Cell Membranes and Signaling

1
Cell Membranes and Signaling
5
2
Chapter 5 Cell Membranes and Signaling

• Key Concepts
• 5.1 Biological Membranes Have a Common Structure
  and Are Fluid
• 5.2 Some Substances Can Cross the Membrane by
  Diffusion
• 5.3 Some Substances Require Energy to Cross the
  Membrane

3
Chapter 5 Cell Membranes and Signaling

• 5.4 Large Molecules Cross the Membrane via
  Vesicles
• 5.5 The Membrane Plays a Key Role in a Cells
  Response to Environmental Signals
• 5.6 Signal Transduction Allows the Cell to
  Respond to Its Environment

4
Chapter 5 Opening Question

• What role does the cell membrane play in the
  bodys response to caffeine?

5
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• A membranes structure and functions are
  determined by its constituents lipids, proteins,
  and carbohydrates.
• The general structure of membranes is known as
  the fluid mosaic model.
• Phospholipids form a bilayer which is like a
  lake in which a variety of proteins float.

6
Figure 5.1 Membrane Molecular Structure
7
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Lipids form the hydrophobic core of the membrane.
• Most lipid molecules are phospholipids with two
  regions
• Hydrophilic regionselectrically charged heads
  that associate with water molecules
• Hydrophobic regionsnonpolar fatty acid tails
  that do not dissolve in water

8
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• A bilayer is formed when the fatty acid tails
  associate with each other and the polar heads
  face the aqueous environment.
• Bilayer organization helps membranes fuse during
  vesicle formation and phagocytosis.

9
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Membranes may differ in lipid composition as
  there are many types of phospholipids.
• Phospholipids may differ in
• Fatty acid chain length
• Degree of saturation
• Kinds of polar groups present

10
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Two important factors in membrane fluidity
• Lipid compositiontypes of fatty acids can
  increase or decrease fluidity
• Temperaturemembrane fluidity decreases in colder
  conditions

11
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Biological membranes contain proteins, with
  varying ratios of phospholipids.
• Peripheral membrane proteins lack hydrophobic
  groups and are not embedded in the bilayer.
• Integral membrane proteins are partly embedded in
  the phospholipid bilayer.

12
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Anchored membrane proteins have lipid components
  that anchor them in the bilayer.
• Proteins are asymmetrically distributed on the
  inner and outer membrane surfaces.
• A transmembrane protein extends through the
  bilayer on both sides, and may have different
  functions in its external and transmembrane
  domains.

13
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Some membrane proteins can move within the
  phosopholipid bilayer, while others are
  restricted.
• Proteins inside the cell can restrict movement of
  membrane proteins, as can attachments to the
  cytoskeleton.

14
Figure 5.2 Rapid Diffusion of Membrane Proteins
15
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Plasma membrane carbohydrates are located on the
  outer membrane and can serve as recognition
  sites.
• Glycolipida carbohydrate bonded to a lipid
• Glycoproteina carbohydrate bonded to a protein

16
Concept 5.1 Biological Membranes Have a Common
Structure and Are Fluid

• Membranes are constantly changing by forming,
  transforming into other types, fusing, and
  breaking down.
• Though membranes appear similar, there are major
  chemical differences among the membranes of even
  a single cell.

17
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Biological membranes allow some substances, and
  not others, to pass. This is known as selective
  permeability.
• Two processes of transport
• Passive transport does not require metabolic
  energy.
• Active transport requires input of metabolic
  energy.

18
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Passive transport of a substance can occur
  through two types of diffusion
• Simple diffusion through the phospholipid bilayer
• Facilitated diffusion through channel proteins or
  aided by carrier proteins

19
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Diffusion is the process of random movement
  toward equilibrium.
• Speed of diffusion depends on three factors
• Diameter of the moleculessmaller molecules
  diffuse faster
• Temperature of the solutionhigher temperatures
  lead to faster diffusion

20
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• The concentration gradient in the systemthe
  greater the concentration gradient in a system,
  the faster a substance will diffuse
• A higher concentration inside the cell causes the
  solute to diffuse out, and a higher concentration
  outside causes the solute to diffuse in, for many
  molecules.

21
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Simple diffusion takes place through the
  phospholipid bilayer.
• A molecule that is hydrophobic and soluble in
  lipids can pass through the membrane.
• Polar molecules do not pass throughthey are not
  soluble in the hydrophilic interior and form
  bonds instead in the aqueous environment near the
  membrane.

22
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Osmosis is the diffusion of water across
  membranes.
• It depends on the concentration of solute
  molecules on either side of the membrane.
• Water passes through special membrane channels.

23
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• When comparing two solutions separated by a
  membrane
• A hypertonic solution has a higher solute
  concentration.
• Isotonic solutions have equal solute
  concentrations.
• A hypotonic solution has a lower solute
  concentration.

24
Figure 5.3A Osmosis Can Modify the Shapes of
Cells
25
Figure 5.3B Osmosis Can Modify the Shapes of
Cells
26
Figure 5.3C Osmosis Can Modify the Shapes of
Cells
27
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• The concentration of solutes in the environment
  determines the direction of osmosis in all animal
  cells.
• In other organisms, cell walls limit the volume
  that can be taken up.
• Turgor pressure is the internal pressure against
  the cell wallas it builds up, it prevents more
  water from entering.

28
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Diffusion may be aided by channel proteins.
• Channel proteins are integral membrane proteins
  that form channels across the membrane.
• Substances can also bind to carrier proteins to
  speed up diffusion.
• Both are forms of facilitated diffusion.

29
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Ion channels are a type of channel proteinmost
  are gated, and can be opened or closed to ion
  passage.
• A gated channel opens when a stimulus causes the
  channel to change shape.
• The stimulus may be a ligand, a chemical signal.

30
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• A ligand-gated channel responds to its ligand.
• A voltage-gated channel opens or closes in
  response to a change in the voltage across the
  membrane.

31
Figure 5.4 A Ligand-Gated Channel Protein Opens
in Response to a Stimulus
32
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Water crosses membranes at a faster rate than
  simple diffusion.
• It may hitchhike with ions such as Na as they
  pass through channels.
• Aquaporins are specific channels that allow large
  amounts of water to move along its concentration
  gradient.

33
Figure 5.5 Aquaporins Increase Membrane
Permeability to Water (Part 1)
34
Figure 5.5 Aquaporins Increase Membrane
Permeability to Water (Part 2)
35
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Carrier proteins in the membrane facilitate
  diffusion by binding substances.
• Glucose transporters are carrier proteins in
  mammalian cells.
• Glucose molecules bind to the carrier protein and
  cause the protein to change shapeit releases
  glucose on the other side of the membrane.

36
Figure 5.6 A Carrier Protein Facilitates
Diffusion (Part 1)
37
Figure 5.6 A Carrier Protein Facilitates
Diffusion (Part 2)
38
Concept 5.2 Some Substances Can Cross the
Membrane by Diffusion

• Transport by carrier proteins differs from simple
  diffusion, though both are driven by the
  concentration gradient.
• The facilitated diffusion system can become
  saturatedwhen all of the carrier molecules are
  bound, the rate of diffusion reaches its maximum.

39
Concept 5.3 Some Substances Require Energy to
Cross the Membrane

• Active transport requires the input of energy to
  move substances against their concentration
  gradients.
• Active transport is used to overcome
  concentration imbalances that are maintained by
  proteins in the membrane.

40
Table 5.1 Membrane Transport Mechanisms
41
Concept 5.3 Some Substances Require Energy to
Cross the Membrane

• The energy source for active transport is often
  ATP.
• Active transport is directional and moves a
  substance against its concentration gradient.
• A substance moves in the direction of the cells
  needs, usually by means of a specific carrier
  protein.

42
Concept 5.3 Some Substances Require Energy to
Cross the Membrane

• Two types of active transport
• Primary active transport involves hydrolysis of
  ATP for energy.
• Secondary active transport uses the energy from
  an ion concentration gradient, or an electrical
  gradient.

43
Concept 5.3 Some Substances Require Energy to
Cross the Membrane

• The sodiumpotassium (NaK) pump is an integral
  membrane protein that pumps Na out of a cell and
  K in.
• One molecule of ATP moves two K and three Na
  ions.

44
Figure 5.7 Primary Active Transport The
SodiumPotassium Pump
45
Concept 5.3 Some Substances Require Energy to
Cross the Membrane

• Secondary active transport uses energy that is
  regained, by letting ions move across the
  membrane with their concentration gradients.
• Secondary active transport may begin with passive
  diffusion of a few ions, or may involve a carrier
  protein that transports both a substance and ions.

46
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• Macromolecules are too large or too charged to
  pass through biological membranes and instead
  pass through vesicles.
• To take up or to secrete macromolecules, cells
  must use endocytosis or exocytosis.

47
Figure 5.8 Endocytosis and Exocytosis (Part 1)
48
Figure 5.8 Endocytosis and Exocytosis (Part 2)
49
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• Three types of endocytosis brings molecules into
  the cell phagocytosis, pinocytosis, and
  receptormediated endocytosis.
• In all three, the membrane invaginates, or folds
  around the molecules and forms a vesicle.
• The vesicle then separates from the membrane.

50
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• In phagocytosis (cellular eating), part of the
  membrane engulfs a large particle or cell.
• A food vacuole (phagosome) forms and usually
  fuses with a lysosome, where contents are
  digested.

51
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• In pinocytosis (cellular drinking), vesicles
  also form.
• The vesicles are smaller and bring in fluids and
  dissolved substances, as in the endothelium near
  blood vessels.

52
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• Receptormediated endocytosis depends on
  receptors to bind to specific molecules (their
  ligands).
• The receptors are integral membrane proteins
  located in regions called coated pits.
• The cytoplasmic surface is coated by another
  protein (often clathrin).

53
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• When receptors bind to their ligands, the coated
  pit invaginates and forms a coated vesicle.
• The clathrin stabilizes the vesicle as it carries
  the macromolecules into the cytoplasm.
• Once inside, the vesicle loses its clathrin coat
  and the substance is digested.

54
Figure 5.9 Receptor-Mediated Endocytosis (Part 1)
55
Figure 5.9 Receptor-Mediated Endocytosis (Part 2)
56
Concept 5.4 Large Molecules Cross the Membrane
via Vesicles

• Exocytosis moves materials out of the cell in
  vesicles.
• The vesicle membrane fuses with the plasma
  membrane and the contents are released into the
  cellular environment.
• Exocytosis is important in the secretion of
  substances made in the cell.

57
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Cells can respond to many signals if they have a
  specific receptor for that signal.
• A signal transduction pathway is a sequence of
  molecular events and chemical reactions that lead
  to a cellular response, following the receptors
  activation by a signal.

58
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Cells are exposed to many signals and may have
  different responses
• Autocrine signals affect the same cells that
  release them.
• Paracrine signals diffuse to and affect nearby
  cells.
• Hormones travel to distant cells.

59
Figure 5.10 Chemical Signaling Concepts
60
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Only cells with the necessary receptors can
  respond to a signalthe target cell must be able
  to sense it and respond to it.
• A signal transduction pathway involves a signal,
  a receptor, and a response.

61
Figure 5.11 Signal Transduction Concepts
62
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• A common mechanism of signal transduction is
  allosteric regulation.
• This involves an alteration in a proteins shape
  as a result of a molecule binding to it.
• A signal transduction pathway may produce short
  or long term responses.

63
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• A signal molecule, or ligand, fits into a
  three-dimensional site on the receptor protein.
• Binding of the ligand causes the receptor to
  change its three-dimensional shape.
• The change in shape initiates a cellular response.

64
Figure 5.12 A Signal Binds to Its Receptor
65
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Ligands are generally not metabolized further,
  but their binding may expose an active site on
  the receptor.
• Binding is reversible and the ligand can be
  released, to end stimulation.
• An inhibitor, or antagonist, can bind in place of
  the normal ligand.

66
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Receptors can be classified by their location in
  the cell.
• This is determined by whether or not their ligand
  can diffuse through the membrane.

67
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Cytoplasmic receptors have ligands, such as
  estrogen, that are small or nonpolar and can
  diffuse across the membrane.
• Membrane receptors have large or polar ligands,
  such as insulin, that cannot diffuse and must
  bind to a transmembrane receptor at an
  extracellular site.

68
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Receptors are also classified by their activity
• Ion channel receptors
• Protein kinase receptors
• G proteinlinked receptors

69
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Ion channel receptors, or gated ion channels,
  change their three-dimensional shape when a
  ligand binds.
• The acetylcholine receptor, a ligand-gated sodium
  channel, binds acetylcholine to open the channel
  and allow Na to diffuse into the cell.

70
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Protein kinase receptors change their shape when
  a ligand binds.
• The new shape exposes or activates a cytoplasmic
  domain that has catalytic (protein kinase)
  activity.

71
Figure 5.13 A Protein Kinase Receptor
72
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Protein kinases catalyze the following reaction
• ATP protein ? ADP phosphorylated protein
• Each protein kinase has a specific target
  protein, whose activity is changed when it is
  phosphorylated.

73
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Ligands binding to G proteinlinked receptors
  expose a site that can bind to a membrane
  protein, a G protein.
• The G protein is partially inserted in the lipid
  bilayer, and partially exposed on the cytoplasmic
  surface.

74
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• Many G proteins have three subunits and can bind
  three molecules
• The receptor
• GDP and GTP, used for energy transfer
• An effector protein to cause an effect in the cell

75
Concept 5.5 The Membrane Plays a Key Role in a
Cells Response to Environmental Signals

• The activated G proteinlinked receptor exchanges
  a GDP nucleotide bound to the G protein for a
  higher energy GTP.
• The activated G protein activates the effector
  protein, leading to signal amplification.

76
Figure 5.14 A G ProteinLinked Receptor
77
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Signal activation of a specific receptor leads
  to a cellular response, which is mediated by a
  signal transduction pathway.
• Signaling can initiate a cascade of protein
  interactionsthe signal can then be amplified and
  distributed to cause different responses.

78
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• A second messenger is an intermediary between the
  receptor and the cascade of responses.
• In the fight-or-flight response, epinephrine
  (adrenaline) activates the liver enzyme glycogen
  phosphorylase.
• The enzyme catalyzes the breakdown of glycogen to
  provide quick energy.

79
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Researchers found that the cytoplasmic enzyme
  could be activated by the membrane-bound
  epinephrine in broken cells, as long as all parts
  were present.
• They discovered that another molecule delivered
  the message from the first messenger,
  epinephrine, to the enzyme.

80
Figure 5.15 The Discovery of a Second Messenger
(Part 1)
81
Figure 5.15 The Discovery of a Second Messenger
(Part 2)
82
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• The second messenger was later discovered to be
  cyclic AMP (cAMP).
• Second messengers allow the cell to respond to a
  single membrane event with many events inside the
  cellthey distribute the signal.
• They amplify the signal by activating more than
  one enzyme target.

83
Figure 5.16 The Formation of Cyclic AMP
84
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Signal transduction pathways involve multiple
  stepsenzymes may be either activated or
  inhibited by other enzymes.
• In liver cells, a signal cascade begins when
  epinephrine stimulates a G proteinmediated
  protein kinase pathway.

85
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Epinephrine binds to its receptor and activates a
  G protein.
• cAMP is produced and activates protein kinase
  Ait phosphorylates two other enzymes, with
  opposite effects
• Inhibition
• Activation

86
Figure 5.17 A Cascade of Reactions Leads to
Altered Enzyme Activity (Part 1)
87
Figure 5.17 A Cascade of Reactions Leads to
Altered Enzyme Activity (Part 2)
88
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Inhibitionprotein kinase A inactivates glycogen
  synthase through phosphorylation, and prevents
  glucose storage.
• ActivationPhosphorylase kinase is activated when
  phosphorylated and is part of a cascade that
  results in the liberation of glucose molecules.

89
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Signal transduction ends after the cell
  respondsenzymes convert each transducer back to
  its inactive precursor.
• The balance between the regulating enzymes and
  the signal enzymes determines the cells response.

90
Figure 5.18 Signal Transduction Regulatory
Mechanisms
91
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Cells can alter the balance of enzymes in two
  ways
• Synthesis or breakdown of the enzyme
• Activation or inhibition of the enzymes by other
  molecules

92
Concept 5.6 Signal Transduction Allows the Cell
to Respond to Its Environment

• Cell functions change in response to
  environmental signals
• Opening of ion channels
• Alterations in gene expression
• Alteration of enzyme activities

93
Answer to Opening Question

• Caffeine is a large, polar molecule that binds to
  receptors on nerve cells in the brain.
• Its structure is similar to adenosine, which
  binds to receptors after activity or stress and
  results in drowsiness.
• Caffeine binds to the same receptor, but does not
  activate itthe result is that the person remains
  alert.

94
Figure 5.19 Caffeine and the Cell Membrane (Part
1)
95
Figure 5.19 Caffeine and the Cell Membrane (Part
2)
