Architecture of the R/3 System

1
Architecture of the R/3 System

• Chapter 14 C L
• Chapter 8 M W

2
Problems of Enterprise-Wide Computing

• Slow response time during peak traffic loads
• Different time zones, systems, upgrades
• Heterogeneous database problem
• Multiple platforms

3
R/3 and Enterprise Computing

• Development of middleware enables portability
  across platforms
• Technologies include
• Db replication, messaging, XML, remote procedures
• R/3 supports
• TCP/IP
• RFC
• SQL ODBC
• OLE, MAPI, EDI

4
R/3 Server Installations

• 3-tier C/S preferred
• Homogeneous - same OS on one or more platforms
• Heterogeneous - a variety of platforms ex. UNIX,
  NT, Windows on application server
• UNIX with Oracle, Informix, DB2 on db server
• R/3 solves the distributed multiple heterogeneous
  platform problem with middleware

5
Benefits of Multiple Application Servers

• An alternate server can be automatically selected
  if one is unavailable
• Load balancing of clients to least busy server
• Can optimize queries and reduce load on db server
  to improve response time
• Because it is scalable, servers can be added as
  more processing capability is needed

6
C/S Scenarios

• Centralized host computer performs all tasks
  including db, applications, and presentation
• 2-tier C/S - db server is separate from thick
  client which processes apps and presentation
• 3-tier C/S - separate systems for db, apps, and
  presentation (preferred by R/3)
• N-tier C/S extension using servers on Internet

7
SAP R/3 Basis System
Data General HP (Intel) IBM (Intel)
UNIX Systems
Hardware
ATT Compaq
Sequent SNI . . .
IBM SNI SUN
Bull Digital HP
IBM AS/400
AIX Digital UNIX HP-UX
Operating Systems
SINIX SOLARS
OS/400
Windows NT
ADABAS D DB2 for AIX INFORMIX-OnLine ORACLE 10
ADABAS D MS SQL Server 9 ORACLE 10
Databases
Windows XP Windows NT, OS/2-Warp
Dialog SAP-GUI
Windows XP, Windows NT, OSF/Motif, OS/2-Warp,
Macintosh , Linux
Languages
ABAP/4, C, C
8
R/3 Middleware Transfer Protocols

• Front-end (presentation tier)
• R/3 GUI uses resident OS resources to cut flow of
  data to 1-2 KB
• whole screens are not passed but only logical
  control information and user inputs
• DB interface (between app and db servers)
• SAP SQL within ABAP/4 environment
• then translates queries into native SQL

9
R/3 Distribution Scenarios

• Initially, R/3 was designed with one centralized
  db in mind (from late 80s)
• ALE technology was developed to enable different
  integration scenarios
• Contained in Business Blueprint
• Centralized, integrated DB and application server
• Centralized by module on servers
• Completely decentralized R/3 with central db
• Next Generation architecture

10
DEV
QAS
PRD
CUST
TEST
SAND
QTST
TRNG
QTST
System Landscape for SAP R/3 Implementation
11
Next Generation ERP Architecture

• What is Internet ERP?
• N-tier
• EC, K Mgt, CRM, data mining, DSS, BI
  functionality on top of back office
• Integrated tools include
• BW with OLAP
• APO
• Sales Force Automation
• CRM
• B2B
• SCM

12
Enterprise Application Integration (EAI)
MS Office
Visual Basic
Java
DW environments
EAI Server
Legacy Applications
ERP Applications
CRM, etc
13
NetWeaver Adoption

• SAP anticipates that NetWeaver will redefine the
  company in a global manner
• About 5000 of more than 24,000 potential
  companies have put some portion of NetWeaver into
  play
• Early stage of maturity
• IBM and MicroSoft supporting NetWeaver
• SAP committed heavily to grow this in 2004 and
  2005

14
E-commerce and ERP

• E-commerce and ERP technologies are complements
• If the competition is using the Internet
  effectively, then a company needs to develop an
  Internet strategy
• Without integrated information systems, companies
  cannot support e-commerce effectively
• In 1999, eToys.com announced a week before
  Christmas that it would not be able to fill all
  Web orders
• Toys were in the warehouse, but the systems were
  not in place to process orders

15
SAPs Portal Play
16
Application Service Providers

• An Application Service Provider (ASP) provides
  management of application programs over a network
• Companies using the ASP do not have to purchase
  the hardware or software or higher people to
  operate systems
• ASPs can also provide consulting services for
  software applications like ERP
• ASPs can provide access to expensive applications
  like ERP with much lower startup costs

17
(No Transcript)
18
Application Service Providers

• ASP Advantages
• Affordability Many companies that previously
  couldnt afford ERP systems can now afford to
  lease it through an ASP
• Shorter implementation times Implementation time
  is shorter because the company does not have to
  purchase hardware and software and train
  technical staff
• Expertise ASPs are more likely to be able to
  hire and retain competent technical personnel
  than a small company can

19
Application Service Providers

• ASP Disadvantages
• Security Companies turn their critical
  information over to a 3rd party
• ASP must be able to insure data integrity
• ASP may have better security and controls than a
  small company
• Bandwidth/response time Telecommunications
  channel between ASP and company must be able to
  handle volume of transactions
• Flexibility The ASP must be flexible in working
  with users and satisfying requests for
  modifications

20
Application Service Providers

• ASP Disadvantages
• No frills An ASP may not be willing to support
  3rd party software or develop custom applications
  (e.g. ABAP programs)
• Technical, not business An ASP may know the
  technical aspects of the software but may not be
  capable of helping customers with business
  process and configuration decisions

21
(No Transcript)
