Redesign of ECMO Circuit Pressure Alarm System

1
Redesign of ECMO Circuit Pressure Alarm System
University of Pittsburgh Senior Design - BioE1161

• Desiree Bonadonna
• Apryle Craig
• Laura Gilmour

2
Summary

• Market review
• Problems
• Regulations
• Solutions
• Implementing the design
• Testing
• Future work

3
Need for Pressure Monitor Redesign

• gt120 Neonatal/Pediatric ECMO Centers in United
  States, increasing at a rate of 2-5/year
• Growing number of private perfusion groups
• Sold through distributors and consultants
• Clots in the circuit are the most common
  mechanical complication (19)

4

Need for Pressure Monitor Redesign

• Expenditure may be between 80,000 and 100,000
  per life saved
• Insurance reimbursement rate 60-70

Expense Breakdown Cost/day Cost/patient
ECMO 112
Disposables - 4,000
PICU bed 3,400
Physician 520
Respiratory
Blood Bank
5

• Users Healthcare Workers
• Perfusionists
• ECMO Technicians
• Nurses
• Physicians

• Current system with roller pump is analog
• Current system with centrifugal is digital
• Redesign of the ECMO pressure system includes
• Digital system for roller pump
• Additional pressure monitor
• Audible and visual alarm

6
User Requirements

• Accurate to within /- 15mmHg
• Refresh rate should not exceed 15 seconds
• Cost effective
• Safe and reliable
• Meets medical device regulations

7
Current ECMO Circuit Pressure Problems and
Proposed Solutions

• Imprecise/inaccurate readings
• Convert to digital display
• Unknown post-heat exchanger pressure
• Add a third pressure gauge
• Requires constant monitoring
• Add audible and visual alarms
• Cluttered
• Design the device to hang on an IV pole

8
Regulations

• Classification
• Class II, CFR 870.2100
• Cardiovascular blood flowmeter
• Predicate device
• Digibio Digital Blood Pressure Monitor
• Electronic Regulations
• IEC 61000-4-2
• IEC 60601-1-2

9
JCAHO 2004 National Patient Safety Goals

• Goal 6 Improve the effectiveness of clinical
  alarm systems.
• a)    Implement regular preventive maintenance
  and testing of alarm systems.
• b)    Assure that alarms are activated with
  appropriate settings and are sufficiently audible
  with respect to distances and competing noise
  within the unit.

10
Project Objectives and Features Programmable
Alarm Range

• Assure that alarms are activated with
  appropriate settings
• Adjustable range for anthropometric differences
  and varying pathologies

11
Project Objectives and Features Audible Alarm

• are sufficiently audible with respect to
  distances and competing noise within the unit.
• Immediate notification of deviation
• Alarm120dB
• Mean unit noise level 80-89dB
• Startle response occurs at 30dB gt mean noise
• Max Impulses 1016-P/10 8,913

12
Project Objectives and FeaturesVisual Alarm

• Indicates which pressure is deviant from set range

13
Project Objectives and Features Digital Display
?
Human Factors Decrease Human Error Ease of Use
14
Project Objectives and Features Additional
Pressure Indicator

• Pressure drop across heat exchanger can be
  determined and differentiated from patient

15
Design Alternatives
Based on human factors
16
Design Alternatives
17
Engineering Technologies/Methodologies

• Technologies
• SolidWorks
• PSpice
• Rapid Prototyping
• Excel

• Methodologies
• Circuitry analysis
• Digital logic

18
Schematic of One Display Unit
ADC Display
Op-Amp
Audible Alarm
Visual Alarm
19

• 2 Stages of A/D Converter Choice
• 1st type produced larger error and required more
  circuitry
• 2nd type (ICL7107) included built-in display
  driver

20

• 3 Stages of Op-Amp Design
• Scaled down 0-10V to 0-.2V and included another
  inverting op-amp
• Scaled down 0-1V to 0-.2V
• Eliminated 2nd inverting op-amp since input was
  determined to be negative

21

• Visual Alarm Highlights
• Programmable range
• Comparators for high and low
• Switches to view range while adjusting it
• LED lights when out of range

22

• Audible Alarm Highlights
• Inverters needed between comparator and OR-gate
• OR-gate will be 61 in final design

23
Experimental Design

• A/DTP-001
• Tests linearity of input voltage to output
  reading
• PCTP-001
• Tests deviation of first-generation prototype
  from known pressure
• VACTP-001
• Tests accuracy and independence of visual alarms
• AACTP-001
• Tests accuracy and independence of audible alarm

24
A/DTP-001 Results
25
PCTP-001 Results
26
PCTP-001 Results
27
Statistical Analysis
Within the physiological range, the percent error
of our device is lower than that of the currently
used technology at CHP.
28
Statistical Analysis
29
Competitive Analysis

• Analog Pressure Gauges
• Custom Made Digital Monitors
• COBE Cardiovascular
• SIII Pump Modules
• Console mounted control unit

• Strengths
• Smaller
• Not part of a kit
• Less expensive
• Hangs on IV pole

• Weaknesses
• Does not monitor all
• circuit information such
• as temperature, etc.

30
Team Roles
31
Project Management
BioE 1160 Goals BioE 1161 Accomplishments
Model circuitry in PSpice X
Build working circuit X
Test A/D Converter X
Test First Generation Prototype X
Add Visual Alarm X
Test Addition of Visual Alarm X
Implement Results of Testing
Add Audible Alarm X
Test Addition of Audible Alarm
Implement Results of Testing
Design Casing X
32
Future Work

• Further Testing
• Visual Alarm VACTP-001
• Audible Alarm AACTP-001
• Electrical Prototyping
• Second Generation Prototype

33
Acknowledgements

• University of Pittsburgh
• Department of Bioengineering
• Department of Electrical Engineering
• Michael Shaver, CCP
• Steven Jacobs, PhD
• Vikram Sundararaman

34
Questions?
