Curtis Spencer

1
An Internet Forum Index

• Curtis Spencer
• Ezra Burgoyne

2
The Problem

• Forums provide a wealth of information often
  overlooked by search engines.
• Semi-structured data provided by forums is not
  taken advantage of by popular search software
  (e.g. Google, Yahoo).
• Despite being crawled, many useful information
  rich posts never appear in results due to low
  page rank.
• Discovering what the best forums are for a given
  topic is difficult even when the help of a search
  engine is enlisted.
• Forum users are often unaware of related
  information found on rival forums.
• A forums own search software is often slow and
  returns poor results.

3
Quick summary of solution

• Forum detection crawlers continually find new
  forums with the help of a web search engine (e.g.
  Dogpile)
• These discovered forums are eventually wrapped
  in their entirety through a distributed crawler.
• Forum content collected in the database is
  indexed using latest MySQL fulltext natural
  language index.
• Search ranking algorithm uses data ignored by
  traditional search engines such as number of
  replies, number of views, popularity of poster,
  etc.

4
(No Transcript)
5
Forums supported by Forum Looter

• phpBB

vBulletin
6
(No Transcript)
7
Discovering forums

• Using WordNet, a program serves dictionary words
  and their synonyms to a set of distributed
  crawlers.
• Every link returned by Dogpile subjected to a
  detection algorithm that consist of URL
  formations as well as common patterns in the
  markup.
• Detects the three most popular forum types used
  on the internet
• vBulletin, phpBB, Invision
• In trying to be good netizens, Dogpile website
  only accessed every two minutes. In addition,
  robots.txt was respected.

8
Dogpile example query
9
(No Transcript)
10
Distributed forum wrapping (architecture)

• Synchronized Java RMI server stores a queue of
  jobs.
• Distributed crawlers retrieve jobs from the
  central RMI server.
• Distributed crawlers wrap whatever page their
  fetched job contains and saves results into
  database.
• Distributed crawlers can schedule new jobs on
  the RMI server, too.

11
More on distributed forum wrapping (access)

• In trying to be good netizens, each forum
  website is only accessed once in any 20 second
  time period.
• At the mentioned rate, it would take two months
  to completely wrap some of the largest forums out
  there.
• Last request times of forum websites were set by
  individual client crawlers and kept track of in
  the RMI server.
• Exponential back off algorithm used for slow
  sites.

12
More on distributed forum wrapping (performance)

• Java RMI server performed very well, only using
  10 of an AMD Athlon CPU.
• Individual crawlers were rather memory
  intensive.
• Individual crawlers used JTidy for parsing pages
  and performed DOM manipulation in addition to
  regular expressions to extract data.
• Memory use attributed to Hibernate and JTidy.
• Database access caused main bottleneck in the
  distributed system.

13
(No Transcript)
14
Indexing of data

• Shadow database periodically updates forum data
  from crawl and creates an incremental MySQL
  fulltext index.
• Has built-in support for stop words and document
  frequency scaling.

15
Ranking algorithm for search results

• Forum software has many missed opportunities for
  metadata analysis.
• We do a hierarchical weighted value calculation
  for each post once it is matched a NLP query from
  MySQL.
• An approximation of this calculation is
• Value w(apc)apc w(numViews) w(numReplies)
  w(isThread())

16
Future changes

• Natural language parsing of forum post corpus so
  ranking may be affected by things such as thank
  you or great post replies.
• Collaborative filtering of results per query by
  tracking user clicks.
• Improve resource usage of crawlers.

17
(No Transcript)
18
(No Transcript)
