Cell Structure and Function I

1
Cell Structure and Function I
2
Cell Theory

• 1. All living things are made of cells.
• 3. New cells are produced from existing cells
• 2. Cells are the basic unit of structure and
  function in living things.

3
Cell Exploration

• Light Microscopes
• Living organisms can be seen
• Light limits the resolution
  so extremely small things
  like proteins and viruses
  cannot be observed

4
Cell Exploration

• High resolution video technology
• Allows scientists to see time elapsed movies of
  cells as the grow, divide and develop.
• http//www.cellsalive.com/mitosis.htm

5
Cell Exploration

• Transmission
  Electron
  Microscopes
  (TEMs)
• Can see more detain and extremely small
  structures
• Beams of electrons must pass through ultra-thin
  sliced samples therefore no living things can be
  seen

6
Cell Exploration

• Scanning Electron Microscope (SEMs)
• Beams of electrons scanned over the surface of a
  specimen
• Produces a 3D image
• Samples must be chemically
  preserved
  and removed of all
  water so no living
  things can be seen.

7
Prokaryotes vs. Eukaryotes

• Prokaryotes
  (bacteria)
  have no nucleus
  and very few
  organelles. DNA is
  not contained
• Eukaryotes
  (protists, fungi, plants and animals) larger,more
  complex,DNA is inside the nucleus

8
Plant Cells Vs. Animal Cells

• Both plant and animal cells contain a variety of
  organelles. Some structures are specific to
  either plant cells or animal cells only.
• Only plant cells contain
• Cell wall
• Chloroplasts
• Large central vacuoles
• Only animal cells contain
• Centrioles

9
(No Transcript)
10
(No Transcript)
11
Smooth ER vs. Rough ER

• Rough ER - ribosomes on the ER make proteins, the
  ER modifies the proteins
• Smooth ER - makes lipids

12
Mitochondria vs. Chloroplasts

• Mitochondria make energy from chemicals (food
  molecules)
• Chloroplasts make energy from light
  through photosynthesis

13
Cytoskeleton

• Network of protein filaments
• Maintains shape
• Involved in cell movement

14
Prokaryotes
Eukaryotes
Nucleus Endoplasmic reticulum Golgi
apparatus Lysosomes Vacuoles Mitochondria Cytoskel
eton
Has a Cell membrane DNA
DNA is free floating
15
Cell Structure and Function II
16
Cell Wall

• Provides support and
  protection for plant
  cell walls
• Made of porous cellulose
  so it does not regulate
  what enters and
  leaves

17
Phospholipids are Building Blocks of Cellular
Membranes
The hydrophilic head group and hydrophobic tails
are the keys to phospholipid function.
18
Phospholipids Form Biological Membranes
19
Cell Membrane

• Regulates what enters and leaves the cell and
  provides support and protection
• Structure lipid bilayer with embedded proteins

20
Diffusion through Cell Boundaries

• Particles move from an area of high concentration
  to an area of lower concentration
• No energy is required

21
Osmosis

• Diffusion of water through a selectively
  permeable membrane

22
Is this really Osmosis???
23
Isotonic"ISO" means the same

• Concentration of solutes (salts) is the same
  inside and outside of cell.
• Water flows in and out in equal amounts
• No effect on cell

24
HypertonicHyper means more

• Concentration of solutes is greater outside the
  cell than inside
• Water flows out of cell
• The cell shrivels and may die.
• This is why it is dangerous to drink sea water
• This is also why "salting fields" was a common
  tactic during war, it would kill the crops in the
  field, thus causing food shortages.

25
Hypotonic "HYPO" means less

• Concentration of solutes is less outside the cell
  than in.
• Water flows in
• The cell swell with water and becomes turgid

26
Active Transport

• Carried our by protein pumps found in the
  membrane
• Energy is required

27
Facilitated Diffusion

• Molecules move through protein channels.
• No energy required

28
Endocytosis

• Cell takes material into cell by infolding of the
  cell membrane
• Phagocytosis eating cell engulfs large
  particles
• Pinocytosis drinking cell takes in liquid
• www.endocyte.com/ animation/animation.htm

29
Exocytosis

• Cell releases large
• amounts of material

30
Cell Differentiation

• The cells in multicellular organisms can develop
  in different ways to perform different tasks.

31
Levels of Biological Organization

• Organism
• Organ system
• Organ
• Tissue
• Cell
• Organelle
• DNA
• Atoms
