Large Wind Integration Impacts on Operations

1
Large Wind Integration Challenges for Operations
/ System Reliability
By Steve Enyeart, BPA With contributions
from Bart McManus, BPA Roy Ellis, BPA Dmitry
Kosterev 2/12/08 Photo courtesy of PPM Energy
2
NW Wind Integration Action Plan Summary

• NW added 900 MW of wind in 2007, gt2200 MW Total
  now
• Total Wind in the NW Forecast 3500 - 3800 MW by
  end of 2009
• Northwest Wind Integration Forum formed to
  Address
• Transmission System Expansion and Funding
• Wind Integration Costs and Cost Shifts from Load
  to Wind Generation
• Operating Issues including Regulation and Balance
  of Hour
• A Regional Wind Forecasting System
• ACE Diversity Interchange and other Control Area
  sharing ideas to increase flexibility for Wind
  Integration
• Severe Wind Ramps Impact on Reliability

3
Impact of State RPS Requirements

• Montana, Washington, and Oregon have implemented
  Renewable Portfolio Stds
• According to the estimates from the NW Power
  Council
• Oregon 15 by 2015 - 650 aMW, 25 by 2025
• Washington 7.5 by 2015 672 aMW, 15 by 2020
• Wind is the primary Renewable Resource at this
  time
• Assume 1400 aMW _at_ 30 equals 4700 MW peak
  capacity. This and export of 2000 MW would be
  7, 000 MW by 2015.
• BPA has provided interconnection for 3500 MW at
  various locations and Rock Creek, John Day 500 kV
  interconnects (1200 MW each).
• Other NW Utilities have connected over 800 MW
  with plans for more.

4
(No Transcript)
5
Wind Gen. within BPA Control Area (BAA)

• BPA integrated 650 MW in 2007, total 1400 MW,
  may be 3000 MW by late 2009
• Queue requests exceed 10,000 MW under study (due
  in part to BPA transmission location relative to
  wind resources)
• Present 1400 MW, 15 of 9000 MW Peak BPA Load,
  higher than any BAA in US.
• BPA Addressing
• Intra-hour increases in total Balancing
  requirements
• Impact of severe wind ramps on Balancing Capacity

• Cost/Cost Shift of addl Balancing Capacity
• Need for Voltage Support, Dynamic VAr
• Balancing within 1 Minute Regulation (AGC
  response) Load Following for balance of hour
  schedule see next slide

6
Within Hour Balancing Definitions

• Regulation minute-minute difference between
  generation and load (AGC).
• Following is defined as the change in the general
  trend over a specific time interval 5, 10, 15 or
  even 60 minutes.
• Within-Hour Balancing Load Following
  Regulation

Within Hour Balancing defined as the with-in hour
generation adjustments for variances of Load /
variable (wind) Generation New Requirement for
Wind Generation
7
(No Transcript)
8
Wind Balancing Analysis

• As previous slide demonstrates, Wind Generation
  is quite variable, impacting BAA Balancing and
  total AGC Capacity Requirements.
• The next slide shows the balancing required for a
  recent large wind ramp. Not nearly as extreme as
  the previous slide would have implied.
• The 2nd slide shows the balancing required for
  simulated period for total wind of 2700 MW. Note
  the peak Balancing required.

9
Regulation versus Following (Wind Example)
10
2700 MW Simulated Balancing Capacity Requirements
2nd 3 week Period Simulation
11
Wind Balancing Analysis (Cont.)

• The next slide shows the problems with scheduled
  vs actual (even with hourly adjustments) Note
  that scheduled trails actual and misses peaks and
  valleys.
• This increases Within-Hour Balancing reserves
  requirements.
• Better forecasts would reduce this problem.
• The 2nd slide is Frequency Distribution Analysis
  for total Balancing Capacity requirements
  assuming 5000 MW.

12
Schedule Vs. Actual 12/27 12/29 2007
lt Actual
Note - Wind acts more like load - generation
seldom matches schedule, and - Good hourly
schedule will still increase Balancing Capacity
requirements.
13
Example Frequency Distribution of Wind
Generation Variation
14
Wind Within-Hour Balancing Analysis

• The next slide BPA estimates the increase in
  Balancing Capacity required for up to 2880 MW.
• Cumulative Frequency Distribution method used to
  calculate increase in Balancing Capacity,
  assuming 97.5 of Regulation and 95 Balance of
  Hour events are covered.
• The Tail events from the previous slide
  indicate that some wind ramps could exceed
  Balancing Capacity. Options include
• Increase Balancing Capacity More cost to all
  wind farms
• Wind Ramp Controls to limit severe ramps
• Other BA tools like shared ACE
• Analysis includes using locations of proposed
  wind sites in BPA queue to provide simulation of
  locational diversity.

15
(No Transcript)
16
Wind Ramps

• Wind Ramps are large unscheduled changes in the
  output of a wind farm or the aggregate of all
  wind farms in a Control Area.
• As seen above Wind increases Balancing Capacity
  Requirements.
• BPA now Concerned for Reliability Impacts (CPS2
  Violations).
• Late fall 2007 BPA experienced increase in
  within-hour Balancing due to wind. CPS2
  Violations are also increasing.
• Wind Ramp Controls now considered necessary and
  may be implemented in some form in the next year.

17
Improved AGC Response

• Improving the AGC response to deviations of the
  load-generation balance due to wind generation is
  one option to reducing overall wind integration
  costs.
• BPA Proposal Modify AGC Algorithm (Feed
  Forward AGC)
• Present AGC Actual Load Scheduled Generation
  (includes Wind schedules)
• New AGC Load Forecaster Scheduled Generation
  Forecasted Wind Generation
• Goal is to anticipate AGC response, reduce
  overshoot, cycling of units (wear and tear) and
  minimize generation on stand-by.
• Load Forecaster module to also be included in
  FF AGC.

18
Wind Forecast Module for FF AGC

• Develop 5 minute within-hour wind generation
  forecasts enhanced with weather and regional
  monitoring of wind generation.
• Uses Data (MW, wind speed, direction, unit
  status) from WTGs in Wind Farm, from all wind
  farms in BAA
• Other goals
• Provide output to adjust FCRPS generation
  schedules (mid-hour adjustment), reducing AGC
  units on stand-by or set aside for AGC.
• Provide mechanism to automate Wind Ramp Limits
  control if Balancing reserves below minimum
  capability (next 10 30 minutes).
• Pilot Project underway with 3-Tier to provide
  Forecasts
• Target Mid 2009 to have Pilot FF AGC implemented

19
BPA Wind Integration Rate

• Traditionally Loads have paid for regulation and
  load following as generation deviations were rare
  not so for wind.
• BPA held Public workshops to develop a new Wind
  Integration Rate for within-hour balancing.
  (Public review still underway).
• Rate to be applied to Wind Generation
• Rate to be effective for a one-year period, FY
  2009
• Rate will be based on installed capacity during
  rate period
• Assumes 2240 MW up to 2880 MW in BPA Control Area
• Estimates up to 23M needed for FY09 rate period

20
Wind Farm Dynamic Voltage Performance

• Early WTG designs were mostly induction machines
  (used switched caps for PF correction)
• Voltage control was limited to switched Caps on
  34.5kV bus
• Integration of large amounts of wind generation
  requires dynamic reactive control capabilities
• Need to match Synchronous Machines performance to
  maintain system performance and line loadings.
• Next slide compares effect of 2700 MW of wind on
  grid without Dynamic VAr support to synchronous
  generation response

21
Dynamic Simulations - Malin 500-kV bus voltage
Baseline 2700 MW of Wind with No Voltage
Control replaced 2700 MW of hydro thermal
22
Wind Farm Voltage Controller Requirements

• Voltage control of wind farms required to provide
  primary voltage support for system events.
  Options include
• High side Voltage Control (may be overly
  sensitive)
• Low side Voltage Control (may be too insensitive
  for system response)
• Line Drop reactive compensated Voltage Control
  (Qdroop)
• Line Drop adjustable up to15 (mid-line subgrid
  applications), for 7.5 typical applications
  allows for fine tuning of VC.
• Next slide demonstrates Line Drop options

23
Voltage Control Types
POI Voltage
High Side Voltage Control
VC with 7.5 Reactive Droop
VC with 15 Reactive Droop Low Side Voltage
Control
Power Factor / VAR Control
POI Reactive Power
24
Wind Farm Dynamic Performance Summary

• For Large Wind Generation BPA Requires -
  Controllable Dynamic VAr devices required (either
  WTG or DVAr devices)
• Voltage control mode required (no PF control) to
  provide primary voltage support for system events
• Type of voltage control depends on application,
  but Line Drop compensation preferred for
  flexibility of Application.
• Smaller Wind farms or those in mid-line or remote
  areas will still need to be evaluated on
  case-by-case basis.

25
Summary Wind Integration for BPA

• BPA continues to study a lot of wind
  interconnection requests (presently gt9000 MW in
  study queue)
• Total 1400 MW now interconnected and operating,
  may be 3000 MW by late 2009. Operation
  Challenges to be Addressed
• Regulation/Balance of Hour AGC/reserve
  requirements are increasing and are being
  addressed with new rate
• FF AGC should reduce impact and cost of Wind in
  BAA
• Wind ramp controls may be needed for Reliability
• Dynamic VAr for Voltage control needed to
  maintain system capacity and reliability

26
Questions?
