Database Management Systems

1
Database Management Systems

• Entity-Relationship Model

2
Database Design

• Why do we need it?
• Agree on structure of the database before
  deciding on a particular implementation.
• Consider issues such as
• What entities to model
• How entities are related
• What constraints exist in the domain
• How to achieve good designs

3
Database Design Formalisms

• 1. Object Definition Language (ODL)
• Closer in spirit to object-oriented models
• 2. Entity/Relationship model (E/R)
• More relational in nature.
• Both can be translated (semi-automatically) to
  relational schemas
• ODL to OO-schema direct transformation (C or
  Smalltalk based system).

4
Purpose of E/R Model

• The E/R model allows us to sketch the design of a
  database informally.
• Designs are pictures called entity-relationship
  diagrams.
• Fairly mechanical ways to convert E/R diagrams to
  real implementations like relational databases
  exist.

5
Entity / Relationship Diagrams
Product
Entities Attributes Relationships between
entities
address
buys
6

name
category
name
price
makes
Company
Product
stockprice
buys
employs
Person
name
ssn
address
7
University Example

• A college contains many departments
• Each department can offer any number of courses
• Many instructors can work in a department
• An instructor can work only in one department
• For each department there is a Head
• An instructor can be head of only one department
• Each instructor can take any number of courses
• A course can be taken by only one instructor
• A student can enroll for any number of courses
• Each course can have any number of students

8
Modeling

• A database can be modeled as
• a collection of entities,
• relationship among entities.
• An entity is an object that exists and is
  distinguishable from other objects.
• Example person, company, event, plant
• Entities have attributes
• Example people have names and addresses
• An entity set is a set of entities of the same
  type that share the same properties.
• Example set of all persons, companies, trees,
  holidays

9
Entity Sets instructor and student
instructor_ID instructor_name
student-ID student_name
10
ER Case Study
Banks Database

• Each bank has a unique name.
• Each branch has a number, name, address (number,
  street, city), and set of phones.
• Customer includes their name, set of address
  (P.O. Box, city, zip code, country), set of
  phones, and social security number.
• Accounts have numbers, types (e.g. saving,
  checking) and balance. Other branches might use
  the same designation for accounts. So to name an
  account uniquely, we need to give both the branch
  number to which this account belongs to and the
  account number.
• Not all bank customers must own accounts and a
  customer may have at most 5 accounts in the bank.
• An account must have only one customer.
• A customer may have many accounts in different
  branches.
•

11
Relationship Sets

• A relationship is an association among several
  entities
• Example 44553 (Ahmed) advisor 22222
  (Hassan) student entity relationship set
  instructor entity
• A relationship set is a mathematical relation
  among n ? 2 entities, each taken from entity sets
• (e1, e2, en) e1 ? E1, e2 ? E2, , en ?
  Enwhere (e1, e2, , en) is a relationship
• Example
• (44553,22222) ? advisor

12
Relationship Set advisor
13
Relationship Sets (Cont.)

• An attribute can also be property of a
  relationship set.
• For instance, the advisor relationship set
  between entity sets instructor and student may
  have the attribute date which tracks when the
  student started being associated with the advisor

14
What is a Relation ?

• A mathematical definition
• if A, B are sets, then a relation R is a subset
  of A x B
• A1,2,3, Ba,b,c,d,
• R (1,a), (1,c), (3,b)
• - makes is a subset of Product x Company

15
Relationships

• Relationships indicate a meaningful connection
  between two entity types
• Relationships may have attributes, but they
  cannot have key attributes.
• Identifying relationships connect a weak entity
  type to some other entity type
• indicates where the weak entity gets a key to
  complete its own partial key

16
Multiplicity of E/R Relations

• one-one
• many-one
• many-many

17
Mapping Cardinalities
One to many
One to one
Note Some elements in A and B may not be mapped
to any elements in the other set
18
Mapping Cardinalities
Many to one
Many to many
Note Some elements in A and B may not be mapped
to any elements in the other set
19
One-to-One Relationship

• one-to-one relationship between an instructor and
  a student
• an instructor is associated with at most one
  student via advisor
• and a student is associated with at most one
  instructor via advisor

20
One-to-Many Relationship

• one-to-many relationship between an instructor
  and a student
• an instructor is associated with several
  (including 0) students via advisor
• a student is associated with at most one
  instructor via advisor,

21
Many-to-Many Relationship

• An instructor is associated with several
  (possibly 0) students via advisor
• A student is associated with several (possibly 0)
  instructors via advisor

22
Alternative Notation for Cardinality Limits

• Cardinality limits can also express participation
  constraints

23
Multi-way Relationships
How do we model a purchase relationship between
buyers, products and stores?
Can still model as a mathematical set (how ?)
24
Relational Roles

• It is sometimes convenient to name an
  entitys role in a relationship.
• particularly useful in recursive relationships
• removes ambiguity in direction of relationship

25
Roles in Relationships
What if we need an entity set twice in one
relationship?
Product
Purchase
Store
buyer
salesperson
Person
26
Data Modeling Case Study

• The following is description by a pharmacy owner

• Ahmed Hassan catches a cold and what he
  suspects is a flu virus. He makes an appointment
  with his family doctor who confirm his diagnosis.
  The doctor prescribes an antibiotic and nasal
  decongestant tablets.
• Ahmed leaves the doctor's office and drives to
  his local drug store. The pharmacist packages
  the medication and types the labels for pill
  bottles.
• The label includes information about customer,
  the doctor who prescribe the drug, the drug
  (e.g., Penicillin), when to take it, and how
  often, the content of the pill (250 mg), the
  number of refills, expiration date, and the date
  of purchase."
• Please develop a data model for the entities and
  relationships within the context of pharmacy.

27
Attributes

• An entity is represented by a set of attributes,
  that is descriptive properties possessed by all
  members of an entity set.
• Example
• instructor (ID, name, street, city,
  salary ) course (course_id, title, credits)
• Domain the set of permitted values for each
  attribute
• Attribute types
• Simple and composite attributes.
• Single-valued and multivalued attributes
• Example multivalued attribute phone_numbers
• Derived attributes
• Can be computed from other attributes
• Example age, given date_of_birth

28
Sets and Derived Attributes

• Multivalued attributes ? double lined oval
• multivalued set valued
• that there may be more than one value for the
  attribute.
• Derived attributes ? dashed line ovals
• the attribute is computed from other data

29
Composite Attributes

• Composite attributes ? tree
• composed of other attributes.
• used for a set of related attributes, when the
  set is not a conceptual entity
• the composite doesnt have identity it doesnt
  have a key

Address
City
ZipCode
State
Street
CompositeAttribute
30
Composite Attributes
31
(No Transcript)
32
Attributes on Relationships
date
Product
Purchase
Store
Person
33
Converting Multi-way Relationships to Binary
ProductOf
date
Product
Purchase
StoreOf
Store
BuyerOf
Person
34
ER Case Study
Television Series Database
A Television network wishes to create a database
to keep track of its TV series. A television
series has one or more episode. Television series
identified by name and season number, and
includes their production company name and
Num_of_Episodes ( i.e. total number of episodes
in a specific season of a series ). Episode of
a specific season of a series is identified by
episode number and has a title and a length. No
episode can exist without a corresponding
television series. Also each episode has only one
writer. A writer is identified by name, and also
has birth date and a literary agency that
represents him or her. An actor appears as a
performer in a television series or a guest star
on an episode. An actor is identified by name
and also has a nationality and birth date. An
actor plays a particular character in a
television series or episode.
35
Keys in E/R Diagrams

• Every entity must have a key

name
category
price
Product
36
Attributes and Keys

• Key attributes must be unique for each entity
• Keys are used to identify particular entities
• Partial keys are only partially unique
• used for weak entity types

37
Keys

• A super key of an entity set is a set of one or
  more attributes whose values uniquely determine
  each entity.
• A candidate key of an entity set is a minimal
  super key
• ID is candidate key of instructor
• course_id is candidate key of course
• Although several candidate keys may exist, one of
  the candidate keys is selected to be the primary
  key.

38
Keys in E/R Diagrams
name
category
Underline
price
Product
No formal way to specify multiple keys in
E/R diagrams
Person
name
ssn
address
39
Entity With Composite, Multivalued, and Derived
Attributes
40
E-R Diagrams

• Rectangles represent entity sets.
• Diamonds represent relationship sets.
• Attributes listed inside entity rectangle
• Underline indicates primary key attributes

41

name
category
name
price
makes
Company
Product
stockprice
buys
employs
Person
name
ssn
address
42
Relationship Sets with Attributes
43
Entity Set to Relation
name
category
price
Product
Product(name, category, price) name
category
price gizmo
gadgets 19.99
44
Classroom Design Exercise

• Imagine we are creating a database for a dorm,
  which includes a cooperative kitchen.
• We want to record certain information about each
  resident. What?
• Not all residents belong to the kitchen coop.
  Those that do interact in various ways
• They take turns at various jobs preparer,
  cleanup, buyer (for supplies). No one should
  have two jobs on one day.
• They may or may not be vegetarian. Each meal must
  have at least one vegetarian entreé.
• They pay fees to the coop.
• For each meal, there is a menu. Each menu item
  requires certain ingredients, which must be on
  hand.

45
Constraints in E/R Diagrams
Finding constraints is part of the modeling
process. Commonly used constraints Keys
social security number uniquely identifies a
person. Single-value constraints a person
can have only one father. Referential
integrity constraints if you work for a company,
it
must exist in the database. Other
constraints peoples ages are between 0 and 150.
46
Other Constraints
makes
lt100
Company
Product
What does this mean ?
47
Entity Types

• Entity types ?boxes Weak entity type ? double
  box

DEPENDENT
Weak Entity
48
Weak Entity Sets
Entity sets are weak when their key comes from
other classes to which they are related.
affiliation
University
Team
number
sport
name
49
Weak Entity Sets

• Sometimes an E.S. E s key comes not (completely)
  from its own attributes, but from the keys of one
  or more E.S.s to which E is linked by a
  supporting many-one relationship.
• Called a weak E.S.
• Represented by putting double rectangle around E
  and a double diamond around each supporting
  relationship.
• Many-one-ness of supporting relationship
  (includes 1-1) essential.
• With many-many, we wouldn't know which entity
  provided the key value.
• Exactly one also essential, or else we might
  not be able to extract key attributes by
  following the supporting relationship.

50
Example Logins (Email Addresses)

• Login name user name host name, e.g.,
  ark_at_soe.ucsc.edu.
• A login entity corresponds to a user name on a
  particular host, but the passwd table doesnt
  record the host, just the user name, e.g., ark.
• Key for a login the user name at the host
  (which is unique for that host only) the IP
  address of the host (which is unique globally).

name
name
_at_
_at_
Logins
Hosts
51
Example Schema
DependentOf
WorksOn
52
Design Principles

• Setting client has (possibly vague) idea of what
  he/she wants. You must design a database that
  represents these thoughts and only these
  thoughts.
• Avoid redundancy
• saying the same thing more than once.
• Wastes space and encourages inconsistency.
• Example
• Good

name
addr
name
ManfBy
product
Manfs
53
Example

• Bad repeats manufacturer address for each beer
  they manufacture.
• Bad manufacturers name said twice.

name
manf
product
Manf addr
name
addr
name
manf
ManfBy
product
Manfs
54
Entity Sets Vs. Attributes

• You may be unsure which concepts are worthy of
  being entity sets, and which are handled more
  simply as attributes.
• Especially tricky for the class design project,
  since there is a temptation to create needless
  entity sets to make project larger.
• Wrong
• Right

name
name
ManfBy
Cars
Manfs
name
manf
Cars
55
Intuitive Rule for E.S. Vs. Attribute

• Make an entity set only if it either
• Is more than a name of something i.e., it has
  nonkey attributes or relationships with a number
  of different entity sets, or
• Is the many in a many-one relationship.

56
Don't Overuse Weak E.S.

• There is a tendency to feel that no E.S. has its
  entities uniquely determined without following
  some relationships.
• However, in practice, we almost always create
  unique ID's to compensate social-security
  numbers, VIN's, etc.
• The only times weak E.S.'s seem necessary are
  when
• We can't easily create such ID's e.g., no one is
  going to accept a species ID as part of the
  standard nomenclature (species is a weak E.S.
  supported by membership in a genus).
• There is no global authority to create them,
  e.g., crews and studios.

57
Notation Summary
58
(No Transcript)
59
(No Transcript)
60
Equivalent Schema defined in UML
61
Design an ER schema for the following enterprise
62
(No Transcript)
63
University Example

• A college contains many departments
• Each department can offer any number of courses
• Many instructors can work in a department
• An instructor can work only in one department
• For each department there is a Head
• An instructor can be head of only one department
• Each instructor can take any number of courses
• A course can be taken by only one instructor
• A student can enroll for any number of courses
• Each course can have any number of students

64
Steps in ER Modeling

• Step 1 Identify the Entities
• DEPARTMENT
• STUDENT
• COURSE
• INSTRUCTOR

65
Steps in ER Modeling

• Step 2 Find the relationships
• One course is enrolled by multiple students and
  one student enrolls for multiple courses, hence
  the cardinality between course and student is
  Many to Many.
• The department offers many courses and each
  course belongs to only one department, hence the
  cardinality between department and course is One
  to Many.
• One department has multiple instructors and one
  instructor belongs to one and only one department
  , hence the cardinality between department and
  instructor is one to Many.
• Each department there is a Head of department
  and one instructor is Head of department
  ,hence the cardinality is one to one .
• One course is taught by only one instructor, but
  the instructor teaches many courses, hence the
  cardinality between course and instructor is
  many to one.

66
Steps in ER Modeling

• Step 3 Identify the key attributes
• Deptname is the key attribute for the Entity
  Department, as it identifies the
• Department uniquely.
• Course (CourseId) is the key attribute for
  Course Entity.
• Student (Student Number) is the key attribute
  for Student Entity.
• Instructor Name is the key attribute for
  Instructor Entity.
• Step 4 Identify other relevant attributes
• For the department entity, the relevant
  attribute is location
• For course entity, course name, duration,
  prerequisite
• For instructor entity, room, telephone
• For student entity, student name, date of birth

67
Steps in ER Modeling

• Step 5 Draw complete E-R diagram with all
  attributes including Primary Key

68
E-R Diagram for a University Enterprise
69
Case Study 2

• Design a DB representing cities, counties, and
  states in the US
• For states, record the name, population, and
  state capital (a city).
• For counties, record the name, the population,
  and the located state.
• For cities, record the name, the population, the
  located state and the located county.
• Uniqueness assumptions
• Names of states are unique.
• Names of counties are unique within a state
  (e.g., 26 states have Washington Counties).
• Cities are unique only within a state (e.g.,
  there are 24 Springfields among the 50 states).
• Some counties and cities have the same name, even
  within a state (e.g., Los Angeles).
• All cities are located within a single county

70
Design 1 bad
Co. Popu.
Co. name
Popu.
Located
cities
states
name
Ci. Popu.
Ci. name
capital
Problem County Population is repeated for each
city.
71
Design 2 good
Co. Popu.
Co. name
Popu.
name
Located
counties
states
Belongs-to
capitals
cities
Ci. name
Ci. Popu.
72
Case Study 3

• Design a DB consistent with the following facts.
• Trains are either local trains or express trains,
  but never both.
• A train has a unique number and an engineer.
• Stations are either express stops or local stops,
  but never both.
• A station has a unique name and an address.
• All local trains stop at all stations.
• Express trains stop only at express stations.
• For each train and each station the train stops
  at, there is a time.

73
Design 1 bad
number
type
time
name
addr
StopsAt
trains
stations
engineer
type
Problem does not capture the constraints that
express trains only stop only at express stations
and local trains stop at all local stations
74
Design 2 good
Lname
address
local stations
time
Lnumber
engineer
StopsAt2
local trains
Enumber
engineer
express trains
time
StopsAt1
express stations
Ename
address
75
Case Study 4 (Pine Valley Furniture Company

• 1. The company sells a number of different
  furniture products.
• These products are grouped into several product
  lines.
• The identifier for a product is Product_ID, while
  the identifier for a product line is
  Product_Line_ID.
• Referring to the customer invoice, we identify
  the following additional attributes for product
  Product_Description, Product_Finish, and
  Unit_Price.
• Another attribute for product line is
  Product_Line_Name.
• A product line may group any number of products,
  but must group at least one product.
• Each product must belong to exactly one product
  line.

76
Case Study 4

• 2. Customers submit orders for products The
  identifier for an order is Order-ID, and another
  attribute is Order_Date.
• A customer may submit any number of orders, but
  need not submit any orders.
• Each order is submitted by exactly one customer.
• The identifier for a customer is Customer_ID.
• Other attributes include Customer_Name and
  Customer_Address.

77
Case Study4

• 3. A given customer order must request at least
  one product.
• Any product sold by Pine Valley Furniture may not
  be requested on any order, or may be requested on
  one or more orders.
• An attribute associated with each order and
  product is Quantity, which is the number of units
  requested.

78
Case Study4

• 4. Pine Valley Furniture has established sales
  territories for its customers.
• Each customer does business in one or more of
  these sales territories.
• The identifier for a sales territory is
  Territory_ID.
• A sales territory may have any number of
  customers, or may not have any customers doing
  business.

79
Case Study4

• 5. Pine Valley Furniture Company has several
  salespersons. The identifier for a salesperson is
  Salesperson_ID.
• Other attributes include Salesperson_Name,
  Salesperson_Telephone, and Salesperson_Fax.
• A salesperson serves exactly one sales territory.

• Each sales territory is served by one or more
  salespersons.

80
Case Study4

• 6. Each product is assembled from one or more raw
  materials.
• The identifier for the raw material entity is
  Material_ID.
• Other attributes include Unit_of_Measure and
  Unit_Price.
• Each raw material may be assembled into one or
  more products.

81
Case Study4

• 7. Raw materials are supplied by vendors.
• The identifier for a vendor is Vendor_ID.
• Other attributes include Vendor_Name and
  Vendor_Address.
• Each raw material can be supplied by one or more
  vendors.
• A vendor may supply any number of raw materials,
  or may not supply any raw materials to Pine
  Valley Furniture.
• An attribute of the relationship between vendor
  and raw material is Unit_Price

82
Case Study4

• 8. Pine Valley Furniture has established a number
  of work centers.
• The identifier for a work center is
  Work_Center_ID.
• Another attribute is Location. Each product is
  produced in one or more work centers.
• A work center may be used to produce any number
  of products, or may not be used to produce any
  products.

83
Case Study4

• 9. The company has over 100 employees.
• The identifier for employee is Employee_ID.
• Other attributes are Employee_Name,
  EmployeeAddress, and Skill.
• An employee may have more than one skill. And
  Each skill can be mastered by many employees or
  none.

84
Case Study4

• 10 Each employee works in one or more work
  centers.
• A work center must have at least one employee
  working in that center, but may have any number
  of employees.

85
Case Study4

• 11. Each employee has exactly one supervisor.
• An employee who is a supervisor may supervise any
  number of employees, but not all employees are
  supervisors.

86
Library Case Study

• When a library first receives a book from a
  publisher it is sent, together with the
  accompanying delivery note, to the library desk.
  Here the delivery note is checked against a file
  of books ordered.
• If no order can be found to match the note, a
  letter of enquiry is sent to the publishers. If a
  matching order is found, a catalogue note is
  prepared from the details on the validated
  delivery note.
• The catalogue note, together with the book, is
  sent to the registration department. The
  validated delivery note is sent to the accounts
  department where it is stored.
• On receipt of an invoice from the publisher, the
  accounts department checks its store of delivery
  notes. If the corresponding delivery note is
  found then an instruction to pay the publishers
  is made, and subsequently a cheque is sent. If no
  corresponding delivery note is found, the invoice
  is stored in a pending file.

87
A Case Study
Conference centre booking system A conference
centre takes bookings from clients who wish to
hold courses or conferences at the centre. When
clients make bookings they specify how many
people are included in the booking, and of
these, how many will be resident during the
booking, and how many will require catered or
non-catered accommodation at the centre. The
centre contains a number of facilities which may
be required by clients making bookings as
follows A. There are 400 bedrooms for clients
who will be resident during the Course or
conference. B. A maximum of 250 catered people
can be handled at any one time. C. Six main
lecture theatres providing seating for 200
people. D. Twenty seminar rooms each able to
accommodate 25 people. E. Video conference
facilities. The video conference facilities
consist of four separate video conference
networks. Each video conference network has a
large screen based in one of the main lecture
theatres, along with 3 satellite screens each of
which is based in one of the seminar rooms.
Draw an entity relationship diagram for the
case, stating any assumptions you deem necessary.
88
Shipping company example

• The London and Ireland Shipping Company PLC
  (LISC) was founded in 1852 and owns a fleet of
  cargo ships. The company had historically run
  passenger liners, but recent policy decisions
  involved the sale of all passenger-carrying
  vessels. The company currently has 14 vessels,
  including one oil tanker and one tugboat
  operating out of Liverpool. Most of the vessels
  are registered in Liberia for tax reasons.
• Each ship has one or more holds divided into
  spaces. The holds are defined by steel bulkheads
  and the spaces are defined by shelf racks or
  other physical dividers. Sister ships, built by
  the same shipbuilders and to the same designs
  have similar names, such as Pride of Ireland,
  Queen of Ireland, Song of Ireland and Warrior of
  Ireland. Sister ships also have identical cargo
  storage facilities.
• LISC issues contracts to agents for one or more
  manifests (lists of cargo items to be shipped).
  LISC's charges for cargo carried are based on the
  number of spaces the cargo requires for storage.
  The types of cargo typically carried by LISC
  include grain, coal and ores (carried only in
  ships equipped with bulk cargo holds). They also
  transport sacked grain, heavy cases, containers
  (which may be carried on deck), pallets and so on.

89
Shipping company example

• Cargo items may take up less than one space in a
  hold, or one or more spaces, depending on the
  size of the item. A space may therefore contain
  several small cargo items.
• The ships owned by LISC are kept as busy and as
  full as possible, in order to maximise the
  profits that each vessel makes and minimise
  running operating costs. LISC's ships ply most
  of the seas of the world, but tend to operate
  mainly in the Mediterranean, the North and Mid
  Atlantic and the Indian Ocean. Different ships
  require different crew complements.
• LISC intends to create a computer based
  information system that will be able to perform
  the following tasks
• record the voyages of each ship with the start
  and end ports.
• record the cargo held by a ship on each voyage
• keep records of their employees and the ships
  they are assigned to
• producing invoices for agents and customers
• keep a record of customers' payments on
  invoices
• analyse the efficiency of use of cargo space
  and of percentage wasted cargo space for ships
  voyages

90
Film Club Case Study Film Club UK is a
company that owns or leases a number of small
cinemas in the UK. They have commissioned a
database designer to design a database solution
to enable them to maintain details about their
cinemas and the films that they show. Note that
it is possible to have two cinemas in the same
location with the same name (there used to be two
Odeons in Newcastle). It is also possible to have
different films with the same title (for example,
different versions of a Shakespeare play).
Films are scheduled for one or more showings
at a cinema within a season. Season details
are to be notified in advance of the dates and
times of showings, takings, etc. to be notified
later. Any one film may have more than one
season at any one cinema (for example, a cinema
showing The Snowman each Christmas). At
present, all cinemas are single-screen.
