Instructor

1
Sybex CCNA 640-802 Chapter 9 VLANs

• Instructor Todd Lammle

2

• The CCNA Topics Covered in this chapter include
• What is a VLAN?
• VLAN Memberships
• VLAN links
• Frame tagging
• VTP
• Trunking
• Configuring VLANs
• Inter-VLAN Communication
• Configuration examples

2
3

• VLAN - Definition
• A logical grouping of network users and resources

• connected to
• administratively defined ports on a switch.
• gives you
• Smaller broadcast domains
• Organized by
• Location (e.g., the 4th floor)
• Function e.g., IT techs, or a group with
  high security needs)
• Department (e.g., the accounting department)
• Application or protocol (e.g., everyone running
  AppleTalk maybe in the Graphics dept.)

4
(No Transcript)
5

• Simplify network management
• You control each port in a VLAN, and each switch
  can contain a number of VLANs, so you can no
  longer just cable into a switch and see all of
  the traffic on that switch.
• Also, a VLAN can be configured with a number of
  reporting functions, for example, report any
  attempt at unauthorized access
• Provides a level of security over a flat network
• Flat as in a network that is one, large
  broadcast domain
• Security see ff
• Flexibility and Scalability
• With the old hub switch networks, you could run
  out of space on a switch or in an office, but
  with VLANs, you just add a new user to an
  existing VLAN and go.

6

• Broadcasts occur in every protocol
• but how often they occur depends upon 3 things
• The type of protocol (some are worse than
  others)
• The application(s) running on the internetwork
  (ditto)
• How these services are used

7
(No Transcript)
8

• Flat network problems
• A flat internetworks security used to be tackled
  by connecting hubs and switches together with
  routers.
• So it was the routers job to maintain security.
  This was pretty ineffective for several reasons.
• First, anyone connecting to the physical network
  could access the network resources on that
  physical LAN.
• Second, all anyone had to do to observe any and
  all traffic in that network was to plug a network
  analyzer into the hub
• VLANs
• If you create multiple broadcast groups, you have
  total control over each port and user!
• So the days when anyone could just plug their
  workstations into any switch port and gain access
  to network resources are history because now you
  get to control each port, plus whatever resources
  that port can access.

9

• Layer-2 switches only read frames
• Can cause a switch to forward all broadcasts
• VLANs
• Essentially create broadcast domains
• Greatly reduces broadcast traffic
• Ability to add wanted users to a VLAN regardless
  of their physical location
• Additional VLANs can be created when network
  growth consumes more bandwidth

10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13

• Static VLANs
• Typical method of creating VLANs
• Most secure
• A switch port assigned to a VLAN always maintains
  that assignment until changed
• Dynamic VLANs
• Node assignment to a VLAN is automatic
• MAC addresses, protocols, network addresses, etc
• VLAN Management Policy Server (VMPS)
• MAC address database for dynamic assignments
• MAC-address to VLAN mapping

14

• Access links
• A link that is part of only one VLAN
• Trunk links
• Carries multiple VLANs

15
(No Transcript)
16

• Frame Tagging A means of keeping track of users
  frames as they travel the switch fabric VLANs
• User-defined ID assigned to each frame
• VLAN ID is removed before exiting trunked links
  access links

17

• Inter-Switch Link (ISL)
• Cisco proprietary (becoming obsolete)
• FastEthernet Gibabit Ethernet only
• IEEE 802.1q
• Must use if trunking between Cisco non-Cisco
  switch

18

• ISL A means of explicitly tagging VLAN
  information onto an Ethernet frame
• Allows VLANs to be multiplexed over a trunk line
• Cisco proprietary
• External tagging process

19

• Purpose to manage all configured VLANs across a
  switch internetwork maintain consistency
• Allows an administrator to add, delete, rename
  VLANs

20

• Benefits
• Consistent configuration across all switches in
  the network
• Permits trunking over mixed networks, such as
  Ethernet to ATM LANE or even FDDI
• Accurate tracking and monitoring of VLANs
• Dynamic reporting of added VLANs to all switches
  in the VTP domain
• Plug-and-Play
• A VTP server must be created to manage VLANs

21
(No Transcript)
22

• Server
• Default for all Catalyst switches
• Minimum one server for a VTP domain
• Client
• Receives information sends/receives updates
• Cannot make any changes
• Transparent
• Does not participate in a VTP domain but forwards
  VTP advertisements
• Can add/delete VLANs
• Locally significant

23
(No Transcript)
24
(No Transcript)
25

• Creating VLANs
• Assigning Switch Ports to VLANs
• Configuring Trunk Ports
• Configuring Inter-VLAN routing

26

• Default Switches are configured to be VTP
  servers

27
Switchconfig t Switch(config)int
fa0/1 Switch(config-if) switchport mode trunk
28
Routerconfig t Router(config)int
f0/0 Router(config-if)no ip address Router(config
-if)no shutdown Router(config-if)int
f0/0.1 Router(config-subif)encapsulation dot1q
1 Router(config-subif)ip address 192.168.10.17
255.255.255.240
Switchconfig t Switch(config)int
f0/1 Switch(config-if)switchport mode
trunk Switch(config-if)int f0/2 Switch(config-if)
switchport access vlan 1
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
The End
