MVA Safety and Principles of Extrication

1
MVA Safety and Principles of Extrication
2
PREPARATION

• Proper Training
• Proper Equipment for the conditions and situation

3
RESPONSE TO THE SCENE

• Follow all Dept. response policies
• Remember, this is NOT your emergency. You have
  been called to assist someone else.
• If we cant arrive safely, we are no help.
• Be preparing mentally enroute to the call.

4
SCENE ASSESSMENT AND HIGHWAY SAFETY
5

• Warning on-coming traffic
• Set-up appropriate warning devices such as
  flares, strobes, traffic cones well ahead of
  accident scene
• At least 400 before the accident
• Dont use flares in cold, foggy conditions!!
• Request additional units if necessary
• Protecting the Scene
• Park apparatus in a defensive position
• Your engine is the best road block

6
(No Transcript)
7
DONT BECOME A VICTIM

• Dozens of Firefighters and EMTs die every year
  across the U.S.A. while operating at MVAs.
• Never turn your back to on-coming traffic
• Always remain in radio contact with person doing
  traffic control
• Always leave yourself a way out.

8
Scene Hazards

• A 360 must be completed prior to any other
  activities being performed.
• Downed Power Lines
• Unstable Structures and vehicles
• Hazardous Materials
• Other?

9
OTHER ASSESSMENT

• Victims outside vehicles (ejection)
• Hot and Cold zones around accident
• Size-up before beginning activity
• READ THE WRECK
• Additional Resources?
• Full protective equipment a must!!
• Set-up Tool Staging Area (Engine Operator or per
  dept. SOPs)
• Supplemental Safety Systems

10
(No Transcript)
11
HAZARD CONTROL

• Stabilize vehicles Create a safe platform for
  extrication work. Cribbing, struts, etc.
  Practical Activity
• Fire prevention and control pull and maintain
  charged, manned hoseline.
• Traffic Control Traffic control must always
  maintain radio contact with command or those
  working at scene.

12
Supplemental Restraint Systems

• Air Bags Deployed or not? Location?
• Front Impact Bags Do Not put yourself between
  undeployed bag and patient.
• Side Impact Bags Normally curtain type from
  ceiling or side of seat mounted. Cylinder for
  systems normally in A, B, or C post. Avoid!! Pull
  off trim to expose and identify location before
  cutting.
• Rear seat bags Newer high end cars.
• NO universal marking system. Most, however use
  SRS, HPS, IC, SIPS, or Airbag.

13

• Static Electricity can cause air bags to deploy.
• Remember the 5-10-20 Rule
• 5 away from side air bags
• 10 away from steering wheel air bags
• 20 away from front passenger air bags

14

• Air Bag Deactivation Times Cutting the battery
  cables doesnt always work! The system can still
  hold a charge! Vary depending upon make, model of
  vehicle. Some older vehicles can hold a charge
  for up to 20-30 minutes.
• Battery locations Vary based upon make, model.
  Batteries can now be found under hood, in the
  trunk, in the wheel well, and behind the rear
  seat.

15
Hybrid Vehicles

• Avoid ORANGE wires They are part of the high
  voltage system!
• Turn off ignition and remove key to render car
  safe.
• Remember, the SILENT CAR. It may be running and
  can move even if you dont hear it!
• High voltage systems are very safe.

16
Seat Belt Pre Tensioning

• Seat Belt Pre-Tensioner systems Designed to
  pull back seatbelt upon impact in coordination
  with airbag system. A part of the total SRS
  system.
• Normally found mid-height or near the floor in
  the door post. Contains an explosive charge
  similar to shotgun shell. Avoid cutting into
  this as it may go off.

17
SUPPORT OPERATIONS

• Lighting
• Scene
• Extrication Area
• Patient Assessment
• Helicopter LZ Review LZ set-up and video
  (optional)

18
GAINING ACCESS

• Hand Tools Types of hand tools
• Power Tools - Types of Power tools
• Normal Means Unlocked or open doors and
  windows, Try before you pry
• Alternate Means Front and rear windows, locked
  doors and windows

19
EMERGENCY CARE

• Patient Assessment 90 second survey. Determine
  ALS vs. BLS and Rapid extrication vs. routine.
• Upgrade early, upgrade fast.
• MOI??
• Coordination with extrication personnel
• Patient Immobilization

20
DISENTANGLEMENT

• Coordinate with EMS personnel regarding route of
  removal.
• STOP, LOOK, THINK, PLAN OF ACTION, ACT

21

• Disentanglement techniques
• Door Removal
• Roof opening and removal
• Seat Displacement
• Steering Wheel Cutting
• Steering Wheel Displacement
• Pedal Displacement
• Dash Roll-up

22
(No Transcript)
23
(No Transcript)
24
Remember, when performing extrication operations
on a vehicle, for every action, there is a
Reaction.
25
REMOVAL TRANSFER

• Assisting with Victim Removal
• Coordinated
• Be Prepared
• Good Communications
• Transfer of pt. Care
• Proper documentation and pictures (if possible)

26
TERMINATION OF INCIDENT

• Scene Clean-up
• Inventory equipment
• Check equipment function
• Place apparatus back in service
• Decon all equipment as necessary per department
  SOPs
