Title: Conversations with the Earth Tom Burbine tburbine@framingham.edu


1
Conversations with the EarthTom
Burbinetburbine_at_framingham.edu
2
Quiz
  • Monday for M,W, Th class
  • Tuesday for T, Th class
  • Covers material after last quiz
  • Chemistry
  • Global warming
  • Dinosaur extinction

3
Geologic time scale
  • System of measurement relating stratigraphy to
    time that is used to describe the timing and
    relationships between events that have occurred
    during the history of the Earth.

4
Stratigraphy
  • Stratigraphy study of rock layers and layering

5
Original Horizontality
  • Layers of sediment are originally deposited as an
    even, horizontal layer
  • Layers inclined at angles were moved by
    disturbances after deposition

6
Superposition
  • Each layer was deposited on top of older
    preexisting layers below

7
Principle of Superposition

http//earthsci.org/fossils/geotime/time/Super.gif
8
(No Transcript)
9
Exercise 3
  • Question 1
  • What is used to differentiate between different
    time periods?

10
  • Question 2
  • How long ago did the dinosaurs become extinct?

11
  • Question 3
  • How long were there dinosaurs living on the Earth?

12
(No Transcript)
13
(No Transcript)
14

15
  • Index fossils are fossils used to define and
    identify geologic periods
  • The shorter the lifespan of a species, the more
    precisely different sediments can be correlated

16
(No Transcript)
17
K-T layer
  • K-T layer is the boundary between the Cretaceous
    (K) and Tertiary (T) time periods
  • Clay layer that is found all
    over the globe

Colorado
18


Wyoming
19
Italy
20
K-T Boundary
  • 65 million years ago
  • Boundary in the rock record separating the
    Cretaceous and Tertiary Periods
  • Corresponds to one of the greatest mass
    extinctions in history
  • 1 cm global layer of clay separating the two
    periods
  • A reason for the extinction was proposed by
    Walter Alvarez and Luis Alvarez in 1980

21
(No Transcript)
22
  • Question 4
  • Why is a high concentration of iridium evidence
    that an asteroid hit the Earth?

23
Iridium
  • Iridium (Ir) is a chemical element with atomic
    number 77
  • Iridium is one of the least abundant elements
    (0.001 ppm) in the Earth's crust
  • Iridium is much more abundant in meteorites (0.5
    ppm or higher)

24
What happened?
  • An asteroid roughly 10 km (6 miles) across hit
    Earth about 65 million years ago.
  • This impact made a huge explosion and a crater
    about 180 km (roughly 110 miles) across.
  • Debris from the explosion was thrown into the
    atmosphere, severely altering the climate, and
    leading to the extinction of roughly 60 of
    species that existed at that time, including the
    dinosaurs.

25
Environmental Damage
  • http//www4.tpgi.com.au/users/horsts/climate.htm

26
  • The worst hit organisms were those in the oceans.
  • On land, the Dinosauria of course went extinct,
    along with the Pterosauria.
  • Mammals and most non- dinosaurian reptiles seemed
    to be relatively unaffected.
  • The terrestrial plants suffered to a large
    extent, except for the ferns, which show an
    apparently dramatic increase in diversity at the
    K-T boundary, a phenomenon known as the fern
    spike.

27
  • Pterosaurs were flying reptiles

28
  • Dinosaurs lived during the Mesozoic Era, from
    late in the Triassic period (about 225 million
    years ago) until the end of the Cretaceous (about
    65 million years ago).

29
  • Question 5
  • What species today are direct descendants of the
    dinosaurs?

30
Archaeopteryx
  • Modern birds are considered
    to be the direct descendants
    of dinosaurs
  • Idea first formulated in 1860s-1870s

31
Rahonavis
32
  • http//www.hulu.com/watch/63729/nova-the-four-wing
    ed-dinosaur

33
Any Questions?
