Systems Supporting Distributed Collaboration

1
Systems Supporting Distributed Collaboration
Prasun Dewan
Department of Computer Science University of
North Carolina CB 3175 Sitterson Hall Chapel
Hill, NC 27599-3175 dewan_at_cs.unc.edu http/www.c
s.unc.edu/dewan
2
Definition

• Oxford Work jointly esp at literary or artistic
  production
• Malone helps people work together more
  effectively
• Lynch et al makes users aware they are part of a
  group
• Wells software and hardware for shared
  interactive environment
• Ellis supports groups engaged in a common task
  and provides an interface to shared environment
• Peter Johnson-Lenz computer-mediated culture,
  intentional group processes plus supporting
  software
• Johansen specialized computer aids for
  collaborative work groups
• Winograd state of mind

3
Definition
Collaborative Application

• Same output?
• Symmetric?
• N-User?

I/O
I/O
Coupling
User 2
User 1
Potentially Real-Time
4
Traditional Collaborative Applications
File
Mail
Talk
5
Benefits Towards Being There
Face-to-Face
Interaction
Computer-Supported
Interaction
Network
6
Gesture Cam Remote Surrogate
7
Benefits Beyond Being There
Face-to-Face
Hollan Stornetta 92
Interaction
Computer-Supported
Interaction
Network
8
Action Workflow
Status By Candidate Workflow Step
Manage Review
Manager
Director
9
Combining Both Goals?

• IM
• Feel transported to a common abstract world
• Can specify mood
• Collaborative nanoManipulator

10
(No Transcript)
11
Collaboration vs. Virtual Environments
VE
12
Collaboration vs. Real-Time Distributed Apps.
Collaborative Applications
13
Collaboration vs. Mobile Apps.
Mobile Applications
Collaborative Applications
14
Relationship with Object-Oriented and User
Interface- Technology
Interactive Applications
O-O Applications
15
Traditional System Aspects
Applications
Shared Screen
FC vs. CC
Interoperability
Extensibility/Composability
Applications
Telepointer Jitter
Performance/Resource Management
Functionality/Abstraction
Coupling
System Support
16
Views of Collaboration Systems

• Ensure actual needs met.
• Conceptual depth, avoid duplication.
• Build on existing knowledge.
• See integrated sets of features

• Problems
• Issues
• Disciplines
• Systems
• Applications and Infrastructures

17
Problems Application Areas

• Business Management
• National Collaboratory
• Software Engineering
• Engineering/Design
• Writing

• Decision making, business processes, monitor
  state.
• Connected labs.
• Team development, pair programming
• Just in time VR-based
• Distributed co-authoring.

18
Problems Application Areas

• Education
• Medicine
• Air Traffic Control
• Command and Control
• Games/Casual Interaction
• Any complex task!

• Distance presentation, remote lab., colab
  projects
• Remote consult, workflow
• Coordinate controllers
• Coordination
• Sharing of information/actions
• Is collaborative

19
Generic Tasks

• Social Interaction
• Information Exchange
• Presentation
• Consulting
• Comment/Discuss
• Compose Artifact

20
Generic Tasks Product Life Cycle

• Design
• Implementation
• Debugging/Testing
• Inspection/Review

21
Specific Experimental Tasks

• Annotate/discuss research article/software
  specs/video
• Present lecture to remote and local audience
• Rank job candidates
• Choose videos to rent, take on road trip
• Get status report on action items and feedback
  from each participant
• Choose name for new game
• Search for shopping list online

22
Views of Collaboration Systems

• Problems
• Issues
• Disciplines
• Systems Applications and Infrastructures

23
Issues Semantics

• Session Management How do distributed users
  create, destroy, join, and leave collaborative
  sessions?
• Single-User Interface What are the application
  semantics if there is a single user in the
  session?
• Coupling what feedback does a user receive in
  response to the input of another user?
• Access Control How do we ensure that users do
  not execute unauthorized commands?
• Concurrency Control How do we ensure that
  concurrent users do not enter inconsistent
  commands?

24
Issues Semantics (Contd.)

• Process Control How do we ensure that users
  follow prescribed group processes?
• Merging How do we merge concurrent commands
  entered by different users?
• Undo/Redo What are the semantics of undo/redo
  in a collaborative session?
• Awareness How are users made aware of out of
  band'' activities of their collaborator?

25
Issues Implementation

• Objects What kind of objects are composed in a
  collaborative application?
• Collaboration Awareness Which of these objects
  are collaboration aware and how are these objects
  integrated with existing, collaboration-unaware
  objects?
• Layers How are these objects arranged in
  layers?
• Concurrency How is the application decomposed
  into concurrent threads?
• Distribution How are the application objects
  placed in different address spaces and hosts?

26
Issues Implementation (Contd.)

• Replication/Migration Which of these objects
  are centralized and which are replicated? Which
  of the centralized objects can migrate?
• Display Consistency How to ensure actions are
  executed in the same order on computers that
  share them?
• Real-Time Support What kind of services are
  provided to ensure real-time interaction with
  tolerable jitter and latency?

27
Views of Collaboration Systems

• Problems
• Issues
• Disciplines
• Systems Applications and Infrastructures

28
Computer Science Disciplines

• Operating Systems
• Database Management Systems
• Programming Languages
• User Interface Systems
• Software Engineering

• Distributed file, memory, scheduling, OS-based
  IM
• Concurrency Control, Recovery
• Shared object constructs
• I/O distribution of window systems, toolkits
• Application area, process control, patterns

29
Views of Collaboration Systems

• Problems
• Issues
• Disciplines
• Systems Applications and Infrastructures

30
Systems Applications

• RTCALendering
• Cognoter whiteboard
• CES (Transaction-based Collaborative Editing
  System)
• Grove Outline Editor
• Information Lens Typed Email
• Coordinator Speech-Act Workflow
• Quilt Editor Annotations
• IBIS Discussions
• Video Walls
• Hydra
• GroupDraw optimistic CC
• PREP Diff-based Editor
• MUDs (Multiuser Dungeons)
• DIVE (Distributed Interactive
• Virtual Environment)/ MASSIVE

• MIT (Sarin Greif)
• Xerox (Stefik et al)
• MIT (Liskov)
• MCC (Ellis)
• MIT (Malone )
• Stanford (Winograd 88)
• Bellcore (Leland)
• MCC (Ellis)
• Xerox (Abel)
• U. Toronto (Buxton)
• U. Calgary (Greenberg)
• CMU (Neuwirth)
• Xerox (Curtis)
• Sweden (Fahlen)/ Nottingham (Benford)

31
Applications Products

• Groove Apps
• OneNote
• Spreadsheet
• Word Processor
• IM

• Microsoft
• Microsoft
• Google
• Google/Writely
• Everyone

32
Systems Infrastructures

• NLS (Engelbart 68)
• Colab (Stefik 85)
• VConf (Lantz 86)
• Rapport (Ahuja 89)
• XTV (Abdel-Wahab, Jeffay Feit 91)
• Rendezvous (Patterson 90)
• Suite (Dewan Choudhary 92)
• TeamWorkstation (Ishii 92)
• Weasel (Graham 95)
• Habanero (Chabert et al 98)
• JCE (Abdel-Wahab 99)
• Disciple (Marsic 01)
• Sync (Munson Dewan 96)
• App-Sharer (Chung, Junuzovic, Dewan 06)

• Post Xerox
• Xerox
• Stanford
• Bell Labs
• UNC/ODU
• Bellcore
• Purdue
• Japan
• Queens
• U. Illinois
• ODU
• Rutgers
• UNC

33
Infrastructure Products

• VNC (Li, Stafford-Fraser, Hopper 01)
• NetMeeting (MSFT)
• Groove (MSFT)
• Advanced Reality
• LiveMeeting -Pay by minute service model (MSFT)
• Webex (service model)
• MeetingPlace (Cisco)
• CollaborateNow (IBM)

34
Multiple Views
Coupling
Cognoter
WYSIWIS Interaction
Database Transactions
NetMeeting
Software Engineering
Design
35
Course Goals

• Study State-of-the-art
• Applications
• Shared Word, Browser
• Infrastructure
• Groove, Shared Objects
• Project
• Survey
• Writing
• Integrate with Survey Paper
• Programming
• Integrate with 243/Program Product
• Presentation
• Research
• Assignments
• Using applications and infrastructures
  collaboratively

36
Projects

• Infrastructure-based
• Application-/usage- based
• Something usable as this area is
• Practical (probably)
• Unexplored
• Build on top of existing infrastructure
• Sync
• Asynchronous and synchronous
• Application Sharer
• Synchronous existing and new applications

37
Application-based

• Make familiar apps collaborative
• Microsoft Office
• Open Office
• Basics implemented
• Make it really work, efficiently
• Eclipse
• Jazz provides some asynchronous support
• Sangam some synchronous support
• Can provide semi-synchronous support
• Loosely coupled pair programming
• Probably remain a prototype

38
Application-based

• Custom application for data shared through
  Wikis/Google spreadsheet
• Shared shopping list
• Recreation activities
• Organizing pot-luck parties (custom Evite)
• Departmental activities
• Organizing study groups
• Scheduling departmental picnics
• Signup sheet for demos in 242
• Creating groups in 790-063

39
Application-based

• Teaching and TA Award
• Currently nominations requested and then some
  magic happens.
• Allow entry of data and voting and linking of
  teaching evaluations and other data.
• Departmental calendar
• Every week mail sent to coordinator by a certain
  time.
• Calendar emailed and updated by a central person.
• Make this distributed and allow people to enter
  data way in advance.
• Same with Systems Tea

40
Application-based

• Qual scheduler
• Automatic did not work.
• Semi-automatic, collaborative.
• Students enter courses and time constraints
• Faculty members enter expertise and time
  constraints
• Schedulers form committees and assign times
  based.
• System checks qual constraints met.
• TA/RA Matcher
• Students and faculty enter preferences.
• Administrators can see all data.
• Students and faculty can see filtered data.
• E.g. one on one matches.

41
Application-based

• Undergrad Advising
• filling a form.
• Looking up requirements
• Scheduling a meeting
• Some initial work done by a 145 team

42
Infrastructure-based

• Shared layer
• VNC and NetMeeting share different user-interface
  layers
• Benefits of different sharing different layers.
• Can we dynamically change shared layer?
• Dynamic policies, performance model
• Work on application sharer

43
Infrastructure-based

• Scheduling
• Feedback vs. Feedthrough processing
• Give sufficient time to both using proportional
  scheduling.
• Energy-aware collaboration
• Energy dissipation a function of amount and rate
  of information communication
• Can study and adjust the coupling (send summary
  information in batches)

44
Infrastructure-based

• Locking
• Many locking schemes
• Lock whole spreadsheet vs. individual cell.
• Provide one comprehensive mechanism.
• Partly designed but not implemented.
• Lock-free Consistency management
• Locking ensures displays are consistent no race
  conditions.
• Consistency without locks operation
  transformation
• Called optimistic CC misnomer
• For the mathematically inclined

45
Infrastructure-based

• Context-specific presence
• Can synchronously monitor idle time.
• Can synchronously monitor every input in shared
  apps.
• Synchronously summarize application-specific
  information
• E.g. whose mail are you reading?
• Access control
• Needed because we collaborate
• But it is a pain
• Let us collaborate on setting access control.
• An implementation exists
• User studies

46
Example collaborative application
47
Example collaborative application
48
Example collaborative application
49
Example collaborative application
50
Example collaborative application
51
Implementation Alternatives

• Collaboration-unaware apps
• Screen/window (Application) sharing
• Based on existing UI architectures
• App sharing system is collaboration-aware
• ???
• Based on other, ideally popular architectures
• Maybe based on some other cola-aware
  infrastructure
• Collaboration-aware apps
• Based on some architecture or collaboration-aware
  infrastructure

52
Does App Sharing work?
Different Window Sizes, Data
53
Implementation Alternatives

• Collaboration-unaware apps
• Screen/window (Application) sharing
• Based on existing UI architectures
• App sharing system is collaboration-aware
• ???
• Based on other, ideally popular architectures
• Maybe based on some other colab-aware
  infrastructure
• Collaboration-aware apps
• Based on some architecture or collaboration-aware
  infrastructure

54
Model, View and Controller (MVC)
View
Controller
Model
55
Model, View and Controller (MVC)
Controller
View
Model
View
Controller
56
Model Code

• public class ConcertExpense
• float unitCost 0
• int numberOfAttendees 0
• PropertyChangeSupport propertyChange
  new PropertyChangeSupport(this)
• public float getTicketPrice() return
  unitCost
• public void setTicketPrice(float newVal)

• if (newVal unitCost) return
• float oldVal unitCost int oldTotal
  getTotal()
• unitCost newVal
• propertyChange.firePropertyChange("ticket
  Price", oldVal, newVal)
• propertyChange.firePropertyChange("total"
  , oldTotal, getTotal())
• public int getNumberOfAttendees()
  return numberOfAttendees
• public void setNumberOfAttendees(int
  newVal)
• if (numberOfAtendees newVal) return
• int oldVal numberOfAttendees int oldTotal
  getTotal()
• numberOfAttendees newVal
  propertyChange.firePropertyChange("numberOfAttend
  ees", oldVal, newVal)
• propertyChange.firePropertyChange("total"
  , oldTotal, getTotal())

57
MVC Composition

• package main
• import budget.ConcertExpense
• import bus.uigen.ObjectEditor
• public class MVCBudget
• public static void main(String args)
• ConcertExpense model new ConcertExpense ()
• ObjectEditor.edit(model)

58
Distributed MVC
Controller
View
Model
View
Controller
59
DistributedModel Code

• public class ConcertExpense extends
  UnicastRemoteObject implements Remote
• float unitCost 0
• int numberOfAttendees 0
• RemotePropertyChangeSupport
  propertyChange new RemotePropertyChangeSupport(t
  his)
• public float getTicketPrice() throws
  RemoteException return unitCost
• public void setTicketPrice(float newVal)

• unitCost newVal
• propertyChange.firePropertyChange("ticket
  Price", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())
• public int getNumberOfAttendees() throws
  RemoteException return numberOfAttendees
• public void setNumberOfAttendees (int
  newVal) throws RemoteException
• numberOfAttendees newVal
• propertyChange.firePropertyChange("number
  OfAttendees", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())
• public float getTotal() throws
  RemoteException return unitCostnumberOfAttendees

• public void addRemotePropertyChangeListene
  r(RemotePropertyChangeListener l) throws
  RemoteException
• propertyChange.addRemotePropertyChange
  Listener(l)

Distribution-Aware
60
Notification

• public interface PropertyChangeListener
• public void propertyChange(PropertyChangeEve
  nt evt)

Does not extend Remote
61
Remote Notification
package util import java.beans.PropertyChangeEven
t import java.rmi.Remote import
java.rmi.RemoteException public interface
RemotePropertyChangeListener extends Remote
public void remotePropertyChange(PropertyChange
Event evt) throws RemoteException
62
Registering a Model

• import java.rmi.Naming
• public class AConcertExpenseRegisterer
• public final static String RMI_PORT 1099
  // default port for RMI service
• public final static MODEL_NAME
  myDemoBudget
• public static void main (String args)
• try
• String host_name
• java.net.InetAddress.getLocalHost().getCanonica
  lHostName()
• ConcertExpense model new ConcertExpense()
• String budgetName "//" host_name ""
  RMI_PORT "/" MODEL_NAME
• Naming.rebind(budget_name, model)
• catch (Exception e)
• e.printStackTrace()

63
Looking up a Model

• import java.rmi.Naming
• import bus.uigen.ObjectEditor
• public class AConcertExpenseComposer
• final static String REMOTE_HOST
  dewan-cs.cs.unc.edu
• final static FULL_MODEL_NAME //"
  REMOTE_HOST "" AConcerExpenseRegisterer.RM
  I_PORT "/" AConcertExpenseRegisterer.MODEL_
  NAME
• public static void main (String args)
• try
• ConcertExpense model (ConcertExpense)
  Naming.lookup(MODEL_NAME)
• // connect to generic model and view
• ObjectEditor.edit(model)
• catch (Exception e)
• e.printStackTrace()

64
Compile Runtime steps

• Compile steps
• rmic budget.ConcertExpense
• Runtime steps
• Start rmi service
• set CLASSPATHltmodel, stubs, skel directorygt
• rmiregistry 1099
• Start registerer
• Start composer at each users workstation

65
Screen Sharing vs. MVC Sharing
Data convergence after each user command
WYSIWIS
66
Transactions/Disconnection
67
Transactions/Disconnection
68
Concurrent Transactions
69
Concurrent Transactions
70
Concurrent Transactions
71
Concurrent Transactions
72
Concurrent Transactions
73
Concurrent Transactions
74
Concurrent Transactions
75
Conflicting Transactions
76
Conflicting Transactions
77
Conflicting Transactions
78
Conflicting Transactions
79
Overriding Transactions
80
Overriding Transactions
81
Private Data
82
Minimum Goals

• Model and not View Sharing
• Logical Disconnection
• Asynchronous Connected Transactions
• Disconnected Transactions
• Conflict resolution
• Awareness of collaborators
• Private Data

83
Distributed MVC
Controller
View
Model
View
Controller
84
Replicated MVC
Controller
View
Model
Model-View Communication same as Model-Model
Communication?
Model
View
Controller
85
Distributed MVC
Controller
View
Model

• Equivalent to Centralized
• Performance difference
• May change dynamically

View
Controller
86
Replicated MVC
Controller
View
Model
Both users create replicas?
Model
View
Controller
87
Disconnected Interaction
Controller
View
Model
88
Need Replicating Infrastructure
Controller
View
Model
Binds to Local (Possibly Different)
View/Controller
Serializes Model
Infrastructure
89
Need Replicating Infrastructure
Controller
View
Model
Client Part
Server Part
90
Original Model Code

• public class ConcertExpense
• float unitCost 0
• int numberOfAttendees 0
• PropertyChangeSupport propertyChange
  new PropertyChangeSupport(this)
• public float getTicketPrice() return
  unitCost
• public void setTicketPrice(float newVal)

• if (newVal unitCost) return
• float oldVal unitCost int oldTotal
  getTotal()
• unitCost newVal
• propertyChange.firePropertyChange("ticket
  Price", oldVal, newVal)
• propertyChange.firePropertyChange("total"
  , oldTotal, getTotal())
• public int getNumberOfAttendees()
  return numberOfAttendees
• public void setNumberOfAttendees(int
  newVal)
• if (numberOfAtendees newVal) return
• int oldVal numberOfAttendees int oldTotal
  getTotal()
• numberOfAttendees newVal
  propertyChange.firePropertyChange("numberOfAttend
  ees", oldVal, newVal)
• propertyChange.firePropertyChange("total"
  , oldTotal, getTotal())

Requires use of standard notification mechanism
so local infrastructure can listen
91
Replicated Model Code

• public class ConcertExpense implements
  Serializable
• float unitCost 0
• int numberOfAttendees 0
• transient PropertyChangeSupport
  propertyChange new PropertyChangeSupport(this)

• public float getTicketPrice() return
  unitCost
• public void setTicketPrice(float newVal)

• if (newVal unitCost) return
• float oldVal unitCost int oldTotal
  getTotal()
• unitCost newVal
• propertyChange.firePropertyChange("ticket
  Price", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())
• public int getNumberOfAttendees()
  return numberOfAttendees
• public void setNumberOfAttendees(int
  newVal)
• if (numberOfAtendees newVal) return
• int oldVal numberOfAttendees int oldTotal
  getTotal()
• numberOfAttendees newVal
• propertyChange.firePropertyChange("number
  OfAttendees", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())

Transient variables null in serialized object
No cycles should be created by non-transient
links
92
Replicated Model Code

• public class ConcertExpense implements
  Serializable
• float unitCost 0
• int numberOfAttendees 0
• transient PropertyChangeSupport
  propertyChange new PropertyChangeSupport(this)

• public float getTicketPrice() return
  unitCost
• public void setTicketPrice(float newVal)

• if (newVal unitCost) return
• float oldVal unitCost int oldTotal
  getTotal()
• unitCost newVal
• propertyChange.firePropertyChange("ticket
  Price", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())
• public int getNumberOfAttendees()
  return numberOfAttendees
• public void setNumberOfAttendees(int
  newVal)
• if (numberOfAtendees newVal) return
• int oldVal numberOfAttendees int oldTotal
  getTotal()
• numberOfAttendees newVal
• propertyChange.firePropertyChange("number
  OfAttendees", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())

Method with well known signature called by
Infrastructure on serialized object
93
Fine-Grained Merging

• Objects are encapsulated.
• How to break state into units
• To read incremental state
• Set incremental state
• Serializing copies complete object
• Use Bean Programming Patterns and Property
  Notifications

94
MVC Composition

• package main
• import budget.ConcertExpense
• import bus.uigen.ObjectEditor
• public class MVCBudget
• public static void main(String args)
• ConcertExpense model new ConcertExpense ()
• ObjectEditor.edit(model)

95
Registering and composing

• package main
• import budget.ConcertExpense
• import edu.unc.sync.Sync
• public class SyncBudgetCreator
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static String CLIENT_ID "alice"
• public static void main(String args)
• ConcertExpense model new ConcertExpense ()
• Sync.replicate (SERVER_NAME,
• MODEL_NAME,
• model,
• CLIENT_ID)
• ObjectEditor.edit(model)

96
Looking up and composing
Special program needed for creator

• package main
• import budget.ConcertExpense
• import edu.unc.sync.Sync
• import edu.unc.sync.server.SyncClient
• import edu.unc.sync.server.ServerProxy
• public class SyncBudgetUser
• static String CLIENT_ID bob"
• public static void main(String args)
• SyncClient client Sync.open
  (SyncBudgetCreator.SERVER_NAME,
• SyncBudgetAlice.MODEL_NAME,
• CLIENT_ID)
• ServerProxy server client.getServerProxy(SyncB
  udgetCreator.SERVER_NAME)
• ConcertExpense model (ConcertExpense)
  server.getModel
• (SyncBudgetCreator.MODEL_NAME)
• ObjectEditor.edit(model)

97
Symmetric Programs

• System can create new model only if it does not
  exist.
• It can be given model class instead of model
  instance

98
Maybe Registering and composing

• package main
• import budget.ConcertExpense
• import edu.unc.sync.Sync
• import edu.unc.sync.SyncClient
• import edu.unc.sync.SyncProxy
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static Class MODEL_CLASS
  ConcertExpense.class
• public static void main(String args)
• SyncClient client Sync.replicate
  (SERVER_NAME, MODEL_NAME,
• MODEL_CLASS, args0)
• ServerProxy server client.getServerProxy(SERVE
  R_NAME)
• ConcertExpense model (ConcertExpense)
  server.getModel (MODEL_NAME)
• ObjectEditor.edit(model)

99
Infrastructure-defined Model-View Interface

• If Infrastructure defines model-view interface
• It can create model and view
• It can compose them

100
Automatic Creation of MVC Structure

• package main
• import budget.ConcertExpense
• import edu.unc.sync.SyncObjectEditor
• import edu.unc.sync.Sync
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static Class MODEL_CLASS
  ConcertExpense.class
• public static Class EDITOR_CLASS
  SyncObjectEditor.class
• public static void main(String args)
• Sync.replicate (SERVER_NAME, MODEL_NAME,
•
  MODEL_CLASS, EDITOR_CLASS, args0)

Can execute this interactively!
101
View Interfaces

• package edu.unc.sync.server
• import edu.unc.sync.Replicated
• public interface SyncApplication
• public void init(Object invoker) // invoker
  is sync client or server
• public void addObject(Replicated object,
  String name) // replicated is what model gets
  converted to
• public void addObject(Object object, String
  name)
• public void doRefresh() // Sync calls this
  whenever it updates model in case app does not
  listen to events

102
Automatic Creation of MVC Structure

• package main
• import budget.ConcertExpense
• import edu.unc.sync.SyncObjectEditor
• import edu.unc.sync.Sync
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static Class MODEL_CLASS
  ConcertExpense.class
• public static Class EDITOR_CLASS
  SyncObjectEditor.class
• public static void main(String args)
• Sync.replicate (SERVER_NAME, MODEL_NAME,
•
  MODEL_CLASS, EDITOR_CLASS, args0)

Constructors with parameters?
103
Constructors with Parameters

• Dont have them
• Use init method.
• Application knows what parameters to give.
• Infrastructure knows when and if to create
  instance.
• Application gives factory.
• For any model or editor class

104
Automatic Creation of MVC Structure

• package main
• import budget.ConcertExpense
• import edu.unc.sync.SyncObjectEditor
• import edu.unc.sync.Sync
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static Class MODEL_CLASS
  ConcertExpense.class
• public static Class EDITOR_CLASS
  SyncObjectEditor.class
• public static void main(String args)
• Sync.register(ConcertExpense.class, new
  ConcertExpenseFactory())
• Sync.replicate (SERVER_NAME, MODEL_NAME,
•
  MODEL_CLASS, EDITOR_CLASS, args0)

105
Factory Interfaces
package edu.unc.sync public interface
ObjectFactory public Object newInstance(Class
c)

• import budget.ConcertExpense
• import edu.unc.sync.ObjectFactory
• public class ConcertExpenseFactory implements
  ObjectFactory
• public Object newInstance (Class c)
• return new ConcertExpense()

106
Multiple Models

• package main
• import budget.ConcertExpense
• import edu.unc.sync.SyncObjectEditor
• import edu.unc.sync.Sync
• import edu.unc.sync.SyncClient
• import edu.unc.sync.SyncProxy
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static String MODEL_NAME_2
  "demoBudget2"
• public static Class MODEL_CLASS
  ConcertExpense.class
• public static Class EDITOR_CLASS
  SyncObjectEditor.class
• public static void main(String args)
• SyncClient client Sync.replicate
  (SERVER_NAME, MODEL_NAME,
•
  MODEL_CLASS, EDITOR_CLASS, args0)
• ServerProxy server client.getServerProxy(SERVE
  R_NAME)
• server.newObject(MODEL_NAME_2,
  ConcertExpense.class, EDITOR_CLASS)

107
Replicated Model Code

• public class ConcertExpense implements
  Serializable
• float unitCost 0
• int numberOfAttendees 0
• transient PropertyChangeSupport
  propertyChange new PropertyChangeSupport(this)

• public float getTicketPrice() return
  unitCost
• public void setTicketPrice(float newVal)

• if (newVal unitCost) return
• float oldVal unitCost int oldTotal
  getTotal()
• unitCost newVal
• propertyChange.firePropertyChange("ticket
  Price", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())
• public int getNumberOfAttendees()
  return numberOfAttendees
• public void setNumberOfAttendees(int
  newVal)
• if (numberOfAtendees newVal) return
• int oldVal numberOfAttendees int oldTotal
  getTotal()
• numberOfAttendees newVal
• propertyChange.firePropertyChange("number
  OfAttendees", null, newVal)
• propertyChange.firePropertyChange("total"
  , null, getTotal())

No cycles created by non-transient links
108
Supporting Private Data?
109
Unshared Property

• public class ConcertExpenseWithAttendance extends
  ConcertExpense
• boolean attend
• public boolean getWillAttend()
• return attend
• public void setWillAttend(boolean newVal)

• if (attend newVal) return
• attend newVal
• if (newVal)
• setNumberOfAttendees (getNumberOfAttende
  es() 1)
• else
• setNumberOfAttendees (getNumberOfAttende
  es() - 1)

Infrastructure not told about change to
willAttend property
Can use two different notification models. Or use
special API
Neither is View!
110
Selective Replication

• package main
• import budget.ConcertExpense
• import edu.unc.sync.SyncObjectEditor
• import edu.unc.sync.Sync
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static Class MODEL_CLASS
  ConcertExpenseWithAttendance.class
• public static Class EDITOR_CLASS
  SyncObjectEditor.class
• public static void main(String args)
• // can also choose if replicate in or out
• Sync.setReplicate(ConcertExpenseWithAttendance.c
  lass, willAttend", false)
• Sync.replicate (SERVER_NAME, MODEL_NAME,
• MODEL_CLASS,
  EDITOR_CLASS, args0)

111
Awareness Controlling Synchronization
112
Awareness Controlling Synchronization

• package main
• import budget.ConcertExpense
• import edu.unc.sync.SyncObjectEditor
• import edu.unc.sync.Sync
• import edu.unc.sync.SyncClient
• public class SyncBudget
• public static String SERVER_NAME
  "dewan-cs.cs.unc.edu/A"
• public static String MODEL_NAME "demoBudget"
• public static Class MODEL_CLASS
  ConcertExpenseWithAttendance.class
• public static Class EDITOR_CLASS
  SyncObjectEditor.class
• public static void main(String args)
• SyncClient client Sync.replicate
  (SERVER_NAME, MODEL_NAME,
• MODEL_CLASS,
  EDITOR_CLASS, args0)
• ObjectEditor.edit (new SyncControls(client.getSe
  rverProxy(SERVER_NAME))

113
Sync Controls

• package budget
• import java.beans.PropertyChangeListener
• import java.beans.PropertyChangeSupport
• import java.util.Observable
• import java.util.Observer
• import java.util.Vector
• import edu.unc.sync.server.ServerProxy
• public class SyncControls extends Observable
  implements Observer
• PropertyChangeSupport propertyChange new
  PropertyChangeSupport(this)
• ServerProxy server
• public SyncControls (ServerProxy theServer)
• server theServer
• server.addObserver(this)
• public boolean getRealTimeSynchronize()
• return server.getRealTimeSynchronize()
• public void setRealTimeSynchronize (boolean
  newVal)
• server.setRealTimeSynchronize(newVal)

114
Sync Controls (contd.)

• public Vector getCurrentCollaborators()
• return server.getOtherClientNames()
• public void synchronize()
• server.synchronize()
• public void addPropertyChangeListener(PropertyCha
  ngeListener l)
• propertyChange.addPropertyChangeListener(
  l)
• public void notifyObservers (Object arg)
• setChanged()
• super.notifyObservers(arg)
• public void update (Observable observable,
  Object event )
• notifyObservers(event)

115
Does this work?

• public class ConcertExpenseWithAttendance extends
  ConcertExpense
• boolean attend
• public boolean getWillAttend()
• return attend
• public void setWillAttend(boolean newVal)

• if (attend newVal) return
• attend newVal
• if (newVal)
• setNumberOfAttendees (getNumberOfAttende
  es() 1)
• else
• setNumberOfAttendees (getNumberOfAttende
  es() - 1)

116
Concurrent Transactions
117
Concurrent Transactions
118
Concurrent Transactions
119
Concurrent Transactions
120
Concurrent Transactions
121
Concurrent Transactions
Race condition!
122
Does this work?

• public class ConcertExpenseWithAttendance extends
  ConcertExpense
• boolean attend
• public boolean getWillAttend()
• return attend
• public void setWillAttend(boolean newVal)

• if (attend newVal) return
• attend newVal
• if (newVal)
• setNumberOfAttendees (getNumberOfAttende
  es() 1)
• else
• setNumberOfAttendees (getNumberOfAttende
  es() - 1)

Does not keep track of who is attending. Event
vs. state-based
123
Bean Properties vs. Records

• Previous solution requires table mapping users to
  attendance
• Bean properties define replicated records
• No notifications needed if property object does
  not change
• Though its components may.
• Currently need to define getter and setter for
  each shared property
• Other important concrete types
• Dynamic Sequences
• Hashtables
• Want arbitrary compositions of records,
  sequences, and tables

124
Inheritance Based Approach

• Create predefined replicated hashtable and vector
• ReplicatedSequence
• ReplicatedHashtable
• Can subclass to add functionality
• Sequence user
• is-a sequence
• has-a sequence

125
Inheritance Based Approach

• public class ReplicatedDirectory extends
  ReplicatedDictionary implements FileWrapper
• public Replicated remove(Object key)
• Replicated value super.remove(key)
• if (value instanceof FileWrapper)
• File file ((FileWrapper)
  value).getFile()
• if (file.exists() !delete(file))
  toBeDeleted.addElement(file)
• return value

126
Hashtable Pattern

• import bus.uigen.HashtableChangeSupport
• import bus.uigen.HashtableListener
• public class AConcertExpenseTable implements
  java.io.Serializable
• String name ""
• HashtableltString, ConcertExpensegt table new
  Hashtable()
• public Enumeration keys ()
• return table.keys()
• public Enumeration elements ()
• return table.elements()
• public void put (String key, String
  ConcertExpense)
• table.put(key, value)
• hashtableChangeSupport.keyPut(key, value)
• public ConcertExpense remove (String key)
• ConcertExpense retVal table.remove(key)
• hashtableChangeSupport.keyRemoved(key)
• return retVal

Arbitrary type
127
Hashtable Events

• HashtableChangeSupport hashtableChangeSupport
  new HashtableChangeSupport(this)
• public void addHashtableListener
  (HashtableListener hashtableListener)
• hashtableChangeSupport.addHashtableListener(hash
  tableListener)
• public void removeHashtableListener(HashtableList
  ener hashtableListener)
• hashtableChangeSupport.removeHashtableListener(h
  ashtableListener)

128
Hashtable Listener Interface

• // dont really need to worry about this unless
  implementing custom UI
• package bus.uigen
• public interface HashtableListener
• public void keyPut(Object key, Object value,
  int newSize)
• public void keyRemoved(Object key, int newSize)


129
Vector Pattern

• import bus.uigen.VectorChangeSupport
• import bus.uigen.VectorMethodsListener
• import bus.uigen.VectorListener
• public class AnOutline implements
  java.io.Serializable
• Vector contents new Vector()
• //non pattern method
• public void addString() addElement("")
• //non pattern method for creating recursive
  structure
• public void addOutline() addElement (new
  AnOutline())
• // either this read method
• public Enumeration elements () return
  contents.elements()
• //or this pair
• public int size() return contents.size()
• public Object elementAt() return
  contents.elementAt()

Programmer-defined
130
Vector Pattern

• // optional
• public void addElement(Object element)
• contents.addElement(element)
• vectorChangeSupport.elementAdded(element)
• //optional
• public void removeElement(Object element)
• contents.removeElement(element)
• vectorChangeSupport.elementRemoved(element)
• //optional
• public void setElementAt(Object element, int
  index)
• System.out.println("AnOutline" element
  "at" index)
• contents.setElementAt(element, index)
• vectorChangeSupport.elementChanged(element,
  index)
• //optional

131
Vector Events

• VectorChangeSupport vectorChangeSupport new
  VectorChangeSupport(this)
• // the following two needed for Sync
• public void addVectorMethodsListener(VectorMethod
  sListener vectorListener)
• vectorChangeSupport.addVectorMethodsListener(vec
  torListener)
• public void removeVectorMethodsListener(VectorMet
  hodsListener vectorListener)
• vectorChangeSupport.removeVectorMethodsListener(
  vectorListener)
• // the ones below needed for automatic user
  interface generation
• public void addVectorListener(VectorListener
  vectorListener)
• vectorChangeSupport.addVectorListener(vectorList
  ener)
• public void removeVectorListener(VectorListener
  vectorListener)
• vectorChangeSupport.removeVectorListener(vectorL
  istener)

132
VectorMethodsListener

• package bus.uigen
• public interface VectorMethodsListener
• public void elementAdded(Object element, int
  newSize)
• public void elementInserted(Object element, int
  pos, int newSize)
• public void elementChanged(Object element, int
  pos)
• public void elementRemoved(int pos, int
  newSize)
• public void elementRemoved(Object element, int
  newSize)

133
VectorListener

• package bus.uigen
• public interface VectorListener
• public void updateVector(uiVectorEvent evt)

134
VectorEvent

• public class uiVectorEvent implements
  java.io.Serializable
• public static final int AddComponentEvent 1,
• DeleteComponentEvent
  2,
• ChangeComponentEvent
  3,
• InsertComponentEvent 4,
• CompletedComponentsEvent 5,
• UndefEvent 1000
• public int getEventType()
• public Object getNewValue()
• public int getNewSize()
• public Object getOldValue()
• public int getPosition()

135
Three Useful Existing Classes

• bus.uigen.AListenableVector implements
  bus.uigen.VectorInterface
• implements vector pattern and fires appropriate
  events
• bus.uigen.AListenableString implements
  bus.uigen.VectorInterface
• implements the vector pattern with character
  instead of object elements.
• fires vector events as user inserts, deletes,
  characters
• SyncObjectEditor displays it as a text field
• updates it incrementally
• Write method of associated property/sequence/hasht
  able invoked when user hits Enter
• bus.uigen.AListenableHashtable implements
  bus.uigen.HashtableInterface
• implements hashtable pattern and fires
  appropriate events

136
Does this work?

• public class ConcertExpenseWithAttendance extends
  ConcertExpense
• boolean attend
• public boolean getWillAttend()
• return attend
• public void setWillAttend(boolean newVal)

• if (attend newVal) return
• attend newVal
• if (newVal)
• setNumberOfAttendees (getNumberOfAttende
  es() 1)
• else
• setNumberOfAttendees (getNumberOfAttende
  es() - 1)

Need table of who is attending.
137
Overcoming Race Conditions

• package budget
• import java.io.Serializable
• import java.util.Enumeration
• import java.beans.PropertyChangeSupport
• import java.beans.PropertyChangeListener
• import bus.uigen.AListenableHashtable
• import bus.uigen.HashtableInterface
• public class ConcertExpenseWithAttendanceTable
  extends ConcertExpense HashtableInterfaceltStri
  ng, Booleangt attendance new AListenableHashtable
  ()
• public HashtableInterface getAttendance()
  return attendance
• public void setAttendance(HashtableInterface
  newVal) attendance newVal
• public int getNumberOfAttendees()
• Enumeration elements attendance.elements()

• int retVal 0
• while (elements.hasMoreElements())

• if (((Boolean) elements.nextElement()).equals(tr
  ue)) retVal
• return retVal

138
Overcoming Race Conditions

• transient String userName "Anonymous"
• public void initUserName (String initVal)

• userName initVal attendance.put(userName
  , attend)
• boolean attend
• public boolean getWillAttend() return
  attend
• public void setWillAttend(boolean newVal)

• if (attend newVal) return
• attend newVal
• attendance.put(userName, attend)

139
Attendance Table
140
Attendance Table
141
Attendance Table
142
Patterns Summary

• Record
• Vector
• Hashtable

143
Infrastructure Derivation

• Derived from first principles
• Some Java constraints
• Implemented in Sync
• Presentation influenced Sync design
• Just in time implementation

144
Interfaces vs. Patterns

• Patterns describe a family of interfaces
• Unification done at runtime, as in type inference
• T elementAt (int i), addElement (T newVal)
• T getP(), void setP(T newVal)
• Certain methods are optional
• insertElement() or addElement() can change a
  sequence
• Parameterized interfaces require fixed number of
  methods and have no runtime unification
• Errors in usage caught at compile time.

145
Possible Pattern errors

• May forget to define read or write methods
• E.g. missing setter
• Read and write methods may not unify.
• Write methods may not send events
• Missing or unexpected method for registering
  observers.
• Missing or unexpected initializer of serialized
  objects

146
Possible Serialization Errors

• Object may not be serializable
• Serializable superclass gt Serializable subclass
• Improper use of transient
• Cycles in non-transient variables
• Assigning serialVersionUID a value of 1L.
• Dont know why Eclipse assigns one

147
Summary

• Clients can be started in any order.
• First one run results in object creation.
• Other one gets serialized replica
• View connected by Sync to replica
• SyncObjectEditor is a generic extendible editor
• SyncApplication interface around ObjectEditor
• Can replace it with custom editor implementing
  common interface
• Can create multiple objects in server
• Each model tree converted to an internal tree of
  records, vectors and hashtables in SyncClient
  based on patterns in model tree.
• Events fired from model tree result in updates to
  client tree.
• Client tree synchronized with Server tree when
  synchronize called.
• Synchronize side effect of property handler if in
  realTime mode.
• Model can be changed by programmer.
• Synchronize can be called by programmer.

148
Limits of Replicated

• Records
• Hashtables
• Vectors
• What kinds of apps can be built?

149
Sync Drawer (Munson)

• Shape object to capture coordinates.
• Hashtable for shapes
• Existing single-user app transformed

150
Weather Report (Calandrino)

• Extends SyncObjectEditor
• Users from different locations enter data
• Aggregated by Object

151
Word Processor (Agiwal)

• Hierarchical document
• Text objects have shared properties

152
Word Processor (Porwal)

• Hierarchical Outline
• Can move items

153
Spreadsheet (Luebke)

• Hashtable
• Used existing single-user tool

154
Calendar (McEuen)

• Hashtable
• Used existing single-user tool

155
Chat Application (Karl)
156
Aware Chat (Wiegand)
157
Experimental Data Set (Jordan)

• Scientists collaborating on experimental data

158
Starting the Server
159
Starting the Server
160
Server UI
161
Server Script and java.policy

• set synclib D/dewan_backup/java/lib/syncall.jar
• set CLASSPATHsynclib ltother dirs or jarsgt
• java -classpath CLASSPATH -Djava.security.policy
  synclib/java.policy
• -Djava.util.prefs.syncInterval2000000
  edu.unc.sync.server.SyncServer ui trace
  server_id A

Default port is 1099
162
Java.policy
grant permission java.security.AllPermission

163
RMI Registry Script

• set javabinC\"Program Files"\Java\jre1.5.0_04\bi
  n
• set synclib D/dewan_backup/java/lib/syncall.jar
• set CLASSPATHsynclib ltother dirs or jarsgt
• javabin\rmiregistry 1099

164
Steps

• Install sync jar file
• Install java.policy file
• Runtime
• Start rmiregistry
• Make sure it has the jar file in class path.
• Start Sync server
• Make sure it has the jar file in class path and
  arguments like reference to java.policy
• Start program interacting with SyncClient on
  computer of each interacting user.
• Make sure it has the jar file in class path
• Can do this all on one machine.
• Need to loosen firewall if server on different
  machine
• One same machine, must give unique IDs to clients.

165
Possible Errors and Symptoms

• SyncServer could not be bound at specified port
  access denied (java.net.SocketPermission
  127.0.0.11099 connect,resolve
• rmiregistry not started, Java.policy file not
  installed or not given as server argument
• SyncServer could not be bound at specified port
  RemoteException occurred in server thread nested
  exception is  java.rmi.UnmarshalException error
  unmarshalling arguments nested exception is
       java.lang.ClassNotFoundException
  edu.unc.sync.server.SyncServer_Stub
• Sync not in class path of rmiregistry
• No user interface created
• -- ui not passed as argument to Sync server
• Could not open dewan-cs.cs.unc.edu/A
• Server not started,
• Client gives wrong id or hostname for server
  (case matters!)
• The user-interfaces not connected
• Unique client IDs not given

166
Possible Errors and Symptoms

• Initial client interfaces same but subsequent
  synchronization does not occur
• Property events not fired
• Explicitly set replicate to false
• Initial user-interfaces different but subsequent
  synchronization of components occurs
• Transient or non-serializable components
• Get null pointer exception when firing events
• Not defined initSeralizedObject() method
• InvalidClass Exception
• private static final long serialVersionUID 1L
• Get rid of the variable declaration or dont
  assign it a value

167
Possible Errors

• Get null server proxy
• May be passing in wrong name
• Or could be an eclipse error
• Call getServerProxy() with no argument
• Returns the first server opened by client
• Get null model from server proxy
• Maybe passing wrong model name
• Call initialModel
• Returns the first model created at proxy
• Get events from AListenableString only sometimes
• Not registering listener of all instances created

168
Sync Client User Interface

• SyncClient is also a main program
• Can be used to connect to servers.
• Add objects to a server

169
Sync Client User Interface
170
Mapping Names to Classes

• objectsReplicated_Directory Text
• Replicated_Directory.classSyncFiles.ReplicatedDir
  ectory
• SyncFiles.ReplicatedDirectory.editorSyncFiles.Fil
  eEditor
• Text.class bus.uigen.AListenableString
• bus.uigen.AListenableString.editorSyncObjectEdito
  r
