Quick-Release Field Experiments on Seismically Isolated Bridges

1
Quick-Release Field Experiments on Seismically
Isolated Bridges

• Stuart S. Chen, Ph.D., P.E.
• Associate Professor, University at Buffalo
  (SUNY),
• Fulbright Senior Lecturer, ITU

2
Presentation Outline

• Comprehensive Study Overview
• Bridges Studied
• Loading and Instrumentation Apparatus
• Selected Results
• Anticipating Seismic Performance
• Summary, Conclusions, Recommendations
• Acknowledgements

3
Comprehensive Study! Overview

• Two Similar Bridges, Before and After Seismic
  Retrofit with Isolation Bearings
• Field (System Quick-Release) and Laboratory
  (Component Reverse-Cyclic) Experiments
• Comparing Analytical vs. Experimental Dynamic
  Behavior
• Inferring Seismic Performance from Calibrated
  Models

4
Seismic Isolation Concept
(Kelly, 2001)
5
Seismic Isolation Concept (contd)
(Kelly, 2001)
6
Bridges Plan View
7
Bridges Elevation Brg. Schedule
8
Bridge Cross Sections
9
Bridge Bearing Replacement (Abut.)
10
Bridge Bearing Replacement (Pier)
11
Installing Isolation Brgs at Abutments
12
Southbound Abutment Isolator
Kelly, 2001
13
Southbound Pier Isolator
14
Northbound Expansion Bearing (non-seismic)
15
Northbound Bridge Bearings
16
Objectives

• Measure and assess in-situ dynamic behavior and
  performance of typical slab- on- girder bridge
  subjected to transverse quick-release loading
  (steel brgs vs. seismic isolation brgs vs.
  standard laminated elastomeric brgs)
• Quantify in-situ dynamic performance change
  attributable to bearing retrofits

17
Objectives, contd

• Quantify Winter-Weather Effects on In-Situ
  Performance of Isolation and Elastomeric Bearings
• Assess Relative Merits of Several Modeling
  Approaches (at varying levels of complexity) in
  predicting transverse transient dynamic behavior
  of straight skewed slab-on-girder bridge
  structures

18
Loading Scheme
19
Loading Scheme (contd)
20
Loading Scheme (contd)
21
Loading Scheme (contd)
22
Loading Scheme (contd)
23
Loading Scheme (contd)
24
(Under-Bridge) Loading Scheme!
25
Loading Scheme (contd)
26
Loading Scheme The Importance of Genuinely Quick
Release!
27
Loading Scheme Mechanical Fuse
28
Loading Scheme Mechanical Fuse in Place
29
Selected Instrumentation
30
Selected Instrumentation (contd)
31
Selected Instrumentation (contd)
32
Selected Instrumentation (contd)
33
Selected Instrumentation (contd)
34
Selected Instrumentation (contd)
35
Selected Results Free Vibn
36
Pre-Retrofit in Frequency Domain
37
1st 2 Pre-Retrofit Mode Shapes
38
SAP Model
39
DRAIN-2DX Model
40
3rd Pre-Retrofit Mode Shape
41
Seismic Isolation Concept Recall!
Sd
Sa
?
T
T
42
Post- Retrofit Time- History at Abutment
43
Post-Retrofit SB (Linear Portion 2)
44
Post-Retrofit SB contd (Linear Portion 2)
45
Post-Retrofit NB (Linear Portion 2)
46
Post-Retrofit NB contd (Linear Portion 2)
47
Selected NB Post-Retrofit T-Hs
48
Post-Retrofit SB contd
49
Post-Retrofit SB (Nonlinear Portion 1)
50
Time, Temperature, Setup Effects (SB)
51
Old Steel Bearings Not So Bad After All!
52
C/D vs. PGA, Pre-Retrofitted
53
C/D vs. PGA, Post-Retrofitted
54
Summary, Conclusions, Recommendations

• Transverse Quick-Release Experiments are
  successfully executed using the deployed
  apparatus
• Replacement of the original steel bearings with
  seismic isolation bearings leads to substantial
  behavior changes (period shift, etc.) in the
  transverse direction, as predicted. However,
• Due to reserve strength of columns and steel
  bearings, actual seismic resistance of the
  retrofitted southbound bridge is not greatly
  increased by its seismic isolation retrofit, and
• The torsional behavior induced in the retrofitted
  northbound bridge nullifies the otherwise
  seismically beneficial effect of its standard
  (non-seismic) elastomeric bearing retrofit

55
Summary, Conclusions, and Recommendations (contd)

• Neither a 3D Model nor formal structural
  identification methods produce any significant
  advantages over 2D modeling as long as nonlinear
  behavior is incorporated into the model
  (DRAIN-2DX)
• Cold-weather effects in western NY are not
  sufficiently severe to have a significant
  influence on LRB seismic isolation behavior

56
Acknowledgements

• J. B. Mander, D. Wendichansky, G. Pekcan, D.-K.
  Kim, I.-S. Ahn, L. Zhang, P. Dreyer, etc.
• New York State Dept. of Transportation, Union
  Concrete and Construction Corp.
• U.S. D.O.T. / Federal Highway Administration
  funding through NCEER/MCEER at the University at
  Buffalo
