Lecture 2. The core Java language

1
Programming for Geographical Information
AnalysisCore Skills
Lecture 2 Storing data
2
This lecture

• Variables
• Objects
• Arrays

3
Variables and statements

• The language is broadly divided into variables
  and statements.
• Variables are places in which you store stuff you
  want to use
• e.g., words, numbers, data.
• They are usually represented by names.
• Statements are what you want to do
• e.g., print a word, add two numbers.

4
Variables continued

• Lets imagine we need to use an x coordinate a
  number of times in a program.
• We could hardwire or hardcode values in
• System.out.println(x value is 100.0)
• Say we use this value of x a thousand times in
  the program. What if we want to change the x
  location?
• What we need is to attach the value to a name,
  and use the name instead if we want to change
  the value, we just change the value the name
  points at.
• This is what a variable is for.

5
Variable types

• The computer usually needs to know what kind of
  thing they are before they can be used, so they
  can be stored efficiently.
• There are several simple types (primitives),
  including
• int an integer between 2,000,000,000
• double a real number between 10 38
• boolean either true or false
• char a single character

6
Defining variables

• To tell the computer what type of variable you
  are using you must declare it, usually before you
  use it. The syntax for doing this is
• type variableName
• For example
• double x
• This variable declaration tells the computer to
  make a name-tag in memory in preparation for an
  double and call it x.
• Note that variables should start with a lowercase
  letter and describe the value inside them.

7
Assigning a value to the variable

• Its then usual to assign a value to the
  variable. The computer makes an double-shaped
  space in memory containing the value and attaches
  the name-tag to it, e.g.,
• x 100.0
• You can do both at once, e.g.,
• double x 100.0

8
Using variables

• You can then use the variables, e.g.,
• double nearX x 1.0
• System.out.println("x " x)
• The last prints x 100.0

Adds x and 1.0
Joins two printed things
9
Reassignment

• You could just as easily reassign x
• x 200.0
• Note that it is also common to do this
• x x 1.0
• The right side is assessed first, and the answer
  (201.0) replaces what is currently in x (200.0).

10
Operators

• Operators for manipulating variables
• add
• - subtract
• multiply
• / divide
• modulus gives the remainder of a division
• 5 2 gives a value of 1
• add one to a variable
• x is the same as x x 1

11
Operator precedence

• Operators have a definite order in which things
  are done. For example,
• int i 6 6 / 3
• will give i as 8, not 4.
• Always best to put equations in parentheses to
  make it clear what youre after. In this case,
• int i (6 6) / 3

12
Casting

• Casting is the conversion of one type of variable
  to another.
• Casting can be done implicitly with some types
• int m 3
• double i m
• gives i as 3.0.
• Implicit casting is usually possible with
  primitive types where there is no loss of
  precision.

13
Explicit casting

• Where useful information might possibly be lost,
  explicit casting is needed.
• Syntax is
• (target type) variable
• int numberOfPokemon 150
• byte number
• number (byte)numberOfPokemon

14
Javas Assumptions

• Java assumes any number with a decimal point is a
  double. If you want to make it a float, you have
  to be explicit
• float f (float) 2.5
• float f 2.5f

15
Javas Assumptions

• Equally it assumes numbers without decimals are
  ints.
• This causes problems in maths, as rounding to
  ints will occur if an equation contains them
• i 11 / 5 gives i 2 remainder nothing, even
  if i is a double.
• To stop this, always give figures with decimal
  points, e.g.
• double d 3.0 / 2.0
• not double d 3 / 2

16
Review

• The take home message is
• int x
• declares/creates an integer label, called x.
• x 100
• assigns it the value 100.
• You can do both at once, thus
• int x 100
• But from then on, you just use the label, thus
• x 200

17
This lecture

• Variables
• Objects
• Arrays

18
Review
Object Orientated programs can be made of several
objects which do different jobs and communicate
with each other.

• In the introduction we looked at this example of
  objects and we said each object had its own file.
• So how do these objects relate to what we have
  talked about today?

19
Classes

• We have seen that the basic unit of code is the
  class.
• We have one class that sets everything running.
  But how do we run the others?
• The main class is unusual in running directly as
  a program.
• More usual to think of classes as chunks of code
  that define a type.
• We use them to make (instantiate) specific
  objects of that type a bit like an original of
  a photocopy.
• These are variables that contain the class code.
• This is the real genius of Object Orientated
  Programming.

20
Objects

• Because they are based on classes, objects can
  contain any code classes can.
• Code to do jobs.
• Code to communicate with other code.
• Code to store data which well concentrate on
  today.

21
Creating Objects

• Objects are just variables with a type (class)
  you can define yourself.
• Lets make a class for storing a geographical
  point
• public class Point
• double x 100.0
• double y 200.0
• Note that theres no main block as were going to
  use this class inside a main block of another
  class which is in the same directory.
• This class just contains some initialised
  variables.

22
Creating Objects

• In the main block, you tell the computer to make
  a name-tag ready for the new object, e.g.,
• Point home
• Then attach it to a new object of this class.
• home new Point()
• Or all in one go
• Point home new Point()
• Note, again, the capitalisation. Contrast this
  with the primitive variables.
• double x 100.0

23
Accessing variables in objects

• You can use the dot operator . to access things
  inside the objects.
• You can imagine it means look inside and get.
  So, in our main class, after making the object,
  we might have
• double myHomeX home.x
• to get the object's x variable or
• home.x 200.0
• to set it to some value.
• Each object gets a complete copy of the class
  code for itself. Change a variable in one object
  and it usually just changes there, not for all
  objects of the same class.

24
Finished program

• public class HomeFire
• public static void main(String args)
• Point home new Point()
• home.x 23.42
• home.y 79.79
• System.out.println("x" home.x)
• Obviously this isnt the most exciting program in
  the world, but you get the idea.

25
Running our program

• We have more than one file to compile, so how do
  we go about it?
• We put the Point.java and HomeFire.java files in
  the same directory.
• We compile them using the all files wildcard

• javac .java
• 3) We then run the main file
• java HomeFire
• The compiler / JVM work out all the links for us.

26
Some objects revised

• Menu fileMenu new Menu (File)
• MenuItem saveWeb
• new MenuItem (Save as Web Page)
• fileMenu.add(saveWeb)
• MenuListener a new MenuListener(saveWeb)

27
Some objects revised

• If there is code inside the object, it can be run
  the same way but well come back to that.
• Weve actually seen a kind of example already
• System.out.println("Hello World")
• but this is special, because we dont need to
  make the System class into an object first. Well
  come back to this as well.

28
Review

• The take home message is the same as for
  primitives
• Point p1
• declares/creates an Point label, called p1.
• p1 new Point()
• assigns it to a new Point-type object.
• You can do both at once, thus
• Point p1 new Point()
• But from then on, you just use the label, thus
• p1.x 200.0

29
Assignment to variables

• The major difference between objects and
  primitives is what happens when two labels are
  set to each other
• double a 10.0
• double b a
• With primitives, the value of the primitive is
  copied. So,
• a 20.0
• Will change a, but not b.

30
Assignment to variables

• Whereas with objects, the two labels are stuck to
  the same object and
• Point p1 new Point()
• Point p2 p1
• p2.x 20.0
• will change both p2.x and p1.x to 20.0, because
  they are labels for the same object.
• Confusing the two results in tricky to find
  issues.
• To copy an object you need to copy all its
  primitive contents separately.
• There are techniques for helping with this
  (search for cloning and java), but they are
  tricky to implement well, so we wont cover them
  in this basic course.

31
Null

• Unassigned primitives are sometimes set as zero,
  but usually the compiler will protest at them.
  Get used to initialising variables with a value
  so you know for certain what they are.
• int a // Avoid this.
• int a 0
• int a 42
• The equivalent for object labels is null. Again,
  get used to using this
• ClassName a // Avoid this.
• ClassName a null
• ClassName a new ClassName()

32
Scope

• Variables labels usually only work in their own
• blocks and any blocks nested within their blocks.
• Labels are destroyed and rebuilt each time a
  scope is left and re-entered. Note that once a
  object has no label, its useless.
• This wouldnt work
• Point a new Point()
• System.out.println(a.x)
• Whereas this would, and isnt unusual
• Point a null
• a new Point()
• System.out.println(a.x)

33
Strings

• We saw earlier that the primitive for storing
  text characters is char.
• However, there is a special class called String
  that can store more than one character. They are
  created for you, without having to use new.
• String hw "Hello World"
• System.out.println(hw)
• If you do this, you cant (unlike the rest of
  Java, break in the middle of the line)
• String hw Hello instead String hw
  Hello
• World World

34
This lecture

• Variables
• Objects
• Arrays

35
Variables

• Remember that we make a variable, thus
• double a 10.0
• Or,
• Point p1 new Point()
• But what if we want to read in a big datafile?

36
Arrays

• Do we need a new name for each data point?
• Ideally wed just have a list or table of data,
  and get at the data with the list/table name and
  the location within it.
• This structure is called an array.
• Arrays are variables with multiple examples of
  the same kind of object in them.
• E.g. a xCoord array variable containing 10
  different x values.

37
Naming

• As for all variables, we first make a label. The
  syntax is
• type arrayName or
• type arrayName
• For example
• double xCoords
• double xCoords
• Point pathway

38
Assigning

• Then we attach it to a suitable set of spaces in
  memory.
• arrayName new typesize
• e.g. xCoords new double10
• pathway new Point10
• This has now made 10 spaces in our arrays,
  numbered 0 to 9.
• Arrays can be declared and assigned at the same
  time
• double xCoords new double 10

39
Using

• We fill them by using the name and index
  location
• xCoords0 100.0
• pathway9 somePoint
• And likewise to get out the value
• myX xCoords0
• Gives myX as 100.0.
• You use them with objects like any normal name
• myX pathway9.x
• If you try to use a space that doesnt exist,
  youll break the program.

40
Primitive arrays

• Arrays are just label collections.
• Java fills primitive arrays with default values
• int 0
• double 0.0
• char spaces
• boolean false
• But you should do this anyhow, so you are sure
  what is in there.

41
Object arrays

• For objects, the unassigned labels just point at
  null.
• So, the first thing you need to do is attach each
  label to an object
• Point pathway new Point10
• pathway0 new Point()
• System.out.println(pathway0.x)
• System.out.println(pathway1.x)
• The second println would break the program,
  because it is trying to read x out of null the
  second Point object hasnt been created.

42
Hardwiring

• We can actually fill them with existing data at
  declaration
• double xCoords
• 100.0,0.0,1.0,1.0,2.0,3.0,5.0,8.0,13.0,200.0
• Point pathway p1, new Point(), p2
• If you are going to do this, the declaration and
  data filling has to be part of the same command.

43
Size

• The size of an array is fixed once made, and can
  be found using the syntax
• name.length
• e.g.
• System.out.println(xCoords.length)

44
Objects revised

• Note also that arrays are a special kind of
  object, as you can see by the way we make them
• int xCoords new int10
• And the fact that they have special variables set
  up inside them
• xCoords.length

45
Multi-dimensional arrays

• You dont just have to have one dimensional
  arrays, you can have as many dimensions as you
  like.
• A map of population density for example may be a
  2D array
• int popMap new int100100
• You can think of the array as a table, with the
  first size as the row numbers and the second as
  the columns.
• You refer to the position as, for example,
• arrayName101
• (value at the 11th row, 2nd column)

46
Multi-dimensional arrays

• Alternatively you can think of them as arrays of
  arrays, and there is nothing to stop you setting
  them up like this
• int array2D new int 4
• array2D0 new int3
• array2D1 new int3
• array2D2 new int3
• array2D3 new int3
• Each position in the first dimension being filled
  with a new array.
• Note that you must always give the size of the
  first dimension.

47
Irregular arrays

• Infact, the dimensions dont have to be regular
• int array2Dirreg new int 4
• array2Dirreg0 new int1
• array2Dirreg1 new int3
• array2Dirreg2 new int2
• array2Dirreg3 new int3
• We can have as many dimensions as we like.
• int array4D new int100

48
Hardwiring

• We can still fill them with existing objects
  instead of defining them empty
• double array2D
• 100.0,0.0,1.0,1.0,2.0,3.0,5.0,8.0,13.0,2
  00.0
• double array2Dirreg
• 100.0,1.0,1.0,1.2,2.0,3.0,5.0,8.0,13.0
• If it helps, you can break this onto several
  lines before the semicolon.

49
Size

• To find the length in the first dimension, we
  use
• name.length
• To find the length in the second dimension, we
  use
• namepositionInFirstDimension.length
• So, for the array on the previous slide
• array2Dirreg.length is 4
• array2Dirreg0.length is 1
• array2Dirreg4.length is 3

50
Review

• Remember that we make a variable, thus
• double a 10.0
• Point p1 new Point()
• We can change the value
• a 20.0
• a a 10.0
• p1.x 10.0
• We can then use them, thus
• System.out.println(a)
• System.out.println(p1.x)

51
Review

• Making a variable is a two-stage process.
• Make the name
• double myValue
• Assign it to a value
• myValue 23.42
• Or all in one go
• double myValue 23.42

• Making an array is a three-stage process.
• Make the name
• double myValues
• Assign it to spaces
• myValues new double5
• Or all in one go
• double myValues
• new double5
• Then assign values
• myValues0 23.42
