Asteroids

1
Asteroids Comets
2
Debris of the Solar System

• Asteroids are rocky or metallic objects orbiting
  the Sun that are smaller than a major planet, but
  that show no evidence of an atmosphere and
  contain little volatile (easily evaporated)
  material
• Comets are icy bodies that revolve around the Sun
  and are smaller than a major planet, but that
  contain frozen water and other volatile materials

3
Discovery of Asteroids

• Most asteroid orbits lie in
  the asteroid belt, between
  Mars and Jupiter
• too small to be visible
  without a telescope
• They were first discovered
  when astronomers were
  hunting for a missing
  planet between Mars and Jupiter
• The 1st asteroid, named Ceres and initially
  thought to be the missing planet, was
  discovered by Giovanni Piazzi in 1801
• It orbits at 2.8 AU from the Sun
• The discovery of other minor planets in similar
  orbits followed in subsequent years
• Now, more than 20,000 asteroids are known to have
  well-determined orbits

4
Asteroid Nomenclature

• Asteroids are given both a
  number and a name
• The names were originally
  chosen from Greek/Roman
  goddesses, then other female
  names were used, and
  finally all names go!
• Asteroids 2410 and
  4859 are named
  after Morrison and
  Fraknoi

Gaspra
Ida
Mathilde
5
Asteroid Census

• The total number of asteroids in the solar system
  is very large
• It must be estimated on the basis of systematic
  sampling of the sky
• Studies indicate that there are 106 asteroids
  with diameters greater than 1 km!
• The largest is Ceres, with a diameter of 1000 km
• Pallas and Vesta have diameters of 500 km
• 15 more are larger than 250 km across
• There are 100 times more objects 10-km across
  than 100-km across
• The total mass of asteroids is less than the mass
  of the Moon

6
Asteroid Orbits

• All asteroids revolve around the Sun in
  west-to-east direction, like the planets
• Most of their orbits lie near the plane in which
  the Earth and the other planets circle
• The asteroid belt is defined as the region that
  contains all asteroids with semi-major
  axes in the range from
  2.2
  to 3.3 AU
• Their orbital periods range
  from 3.3 to 6 years
• 75 of known asteroids are
  in the main belt
• But they are not closely
  spaced

7
Asteroid Families

• Japanese astronomer Kiyotsuga Hirayama found in
  1917 that some asteroids fall into families
• The families are groups with similar orbital
  characteristics
• Each family may have resulted from a breakup of a
  larger body, or from the collision of two
  asteroids
• Members of each family have similar speeds
• There are physical similarities among the larger
  members of a given family
• Several dozen families are found

8
Asteroid Physical Appearance

• The majority of asteroids are very dark
• They do not reflect much light
• Their reflectivities are only 3 to 4 percent
• There is, however, a sizable group that is not
  very dark
• Its typical reflectivities are 15 to 20 percent
  (similar that of the Moon)
• A few asteroids even have reflectivities as high
  as 60
• To understand the reasons for these differences,
  astronomers performed spectral analysis of the
  light reflected by asteroids

9
Asteroid Classification (1)

• The dark asteroids
• are believed to be primitive bodies
• chemically unchanged since the beginning of the
  solar system
• are composed of silicates mixed with dark,
  organic carbon compounds
• include Ceres, Pallas, and most objects in the
  outer third of the asteroid belt
• Most of the primitive asteroids are classed as C
  asteroids
• C stands for carbonaceous (carbon rich)

10
Asteroid Classification (2)

• The second most populous group is the S asteroids

• S stands for a stony or silicate composition
• They have no dark carbon compounds and hence
  higher reflectivities
• Most S asteroids seem to be also primitive
• The third group is the M asteroids
• M stands for metal
• Their identification is difficult
• done by radar for the largest asteroids such as
  Psyche
• They are much less numerous
• Each may have come from a parent body that had
  earlier differentiated and later shattered in a
  collision
• There is enough metal in a 1-km M-type asteroid
  to supply the world with iron for a long period
  of time

11
Asteroid Classification (3)
12
Trojan Asteroids

• The Trojans are located far beyond main belt
• at 5.2 AU from the Sun, nearly the same distance
  as Jupiter
• dark, primitive objects, like some other
  asteroids
• They have stable orbits because of Jupiter
• In Jupiters orbit, there are two points near
  which an
  asteroid can
  stay almost indefinitely
• They make equilateral
  triangles with Jupiter
  and the
  Sun
• Since their first discovery
  in 1906, several hundreds
  have been found
• The larger Trojans can be up to 200 km across

13
Animation the Trojans
Green circles indicate main-belt asteroids and
blue dots on the outermost circle are the Trojans
14
Asteroids in Outer Solar System

• There are asteroids with orbits that carry them
  far beyond Jupiter
• They are hard to detect and only a few have been
  found
• Examples
• Chiron is 200 km across and the largest of them,
  with a path carrying it from just inside the
  orbit of Saturn to almost the distance of Uranus
• Pholus, with an orbit that takes it 33 AU from
  the Sun, beyond Neptune, has the reddest surface
  of any object in the solar system, with unknown
  composition
• They are named after centaurs (mythological half
  horse, half human) because these objects have
  some of the properties of both comets and
  asteroids
• In 1988, on its closest approach to the Sun,
  Chirons brightness doubled, much like the comets
• Chiron, however, is much bigger than comets

15
Earth-Approaching Asteroids

• Some asteroids may stray far outside the main
  belt and travel inward along paths that come
  close to or cross Earths orbit
• Such asteroids, and other objects that come close
  to the Earth, are collectively known as
  Near-Earth Objects (NEOs)
• Needless to say, they are of great interest to us
• Some of these NEOs have collided with the Earth
  in the past, and some others are likely to do so
  in the future
• In 1994, a 1-km object passed closer than the
  Moon
• By the end of 2002, more than 640 NEOs larger
  than 1 km in diameter had been discovered
• Astronomers have estimated that there are
  probably 500 or so NEOs larger than 1 km in
  diameter that have not yet been found

16
NEOs

• NEOs generally have unstable orbits
• Each NEO will meet one of 2 fates
• collide with one of the terrestrial planets and
  be destroyed
• be ejected gravitationally from the inner solar
  system after a near-encounter with a planet
• The probability for impact is once every 100
  million years
• Hence the likelihood is very remote than any one
  of the known NEOs will end up crashing into the
  Earth in the foreseeable future
• The larger of these impacts will likely generate
  environmental catastrophes for our planet
• This is a good reason for further investigation
  of NEOs

17
An NEO Observation

• A 5-km-long NEO called Toutatis
• approached to within 3 million km of the Earth in
  1992
• which is less than 3 times the distance to the
  Moon
• Radar images indicate that it is a double object
• consisting of 2 irregular lumps, with diameters
  of 3 km and 2 km, squashed
  together
• Animation

Radar images
18
Rendezvous with Eros

• Eros is an Earth-approaching S-type asteroid
• potato-shaped, 34 km long, and 11 km wide
• heavily cratered, suggesting that the surface is
  old
• Movies of Eros captured by the
  NEAR-Shoemaker spacecraft,
  which orbited and then landed
  on it in 2000

19
Comets

• They have been observed since
  antiquity
• Typical comets appear as rather
  faint, diffuse spots of light
• smaller than the Moon and many
  times less brilliant
• They are small chunks of icy
  material that develop atmospheres
  as they get closer to
  the Sun
• As a comet gets very close to the Sun, the
  comet may develop a faint, nebulous tail
  extending far from the main body of the comet
• Their appearance is seemingly unpredictable
• Comets typically remain visible for periods from
  a few days to a few months

20
Comet Orbits

• The scientific study of comets dates back to
  Newton who first recognized that their orbits
  were very elongated ellipses
• Edmund Halley (a contemporary of Newton) in 1705
  calculated/published 24 cometary orbits
• He noted that the orbits of bright comets seen in
  1531, 1607, and 1682 were quite
  similar and could belong to the
  same comet returning to the
  perihelion every 76 years
• He predicted a return in 1758
• When the comet did appear in 1758,
  it was given the name Comet Halley

21
Comet Halley

• It has been observed
  and recorded on every
  passage near the Sun at intervals from 74
  to 79 years since 239 B.C.
• The period variations are caused by the jovian
  planets
• In 1910 the Earth was brushed by the comets
  tail, causing much needless public concern
• Its last appearance in our skies was in 1986
• met by several spacecraft
• It is predicted to return in 2061
• Its nucleus is approximately
  16 x 8 x 8 km3

22
Comet Census

• Records exist for 1000 comets
• Comets are discovered at an average rate of 5 to
  10 per year
• Most of them are visible only on photographs made
  with large telescopes
• Every few years, a comet may appear that is
  bright enough to be seen with the naked eye
• Recent flybys
• Comet Hyakutake, with a very long tail, was
  visible for about a month in March 1996
• Comet Hale-Bopp appeared in 1997

23
Comet Components (1)

• Nucleus relatively solid and
  stable, composed mostly of
  ice and gas,
  with a small amount of
  dust and other solids
• Coma a dense cloud of water,
  carbon dioxide, and other neutral
  gases sublimed off of
  the nucleus
• Hydrogen cloud a huge (millions
  of km in diameter), but very
  sparse,
  envelope of neutral H gas
• Dust tail up to 10-million km long, composed of
  smoke-sized dust particles driven off the nucleus
  by escaping gases
• This is the most prominent part of a comet to the
  unaided eye
• Ion tail as much as several-hundred-million km
  long, composed of plasma and laced with rays and
  streamers caused by interactions with the solar
  wind

24
Comet Components (2)
ion tail
dust tail
25
Nucleus and Coma of Comet

• The nucleus is composed of ancient ice, dust, and
  gaseous core material
• The nucleus has low gravity
• It cannot keep dust and gas from escaping
• The coma is the bright head of the comet, as seen
  from the Earth
• The coma is a temporary atmosphere of gas and
  dust around the nucleus
• The coma is 100,000's of kilometers across

Halley's nucleus
Halley's coma
26
Nucleus of Comet Wild 2
The images were captured by NASA's Stardust
spacecraft
27
Comets Ion Tail

• The Sun spews out charged particles
• This solar wind occurs along the solar
  magnetic-field lines, extending radially outward
  from the Sun
• Ultraviolet (UV) sunlight ionizes gases in the
  coma
• These ions (charged particles) are pushed by
  solar-wind particles along field lines to form a
  tail millions of km long
• The blue ion tail acts like a "solar" wind-sock
• The tail always points directly away from the Sun
  because the ions move at very high speed
• When the comet is moving
  away from the Sun, the

  comets ion tail will be
  almost in
  front of it!
• The blue color is mostly
  from the light emitted by

  carbon-monoxide ions, but
  other types of ions also
  contribute to the
  light

28
Origin and Evolution of Comets

• Comets originate from very great distances
• The aphelia of new comets are typically 50,000
  AU
• This clustering of aphelia was first noted by
  Dutch astronomer Jan Oort in 1950
• He then proposed an idea for the origin of those
  comets, which is still accepted by most
  astronomers today
• Oorts model of comet origin
• The Suns sphere of influence extends only a
  little beyond 50,000 AU, or about 1 LY
• Objects in orbit about the Sun at this distance
  can be easily perturbed by the gravity of passing
  stars
• The comets are some of the perturbed objects,
  which take on orbits that bring them much closer
  to the Sun
• The reservoir of ancient icy objects from which
  such comets are presumably derived is called the
  Oort comet cloud

29
(No Transcript)
30
Oort Comet Cloud

• Astronomers estimate that there may be about a
  trillion (1012) comets in the Oort cloud
• In addition, 10 times this number of comets could
  be orbiting the Sun between the planets and the
  Oort cloud
• Such cometary objects remain undiscovered
  probably because they are too faint to be seen
  directly and because their stable orbits do not
  bring them closer to the Sun
• The total number of comets within the sphere of
  influence of our Sun could therefore be on the
  order of ten trillion (1013)!
• Their total mass would be similar to that of 1000
  Earths
• Cometary material could thus be the most
  important constituent of the solar system after
  the Sun itself

31
Kuiper Belt

• Another possible source of comets lies just
  beyond the orbit of Neptune
• The existence of this region was first suggested
  by Gerard Kuiper in 1951
• The first object from this region, now called the
  Kuiper belt, was discovered in 1992
• The object is 200 km across
• Since then, several hundred more Kuiper-belt
  objects (KBOs) have been found
• It appears that these KBOs are heavily influenced
  by the gravity of Neptune
• Many of the known KBOs have orbits like that of
  Pluto
• Some astronomers have, therefore, suggested that
  Pluto can be considered the largest member of the
  Kuiper belt
• For this reason, KBOs are sometimes called
  plutinos

32
Fate of Comets

• Most comets probably spend nearly all their
  existence in the Oort cloud or Kuiper belt
• at a temperature near absolute zero
• But once a comet enters the inner solar system,
  its life likely changes dramatically!
• If it survives the initial passage near the Sun,
  it will return towards the cold aphelion
• and may follow a fairly stable orbit for a
  while
• It may impact the Sun, or be completely vaporized
  as it flies by the Sun
• It may interact with one or more planets with 3
  possible fates
• destroyed after impacting a planet
• speeded up and ejected, leaving the solar system
  forever
• perturbed into an orbit of shorter period
• Each time it approaches the Sun, a comet loses
  part of its material
• It may end its life catastrophically by breaking
  apart

33
Comet Shoemaker-Levy 9

• Some comets die very spectacularly
• When comet Shoemaker-Levy 9 passed close to
  Jupiter in July 1992, the comet broke into about
  20 pieces
• perhaps due Jupiters tidal forces
• Fragments of the comets then orbited Jupiter
  until July 1994 when they
  crashed into Jupiter,
  experiencing violent
  destruction
• Animation
