Two-Port Networks

1
Two-Port Networks

• Chapter 19

2
19.1 Introduction

• A two-port Network is an electrical network with
  two separate ports for input and output.

3
19.2 Impedance Parameters
4

• z11 Open-circuit input impedance
• z12 Open-circuit transfer impedance from port 1
  to port 2
• z21 Open-circuit transfer impedance from port 2
  to port 1
• z22 Open-circuit output impedance

5
Fig 19.3
6
19.4
7
Fig 19.5
8
Fig 19.6
9
Example 19.1

• Determine the z parameters for the circuit in
  Fig. 19.7.

10
Example 19.1 PSpice
To find Z parameters Example 9.1 .Param
Current_at_port21 port2 0 inject 0 A at
port 2 1st row port2 1 inject 1 A at port
2 2nd row I1 0 1 DC 1-Current_at_port2
R1 1 1x 20
R2 1x 0 40 R3 1x 2 30
I2 0 2 DC Current_at_port2 Vd
ummy 100 0 DC 1 .DC Vdummy 1 1 1 .STEP PARAM
Current_at_port2 LIST 0 1 .PRINT DC V(1) V(2) .END
We need to edit here for different circuits
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
The Results
z11
z21
z12
z22
3.000E01 2.000E01
2.000E01 5.000E01
15
19.3 Admittance Parameters
16

• y11 Short-circuit input admittance
• y12 Short-circuit transfer admittance from port
  1 to port 2
• y21 Short-circuit transfer admittance from port
  2 to port 1
• y22 Short-circuit output admittance

17
Fig 19.13
18
Example 19.3

• Obtain the y parameters for the ? network shown
  in Fig. 19.14.

19
Example 19.3
20
Example 19.3
21
Example 19.3
To find y parameters Example 19.3 .Param
Voltage_at_port20 port2 0 apply 0 V at
port 2 to find 1st row port2 1 apply 1 V
at port 2 to find 2nd row V1 1x 0 DC
1-Voltage_at_port2 Vport1 1x 1
R1 1 0 4 R2 1
2 2 R3 2 0 8
Vport2 2x 2 V2 2x 0 DC
Voltage_at_port2 Vdummy 100 0 DC 1 .DC Vdummy 1
1 1 .STEP PARAM Voltage_at_port2 LIST 0 1 .PRINT
DC I(Vport1) I(Vport2) .END
We just need to edit here for different networks.
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
The Results are
y11
y21
y12
y22
7.500E-01 -5.000E-01
-5.000E-01 6.250E-01
26
Example 19.4

• Determine the y parameters for the T network
  shown in Fig. 19.17.

27
Example 19.4
28
Example 19.4
29
Example 19.4
30
Example 19.4
31
PSpice
To find y parameters Example 19.3 .Param
Voltage_at_port20 port2 0 apply 0 V at
port 2 to find 1st row port2 1 apply 1 V
at port 2 to find 2nd row V1 1xx 0 DC
1-Voltage_at_port2 Vport1 1xx
1
R1 1 1x 8 R2 1x 0 2 R3 1x 2 4 F1 1x 2 Vport1
2
Vport2 2xx 2 V2 2xx 0 DC Voltage_at_port2 V
dummy 100 0 DC 1 .DC Vdummy 1 1 1 .STEP PARAM
Voltage_at_port2 LIST 0 1 .PRINT DC I(Vport1)
I(Vport2) .END
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
The Results are
y11
y21
1.500E-01 -2.500E-01
y12
y22
-5.000E-02 2.500E-01
36
19.4 Hybrid Parameters
37

• h11 Short-circuit input impedance
• h12 Open-circuit reverse voltage gain
• h21 Short-circuit forward current gain
• h22 Open-circuit output admittance

38
Fig 19.20
39
Example 19.5

• Find the hybrid parameters for the two-port
  network of . 19.22.

40
Example 19.5
41
Example 19.5
42
Fig 19.31
43

• a Open-circuit voltage gain
• b Negative short-circuit transfer impedance
• c Open-circuit transfer admittance
• d Negative short-circuit current gain

44
Example 19.8

• Find the transmission parameters for the two-port
  network in Fig. 19.32

45
Example 19.8
46
Example 19.8
47
19.6 Relationships Between Parameters
48
Example 19.10

• Find z and g of a two-port network if
• Solution

49
Example 19.10
50
19.7 Interconnection of Networks
51
Example 19.12

• Evaluate V2/V1 in the circuit in Fig. 19.42.

52
Example 19.12
53
Example 19.12
54
Example 19.13

• Find the y parameters of the two-port in Fig.
  19.44.

55
Example 19.14

• Find the transmission parameters for the circuit
  in Fig. 19.46.
