DHCP at Stanford

1
DHCP at Stanford

• Kent Reuber
• 725-8092, reuber_at_stanford.edu

2
Outline

• What DHCP is, and how it works
• Whats special about DHCP at Stanford
• What happens when DHCP doesnt work
• QA

3
Skills Youll Learn

• How to check Netdb records to see if DHCP is
  working the way you want
• How to look at DHCP server logs to troubleshoot
  problems
• How to uncover rogue DHCP servers on your network

4
DHCP Basics
5
What is DHCP

• Dynamic Host Configuration Protocol (RFC 2131)
• Automatically assigns IP addresses to devices
  (I.e. hosts) on your network
• Prevents having to manually enter data
• Prevents typos that can cause connectivity
  problems or disrupt the network (e.g., exchanging
  IP address and gateway address)

6
DHCP Conversation

• Four step process between client (UDP port 68)
  and servers (UDP port 67)
• Client sends Discover Someone send me an
  address. This is a broadcast.
• Servers Offer Use this address.
• Client Requests Ill use this one. (broadcast)
• Servers Acknowledge OK or No Way! (ACK/NAK)

7
DHCP Results

• Servers should provide address, net mask, DNS
  servers, domain, and gateway (and perhaps other
  stuff, e.g., WINS)
• Client will be allowed to use the address for a
  period of time called a Lease
• Normal campus addresses 2 day lease
• Roaming addresses 42 minutes

8
Lease Renewal

• Halfway through lease period, client asks its
  current server to continue using the address.
• Client sends Request (unicast).
• Server sends Acknowledge.
• If current server isnt available, client will
  broadcast request. This may cause it to change
  servers.
• If lease expires, client must stop using the
  address and start the process from scratch.

9
Looking at DHCP Information

• MacOS X
• Use ipconfig getpacket interface_name (e.g.,
  en0). Lease times are in hexadecimal.
• Windows NT/2000/XP
• Command line ipconfig /all
• Windows 95/98
• Winipcfg GUI utility

10
DHCP at Stanford
11
DHCP at Stanford Netdb Connection

• Have to have MAC (hardware) address in Netdb and
  DHCP box checked to get DHCP provided address
• If you specify one or more IP addresses for a MAC
  address, you will always get one of those
  addresses if appropriate
• Use more than one IP address if you have multiple
  home bases, for example, an office in one
  building and a lab in another building.

12
Example Whois Record

• Multiple interfaces with multiple addresses
• name lapwarmer
• type Node (Advanced)
• cpu Apple PowerBook

• op-sys MacOS X
• interfaces
• 1) name slab-en0
• hw-addr 000a.95a0.03ce dhcp roam
• ip-addr 171.64.20.45 slab
• 171.65.92.2
  slab-clark-92
• 2) name slab-en1
• hw-addr 0003.93eb.26dd dhcp roam
• ip-addr 171.66.32.245 slab-ap

13
DHCP and Netdb Roaming

• Checking roaming allows you to get an address
  from the local roaming address pool if none of
  the IP addresses associated with your MAC address
  are appropriate
• For example, my laptop wired interface has two
  home addresses, 171.64.20.45 and 171.65.92.2.
  When on those nets, Ill get the appropriate
  address. On other campus nets, Ill get an
  address from the local roaming pool if one is
  available.
• If local roaming pool is full or doesnt exist,
  Im stuck!

14
How Big is the Local Roaming Pool?

• The number of addresses available for roaming is
  specified by the LNA
• Look at the network record for the network of
  interest
• mac-kent-x reuber whois 171.64.20.0
• name Pine-B-net.Stanford.EDU
• ip-subnets
• 1) addr space 171.64.20.0/24 lo 5
  hi 5
• dhcp-addr 171.64.20.242
  DNab4014f2.Stanford.EDU
• 171.64.20.243
  DNab4014f3.Stanford.EDU
• 171.64.20.244
  DNab4014f4.Stanford.EDU
• 171.64.20.245
  DNab4014f5.Stanford.EDU
• 171.64.20.246
  DNab4014f6.Stanford.EDU

15
More Roaming Trivia

• Each DHCP server (dusk, dawn) is responsible for
  1/2 of the roaming pool.
• For example, if one of the servers were
  unavailable, only 1/2 of our roaming pool would
  be available.

16
Policy Issues

• Never add residential (128.12..) or Stanford
  West (171.66.152-159.) to campus Netdb records.
• Add campus address to residential or Stanford
  West records.
• Never assign clients new addresses in these
  ranges. Clients must contact RCC or Comm
  Services.
• More Stanford West info
• http//www.stanford.edu/group/itss-cns/stanfordwe
  st/faq.html

17
Troubleshooting
18
SUNet Reports Troubleshooting Page

• https//www.stanford.edu/group/networking/dist/sun
  et.reports/
• (Off the main SUNet reports page. Must be a
  registered LNA to access this page.)
• Has links for looking at DHCP conversation for a
  particular client and for DHCP Dynamic (I.e.,
  roaming) Address Utilization

19
Roaming Address Utilization

• Shows how many of your roaming addresses were
  used in the last 24 hrs.
• Pine-B-net 171.64.20.0/24 5
  3 60
• Very rough indicator of usage.

20
DHCP Client Conversation Report

• Takes practice to read. Look for common date and
  time for messages
• Most helpful if you type in the MAC address
  rather than the IP address
• Can see where the laptop has been
• Can see the discover message (I.e., before the
  device gets an address)

21
Odd Addresses You Might Encounter

• 10... Hospital uses this range, but Airport
  base stations also give out this range (esp.
  10.0.1.)
• 192.168... Used for a few special purposes on
  campus, but often used by rogue wireless access
  points
• 169.254.. Zero-conf address -- device cant
  contact DHCP server. May be indicative of Netdb,
  cabling, inactive jack, etc.
• 172.20.. Wireless guest network range
  (experimental). Will get this address on certain
  wireless nets when MAC address isnt in Netdb.

22
Troubleshooting Questions For DHCP Problems

• What address if any did clients receive?
• Is their Netdb record set up correctly (correct
  MAC, DHCP/roaming checked)?
• What network is the user connected to when
  theyre trying to use DHCP? What is the network
  range?
• Does the user have an address on this network or
  is the user roaming?
• Are there available roaming addresses (roaming is
  defined and there are free addresses)?
• Check DHCP server report? What happened?
• There may be a physical problem (cabling issues,
  jack not activated, NIC problems, etc.).

23
Finding Rogue DHCP Servers

• If users are getting inappropriate 10. or
  192.168. addresses, may need to hunt for a rogue
  server on your net.
• Often, these rogue servers are poorly configured
  access points or PCs/Macs set for Internet
  Sharing. Note Internet Sharing means sharing
  your address not your files! This shouldnt be
  used at Stanford!

24
Finding Rogue Servers

• Must do this from a machine getting a bad
  address!
• Ping the machine acting as your DHCP server. Can
  get this info from the command line. Often the
  rogue will advertise itself as the gateway.
• Get the MAC address
• OS X arp IP_ADDR
• Windows arp -a IP_ADDR
• Give MAC address to your LNA or submit a HelpSU
  ticket.

25
Questions?
