Title: Pixels at MTest Presentation


1
Pixels at MTest Presentation
Ryan Rivera Marcos Turqueti Detector
Instrumentation Electronic Systems
Engineering Computing Division
2
ESE EXPERIENCE ON TEST BEAMS
  • Working on pixels test beams since 1998.
    (First testbeam run in 1999 testing fpix0)
  • Designed the whole electronic DAQ for all
    BTeV and the last two CMS test beam runs.
  • Designed the pixel planes for all BTeV and
    the last two CMS test beam runs.
  • Designed test stand for calibrating the
    telescope (softwarehardware).
  • Participated on the development of the DAQ
    software.
  • Supported all BTeV and the last two CMS test
    beam runs.

3
TESTED CHIPS
  • Most of the times the detector under test is
    irradiated before going to the test beam.
  • Single Chips
  • FPIX 0, PFIX 1, FPIX 2, PSI V1, PSI V2
  • Modules
  • FPIX 1 (5x1), FPIX 2 (4x1), PSI V2 (4x2), PSI
    V2 (5x2)
  • Observation the output of FPIX series is
    digital while PSI series is analog, completely
    different outputs but the flexible architecture
    was able to adapt!
  • We are one of few groups that have experience
    with FPIX2.1

4
TESTED CHIPS
5
WHAT IS AT M-TEST NOW?
  • Telescope of 6 BTeV pixel detectors (50 ?m ? 400
    ?m) (legacy setup)
  • 2 Y-measurement planes Y-resolution
    6.24 ?m
  • 4 X-measurement planes X-resolution
    4.75 ?m
  • CMS pixel detector in the center (100 ?m ? 150
    ?m)
  • Triggers to CMS detector are provided by two
    upstream scintillators

CMS Pixel Document 1216-v2
6
WHAT IS AT M-TEST NOW?
7
WHAT ILC COMMUNITY IS LOOKING FOR IN A TEST BEAM
TELESCOPE?
ILC Detector Test Beam Workshop ILC Detector Test Beam Workshop
17-19 January 2007
8
SOME REQUIREMENTS
Approximately 10 different technologies under
study for ILC vertex detector. Sensitive window
varies from single bunch (ie. lt300ns), through
50us (20 time slices per train) to integration
over the entire bunch train (1ms).
9
WHAT WE READ FROM THIS?
  • A friendly interface is needed for the silicon
    telescope both for software and hardware. This is
    fundamental in order to provide efficient
    integration with the chip under test.
  • The DAQ must be able to deal with a good data
    rate (15MB/s).
  • Support is fundamental for both software and
    hardware.
  • The system must be able to be integrated with
    other detectors.
  • It is very continently if the test stand and the
    test beam use the same platform.

10
BASIC ARCHITECTURE
11
BASIC ARCHITECTURE
12
FLEXIBILITY
FERMILAB NETWORK
FIREWALL
13
FLEXIBILITY
TRACKING STATIONS
OTHER IP PERIPHERICAL DEVICES
TELESCOPE ROOM
FERMILAB NETWORK
FIREWALL
TO/FROM OTHER DETECTORS ON THE BEAM LINE
MASS STORAGE
DATA ANALYSIS DAQ CONTROL ONLINE
MONITORING
DAQ SERVER WEB SERVER
CONTROL ROOM
14
DATAFLOW
STATION
SERVER
ROUTER
DAQ SOFT
UDP
IPv 4
IPv 4
ETHERNET
ETHERNET
TWISTED PAIR
TWISTED PAIR
FIRMWARE
COMMUNICATION PROTOCOLS
SOFTWARE
HARDWARE
HARDWARE
15
STATIONS
DETECTOR
THERMOELECTRIC COOLER
THERMOELECTRIC COOLER
LOW VOLTAGE REGULATION
HIGH VOLTAGE MODULE
POWER
ETHERNET
16
STATIONS
NETWORK
MEMORY MANAGER
SECONDARY COMMANDS
TASKS MANAGER
EXTERNAL SIGNALS
FIRMWARE
TIMING
CACHE
DATA MANAGER
PRIMARY COMMANDS
ETHERNET
THERMOELECTRIC COOLING
LOW VOLTAGE REGULATION
RAM 64Mx64
Central Processing Unit (FPGA)
HIGH VOLTAGE GENERATION
ADC
DETECTOR
External Signals Trigger, Clock, Reset
PRIMARY SYSTEM
SECONDARY SYSTEM
OPTIONAL
17
CAPABILITIES
A)
SYSTEM CAPABLE TO DEAL WITH UP TO 100Mbytes/s
337ns
0.95ms
30s
B)
10us
4s
C)
1us
10ms
D)
10ns
10ms
18
SYSTEM TOP VIEW
TELESCOPE
  • TELESCOPE BACKBONE
  • DAQ Software, Hardware and Firmware
  • Pixel Stations
  • Slow Controls
  • Mechanical support and cooling

Integration Signals
SUPPORT
USER

CALIBRATION SOFTWARE

DATABASE

ANALYSIS SOFTWARE
19
(No Transcript)
20
UPGRADE
  • What is needed (from ESE) for this upgrade?
  • Software review and adapt the uffizi/pomone
    DAQ software.
  • Hardware design the pixel stations network
    electronics attached to the pixel plane.
  • - We already have a card (PMIC) that proves the
    concepts for HV and LV as we have the PTA2 that
    is being used currently on the FPIX2 testand.
  • Firmware - write the new DAQ firmware on the
    pixel planes.

21
THE DAQ SOFTWARE
Current Test Beam Software
Lorenzo Uplegger et Al
PInGA FPix2.1 Calibration Software
Marcos Turqueti, Lorenzo Uplegger, Ryan Rivera
DInA Future ILC Test Beam DAQ Software
Ryan Rivera
22
THE DAQ SOFTWARE
PINGA UFFIZI
23
THE DAQ SOFTWARE
24
THE DAQ SOFTWARE
25
WHAT DO WE HAVE RIGHT NOW?
  • First version of the board with the DAQ front end
    will arrive this week.
  • The board will serve as a test stand platform for
    testing the VIP chip.
  • Carrier board for the VIP also provided.
  • HV and low voltage system already tested, FPGA
    already tested (PTA platform).

26
THE FIRST PROTOTYPE
DAQ BOARD
CARRIER BOARD
