Cosc 4/5730

1
Cosc 4/5730

• Android
• Text to Speech
• And Speech To Text

2
Text to Speech

• Android

3
Text to Speech

• In Android 1.6 there is a native Text-to-speech
  built into the Android OS.
• In 2.3.3, Menu-gt Voice input output-gt
  Text-to-speech settings
• In 4.X, Settings-gt Language and Input -gt
  Text-to-speech output
• You can use the Listen to an example to see how
  it works.

4
How it works.

• The Text-to-Speech (TTS) uses a the Pico engine
• It sends the speech to the audio output.
• There is only one TTS engine and it is share
  across all the activities on the device.
• Other activities maybe using it
• The user may have overridden the settings in the
  preferences as well.

5
Using the TTS

• First we need to check if the TTS engine is
  available.
• We can do this with a Intent to with
  ACTION_CHECK_TTS_DATA
• Using startActivityForResult, we then find out if
  the TTS engine is working and avialable.

6
Android.speech.tts

• To use the TTS we need get access to it using the
  constructor
• TextToSpeech(Context context, TextToSpeech.OnInitL
  istener listener)
• The constructor for the TextToSpeech class.
• mTts mTts new TextToSpeech(this, this)
• First this, use the context of our application
• Likely US-EN
• Second this, the listener.
• Activity implements OnInitListener
• _at_override public void onInit(int status)

7
OnInitListener

• onInit(int status)
• Called to signal the completion of the
  TextToSpeech engine initialization.
• Status is either
• TextToSpeech.SUCCESS
• You can use it.
• or
• TextToSpeech.ERROR
• Failure, you cant use it.

8
Using the TTS

• To have it speak words
• speak(String text, int queueMode, HashMapltString,
  Stringgt params)
• To stop, call stop()
• Shutdown() to release everything

9
Example

• mTts.speak(Test, TextToSpeech.QUEUE_ADD, null)
• You should hear the word test spoken.

10
Other methods.

• You can change the pitch and speech rate with
• setPitch(float pitch)
• setSpeechRate(float speechRate)
• To find out if it is still speaking
• Boolean isSpeaking()
• To have the speech written to a file
• synthesizeToFile(String text, HashMapltString,
  Stringgt params, String filename)
• Remember permission for writing to the file
  system.

11
Note

• In the OnPause() method
• You should put at least a stop() call
• You app has lost focus

12
Example code

• Txt2spk example in github
• Simple text box and button. Type in the words
  you want to speak and then press play.
• If you are running the example on a phone
• For fun, use the voice input (microphone on the
  keyboard) for the input and then have it read it
  back to you. ?

13
Speech to Text

• Android

14
Speech To Text

• Like Text to speech, we are going to call on
  another Google's voice recognition software.
• Android.speech package
• The simple version uses an intent and there is a
  dialog box for the users to know when to speech.
• RecognizerIntent
• With a onActivityResult
• A Note speech recognition doesnt work in the
  emulators.

15
Simple version code

• First get the recognize intent
• Intent intent new Intent(RecognizerIntent.ACTION
  _RECOGNIZE_SPEECH)
• Specify the calling package to identify your
  application (this one is generic for any class
  you use)
• intent.putExtra(RecognizerIntent.EXTRA_CALLING_PAC
  KAGE, getClass().getPackage().getName())
• Display an hint to the user in the dialog box
• intent.putExtra(RecognizerIntent.EXTRA_PROMPT,
  "Say Something!")
• Given an hint to the recognizer about what the
  user is going to say
• intent.putExtra(RecognizerIntent.EXTRA_LANGUAGE_MO
  DEL, RecognizerIntent.LANGUAGE_MODEL_FREE_FORM)
• Specify how many results you want to receive. The
  results will be sorted where the first result is
  the one with higher confidence. In this case max
  of 5 results
• intent.putExtra(RecognizerIntent.EXTRA_MAX_RESULTS
  , 5)
• Now launch the activity for a result
• startActivityForResult(intent, VOICE_RECOGNITION_R
  EQUEST_CODE)

16
Simple version code (2)

• When the recognition is done, results are
  returned to onActivityResult
• protected void onActivityResult(int requestCode,
  int resultCode, Intent data)
• if (requestCode VOICE_RECOGNITION_REQUEST_CODE
  resultCode RESULT_OK)
• Fill the list view with the strings the
  recognizer thought it could have heard, there
  should be at most 5, based on the call
• ArrayListltStringgt matches data.getStringArrayLis
  tExtra(RecognizerIntent.EXTRA_RESULTS)
• Now you deal with results in matches array.
• lastly send other results to the super since we
  are not dealing with them.
• super.onActivityResult(requestCode, resultCode,
  data)

17
SpeechRecognizer class

• A second version is more complex, but also
  removes the dialog box
• Which many people want implement their own or
  just not have one.
• You will need record_audio permission
• ltuses-permission androidname"android.permission.
  RECORD_AUDIO"/gt
• Get the speech recognizer and a
  RecognitionListener
• This still uses an intent as well.
• Remember the recognition is done by Google's
  cloud.

18
SpeechRecognizer

• First get the recognizer
• sr SpeechRecognizer.createSpeechRecognizer(this)

• Set your listener.
• sr.setRecognitionListener(new Recognitionlistener(
  ))
• Listener is on the next slide.

19
RecognitionListener

• create a Recognitionlistener and implement the
  following methods
• void onBeginningOfSpeech()
• The user has started to speak.
• void onBufferReceived(byte buffer)
• More sound has been received.
• void onEndOfSpeech()
• Called after the user stops speaking.
• void onError(int error)
• A network or recognition error occurred.
• Error codes are covered here
• void onEvent(int eventType, Bundle params)
• Reserved for adding future events.
• void onPartialResults(Bundle partialResults)
• Called when partial recognition results are
  available.
• void onReadyForSpeech(Bundle params)
• Called when the endpointer is ready for the user
  to start speaking.
• void onResults(Bundle results)
• Called when recognition results are ready.
• void onRmsChanged(float rmsdB)

20
RecognitionListener (2)

• onResults methods
• This is where you would pull out the results from
  the bundle
• ArrayList results results.getStringArrayList(Spe
  echRecognizer.RESULTS_RECOGNITION)

21
Start the recognition

• As in the simple version we need an intent to
  start the recognition, but we are sending the
  intent through the SpeechRecognizer object, we
  declared in the beginning.
• get the recognize intent
• Intent intent new Intent(RecognizerIntent.ACTION
  _RECOGNIZE_SPEECH)
• Specify the calling package to identify your
  application
• intent.putExtra(RecognizerIntent.EXTRA_CALLING_PAC
  KAGE,getClass().getPackage().getName())
• Given an hint to the recognizer about what the
  user is going to say
• intent.putExtra(RecognizerIntent.EXTRA_LANGUAGE_MO
  DEL,RecognizerIntent.LANGUAGE_MODEL_FREE_FORM)
• Specified the max number of results
• intent.putExtra(RecognizerIntent.EXTRA_MAX_RESULTS
  ,5)
• Use our SpeechRecognizer to send the intent.
• sr.startListening(intent)
• The listener will now get the results.

22
Code Examples

• The txt2spk will speak text
• Speak2Text demo shows you more information on
  using other languages for voice recognition, plus
  will speak the results back to you.
• speech2txtDemo is simplified voice recognition
• speech2txtDemo2 is uses the RecognitionListener.

23
iSpeech

• There have SDK and API for blackberry, android,
  and iphone as well.
• Text to speech
• With many voice options as well
• Speech to text
• Limited to 100 word demo key per application
  launch.
• License key removes the 100 word limit.
• http//www.ispeech.org/

24
References

• http//developer.android.com/resources/samples/Api
  Demos/src/com/example/android/apis/app/TextToSpeec
  hActivity.html
• http//developer.android.com/reference/android/spe
  ech/SpeechRecognizer.html
• http//developer.android.com/resources/samples/Api
  Demos/src/com/example/android/apis/app/VoiceRecogn
  ition.html
• http//stackoverflow.com/questions/6316937/how-can
  -i-use-speech-recognition-without-the-annoying-dia
  log-in-android-phones

25
Q
A
