa

33
Evaporation

• Why is evaporation considered a cooling process?
• As the molecules with higher kinetic energy
  evaporate, the average kinetic energy of the
  substance decreases

34
Table H

• Shows the relationship between temperature and
  vapor pressure for four specific substances

35
(No Transcript)
36
(No Transcript)
37
Thermochemistry

• Chapter 17

38
Thermochemistry

• Heat involved with chemical reactions and phase
  changes

39
Heat

• Energy transferred from one object to another,
  usually because of a temperature difference
• Measured in Joules (J) or calories (cal)
• Heat flows from hot to cold

40
Heat Transfer

• Endothermic
• Energy being added
• Exothermic
• Energy being released

41
Specific Heat Capacity

• Amount of heat needed to raise the temperature of
  1 g of a substance by 1C
• Unique for each phase of each substance
• 4.18 J/(gC) for liquid water
• Listed in Table B of Reference Tables

42
Heat

• What factors affect the amount of heat
  transferred?
• Specific Heat Capacity
• Mass
• Temperature difference between objects

43
Heat Equation

• Heat, Q
• Mass, m
• Specific Heat Capacity, c
• Change in Temperature, ?T
• Qmc?T

44
Example

• 200g of water is heated from 20C to 40C, how
  much heat is needed?
• Q mc?T
• Q (200g) (4.18J/gC) (20C)
• Q 16720 J

45
Example

• How much energy is required to raise the
  temperature of 50g of water from 5C to 50C?
• Q mc?T
• Q (50g) (4.18J/gC) (45C)
• Q 9405 J

46
Another Example

• What is the Specific Heat Capacity of Fe, if it
  takes 180J of energy to raise 10g of Fe from 10C
  to 50C?
• Q mc?T
• 180J (10g) c (40C)
• c 0.45 J/(gC)

47
(No Transcript)
48
Phase Change

• At what temperature does ice melt?
• 0C
• At what temperature does water freeze?
• 0C
• Melting point and freezing point are the same

49
Phase Change

• What happens to temperature during phase changes?
• Temperature remains constant
• Temperature remains CONSTANT during a phase
  change

50
Phase Change

• If energy is being added, what kind of energy is
  it?
• Energy being added is potential energy, not
  kinetic energy
• Potential energy is being used to separate or
  spread the particles apart

51
Heat of Vaporization, Hv

• Amount of energy needed to vaporize 1g of a
  substance
• Water 2260 J/g
• QmHv

52
Heat of Fusion, Hf

• Amount of energy needed to melt 1g of a substance
• Water 334 J/g
• QmHf

53
Examples

• How much energy is needed to melt 10g of ice at
  0C?
• Q mHf
• Q (10g) (334J/g)
• Q 3340 J

54
Example

• How much energy is needed to vaporize 10g of
  water at 100C?
• Q mHv
• Q (10g) (2260J/g)
• Q 22600 J

55
Phase Change

• Which requires more energy melting or
  vaporization?
• Vaporization
• Why?
• Molecules are spread farther apart as a gas
• It takes more energy to get gas particles spread
  apart

56
(No Transcript)
57
Heating (Cooling) Curves

• Shows relationship between temperature and time
  during constant heating or cooling.
• Also shows phases, and the phase changes between
  them.

58
Heating Curves

• Diagonal lines are phases
• Horizontal lines are phase changes

59
Heating Curves

• Diagonal lines are phases
• Horizontal lines are phase changes

60
(No Transcript)
61
Conservation of Energy

• Energy can not be created or destroyed, only
  transferred or converted from one form to
  another.
• Energy lost by one object must be gained by
  another object or the environment
• Qlost Qgained

62
Example

• A chunk of iron at 80C is dropped into a bucket
  of water at 20C.
• What direction will heat flow?
• From the iron to the water
• Hot to cold

63
Example

• A chunk of iron at 80C is dropped into a bucket
  of water at 20C.
• What could be the final temperature, when they
  both come to equilibrium?
• Between 20C and 80C

64
Example

• A 100g block of aluminum, c0.90J/gC at 100C
  is placed into 50g of water at 20C, what will be
  the final temperature when the aluminum and water
  reach equilibrium?
• Qlost Qgained
• mc?T mc?T
• 100g0.90J/gC(100C-Tf) 50g4.18J/gC(Tf-20C
  )
• 90(100-Tf) 209(Tf-20)
• 9000-90Tf 209Tf-4180
• 13180 299Tf
• Tf 44C

65
Conservation of Energy
System
Work Done (Energy)
Energy In
Energy Out
66
Conservation of Energy
Work Done (Energy)
Energy In
Energy Out
67
Conservation of Energy
Metabolism
Food In
Waste Out
