ANOVA

1

• ANOVA
• Determining Which Means Differ in Single Factor
  Models

2
Single Factor ModelsReview of Assumptions

• Recall that the problem solved by ANOVA is to
  determine if at least one of the true mean values
  of several different treatments differs from the
  others.
• For ANOVA we assumed
• The distribution of the population for each
  treatment is normal.
• The standard deviations of each population,
  although unknown, are equal.
• Sampling is random and independent.

3
Determining Which Means DifferBasic Concept

• Suppose the result of performing a single factor
  ANOVA test is a low p-value, which indicates that
  at least one population mean does, in fact,
  differ from the others.
• The natural question is, Which differ?
• The answer is that we conclude that two
  population means differ if their two sample means
  differ by a lot.
• The statistical question is, What is a lot?

4
Example

• The length of battery life for notebook computers
  is of concern to computer manufacturers.
• Toshiba is considering 5 different battery models
  (A, B, C, D, E) that have different costs.
• The question is, Is there enough evidence to
  show that average battery life differs among
  battery types?

5
Data

• A B C D E
• 130 90 100 140 160
• 115 80 95 150 150
• 130 95 110 150 155
• 125 98 100 125 145
• 120 92 105 145 165
• 110 85 90 130 125
• ?x 121.67 90 100 140 150

Grand Mean ?x 120
6
(No Transcript)
7
OUTPUT

8
Motivation for The Fisher Procedure

• Fishers Procedure is a natural extension of the
  comparison of two population means when the
  unknown variances are assumed to be equal
• Recall this is an assumption in single factor
  ANOVA
• Testing for the difference of two population
  means (with equal but unknown ss) has the form
• H0 µ1 µ2 0
• HA µ1 µ2 ? 0

9
Best Estimate for s2 and the Appropriate Degrees
of Fredom

• Recall that when there were only 2 populations,
  the best estimate for s2 is sp2 and the degrees
  of freedom is (n1-1) (n2-1) or n1 n2 - 2.
• For ANOVA, using all the information from the k
  populations the best estimate for s2 is MSE and
  the degrees of freedom is DFE.

Two populations With Equal
Variances ANOVA Best estimate for s2 sp2
MSE Degrees of Freedom n1 n2 2
DFE
10
Two Types of Tests

• There are two types of tests that can be applied
• A test or a confidence interval for the
  difference in two particular means
• e.g. µE and µB
• A set of tests which determine differences among
  all means.
• This is called a set of experiment wise (EW)
  tests.
• The approach is the same.
• We will illustrate an approach called the Fisher
  LSD approach.
• Only the value used for a will be different.

11
Determining if µi Differs From µjFishers LSD
Approach

• H0 µi µj 0
• HA µi µj ? 0

LSD stands for Least Significant Difference
12
When Do We Conclude Two Treatment Means (µi and
µj) Differ?

• We conclude that two means differ, if their
  sample means,?xi and?xj, differ by a lot.
• A lot is LSD given by

13
Confidence Intervals for the Difference in Two
Population Means

• A confidence interval for µi µj is found by

14
Equal vs. Unequal Sample Sizes

• If the sample sizes drawn from the various
  populations differ, then the denominator of the
  t-statistic will be different for each pairwise
  comparison.
• But if the sample sizes are equal (n1 n2 n3
  .) , we can designate the equal sample size by N
• Then the t-test becomes

15
LSD For Equal Sample Sizes

16
What Do We Use For a?

• Recall that a is
• In Hypothesis Tests the probability of
  concluding that there is a difference when there
  is not.
• In Confidence Intervals the probability the
  interval will not contain the true difference in
  mean values
• If doing a single comparison test or constructing
  a confidence interval,
• For an experimentwise comparison of all means,
• We will actually be conducting 10 t-tests
• µE - µD, (2) µE - µC, (3) µE - µB, (4) µE - µA,
  (5) µD - µC,
• (6) µD - µB, (7) µD - µA, (8) µC µB, (9) µC -
  µA, (10) µB - µA

select a as usual
Use aEW
17
aEW The probability ofMaking at least one Type
I Error

• Suppose each test has a probability of concluding
  that there is a difference when there is not
  (making a Type I error) a.
• Thus for each test, the probability of not making
  a Type I error is 1-a.
• So the probability of not making any Type I
  errors on any of the 10 tests is (1- a)10
• For a .05, this is (.95)10 .5987
• The probability of making at least one Type I
  error in this experiment, is denoted by aEW.
• Here, aEW 1 - .5987 .4013 -- That is, the
  probability we make at least one mistake is now
  over 40!
• To have a lower aEW, a for each test must be
  significantly reduced.

18
The Bonferroni Adjustment for a

• To make aEW reasonable, say .05, a for each test
  must be reduced.
• The Bonferroni Adjustment is as follows
• NOTE decreasing a, increases ß, the probability
  of not concluding that there is a difference
  between two means when there really is. Thus,
  some researchers are reluctant to make a too
  small because this can result in very high ß
  values.

19
What Should a for Each Test Be?
The required a values for the individual t-tests
for aEW .05 and aEW .10 are

For aEW .05 For aEW .05
Number of Treatments, k a for each test
3 0.01667
4 0.00833
5 0.00500
6 0.00333
7 0.00238
8 0.00179
9 0.00139
10 0.00111
For aEW .10 For aEW .10
Number of Treatments, k a for each test
3 0.03333
4 0.01667
5 0.01000
6 0.00667
7 0.00476
8 0.00357
9 0.00278
10 0.00222
20
LSDEWFor Multiple Comparison Tests

• When doing the series of multiple comparison
  tests to determine which means differ, the test
  would be to conclude that µi differs from µj if

• Where LSDEW is given by

21
Procedure for Testing Differences Among All Means

• We begin by calculating LSDEW which we have shown
  will not change from test to test if the sample
  sizes are the same from each sample. That is the
  situation in the battery example that we
  illustrate here.
• A different LSD would have to be calculated for
  each comparison if the sample sizes are
  different.

22
Procedure (continued)

• Then construct a matrix as follows

23
Procedure (continued)

• Fill in mean of each treatment across the top row
  and down the left-most column (in our example,
  XA 121.67, XB 90, XC 100,
  XD 140, XE 150)

24
Procedure (continued)

• For each cell below the main diagonal, compute
  the absolute value of difference of the means in
  the corresponding column and row

25
Procedure (continued)

• Compare each difference with LSDEw(17.235 in our
  case). If the
• difference between and gt LSDEw. we can
  conclude that there is difference in µi and µj.

26
Tests For the Battery Example

• For the battery example,
• Which average battery lives can we conclude
  differ?
• Give a 95 confidence interval for the difference
  in average battery lives between
• C batteries and B batteries
• E batteries and B batteries

Use LSDEW Multiple Comparisons
Use LSD Individual Comparisons
27
Battery Example Calculations

• Experimental error of ?EW .05
• For k 5 populations, a aEW /10 .05/10
  .005
• From the Excel output
• ? xE 150, ? xD 140, ? xA 121.67,? xc
  100, ? xB 90
• MSE 94.05333, DFE 25, N 6 from each
  population
• Use TINV(.005,25) to generate t.0025,25
  3.078203

28
Analysis of Which Means Differ

• We conclude that two population means differ if
  their sample means differ by more than LSDEW
  17.2355.
• Construct a matrix of differences,
• Compare with LSDEW

29
Conclusion of Comparisons
30
LSD For Confidence Intervals

• Confidence intervals for the difference between
  two mean values, i and j, are of the form
• (Point Estimate) t?/2,DFE(Standard Error)

31
LSD for Battery Example

• For the battery example

32
The Confidence Intervals

• 95 confidence interval for the difference in
  mean battery lives between batteries of type C
  and batteries of type B.
• 95 confidence interval for the difference in
  mean battery lives between batteries of type E
  and batteries of type B.

33
REVIEW

• The Fisher LSD Test
• What to use for
• Best Estimate of s2 MSE
• Degrees of Freedom DFE
• Calculation of LSD
• Bonferroni Modification
• Modify a so that aEW is reasonable
• a aEW/c, where the of tests, c k(k-1)/2
• Calculation of LSDEW
• Excel Calculations
