Clockless Logic

1
Clockless Logic

• System-Level Specification and Synthesis
• Ack Tiberiu Chelcea

2
Asynchronous Communication Protocols Control
A

• Communication protocol 4-phase handshake
• O1 initiates communication
• O2 completes communication
• Communication channel
• req operation start
• ack operation done

Active phase
Return-to-zero (RTZ) phase
3
Asynchronous Communication Protocols Data
A

• Channel parameters
• Data Encoding bundled-data
• Communication channel 2 control wires bundle
  of data wires
• Data Flow Direction
• Push channel data flows with the request
• Pull channel data flows with the acknowledge
• Data Validity broad, early, late
• Broad data valid for the entire handshake
• Early data valid during active phase of
  handshake
• Late data valid during return-to-zero phase of
  handshake
• Data Item Type byte, word, bool
• Data Width data wires to encode data item
• The CH language needs to model all these
  parameters

4
Interleaving of Two Communication Protocols
B
A

• Interleaving combining behaviors on 2 channels
• Example 1
• handshake on B enclosed within handshake on A
• Example 2
• handshake on B sequenced after handshake on A
• Different interleavings provide different
  tradeoffs
• Speed latency/throughput
• Area
• Power
• The CH language needs to model various
  interleavings

5
Balsa Language High-Level Modeling

• High-level asynchonous description language
• Based on CSP
• Block-structured, algorithmic
• Each Balsa module communicates through
  handshaking with the environment

Simple Example One place Buffer procedure Buf1
(input i byte output o byte) is local variable
x byte begin loop begin i -gt x o lt-
x end end
6
Handshake Circuits Intermediate Representation

• Intermediate representation of Balsa/Tangram
  compilation
• Handshake circuit netlist of handshake
  components, connected by channels, corresponding
  to a Balsa program
• Handshake component primitive asynchronous
  component communicating only through handshaking

7
Handshake Circuits

• Intermediate representation of Balsa/Tangram
  compilation
• Handshake circuit netlist of handshake
  components, connected by channels, corresponding
  to a Balsa program
• Handshake component primitive asynchronous
  component communicating only through handshaking

Start
loop begin end
i x

-gt
o lt- x
O
I
X
8
Handshake Circuits

• Intermediate representation of Balsa/Tangram
  compilation
• Handshake circuit netlist of handshake
  components, connected by channels, corresponding
  to a Balsa program
• Handshake component primitive asynchronous
  component communicating only through handshaking

Start
loop begin end
i x

-gt
o lt- x
O
I
X
9
Handshake Circuits

• Intermediate representation of Balsa/Tangram
  compilation
• Handshake circuit netlist of handshake
  components, connected by channels, corresponding
  to a Balsa program
• Handshake component primitive asynchronous
  component communicating only through handshaking

Start
loop begin end
i x

-gt
o lt- x
O
I
X
10
Large-Scale Asynchronous Systems Overview
small microprocessor core
